The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
*
[IS00700(M )01/96]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 12 of 321
9 % [IS01200(M )04/96]
full page art:0010106-L
Mustang GT instrument cluster
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 13 of 321
10 % [IS01300(M )12/95]
full page art:0011226-DMustang instrument cluster
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 14 of 321
11
[IS03100(ALL)12/95] Thisligh tcome son whe ntheparkin gbrak eis
WARNING
Th eBRAK Eligh tindicate stha tth ebrakes
Page 15 of 321
12 % [IS03300( ALL)04/96]Anti-Lock Brake System Light
(If equipped)
[IS03400( ALL)12/95]
This warning light will go on each time you
start your vehicle. If it remains on for longer
than five seconds, you should shut off your
engine and restart. If the anti-lock brake light
stays on, this indicates that the anti-lock feature
is disabled and should receive immediate
attention by a qualified service technician.
Normal braking is not affected unless the brake
warning light is also lit.
*
[IS03500( ALL)03/96]
The Anti-Lock Brake System has self-check
capabilities. As previously described, the system
turns on the anti-lock light each time you start
your engine. After the engine is started and the
anti-lock light is out, the system performs
another test the first time the vehicle reaches
14 mph (22 km/h). The system turns on the
Anti-Lock Brake System (ABS) pump motor for
approximately 1/2 second. At this time a
mechanical noise may be heard. This is a normal
part of the self-check feature. If a malfunction is
found during this check the anti-lock light will
come on.
[IS03600( ALL)04/96]
one inch art:0011194-B
The anti-lock brake system light
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 16 of 321
13
WARNING
If th eanti-loc kbrak esyste mwarning
File:03rcism.ex
Page 17 of 321
14 %
*
[IS06300( ALL)03/96]
Air Bag Readiness Light
*
[IS06400( ALL)04/96]
The air bag system uses a readiness light and a
tone to indicate the condition of the system. The
readiness light is in the instrument cluster. When
you turn the ignition key to the ON position,
this light will light up for six (6) seconds and
then turn off. This indicates that the system is
operating normally. NOTE: Regularly scheduled
maintenance of the air bag system is not
required.
*
[IS06500( ALL)04/96]
If the light fails to illuminate, continues to flash,
remains on, or you hear a beeping sound, have
the system serviced at your Ford or
Lincoln-Mercury dealer immediately.
[IS06600(M GV)04/96]
one inch art:0010514-A
The air bag readiness light
% [IS07100(M )04/96]
Low Coolant Warning Light (If equipped)
[IS07200(M )12/95]
This light tells you that the coolant is low inside
the coolant recovery bottle and that you should
add more coolant.
[IS07300(M )12/95]
This light comes on for a few seconds when
your ignition key is turned to start, but should
turn off when the engine starts. If this light stays
on, check the level of coolant inside the recovery
bottle. SeeEngine Coolantin the Index.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 18 of 321
15 [IS07400(M )04/96]
one inch art:0010579-B
The low coolant warning light
%*
[IS07500( ALL)01/96]
Charging System Light
*
[IS07600( ALL)01/96]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[IS07700( ALL)04/96]
one inch art:0010119-B
The charging system light
*
[IS07800( ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS07900( ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
% [IS08500(M )01/96]
Overdrive Off Indicator (Automatic Only)
[IS08600( ALL)04/96]
one inch art:0010730-B
The overdrive off indicator light
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 19 of 321
16
*
[IS08700( ALL)04/96]
This light tells you that the Transmission Control
Switch (TCS) has been pushed. When the light is
on, the transmission will not shift into overdrive.
Depressing the control will return the vehicle to
ªoverdrive onº mode. The transmission will be
in the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off.
*
[IS08900( ALL)03/96]
NOTE: If the light does not come on when the
TCS is depressed or if the light flashes
when you are driving, have your
vehicle serviced at the first
opportunity. If this condition persists,
damage could occur to the
transmission.
%*
[IS09000( ALL)03/96]
High Beam Light
*
[IS09100( ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
[IS09200( ALL)04/96]
one inch art:0010125-B
The high beam light
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 20 of 321
17 %
*
[IS11000(M GV)03/96]
Check Engine Warning Light
%*
[IS11100(M BCGV)04/96]
This light illuminates when the engine's
Emission Control System requires service. It will
also illuminate when the ignition key is in the
ON position and the engine is off.
[IS11300(M GV)04/96]
one inch art:0010134-A
The check engine warning light
[IS12105(M )04/96]
Anti-Theft Alarm Light
[IS12150(MBC )04/96]
one inch art:0001389-A
Anti-theft alarm light
[IS12200(MBC )04/96]
This light is used when you set the anti-theft
alarm system. SeeAnti-Theft Systemin the
Controls and Featureschapter for more
information.
%*
[IS12300( ALL)03/96]
Turn Signal Indicator Lights
*
[IS12400( ALL)03/96]
The turn signal arrow will flash to indicate the
direction in which you are going to be turning.
[IS12500( ALL)04/96]
one inch art:0010525-A
The turn signal indicator light
File:03rcism.ex
Update:Thu May 30 15:36:44 1996
