Fuel Gauge
[IS14500(M )12/95]
one third page art:0011344-A
The fuel gauge
[IS14600( ALL)12/95]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON. For proper fuel gauge
indication after adding fuel, turn the ignition
switch OFF while refueling the vehicle.
[IS14700( ALL)12/95]
The fuel gauge indicator may vary slightly when
the vehicle is in motion. The most accurate
reading is obtained with the vehicle on level
ground.
*
[IS14800( ALL)01/96]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
%*
[IS15700( ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS15800( ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS15900(M )04/96]
The pointer moves from the C (cold) mark into
the NORMAL band as your engine coolant
warms up. Under normal driving conditions, the
pointer should stay in the NORMAL band. It is
acceptable for the pointer to fluctuate within the
NORMAL band under normal driving
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 22 of 321
19
conditions, and under certain driving conditions
such as, heavy stop and go traffic, or driving up
hills in hot weather, for the pointer to indicate at
the top of the NORMAL band.
*
[IS16000(M )04/96]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine is
overheating and continued operation may cause
engine damage.
% [IS16100(M )12/95]
one third page art:0011143-B
The engine coolant temperature gauge
*
[IS16400( ALL)03/96]
If your engine overheats:
*
[IS16500( ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS16600( ALL)01/96]
2. Turn off the engine.
*
[IS16700( ALL)03/96]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[IS16800( ALL)03/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[IS16900( ALL)03/96]
If the coolant continues to overheat, have the
coolant system serviced.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 23 of 321
20 %
*
[IS18100( ALL)03/96]
Speedometer
[IS18300(M )04/96]
one third page art:0011345-A
The speedometer (GT similar)
*
[IS18350( ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS18900( ALL)03/96]
Odometer
*
[IS19000( ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[IS20400( ALL)01/96]
Trip Odometer
*
[IS20500( ALL)04/96]
If you want to track your mileage up to 999.9
miles (kilometers), use the trip odometer. Simply
set the trip odometer to zero by pressing the
reset control firmly when beginning the distance
you wish to measure.
[IS20600( ALL)04/96]
Since the trip odometer displays distance
independent of the odometer it will not always
advance to the next mile (kilometer) at the same
time as the odometer.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 24 of 321
21 %
*
[IS20700(MBC )03/96]
Tachometer
[IS20900(M )04/96]
one third page art:0011346-A
The tachometer (GT similar)
*
[IS21000(MBC )01/96]
The tachometer displays the approximate engine
revolutions per minute (rpm), or how fast the
engine is running.
[IS21100(M )01/96]
The white zone shows the highest number of
engine revolutions per minute (rpm) at which
you should drive your car. Driving with the
pointer in the red zone may cause engine
damage.
% [IS21400(M GV)04/96]
Battery Voltage Gauge
*
[IS21500(M GV)04/96]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[IS21600(M )04/96]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[IS21700(M )04/96]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 25 of 321
22 [IS21800(M )01/96]
one third page art:0010577-CBattery voltage gauge
%*
[IS22100(M GV)04/96]
Engine Oil Pressure Gauge
[IS22200(M )04/96]
This gauge indicates the engine oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. With the
engine running, the pointer should move into
the NORMAL band. If the pointer drops below
the NORMAL band while the engine is running,
you have lost oil pressure and continued
operation will cause severe engine damage.
[IS22300(M )01/96]
one third page art:0011145-B
Engine oil pressure gauge
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 26 of 321
23
*
[IS22500(M GV)04/96]
If you lose engine oil pressure:
*
[IS22600(M GV)04/96]
1. Pull off the road as soon as safely possible.
*
[IS22700(M GV)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
[IS22800(M GV)04/96]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, see theEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your car should be on level ground.
[IS22900(M )04/96]
4. If the level is low, add oil as necessary
before you start the engine again. Do not
overfill. Do not operate the engine if the
pointer in the oil pressure gauge is below
the NORMAL band, regardless of the oil
level. Contact your nearest dealer for further
service actions.
[IS23000(M GV)04/96]
For more information about adding oil, see
Engine Oil Recommendationsin the Index.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997
Page 27 of 321
25
Electronic Sound Systems
% [AS21350(MBC )04/96]
full page art:0060654-B
Electronic Stereo Radio with Cassette
File:04rcasm.ex
Update:Mon Feb 24 10:13:07 1997
Page 28 of 321
26
% [AS21370(MBC )06/95]
Electronic Stereo Cassette Radio
*
[AS21400(MBC )03/96]
Using the Controls on Your New Radio
*
[AS21500(MBC )08/95]
How to turn the radio on and adjust the
volume
*
[AS22050(MBC )10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS22060(MBC )02/96]
Press the right (+) side of the ªVOLUMEº
button to increase the volume. Press the left (S)
side of the button to decrease the volume.
Illuminated bars in the display show the relative
volume level.
*
[AS22070(MBC )02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS22100(MBC )03/96]
Selecting the AM or FM frequency band
*
[AS22250(MBC )02/95]
Push the ªAM/FMº button to select the desired
frequency band or to stop/store cassette tape
(when in cassette mode). Pushing the button
more than once will alternate between AM, FM1
and FM2. These functions are used with the
station memory buttons described underHow to
tune radio stations.
%*
[AS22300(MBC )03/96]
How to tune radio stations
[AS22425(MBC )06/95]
There are four ways for you to tune in to a
particular station. You can manually locate the
station by using the Automatic Music Search
(ªAMSº) button, ªSEEKº the station, ªSCANº to
the station or select the station by using the
memory buttons, which you can set to any
desired frequency.
File:04rcasm.ex
Update:Mon Feb 24 10:13:07 1997
Page 29 of 321
27 [AS22450(MBC )05/95]
q
Using the ªAMSº function to manually tune
your radio
[AS22650(MBC )03/95]
You can change the frequency up or down
one increment at a time by first pressing the
ªAMSº button, (display shows ªTUNEº) then
pressing and releasing either the right
aor
left
bside of the ªSEEKº button. To change
frequencies quickly, press andhold down
either the right or left side of the ªSEEKº
button.
*
[AS22700(MBC )03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS22800(MBC )04/96]
q
Using the ªSEEKº function
*
[AS22900(MBC )09/95]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the right
a
side of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the left
bside of the button to select
the next listenable station down the
frequency band. By holding the button down,
listenable stations can be passed over to reach
the desired station.
*
[AS23150(MBC )04/96]
q
Using the ªSCANº function
*
[AS23175(MBC )06/95]
Press the ªSCANº button to enter the scan
mode. The radio will begin scanning up the
frequency band, stopping on each listenable
station for approximately a five-second
sampling. This continues until you press the
ªSCANº button a second time. The display
flashes ªAMº or ªFM.º
File:04rcasm.ex
Update:Mon Feb 24 10:13:07 1997
Page 30 of 321
28
*
[AS23200(MBC )02/96]
q
Setting the Station Memory Preset buttons
*
[AS23300(MBC )10/95]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations and 12
FM stations (6 in FM1 and 6 in FM2).
*
[AS23400(MBC )08/95]
Follow the easy steps below to set these buttons
to the desired frequencies:
*
[AS23500(MBC )03/96]
1. Select a band, then select a frequency.
*
[AS23700(MBC )10/95]
2. Press one of the memory preset buttons and
hold the button until the sound returns. That
station is now held in memory on that
button.
*
[AS23800(MBC )10/95]
3. Follow the two steps above for each station
memory preset button you want to set.
[AS23900(MBC )09/95]
NOTE: If the vehicle's battery is disconnected,
the station memory preset buttons will
need to be reset.
*
[AS24000(MBC )10/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS24100(MBC )02/96]
q
Increasing or decreasing bass response
*
[AS24250(MBC )02/96]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the right (+)
side of the ªVOLUMEº button to increase
bass (more ªlowsº), and push the left (S)
side to decrease bass (less ªlowsº).
*
[AS24300(MBC )02/96]
q
Increasing or decreasing treble response
[AS24450(MBC )06/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the right (+)
side of the ªVOLUMEº button to increase
treble (more ªhighsº), and push the left (S)
side to decrease treble (less ªhighsº).
File:04rcasm.ex
Update:Mon Feb 24 10:13:07 1997
