FORD MUSTANG 2000 4.G Owners Manual

MOTORCRAFT PART NUMBERS
Component 3.8L OHV V6 engine 4.6L SOHC V8 engine
Air filter element FA-1611 FA-1634
Fuel filter FG-800AFG-986 FG-800AFG-986
Battery BXT-59 BXT-59
Oil filter FL-400S FL-820S
PCV valve EV-152 EV-98
Spark plugs* AWSF-42EE** AWSF-32P
* Refer to Vehicle Emissions Control Information (VECI) decal for
spark plug gap information.
**If a spark plug is removed for inspection, it must be reinstalled in
the same cylinder. If a spark plug needs to be replaced, use only spark
plugs with the same service part number suffix letter as shown on the
engine decal.
REFILL CAPACITIES
Fluid Ford Part Name Application Capacity
Brake fluid High Performance
DOT 3 Motor
Vehicle Brake
FluidAll Fill to line on
reservoir
Engine oil
(includes filter
change)Motorcraft SAE
5W-30 Super
Premium Motor
OilAll 4.7L (5.0 quarts)
Engine coolant
1Premium Engine
Coolant3.8L OHV V6
engine11.2L
(11.8 quarts)
4.6L SOHC V8
engine13.3L
(14.1 quarts)
Power steering
fluidMotorcraft
MERCONtAT F3.8L OHV V6
engineKeep in FULL
HOT range on
dispstick
4.6L SOHC V8
engineFill to between
MIN and MAX
lines on reservoir
Rear axle
lubricant
2Motorcraft SAE
80W-90 Premium
Rear Axle
Lubricant7.5 inch axle 1.5L (3.25 pints)
8.8 inch axle 1.7L (3.75 pints)
Fuel tank N/A All 59.4L
(15.7 gallons)
Capacities and specifications
191

Fluid Ford Part Name Application Capacity
Transmission fluid
3Motorcraft
MERCONtVATFAutomatic with
3.8L OHV V6
engine13.1L
(13.9 quarts)4
Automatic with
4.6L SOHC V8
engine12.0L
(12.8 quarts)4
Motorcraft
MERCONtAT FManual with 3.8L
OHV V6 engine2.6L (5.6 pints)5
Manual with 4.6L
SOHC V8 engine3.1L (6.6 pints)5
Windshield
washer fluidUltra-Clear
Windshield
Washer
ConcentrateAll 3.8L (4.0 quarts)
1Use Ford Premium Engine Coolant (green in color). DO NOT USE
Ford Extended Life Engine Coolant (orange in color). Refer to
Adding engine coolant, in the Maintenance and Care chapter.
2Rear axle lubricants do not need to be checked or changed unless a
leak is suspected, service is required or the axle assembly has been
submerged in water. The axle lubricant should be changed any time
the rear axle has been submerged in water. Fill 6 mm to 14 mm (1/4
inch to 9/16 inch) below bottom of fill hole. Add 118 ml (4 oz.) of
Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
3Ensure the correct automatic transmission fluid is used.
Transmission fluid requirements are indicated on the dipstick or on
the dipstick handle. MERCONtand MERCONtV are not
interchangeable. DO NOT mix MERCONtand MERCONtV. Refer to
your Scheduled Maintenance Guide to determine the correct service
interval.
4Indicates only approximate dry-fill capacity. Some applications may
vary based on cooler size and if equipped with an in-tank cooler. The
amount of transmission fluid and fluid level should be set by the
indication on the dipstick's normal operating range.
5Service refill capacity is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
Capacities and specifications
192

LUBRICANT SPECIFICATIONS
Item Ford part name Ford part
numberFord
specification
Brake fluid High Performance
DOT 3 Motor
Vehicle Brake
FluidC6AZ-19542-AB ESA-M6C25-A
and DOT 3
Door
weatherstripsSilicone Lubricant F7AZ-19G208-BA
and
F5AZ-19553-AAESR-M13P4-A
Door latch, hood
latch, auxiliary
hood latch, door
hinges, striker
plates, seat tracks
and fuel filler
door hingeMulti-Purpose
GreaseD0AZ-19584-AA
or
F5AZ-19G209-AAESB-M1C93-B or
ESR-M1C159-A
Engine coolant Ford Premium
Engine CoolantE2FZ-19549-AA
(in Canada,
Motorcraft
CXC-8-B)ESE-M97B44-A
Engine oil Motorcraft SAE
5W-30 Super
Premium Motor
OilXO-5W30-QSP WSS-M2C153-G
with API
Certification Mark
Lock cylinders Penetrating and
Lock LubricantE8AZ-19A501-B none
Power steering
fluid and
convertible top
fluid (if
equipped)Motorcraft
MERCONtAT FXT-2-QM MERCONt
Rear Axle
LubricantMotorcraft SAE
80W-90 Premium
Rear Axle
Lubricant
1
XY-80W90-QL WSP-M2C197-A
Automatic
transmission fluidMotorcraft
MERCONtVATF
2
XT-5-QM MERCONtV
Manual
transmission fluidMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Disc brake caliper
railsSilicone Brake
Caliper Grease
and Dielectric
CompoundD7AZ-19A331-A
(Motorcraft
WA-10)ESE-M1C171-A
Windshield
washer fluidUltra-clear
Windshield
Washer
ConcentrateC9AZ-19550-AC ESR-M17P5-A
Capacities and specifications
193

1Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or
equivalent meeting Ford specification EST-M2C118-A for complete
refill of Traction-Lok axles.
Ford design rear axles contain a synthetic lubricant that does not
require changing unless the axle has been submerged in water.
2Ensure the correct automatic transmission fluid is used.
Transmission fluid requirements are indicated on the dipstick or on
the dipstick handle. MERCONtand MERCONtV are not
interchangeable. DO NOT mix MERCONtand MERCONtV. Refer to
your Scheduled Maintenance Guide to determine the correct service
interval.
ENGINE DATA
Engine 3.8L OHV V6 engine 4.6L SOHC V8 engine
Cubic inches 232 281
Required fuel 87 octane 87 octane
Firing order 1-4-2-5-3-6 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm
(0.052-00.056 inch)1.3-1.4 mm
(0.052-00.056 inch)
Ignition system EDIS Coil on plug
Compression ratio 9.4:1 9.0:1
VEHICLE DIMENSIONS
Vehicle dimensions Coupe mm (in) Convertible mm (in)
(1) Overall length 4 653.3 (183.2) 4 653.3 (183.2)
(2) Overall width 1 856.7 (73.1) 1 856.7 (73.1)
(3) Overall height 1 348.7 (53.1) 1 351.3 (53.2)
(4) Wheelbase 2 573.0 (101.3) 2 573.0 (101.3)
(5) Track - Front 1 534.2 (60.4)
11 534.2 (60.4)1
(5) Track - Rear 1 539.2 (60.6)21 539.2 (60.6)2
11 521.5 mm (59.9 in) for Mustang GT21 526.5 mm (60.1 in) for Mustang GT
Capacities and specifications
194

25
3
4
1
Capacities and specifications
195

IDENTIFYING YOUR VEHICLE
Certification label
The National Highway
Traffic Safety
Administration
Regulations require
that a Certification
Label be affixed to a
vehicle and prescribe
where the Certification
Label may be located.
The Certification Label
is located on the front
door latch pillar on the driver's side.
Vehicle identification number
The vehicle
identification number
is attached to a metal
tag and is located on
the driver side
instrument panel.
(Please note that in
the graphic XXXX is
representative of your
vehicle identification
number.)
Engine number
The engine number (the last eight numbers of the
vehicle identification number) is stamped on the
engine block and transmission.
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX
BAR INT TR TP/PS R AXLE TR SPR
X XX XXX X XX X XXXX
XXXXX
XXXXX
UPC ÑF85B-1520472-AB
DATE: XXXXX GVWR:XXXXXXXXXXXX
VIN: XXXXXXXXXXXXXXXXXX
TYPE: XXXXXXXXXXXXXXX FRONT GAWR: XXXXXX/XXXXXXX
REAR GAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY, BUMPER, AND THEFT PRE-
VENTION STANDARDS IN EFFECT ON THE DATE OF
MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
Capacities and specifications
196

Ford Extended Service Plan
You can get more protection for your new car or
light truck by purchasing Ford Extended Service
Plan (Ford ESP) coverage. Ford ESP is an optional
service contract which is backed by Ford Motor
Company or Ford Motor Service Company (in the
U.S.) and Ford of Canada (in Canada). It provides
the following:
²benefits during the warranty period depending on
the plan you purchase (such as: reimbursement
for rentals; coverage for certain maintenance and
wear items)
²protection against repair costs after your Bumper
to Bumper Warranty expires
You may purchase Ford ESP from any participating
Ford and Lincoln/ Mercury and Ford of Canada
dealer. There are several plans available in various
time, distance and deductible combinations which
can be tailored to fit your own driving needs. Ford
ESP also offers reimbursement benefits for towing
and rental coverage. (In Hawaii, rules vary. See your
dealer for details.)
When you buy Ford ESP, you receive Peace-of-Mind
protection throughout the United States and Canada,
provided by a network of more than 5,000
participating Ford or Lincoln/Mercury and Ford of
Canada dealers.
If you did not take advantage of the Ford Extended
Service Plan at the time of purchasing your vehicle,
you may still be eligible. Please contact your dealer
for further information. Since this information is
subject to change, please ask your dealer for
complete details about Ford Extended Service Plan
coverage options.
Customer assistance
197

Getting the service you need
At home
Ford Motor Company and Ford of Canada have
authorized dealerships to service your vehicle. When
you need warranty repairs your selling dealer would
like you to return to it for that service, but you may
also take your vehicle to another Ford Motor
Company or Ford of Canada dealership authorized
for warranty repairs. Certain warranty repairs
require special training though, so not all dealers are
authorized to perform all warranty repairs. That
means that depending on the warranty repair
needed, the vehicle may need to be taken to another
dealer. If a particular dealership can not assist you,
then contact the Customer Assistance Center.
If you have questions or concerns, or are unsatisfied
with the service you are receiving, follow these
steps:
1. Contact your Sales Representative or Service
Advisor at your selling/servicing dealership.
2. If your inquiry or concern remains unresolved,
contact the Sales Manager or Service Manager at the
dealership.
3. If the inquiry or concern cannot be resolved at
the dealership level, please contact the Ford
Customer Assistance Center.
Ford Motor Company and Ford of Canada
dealerships also carry quality parts and accessories,
providing you with equipment reliability.
Away from home
If you own a Ford or Mercury vehicle and are away
from home when your vehicle needs service, or if
you need more help than the dealership could
provide, after following the steps described above,
contact the Ford Customer Assistance Center to find
an authorized dealership to help you. In the United
States:
Customer assistance
198

Ford Motor Company
Customer Assistance Center
16800 Executive Plaza Drive
P.O. Box 6248
Dearborn, Michigan 48121
1-800-392-3673 (FORD)
(TDD for the hearing impaired: 1-800-232-5952)
In Canada:
Customer Assistance Centre
Ford Motor Company of Canada, Limited
P.O. Box 2000
Oakville, Ontario L6J 5E4
1-800-565-3673 (FORD)
If you own a Lincoln vehicle and are away from home
when your vehicle needs service, or if you need more
help than the dealership could provide, after following
the steps described above, contact the Ford
Customer Assistance Center to find an authorized
dealership to help you. In the United States:
Ford Motor Company
Customer Assistance Center
16800 Executive Plaza Drive
P.O. Box 6248
Dearborn, Michigan 48121
1-800-521-4140
(TDD for the hearing impaired: 1-800-232-5952)
In Canada:
Customer Assistance Centre
Ford Motor Company of Canada, Limited
P.O. Box 2000
Oakville, Ontario L6J 5E4
1-800-565-3673 (FORD)
In order to help you service your Ford or Lincoln
Mercury vehicle, please have the following
information available when contacting a Customer
Assistance Center:
²Your telephone number (home and business)
²The name of the dealer and the city where the
dealership is located
Customer assistance
199

²The year and make of your vehicle
²The date of vehicle purchase
²The current odometer reading
²The vehicle identification number (VIN)
If you still have a complaint involving a warranty
dispute, you may wish to contact the Dispute
Settlement Board (U.S.) or the Mediation/Arbitration
Program (Canada).
In some states (in the U.S.) you must directly notify
Ford in writing before pursuing remedies under your
state's warranty laws. Ford is also allowed a final
repair attempt in some states.
In the United States, a warranty dispute must be
submitted to the Dispute Settlement Board before
taking action under the Magnuson-Moss Warranty
Act, or to the extent allowed by state law, before
pursuing replacement or repurchase remedies
provided by certain state laws. This dispute handling
procedure is not required prior to enforcing state
created rights or other rights which are independent
of the Magnuson-Moss Warranty Act or state
replacement or repurchase laws.
THE DISPUTE SETTLEMENT BOARD
(U.S. ONLY)
The Dispute Settlement Board is:
²an independent, third-party arbitration program
for warranty disputes
²available free to owners and lessees of qualifying
Ford Motor Company vehicles
The Dispute Settlement Board may not be available
in all states. Ford Motor Company reserves the right
to change eligibility limitations, modify procedures
and/or to discontinue this service without notice and
without incurring obligations per applicable state
law.
Customer assistance
200
