Item Information
Required fuel Unleaded fuel only - 87 octane
Fuel tank capacity 59.4L (15.7 gallons)
Engine oil capacity
(includes filter
change)4.7L (5.0 quarts). Use Motorcraft SAE
5W-30 Super Premium Motor Oil,
Ford specification WSS-M2C153-G
Tire size and
pressureSee label on inside of glove box door.
Hood release Pull handle under the left side of the
instrument panel.
Coolant
capacity-3.8L OHV
V6 engine
1
11.2L (11.8 quarts)
Coolant capacity-
4.6L SOHC V8
engine
1
13.3L (14.1 quarts)
Power steering fluid
capacityFill to line on reservoir or dipstick.
Use Motorcraft MERCONtAT F.
Manual transmission
fluid capacity-3.8L
OHV V6 engine
2
2.6L (5.6 pints). Use Motorcraft
MERCONtAT F.3
Manual transmission
fluid capacity-4.6L
SOHC V8 engine
2
3.1L (6.6 pints). Use Motorcraft
MERCONtAT F.3
Automatic
transmission fluid
capacity-3.8L OHV
V6 engine
2
13.1L (13.9 quarts). Use Motorcraft
MERCONtV ATF.4
Automatic
transmission fluid
capacity-4.6L SOHC
V8 engine
2
12.0L (12.8 quarts). Use Motorcraft
MERCONtV ATF.4
Windshield washer
fluid3.8L (4.0 quarts). Use Ultra-Clear
Windshield Washer Concentrate.
1Use Ford Premium Engine Coolant (green in color). DO NOT USE
Ford Extended Life Engine Coolant (orange in color). Refer to
Adding engine coolant, in the Maintenance and Care chapter.
2Ensure the correct automatic transmission fluid is used.
Transmission fluid requirements are indicated on the dipstick or on
the dipstick handle. MERCONtand MERCONtV are not
interchangeable. DO NOT mix MERCONtand MERCONtV. Refer to
your Scheduled Maintenance Guide to determine the correct service
interval.
Filling station information
223

3Service refill capacity is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
4Indicates only approximate dry-fill capacity. Some applications may
vary based on cooler size and if equipped with in-tank cooler. The
amount of transmission fluid and fluid level should be set by the
indication on the dipstick's normal operating range.
