faster. Airflow will be from the instrument panel
registers. This mode can also be used to reduce
undesirable odors from entering the vehicle.
²A/C-Uses outside air to cool the vehicle. It is
quieter than MAX A/C but not as economical.
Airflow will be from the instrument panel
registers.
²
(Panel)-Distributes outside air through the
instrument panel registers. However, the air will
not be cooled below the outside temperature
because the air conditioning does not operate in
this mode.
²OFF-Outside air is shut out and the fan will not
operate. For short periods of time only, use this
mode to prevent undesirable odors from entering
the vehicle.
²
(Floor)-Allows for maximum heating by
distributing outside air through the floor ducts.
However, the air will not be cooled below the
outside temperature because the air conditioning
does not operate in this mode.
²
(Floor and defrost)-Distributes outside air
through the windshield defroster ducts and the
floor ducts. Heating and air conditioning
capabilities are provided in this mode. For added
customer comfort, when the temperature control
knob is anywhere in between the full hot and full
cold positions, the air distributed through the
floor ducts will be slightly warmer than the air
sent to the windshield defroster ducts. If the
temperature is about 10ÉC (50ÉF) or higher, the
air conditioner will automatically dehumidify the
air to reduce fogging.
²
-Distributes outside air through the
windshield defroster ducts. It can be used to clear
ice or fog from the windshield. If the temperature
is about 10ÉC (50ÉF) or higher, the air conditioner
will automatically dehumidify the air to reduce
fogging.
Controls and features
21
Page 22 of 224
Operating tips
²In humid weather, selectbefore driving.
This will reduce fogging on your windshield. After
a few minutes, select any desired position.
²To reduce humidity buildup inside the vehicle,
don't drive with the climate control system in the
OFF or MAX A/C position.
²Don't put objects under the front seat that will
interfere with the airflow to the back seats.
²Remove any snow,
ice or leaves from
the air intake area
(at the bottom of
the windshield).
²If your vehicle has been parked with the windows
closed during hot weather, the air conditioner will
do a much faster job of cooling if you drive for
two or three minutes with the windows open. This
will force most of the hot, stale air out of the
vehicle. Then operate your air conditioner as you
would normally.
²Do not place objects over the defroster outlets.
These objects can block airflow and reduce your
ability to see through your windshield. Also, avoid
placing small objects on top of your instrument
panel. These objects can fall down into the
defroster outlets and block airflow and possibly
damage your climate control system.
Do not place objects on top of the
instrument panel, as these objects may
become projectiles in a collision or sudden stop.
Controls and features
22
Page 23 of 224
USING YOUR AUDIO SYSTEM
AM/FM Stereo/Cassette/Premium Sound
Power control
Press the control to
turn the audio system
on or off.
Volume control
Press the control to
raise or lower volume.
If the volume is set
above a certain level and the ignition is turned off,
the volume will come back on at a ªnominalº
listening level when the ignition switch is turned
back on. If you wish to maintain your preset volume
level, turn the audio system off with the power
control before switching off the ignition.
AM/FM select
The AM/FM select
control works in radio
mode and allows you
to select AM or FM
frequency bands.
Press the control to switch between AM, FM1 or
FM2 memory preset stations.
DOLBY SYSTEMSTFM 1
123
4 5 CLOCKAMS SCAN
SEEK
VOLUME
POWERAUDIO AM/FM
–+
POWER
VOLUME+ –
AM/FM
Controls and features
23
Page 24 of 224
Tune adjust in radio mode
Tune adjust allows you
to tune in a particular
radio station. You can
manually locate the
station by using the Automatic Music Search (AMS)
button.
²Press the AMS control until the display shows
TUNE.
²Press and release
either
oron
the SEEK control to
change to the next frequency up or down.
²Press and hold down
orto quickly move
through the frequencies.
Seek function
The seek function control works in radio or tape
mode.
Seek function in radio mode
²Pressto find the
next listenable
station down the
frequency band.
²Press
to find the next listenable station up
the frequency band.
Seek function in tape mode
The Automatic Music
Search (AMS) feature
allows you to quickly
locate the beginning of
the tape selection being played or to skip to the
next selection.
²Press the AMS control.
AMS
SEEK
SEEK
AMS
Controls and features
24
Page 25 of 224
²Pressto listen
to the previous
selection on the
tape.
²Press
to listen to the next selection on the
tape.
The tape deck stops and returns to play mode when
the AMS circuit senses a blank section on the tape.
In order to ensure proper operation of the AMS
feature, the tape MUST have a blank section of at
least 4 seconds duration between programs.
Scan function
The scan function
works in radio mode.
²Press the SCAN
button to activate the scan mode. The radio scans
up the frequency band, stopping on each
listenable station for approximately a five-second
sampling.
²Press the SCAN button a second time to
deactivate the feature.
Radio station memory preset
The radio is equipped with five station memory
preset controls. These controls can be used to select
up to five preset AM stations and ten FM stations
(five in FM1 and five in FM2).
Setting memory preset stations
1. Select the frequency
band with the AM/FM
select control.
2. Select a station. Refer toTune adjustorSeek
functionfor more information on selecting a station.
3. Press and hold a
memory preset control
until the sound returns,
indicating the station is
SCAN
AM/FM
123
45
Controls and features
25
Page 26 of 224
held in memory on the control you selected.
Repeat the steps for each station memory preset
button you want to set.
If the battery is disconnected, the memory preset
stations will need to be reset.
Bass adjust
The bass adjust control allows you to increase or
decrease the audio system's bass output.
²Push the AUDIO
control repeatedly
until the display
reads BASS.
²Press (+) or (þ) on
the volume control
to increase or
decrease bass output.
Treble adjust
The treble adjust control allows you to increase or
decrease the audio system's treble output.
²Push the AUDIO
control repeatedly
until the display
reads TREB.
²Press (+) or (þ) on
the volume control
to increase or
decrease treble output.
Speaker balance adjust
Speaker sound distribution can be adjusted between
the right and left speakers.
²Push the AUDIO
control repeatedly
until the display
reads BAL.
AUDIO
VOLUME+ –
AUDIO
VOLUME+ –
AUDIO
Controls and features
26
Page 27 of 224
²Press the (+) side of
the volume control
to shift sound to the
right speakers.
²Press the (þ) side of the volume control to shift
sound to the left speakers.
Speaker fade adjust
Speaker sound distribution can be adjusted between
the front and rear speakers.
²Push the AUDIO
control repeatedly
until the display
reads FADE.
²Press the (+) side of
the volume control
to shift sound to the
front speakers.
²Press the (þ) side of the volume control to shift
sound to the rear speakers.
Tape play select
Insert a tape to begin tape play.
Push only slightly when inserting a cassette tape (with
the open edge to the right). A cassette deck loading
mechanism pulls the tape in the rest of the way.
Rewind/fast forward
The rewind and fast forward controls work in tape
mode.
Rewind/fast forward function in tape mode
²Pressto
rewind the tape.
Play will continue
once the beginning
of the tape is reached or rewind is stopped.
²Press
to fast forward the tape. Once the
end of the tape is reached, tape direction reverses
and the opposite side of the tape plays.
VOLUME+ –
AUDIO
VOLUME+ –
Controls and features
27
Page 28 of 224
Tape eject
Press the control to
stop and eject a tape.
DolbyTnoise reduction
Dolbytnoise reduction
reduces the amount of
hiss and static during
tape playback.
Press the
control to activate (and deactivate)
Dolbytnoise reduction.
Dolbytnoise reduction is manufactured under
license from DolbytLaboratories Licensing
Corporation. ªDolbytº and the double-D symbol are
trademarks of DolbytLaboratories Licensing
Corporation.
Setting the clock
Press the CLOCK
control while
simultaneously
depressing the SEEK control.
²Press
to set the
hours.
²Press
to set the
minutes.
MACH 460 Sound SystemTwith AM/FM
Stereo/Cassette
CLOCK
SEEK
POWER AUDIO
VOLUMEAM/FM
REWFF
PLAYEJCT
123
45CLOCK
AUTOPRESETPROG
AUTOMATIC
DNR CrO2
SCAN
TUNE
SEEK
FM1ST
Controls and features
28
Page 29 of 224
Power control
Press the control to
turn the audio system
on or off.
Volume control
Press the control to
raise or lower volume.
If the volume is set
above a certain level and the ignition is turned off,
the volume will come back on at a ªnominalº
listening level when the ignition switch is turned
back on. If you wish to maintain your preset volume
level, turn the audio system off with the power
control before switching off the ignition.
AM/FM select
The AM/FM select
control works in radio
mode and allows you to
select AM or FM
frequency bands.
Press the control to switch between AM, FM1 or
FM2 memory preset stations.
Tune adjust
Tune adjust works in
radio mode and allows
you to manually tune in
a particular radio
station.
²Press the SCAN/TUNE button twice.
²The display reads TUNE.
Press the SEEK control
to move up or down
through the
frequencies.
²Press
to move down orto move up the
frequency band.
POWER
VOLUME
AM/FM
SCAN
TUNE
SEEK
Controls and features
29
Page 30 of 224
²Press and hold downorto quickly move
through the frequencies.
Seek function
The seek function control works in radio or tape
mode.
Seek function in radio mode
This feature allows you
to automatically select
listenable stations up
or down the frequency band.
²Press
to find the next listenable station down
the frequency band.
²Press
to find the next listenable station up
the frequency band.
Seek function in tape mode
This feature allows you
to locate the beginning
of the tape selection
being played or to skip to the next selection.
²Press
to listen to the previous selection on
the tape.
²Press
to listen to the next selection on the
tape.
Scan function
The scan function works in radio, tape and CD mode
(if equipped).
Scan function in radio mode
This feature allows you
to scan the frequency
band, stopping on each
listenable station for
approximately a five-second sampling.
²Press the SCAN/TUNE button to enter the scan
mode.
²This display reads SCN.
SEEK
SEEK
SCAN
TUNE
Controls and features
30
