Page 66 of 240
Illuminated entry
The interior lamps illuminate when the remote entry
system is used to unlock the door(s) or sound the
personal alarm.
The system automatically turns off after 25 seconds
or when the ignition is turned to the START/RUN or
ACC position. The dome lamp control (if equipped)
mustnotbe set to the OFF position for the
illuminated entry system to operate.
The inside lights will not turn off if:
²
they have been turned on with the dimmer control or
²any door is open.
The battery saver will shut off the interior lamps 30
minutes after the ignition has been turned to the OFF
position, 10 minutes after if the door is left open, and
30 minutes after if the trunk is left open or the dome
lamp switch is left on.
Replacing lost transmitters
Take all your vehicle's
transmitters to your
dealer if service is
required.
If you purchase
additional transmitters
(up to four may be
programmed into
memory), perform the following procedure:
To reprogram the transmitters yourself, place the key
in the ignition and turn from LOCK to OFF and cycle
between OFF and ON eight times in rapid succession
(within 10 seconds) ending in ON. After doors
lock/unlock, press any control on all transmitters (up
to four). With each control press of the transmitters,
the door should cycle (lock/unlock) to confirm
programming. When completed, turn the ignition to
OFF. The door locks should cycle (lock/unlock) one
last time to confirm completion of programming.
All transmittersmustbe programmed at the same
time.
Controls and features
66
Page 67 of 240
Replacing the batteries
The transmitter is powered by two coin type
three-volt lithium batteries. Typical operating range
will allow you to be up to 10 meters (33 feet) away
from your vehicle. A decrease in operating range can
be caused by:
²weather conditions
²nearby radio towers
²structures around the vehicle
²other vehicles parked next to the vehicle
To replace the
batteries:
1. Twist a thin coin
between the two halves
of the transmitter near
the key ring. DO NOT
TAKE THE FRONT
PART OF THE
TRANSMITTER
APART.
2. Place the positive
(+) side of new batteries down. Refer to the diagram
inside the transmitter unit.
3. Snap the two halves back together.
Replacement of the battery willnotcause the
remote transmitter to become deprogrammed from
your vehicle. The remote transmitter should operate
normally after battery replacement.
SECURILOCKYPASSIVE ANTI-THEFT SYSTEM
SecuriLockypassive anti-theft system is an engine
immobilization system. This system prevents the
engine from being started unless acoded key
programmed to your vehicleis used.
The SecuriLockypassive anti-theft system is not
compatible with non-Ford aftermarket remote start
systems. Use of these systems may result in vehicle
starting problems and a loss of security protection.
Controls and features
67
Page 141 of 240
To remove the
anti-theft lug nut:
1. Insert the key over
the locking lug nut. Make sure you hold the key
square to the lug nut. If you hold the key at an
angle, you could damage the key and the lug nut.
2. Place the lug nut wrench over the lug nut key and
apply pressure on the key with the wrench.
3. Turn the wrench in a counterclockwise direction
to remove the lug nut.
To install the anti-theft lug nut:
1. Insert the key over the locking lug nut.
2. Place the lug nut wrench over the lug nut key and
apply pressure on the key with the wrench.
3. Install the lug nut.
JUMP STARTING YOUR VEHICLE
The gases around the battery can explode if
exposed to flames, sparks, or lit cigarettes.
An explosion could result in injury or vehicle
damage.
Do not push start your vehicle. You could
damage the catalytic converter.
Batteries contain sulfuric acid which can
burn skin, eyes, and clothing, if contacted.
Do not attempt to push start your vehicle.
Automatic transmissions do not have
push-start capability.
Preparing your vehicle
When the battery is disconnected or a new battery is
installed, the transmission must relearn its adaptive
strategy. As a result of this, the transmission may
Roadside emergencies
141
Page 148 of 240
2. Turn off the engine and remove the key.
3. Block the wheels to prevent the vehicle from
moving unexpectedly.
²Manual transmission:
1. Set the parking brake.
2. Depress the clutch and place the gearshift in 1
(First).
3. Turn off the engine and remove the key.
4. Block the wheels to prevent the vehicle from
moving unexpectedly.
Working with the engine on
²Automatic transmission:
1. Set the parking brake and ensure the gearshift is
securely latched in P (Park).
2. Block the wheels to prevent the vehicle from
moving unexpectedly.
Do not start your engine with the air cleaner
removed and do not remove it while the
engine is running.
²Manual transmission:
1. Set the parking brake, depress the clutch and
place the gearshift in neutral.
2. Block the wheels to prevent the vehicle from
moving unexpectedly.
Do not start your engine with the air cleaner
removed and do not remove it while the
engine is running.
The cooling fan is automatic and may come
on at any time. Always disconnect the
negative terminal of the battery before working
near the fan.
Maintenance and care
148
Page 231 of 240
fuel pump shut-off
switch .................... 130
gauge ....................... 14
improving fuel
economy ................ 186
low fuel warning
light .......................... 11
octane
rating ..... 184, 209±210
quality .................... 184
running out of
fuel ......................... 185
safety information
relating to automotive
fuels ....................... 180
Fuses ................ 131±132
G
Gas cap (see
Fuel cap) ........... 11, 182
Gas mileage (see Fuel
economy) ................. 186
Gauges ....................... 14
battery voltage
gauge ....................... 17
engine coolant
temperature
gauge ....................... 15
engine oil pressure
gauge ....................... 17
fuel gauge ................ 14
odometer ................. 16
speedometer ........... 15
tachometer .............. 16
trip odometer .......... 17
GAWR (Gross Axle
Weight Rating) ........ 122
definition ............... 122driving with a heavy
load ........................ 122
location .................. 122
GVWR (Gross Vehicle
Weight Rating) ........ 122
calculating ............. 122
definition ............... 122
driving with a heavy
load ........................ 122
location .................. 122
H
Hazard flashers ....... 130
Head restraints ......... 73
Headlamps ................. 18
aiming .................... 198
bulb specifications 197
daytime running
lights ........................ 18
flash to pass ............ 51
high beam ........... 8, 18
replacing bulbs ..... 193
turning on and off .. 18
warning chime ........ 13
Heating ...................... 20
heating and air
conditioning
system ..................... 20
Hood ........................ 149
I
Ignition ....... 52, 209±210
removing the key .. 122
Infant seats (see Safety
seats) ......................... 95
Inspection/maintenance
(I/M) testing ............ 191
Index
231
