To lower the convertible top:
1. Bring vehicle to a complete stop. Engage the
parking brake. Key must be in the ON position.
2. Check the convertible top stowage compartment
behind the rear seat to be sure it is empty and ready
to receive the top.
3. Unclamp the top from the windshield header at
both the right and left sides by pulling each clamp
rearward until the hook in the windshield header is
free. The clamps are flush with the header when in
the closed position.
4. Close the windshield header clamps immediately
after disengagement, to avoid cutting the top
material and to permit installation of the vinyl boot.
5. If the top has not
been lowered for some
time and sticks to the
windshield header,
push the front of the
top up slightly with
your hand to loosen it.
6. Push the convertible
top switch on the
console in front of the
armrest and hold until
the top is completely
stored.
7. Disengage the
parking brake.
SETPARKBRAKE
Driver Controls
91

Installation of the boot
1. Push boot rearward
and engage boot under
the body molding at
the rear and sides.
2. Fasten snap on boot
to quarter trim panel
on both sides of the
vehicle.
3. Insert boot tongue
into groove located on
rear of seat.
4. To remove unfasten
the snaps and the boot
tongue.
5. Pull forward and lift
off.
Driver Controls
92

Raising the convertible top
The convertible topwill not operateunless the
parking brake is engaged. Do not raise the top while
the vehicle is moving because the top may be
severely damaged.
To raise the convertible top:
1. Bring the vehicle to a complete stop. Engage the
parking brake. Key must be in the ON position.
2. Remove the boot cover and store it in the luggage
compartment.
3. Lower the front and rear side windows.
4. Push the convertible top button, holding it until
the top unfolds and moves forward toward the
windshield header.
5. Open both top clamps before the top meets the
windshield header
6. Continue to use the top motor to raise the top
until it has reached the fully closed position flush to
the header.
7. The two pins under the forward edge of the top
should seat themselves in the matching holes in the
header.
8. To fasten both clamps securely, push the clamp
handles into the header on the top until they are
flush with the header. Pulling down on the header at
the center grip while closing the latches may assist
in fastening the clamps.
9. Raise the front and rear side windows.
10. Disengage the parking brake.
Driver Controls
93

REAR SEATS
Use the seatback
release to fold the back
of the front seat
forward for rear seat
passenger entry or exit.
This release handle is
located on the lower
outboard back of the
seat. The seatback
locks automatically when returned to the normal
position.
The rotating boot on the front seat belt is designed
to allow rear seat entry/exit. To enter the rear seat:
1. Remove safety belt
from safety belt guide
on top of front seat.
2. Rotate the safety
belt boot rearward.
3. Enter the rear seat in front of the safety belt.
4. Rotate the safety belt boot forward and place the
belt in the belt guide on the seat back to allow use
by the front driver/passenger.
2nd seat/split-folding rear seat (if equipped)
One or both rear seatbacks can be folded down to
provide additional cargo space.
To lower the
seatback(s) from inside
the vehicle, pull tab to
release seat back and
then fold seatback
down.
Seating and Safety Restraints
107

8. Allow the safety belt
to retract to remove
any slack in the belt.
9. Before placing the
child in the seat,
forcibly tilt the seat
forward and back to
make sure the seat is
securely held in place. To check this, grab the seat
at the belt path and attempt to move it side to side
and forward and back. There should be no more
than one inch of movement for proper installation.
10. Try to pull the belt out of the retractor to make
sure the retractor is in the automatic locking mode
(you should not be able to pull more belt out). If the
retractor is not locked, unbuckle the belt and repeat
steps two through nine.
Check to make sure the child seat is properly
secured before each use.
Attaching child safety seats with tether
straps
Most new forward-facing child safety seats include a
tether strap which goes over the back of the seat
and hooks to an anchoring point. Tether straps are
available as an accessory for many older safety seats.
Contact the manufacturer of your child seat for
information about ordering a tether strap.
The rear seats of your vehicle are equipped with
built-in tether strap anchors located behind the seats
on the package tray behind the speakers.
The tether anchors in your vehicle are either located
under a cover marked with the child tether anchor
symbol (shown with title) or are under a flap in the
convertible top boot.
Seating and Safety Restraints
132

C
Capacities for
refilling fluids .......... 247
Cargo net ................... 83
CD player ............ 45±46
CD-single premium ... 20
Certification Label .. 253
Changing a tire ....... 170
Child safety
restraints ................. 127
child safety belts .. 127
Child safety seats .... 128
attaching with
tether straps ......... 132
in front seat .......... 129
in rear seat ............ 129
Cleaning your vehicle
engine
compartment ......... 194
exterior .................. 199
instrument
cluster lens ............ 198
instrument panel .. 197
interior ................... 198
plastic parts .......... 196
safety belts ............ 199
washing .................. 192
waxing ................... 192
wheels .................... 193
windows ................ 199
wiper blades .......... 196
Climate control
(see Air conditioning
or Heating) ................ 67
Clock .............. 25, 37, 52
Clutch
adjusting ................ 237operation while
driving ................... 154
recommended
shift speeds ........... 155
Console ...................... 89
Controls
power seat ............. 105
Convertible ................ 90
cleaning ................. 197
installation of
the boot ................... 92
lowering the
convertible top ........ 90
raising the
convertible top ........ 93
Coolant
checking and
adding .................... 213
refill
capacities ....... 220, 247
specifications. 249, 251
Cruise control (see
Speed control) .......... 85
Customer
Assistance ................ 162
Ford accessories
for your vehicle .... 200
Ford Extended
Service Plan .......... 182
Getting assistance
outside the U.S.
and Canada ........... 188
Getting roadside
assistance .............. 162
Getting the service
you need ............... 180
Ordering additional
owner's literature... 189
Index
259
