warning FORD MUSTANG 2003 Workshop Manual

DESCRIPTION AND OPERATION
Jacking
WARNING: Never run the engine with one wheel off the ground, such as when changing a
tire. The wheel still on the ground could cause the vehicle to move.
CAUTION: The jack (17080) provided with the vehicle is intended to be used in an
emergency for changing a deflated tire. To avoid damage to the vehicle, never use the jack to
lift the vehicle for any other purpose. Refer to the Owner Guide when using the jack supplied
with the vehicle.
CAUTION: Under no circumstances should the vehicle ever be lifted by the suspension
arm brackets, rear stabilizer or differential housing or convertible cross brace. Severe damage
to the vehicle could result.
CAUTION: Do not attempt to use jack pressure on either the front bumper (17757) or the
rear bumper (17906) of any vehicle. Damage to the bumper covers will occur.
Lift the vehicle using the Jacking Points procedure in this section.
Jacking Points
To lift the front or either side of the front end, position the floor jack under the front frame lift points. SECTION 100-
02: Jacking and Lifting 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4920/S3B~us~en~ ...

z
Engine oil fluid level.
z Windshield washer solvent fluid level.
z Check and drain fuel/water separator.
Six Month Checks
Check each of the following items at least every six months:
zLap/shoulder belts and seat latches for wear and function.
z Spare tire air pressure.
z Power steering fluid level.
z Parking brake for correct operation.
z Safety warning lamps (brake, ABS, air bag, safety belt) for correct operation.
z Coolant system fluid level and correct strength.
z Battery connections. Clean if necessary.
z Clutch fluid level, if equipped.
z Windshield washer spray, wiper operation, clean all wiper blades.
z Lubricate all hinges, latches and outside locks. Inspect for correct operation.
z Lubricate door rubber weatherstrips. Inspect for excessive wear.
z Clean body and door drain holes. Inspect for clogs and obstructions.
Special Checks (Mustang Only)
Carry out the following check every 8,000 km (5,000 miles):
zAdjust clutch by lifting pedal (manual transmission Mustang only, as described in owner guide).
Normal Schedule
The following checks or procedures should be carried out for all cars, minivans, light trucks, sport
utilities, vans, 4x4s, natural gas and propane vehicles.
8,000 Km (5,000 Miles) zChange engine oil and install a new oil filter.
z Rotate tires and inspect for wear.
16,000 Km (10,000 Miles)
zChange engine oil and install a new oil filter.
z Inspect tires for wear. Rotation recommended for optimal tire life.
24,000 Km (15,000 Miles)
zChange engine oil and install a new oil filter. Klj . 3 ba
112003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

z
Drive the vehicle over a bump or rough surface one wheel at a time to determine if the noise is
coming from the front or the back and the left or the right side of the vehicle.
z Proceed as necessary.
Neutral Engine Run- Up (NERU) Test
To carry out this test, proceed as follows:
zInstall a tachometer.
z Increase the engine rpm up from an idle to approximately 4000 rpm while in PARK on front
wheel drive vehicles with automatic transmissions, or NEUTRAL for all other vehicles. Note the
engine rpm and, if possible, determine the vibration frequency.
z Attempt to identify what part of the vehicle the concern is coming from.
z Attempt to identify the source of the concern.
z Proceed as necessary.
Drive Engine Run- Up (DERU) Load Test
To carry out this test, proceed as follows:
z WARNING: Block the front and rear wheels, and apply the parking brake and the
service brake, or injury to personnel can result.
CAUTION: Do not carry out the Engine Load Test for more than five seconds or
damage to the transmission or transaxle can result.
Block the front and rear wheels.
z Apply the parking brake and the service brake.
z Install a tachometer.
z Shift the transmission into DRIVE, and increase and decrease the engine rpm between an idle
to approximately 2000 rpm. Note the engine rpm and, if possible, determine the vibration
frequency.
z Repeat the test in REVERSE.
z If the vibration/noise is duplicated when carrying out this test, inspect the engine and
transmission or transaxle mounts.
z If the concern is definitely engine speed- related, carry out the Engine Accessory Test to narrow
down the source.
z Proceed as necessary.
Engine Accessory Test
To carry out this test, proceed as follows:
z WARNING: Block the front and rear wheels, and apply the parking brake and the
service brake, or injury to personnel can result.
CAUTION: Limit engine running time to one minute or less with belts removed or
serious engine damage will result. Klj . 8 ba
702003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

PINPOINT TEST I: REAR SUSPENSION NOISE z
WARNING: The electrical power to the air
suspension system must be shut off prior to hoisting,
jacking or towing an air suspension vehicle. This can
be accomplished by turning off the air suspension
switch. Failure to do so can result in unexpected
inflation or deflation of the air springs, which can result
in shifting of the vehicle during these operations.
z Raise and support the vehicle.
z Check the steering system for wear or damage. Carry out a
steering linkage test. Refer Section 211 - 00 .
z Inspect the tire wear pattern. Refer to Tire Wear Patterns
chart in this section.
z Are the steering components worn or damaged? REPAIR the steering
system. INSTALL new
components as necessary.
TEST the system for normal
operation.
No
GO to
H3 .
H3 FRONT SHOCK ABSORBER/STRUT CHECK
z
Check the front shock absorbers/strut mounts for loose
bolts or nuts.
z Check the front shock absorbers/struts for wear or damage.
Carry out a "bounce test".
z Are the front shock absorbers/struts loose or
damaged? Yes
TIGHTEN to specifications if
loose. INSTALL new front
shock absorbers/struts if
damaged. TEST the system
for normal operation.
No
GO to
H4 .
H4 CHECK THE FRONT SPRINGS
z
Check the front spring and front spring mounts/brackets for
wear or damage.
z Are the front springs or spring mounts/brackets worn
or damaged? Yes
REPAIR or INSTALL new
components as necessary.
TEST the system for normal
operation.
No
GO to
H5 .
H5 CHECK THE CONTROL ARMS/RADIUS ARMS
z
Inspect the control arm bushings for wear or damage.
z Inspect for twisted or bent control/radius arm.
z Are the control/radius arms damaged or worn? Yes
REPAIR or INSTALL new
components as necessary.
TEST the system for normal
operation.
No
GO to
H6 .
H6 CHECK THE STABILIZER BAR/TRACK BAR
z
Check the stabilizer bar/track bar bushings and links for
damage or wear.
z Check the stabilizer bar/track bar for damage.
z Check for loose or damaged stabilizer bar isolators or
brackets.
z Are the stabilizer bar/track bar components loose, worn
or damaged? Yes
REPAIR or INSTALL new
components as necessary.
TEST the system for normal
operation.
No
Suspension system OK.
CONDUCT diagnosis on
other suspect systems.
Test Step Result / Action to Take Klj . 54 ba
702003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

PINPOINT TEST J: WHEEL AND TIRE I1 ROAD TEST THE VEHICLE
z
Test drive the vehicle.
z NOTE: An assistant will be needed for this road test.
z During the road test, drive the vehicle over a rough road.
Using ChassisEARs, determine from which
area/component the noise is originating.
z Is there a squeak, creak or rattle noise? Yes
GO to
I2 .
No
The suspension system is
OK. Conduct a diagnosis on
other suspect systems. I2 REAR SHOCK ABSORBER/STRUT CHECK
z
WARNING: The electrical power to the air
suspension system must be shut off prior to hoisting,
jacking or towing an air suspension vehicle. This can
be accomplished by turning off the air suspension
switch. Failure to do so can result in unexpected
inflation or deflation of the air springs, which can result
in shifting of the vehicle during these operations.
z Raise and support the vehicle.
z Check the rear shock absorber/strut mounts for loose bolts
or nuts.
z Check the rear shock absorbers/struts for damage. Carry
out a shock absorber check.
z Are the rear shock absorbers/struts loose or damaged? Yes
TIGHTEN to specifications if
loose. INSTALL new rear
shock absorbers/struts if
damaged. TEST the system
for normal operation.
No
GO to
I3 .
I3 CHECK THE REAR SPRINGS
z
Check the rear springs and rear spring mounts/brackets for
wear or damage.
z Are the rear springs or spring mounts/brackets worn or
damaged? Yes
REPAIR or INSTALL new
components as necessary.
TEST the system for normal
operation.
No
GO to
I4 .
I4 CHECK THE CONTROL ARMS/TRAILING ARMS
z
Inspect the control arm/trailing arm bushings for wear or
damage. Check for loose control arm/trailing arm bolts.
z Inspect for twisted or bent control arm/trailing arms.
z Are the control arm/trailing arms loose, damaged or
worn? Yes
REPAIR or INSTALL new
components as necessary.
TEST the system for normal
operation.
No
GO to
I5 .
I5 CHECK THE STABILIZER BAR/TRACK BAR
z
Check the stabilizer bar/track bar bushings and links for
damage or wear.
z Check the stabilizer bar/track bar for damage.
z Check for loose or damaged stabilizer bar isolators or
brackets.
z Are the stabilizer bar/track bar components loose, worn
or damaged? Yes
REPAIR or INSTALL new
components as necessary.
TEST the system for normal
operation.
No
Suspension system OK.
CONDUCT diagnosis on
other suspect systems.
Test Step
Result / Action to Klj . 55 ba
702003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

z
Is the runout within specifications? persists,GO to
K8 .
No
INSTALL a new wheel.
CHECK the runout on the
new wheel. If the new
wheel is within limits,
LOCATE and MARK the
low spot. INSTALL the
tire, matching the high
spot on the tire with the
low spot on the wheel.
BALANCE the assembly.
TEST the system for
normal operation. If the
condition persists, GO to
K8 .
K8 CHECK FOR VIBRATION FROM THE FRONT OF THE
VEHICLE WARNING: If only one drive wheel is allowed to
rotate, speed must be limited to 55 km/h (34 mph) using
the speedometer reading, since actual wheel speed will
be twice that indicated on the speedometer. Exceeding a
speed of 55 km/h (34 mph) or allowing the drive wheel to
hang unsupported can result in tire disintegration or
differential failure, which can cause serious personal
injury and extensive vehicle damage.
z Spin the front wheel and tire assemblies with a wheel
balancer while the vehicle is raised on a hoist. Feel for
vibration in the front fender or while seated in the vehicle.
z Is the vibration present? Yes
SUBSTITUTE known
good wheel and tire
assemblies as necessary.
TEST the system for
normal operation.
No
GO to
K9 .
K9 CHECK FOR VIBRATION FROM THE REAR OF THE
VEHICLE WARNING: If only one drive wheel is allowed to
rotate, speed must be limited to 55 km/h (34 mph) using
the speedometer reading, since actual wheel speed will
be twice that indicated on the speedometer. Exceeding a
speed of 55 km/h (34 mph) or allowing the drive wheel to
hang unsupported can result in tire disintegration or
differential failure, which can cause serious personal
injury and extensive vehicle damage.
z Chock the front wheels.
z Raise and support the rear end of the vehicle so that the rear
wheel and tire assemblies can spin.
z Engage the drivetrain and carefully accelerate the drive
wheels while checking for vibration.
z Is the vibration present? Yes
GO to
K10 .
No
TEST the system for
normal operation. K10 CHECK THE DRIVETRAIN
WARNING: If only one drive wheel is allowed to
rotate, speed must be limited to 55 km/h (34 mph) using
the speedometer reading, since actual wheel speed will
be twice that indicated on the speedometer. Exceeding a
speed of 55 km/h (34 mph) or allowing the drive wheel to
hang unsupported can result in tire disintegration or
differential failure, which can cause serious personal
injury and extensive vehicle damage.
z Remove the rear wheel and tire assemblies. Refer to the Yes
CHECK/TEST the
drivetrain and driveline
components. TEST the
system for normal
operation.
No
SUBSTITUTE known
good wheel and tire Klj . 60 ba
702003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

PINPOINT TEST M: TRANSFER CASE VIBRATION the system for normal operation.
No
GO to
L6 .
L6 CHECK THE FLYWHEEL BOLTS
z
Check for loose flywheel bolts.
z Are the bolts loose? Yes
TIGHTEN the bolts to
specifications. REFER to
Section 308 - 01 . TEST the system for
normal operation.
No
GO to L7 .
L7 CHECK THE FLYWHEEL SURFACE
z
Inspect the flywheel surface for wear or damage.
Check the flywheel runout.
z Is there any damage or excessive wear? Yes
INSTALL a new flywheel. TEST
the system for normal operation.
No
Clutch system normal. CONDUCT
a diagnosis on other suspect
systems.
Test Step Result / Action to Take
M1 INSPECT THE TRANSFER CASE
z
WARNING: The electrical power to the air suspension
system must be shut off prior to hoisting, jacking or towing
an air suspension vehicle. This can be accomplished by
turning off the air suspension switch. Failure to do so can
result in unexpected inflation or deflation of the air springs,
which can result in shifting of the vehicle during these
operations.
z Inspect the transfer case for loose or missing mounting bolts.
Check for fluid seepage between the transfer case and the
transmission.
z Are the mounting bolts missing or loose? Yes
TIGHTEN to
specifications or
INSTALL new bolts as
necessary. TEST the
system for normal
operation.
No
GO to
M2 .
M2 INSPECT THE REAR DRIVESHAFT
z
NOTE: Verify that the driveshaft and pinion flange index marks
are aligned.
z Inspect the driveshaft for missing weights, damage or
undercoating.
z Inspect the U- joints for freedom of movement.
z Check driveshaft runout and, if necessary, check the pinion
flange runout.
z Is the driveshaft or U- joints worn or damaged or
misaligned? Yes
REPAIR or INSTALL a
new driveshaft as
necessary. TEST the
system for normal
operation.
No
GO to
M3 .
M3 CHECK THE DRIVELINE ANGLES
z
Measure the rear driveshaft and pinion angles. Refer to Section 205 - 00 .
z Measure the front driveshaft and pinion angles. Refer to Section 205 - 00 .
z Are the driveline angles incorrect? Yes
REPAIR as necessary.
TEST the system for
normal operation.
No Klj . 62 ba
702003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

GENERAL PROCEDURES
Brake Disc Machining
WARNING: The electrical power to the air suspension system must be shut off prior to
hoisting, jacking or towing an air suspension vehicle. This can be accomplished by turning off
the air suspension switch. Failure to do so can result in unexpected inflation or deflation of the
air springs, which can result in shifting of the vehicle during these operations.
CAUTION: Do not install brake discs that are less than the minimum thickness specified.
Do not machine a brake disc below the minimum thickness specification.
1. Check wheel bearing end- play and correct as necessary.
2. NOTE: Begin at the front of the vehicle unless the vibration has been isolated to the rear.
Remove the tire and wheel assembly.
3. Remove the brake caliper and the brake caliper anchor plate. Refer to the appropriate section in Group 206 for the procedure.
4. Inspect the brake linings. Install new brake linings if below specification. For additional information, refer to the appropriate brake section.
5. Measure and record the brake disc thickness. Install a new brake disc if the thickness after machining will be at or below specification. The specification is molded into the brake disc.
zDo not machine a new brake disc.
SECTION 100-
04: Noise, Vibration and Harshness 2003 Mustang Workshop Manual Special Tool(s)
Gauge, Clutch Housing
308-
021 (T75L-4201- A) Dial Indicator Gauge with
Holding Fixture
100-
002 (TOOL- 4201-C) or
equivalent
Material Item Specification
Metal Surface Cleaner
F4AZ-
19A536- RA or equivalent WSE-
M5B392-
A High Temperature Nickel Anti-
Seize Lubricant
F6AZ-
9L494- AA or equivalent ESE-
M12A4-A Klj . 1 ba
32003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

GENERAL PROCEDURES
Powertrain/Drivetrain Mount Neutralizing
WARNING: The electrical power to the air suspension system must be shut off prior to
hoisting, jacking or towing an air suspension vehicle. This can be accomplished by turning off
the air suspension switch. Failure to do so can result in unexpected inflation or deflation of the
air springs, which can result in shifting of the vehicle during these operations.
1. Raise and support the vehicle.
2. Loosen, but do not remove, the powertrain/drivetrain mount fasteners.
3. Lower the vehicle.
4. CAUTION: Do not twist or strain the powertrain/drivetrain mounts.
Move the vehicle in forward and reverse 0.6- 1.2 meters (2-4 ft).
5. Raise and support the vehicle.
6. Tighten the powertrain/drivetrain mount fasteners.
7. Lower the vehicle.
8. Test the system for normal operation.
SECTION 100-
04: Noise, Vibration and Harshness 2003 Mustang Workshop Manual Klj . 1 ba
12003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

GENERAL PROCEDURES
Exhaust System Neutralizing
WARNING: Exhaust gases contain carbon monoxide, which is harmful to health and
potentially lethal. Repair exhaust system leaks immediately. Never operate the engine in an
enclosed area.
WARNING: Exhaust system components are hot.
NOTE: Neutralize the exhaust system to relieve strain on mounts which can be sufficiently bound up to
transmit vibration as if grounded.
1. WARNING: The electrical power to the air suspension system must be shut off prior
to hoisting, jacking or towing an air suspension vehicle. This can be accomplished by
turning off the air suspension switch. Failure to do so can result in unexpected inflation
or deflation of the air springs, which can result in shifting of the vehicle during these
operations.
CAUTION: Make sure the system is warmed up to normal operating temperature, as
thermal expansion can be the cause of a strain problem.
Raise and support the vehicle.
2. Loosen all exhaust hanger attachments and reposition the hangers until they hang free and straight.
3. Loosen all exhaust flange joints.
4. Place a stand to support the muffler parallel to the vehicle frame with the muffler pipe bracket free of stress.
5. Tighten the muffler connection.
6. Tighten all the exhaust hanger clamps and flanges (tighten the exhaust manifold flange joint last).
zVerify there is adequate clearance to prevent grounding at any point in the system. Make
sure that the catalytic converter and heat shield do not contact the frame rails.
z After neutralization, the rubber in the exhaust hangers should show some flexibility when
movement is applied to the exhaust system.
z With the exhaust system installed securely and cooled, the rear hanger should be angled
forward.
7. Lower the vehicle.
8. Test the exhaust system for normal operation.
SECTION 100-
04: Noise, Vibration and Harshness 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...
