FORD SUPER DUTY 2011 3.G Diesel Supplement Manual
Manufacturer: FORD, Model Year: 2011, Model line: SUPER DUTY, Model: FORD SUPER DUTY 2011 3.GPages: 90, PDF Size: 0.54 MB
Page 31 of 90
WARNING:Refill DEF in a well-ventilated area. When opening
the cap on the DEF tank or bottle containing DEF, ammonia
vapors may escape. The vapors can be irritating to skin, eyes and
mucous membranes. Inhaling ammonia vapors can cause burning to the
eyes, throat and nose and cause coughing and watery eyes.
To fill the DEF tank, see your authorized dealer or do the following
(before filling the DEF tank in cold climates, seeFilling the DEF tank
in cold climateslater in this section):
•DEF bottle fill with spout:
The following procedure applies to MotorcraftDEF or similar DEF
bottles; for other brands or bottle types, refer to the instructions on the
bottle label.
1. Remove the cap from the DEF
container. Remove the spout from
the bottle and insert the straw end
into the bottle. Ensure that the
arrow above the nut is aligned with
the bottle handle and the small tube
end extends into the far corner of
the bottle. Twist the spout nut on
the container until it is tight.
2. Open the DEF filler port on the
vehicle by turning the blue cap
counterclockwise.
Maintenance and Specifications
31
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 32 of 90
3. Lift and hold the DEF container,
without tipping, and insert the spout
into the DEF filler port until the
small black seal on the spout is
completely seated into the DEF
filler port.
4A. While filling, the fluid level in
the bottle will continually drop.
4B. When the DEF tank is full, the
fluid level in the bottle will stop
dropping, indicating the fluid has
stopped flowing.
Maintenance and Specifications
32
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 33 of 90
5. Once the level in the DEF bottle
has stopped dropping, return the
container to the vertical position
slightly below the DEF filler port
and let any DEF drain out of the
spout. DO NOT try to continue to
add DEF to the tank by shaking or
repositioning the container to
induce flow. This may cause spilling
and overfill the tank. Overfilling the
DEF tank can cause damage to the
tank.
Once the spout has drained, remove the spout from the DEF filler port
and install the blue cap on the DEF filler port.
7. Remove the spout from the DEF container and install the cap back on
the bottle.
8. If the container is empty, discard the empty container and spout, or
recycle if possible. If there is some DEF left in the container, retain it
and the spout for later use. Store the spout to ensure it is kept clean.
9. Wipe away any DEF that has spilled on painted surfaces with water
and a damp cloth.
•DEF filling station nozzle fill:
Filling the DEF tank using a nozzle is similar to a normal fuel fill. The
nozzle will shut off automatically when the tank is full. Do not continue
to fill the tank as this may cause spilling and overfill the tank which can
cause damage.
Note:Some filling station nozzles may prevent filling of your DEF tank
due to a magnetic mechanism in the nozzle. This is not a problem with
your vehicle. To refill your tank either locate another filling station or
use a bottle to refill the tank.
Filling the DEF tank in cold climates
DEF will freeze below 12°F (-11°C); however, your vehicle is equipped
with an automatic preheating system which allows the DEF system to
operate below 12°F (-11°C). When the vehicle is not in operation for an
extended period of time with temperatures at or below 12°F (-11°C), the
DEF tank could freeze. If the tank is OVERFILLED and freezes, it could
be damaged, therefore DO NOT OVERFILL.
Maintenance and Specifications
33
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 34 of 90
To prevent overfilling of the DEF tank when filling with a bottle, Ford
recommends using MotorcraftDEF. Additionally, if the message center
indicatesEXHAUST FLUID UNDER 1/2 FULL, you should only add a
MAXIMUM of 2 gallons (6.7L) of DEF to the tank to prevent freeze
damage due to overfilling. If the message center indicatesEXHAUST
FLUID LEVEL OK, do not add DEF.
Contaminated DEF
SCR systems are sensitive to
contamination of the DEF. USE
ONLY API or ISO 22241 CERTIFIED
DIESEL EXHAUST FLUID. If the
system becomes contaminated, the
DEF light will illuminate and
contaminated exhaust fluid
messages will appear in the message
center.
Continued driving without refilling will result in the following actions as
required by the U.S. Environmental Protection Agency (EPA):
•Within a certain number of miles (kilometers) to empty, speed will be
limited upon restart. Prior to this occurring a message will appear in
the message center.
•Further vehicle operation without replacing contaminated DEF will
cause the engine to enter an idle-only condition. This will only occur
upon vehicle refueling and will be indicated by a message in the
message center indicating required actions to resume normal
operation.
For either vehicle speed limiting or idle-only condition, normal vehicle
operation will resume when the contaminated system is repaired.To
service a contaminated SCR system, see your authorized dealer.
DEF guidelines and information
•Use only DEF that carries the trademark: American Petroleum
Institute (API) certified DEF or ISO 22241.
•Do not put DEF in the diesel fuel tank.
•Do not overfill the DEF tank.
•Do not re-use the DEF container or nozzle once it is emptied.
•Avoid spilling DEF on painted surfaces, carpeting or plastic
components. Immediately wipe away any DEF that has spilled with a
damp cloth and water. If it has already crystallized, use warm water
and a sponge.
Maintenance and Specifications
34
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 35 of 90
•Store DEF out of direct sunlight and in temperatures between 23°F
(-5°C) — 68°F (20°C).
•DEF will freeze below 12°F (-11°C).
•Do not store DEF bottle in vehicle. If it leaks it could cause damage to
interior components or release an ammonia odor inside the vehicle.
•DEF is non-flammable, non-toxic, colorless and water-soluble liquid.
•Do not dilute DEF with water or any other liquid.
•An ammonia odor may be smelled when the cap is removed or during
refill. Refill DEF in a well ventilated area.
FUEL FILTER/WATER SEPARATOR
Diesel Fuel Conditioner Module (DFCM)
The vehicle is equipped with a diesel fuel conditioning module (DFCM)
located on the frame-rail under the driver-side floorboard near the
transmission
Water should be drained from the
module assembly whenever the
warning light comes on and the
message center directs you to drain
the water separator. This will occur when approximately 0.32 pints (150
ml) of water accumulates in the module. If water level is allowed to
exceed this level, the water may be passed through to the engine and
may cause fuel injection equipment damage.
Draining the DFCM
1. Stop the vehicle andshut offthe engine.
WARNING:The vehicle must be stopped with the engine off
when draining the DFCM. Fuel may ignite if the separator is
drained while the engine is running or vehicle is moving.
Note:Air will enter into the fuel system if the DFCM is drained while
the system is running. The engine will not operate properly if air enters
the system.
2. Locate the DFCM and place an appropriate container under the drain
port (see illustration).
Maintenance and Specifications
35
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 36 of 90
3. Rotate the drain counterclockwise
until the O-ring is visible. Allow the
DFCM to drain for approximately
25 seconds or until clean fuel is
observed. Rotate the drain clockwise
to tighten it.
4. Make sure that the drain valve is fully tightened, then remove the
container from under the vehicle.
Note:A loose drain valve can allow air to enter the fuel system and
cause drivetrain issues. The engine will not operate properly. be sure
that the drain valve is fully tightened.
5. Restart the engine. TheWATER IN FUEL DRAIN FILTERor
WATER IN FUEL DRAIN FILTER SEE MANUALmessage and light
should not be illuminated. If they continues to illuminate, have the fuel
system checked and repaired.
LOW FUEL PRESSURE MESSAGE
The engine is equipped with a low fuel pressure detection system. If the
message center displays:LOW FUEL PRESSUREthe following
explains why and what to do:
•Cold start or cold operation (below 32°F (0°C): If this message
appears during a cold start or during cold operation up to 10 minutes
after the initial cold start, monitor the message center. If it disappears
and does not re-appear after the engine has fully warmed up, the low
fuel pressure message is most likely caused by waxed or gelled fuel.
Do not use alcohol based additives to correct fuel gelling. This may
result in damage to the fuel injectors/systems. Use an anti-gel additive
as listed inMaintenance product specifications and capacities
section in this chapter. The customer warranty may be void from using
additives that do not meet or exceed Ford specifications.
If the low fuel pressure message persistently appears after re-fueling
during the cold start and cold operation conditions defined previously
and then disappear when the engine has fully warmed up, consider
different fuel sources.
Maintenance and Specifications
36
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 37 of 90
•Low fuel operation: If the message appears when the vehicle is warm
and during low fuel tank level operation, i.e. the tank level is at or
very near empty, refuel the vehicle and operate the vehicle. If the
message reappears after fueling, see below. If the message does not
come back, the low fuel pressure condition was due to low fuel levels
in the fuel tank.
•Normal operation: If the message appears during normal operation
when the vehicle / engine is fully warm, and fuel level is not low, the
fuel filters must be changed regardless of the maintenance schedule
interval.
•If replacement of the fuel filter does not remedy the low fuel pressure
message during normal operation as defined above, take the vehicle to
your authorized dealer.
CHANGING THE ENGINE-MOUNTED AND DFCM FUEL FILTERS
Your vehicle is equipped with two fuel filters; one is mounted on top of
the driver’s side of the engine and the second filter, inside the DFCM, is
mounted on the frame rail under the driver-side floorboard near the
transmission. Both filters should be replaced at the same time. Regular
fuel filter changes are an important part of engine maintenance; failing to
keep with the scheduled maintenance could lead to engine performance
issues and/or fuel injection system damage. Refer to thescheduled
maintenance informationof this supplement for more information.
Refer toMotorcraft part numberslater in this chapter for the fuel filter
replacement part number. This part number includes filters and seals for
both the engine-mounted and frame-mounted filters.
Removal - DFCM filter
The DFCM filter is located in the lower portion of the DFCM housing.
1. Drain the DFCM. SeeFuel filter/water separatorearlier in this
chapter.
To install the new DFCM filter, seeInstallation – DFCM filterlater in
this section.
Maintenance and Specifications
37
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 38 of 90
2. Remove the lower portion of the
DFCM housing (filter bowl) by
turning it counterclockwise using a
32 mm socket.
Note:Depending on the amount
seal swelling, removal of the filter
bowl may be noisy and require some
effort. Replace the seal prior to
reinstalling the filter/bowl to
improve assembly.
3. Remove and discard the old fuel filter element.
4. Carefully clean the mating surfaces using a lint-free rag.
Installation – DFCM filter
1. Install the new filter into the filter bowl tabs and replace the seal on
the DFCM header (top portion of DFCM). Refer toMotorcraft part
numberslater in this chapter for the fuel filter kit part number.
2. Reinstall the lower portion of the housing by slowly turning it
clockwise onto DFCM housing, allowing fuel to soak into the fuel filter
element. Tighten the lower housing until it contacts the mechanical stop.
Note:The engine will not run properly if the DFCM fuel filter is not
installed in the housing.
The system will need to be purged of air after removal/changing of the
filter. SeePurging air from the fuel system after DFCM and engine
mounted fuel filter replacementfollowing.
Maintenance and Specifications
38
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 39 of 90
Removal - Engine-mounted fuel filter
The engine-mounted fuel filter is a plastic disposable cartridge. To
remove it, do the following:
1. Disconnect both fuel lines by
squeezing the connector tabs and
pulling the lines straight off.
Note:Although the fuel system is
not fully pressurized when the
vehicle is off, some residual
pressure may remain in the fuel
system since it can take some time
for the pressure to completely bleed
off. Therefore, it is recommended to
place a shop rag below the filter
connectors to absorb the small amount of fuel that will drain.
2. Loosen the bracket bolt.
3. Rotate the filter counterclockwise until it unlocks from the bracket.
4. Pull the filter straight out from the bracket and discard the filter.
Installation – Engine-mounted fuel filter
1. Install the new filter into the filter
bracket. The filter has two locking
tabs: one on the bottom and one on
the side approximately 180° from
the bracket bolt. Line this tab up
with the slot and the bottom will
follow. Turn the filter clockwise to
lock it in place.
2. Tighten the bracket bolt until the filter is snug in the bracket.
Maintenance and Specifications
39
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 40 of 90
3. Reconnect both fuel lines.
Using a fuel which has more than average impurities may require
the fuel filter to be replaced more frequently than the service
interval specifies.
The system will need to be purged of air after removal/changing of the
filter. SeePurging air from the fuel system after DFCM and
engine-mounted fuel filter replacementfollowing.
Purging air from the fuel system after DFCM and engine mounted
fuel filter replacement
Turn the ignition key to on for 30 seconds, then turn it to off. Do this a
total of six times in a row to purge any trapped air from the fuel system.
After filter service, a no start or rough running engine may indicate that
air is entering the system through the filter bowl seal or drain. Make sure
the drain is tight.
ENGINE OIL
Checking the engine oil level
Because it is normal to add some oil between oil changes, check your
engine oil level each time you stop for fuel. To check the engine oil level
consistently and accurately, the following procedure is recommended:
1. Have engine at normal operating temperature (at least into the
NORMAL range on the engine coolant temperature gauge).
2. Park the vehicle on a level surface, then turn off the engine and open
the hood.
3. Allow at least20 minutesafter engine shutdown to ensure that the
oil contained in the upper parts of the engine has returned to the oil
pan.
4. Protecting yourself from engine heat, pull out the dipstick, wipe it
clean and reinsert fully.
5. Read oil level on both sides of dipstick and use highest level (reading)
for the actual engine oil level.
Maintenance and Specifications
40
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
