6. it is best to maintain the oil level
within the crosshatch area on the
dipstick by adding oil as required.
The lower hole is the minimum oil
level and the upper hole is the
maximum oil level. Do not overfill.
The distance from the lower hole
(oil minimum) to the upper
crosshatch area on the dipstick represents 1.0 quart (.95L).
Engine oil specifications
To help achieve acceptable engine performance and durability, it is
important that only engine oils of good quality are used in your diesel
engine and it is changed at the recommended interval. For normal or
severe service, use Motorcraftoil or an equivalent oil conforming to
Ford specifications as listed in theMaintenance product specifications
and capacitiessection in this chapter or API service categories CJ-4 or
CJ-4/SM. It is important to use these oils because they are compatible
with the emission control equipment of your vehicle to meet the more
stringent emission standards.
The use of correct oil viscosities for diesel engines is important for
satisfactory operation. Determine which oil viscosity best suits the
temperature range you expect to encounter for the next service interval
from the following SAE viscosity grade chart.
Maintenance and Specifications
41
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 42 of 90
1For severe duty usage, use SAE 5W-40 API CJ-4.
2For biodiesel (grades B5-B20) usage, use SAE 5W-40 or SAE
15W-40 API CJ-4.
An engine block heater is recommended at temperatures below –10°F
(–23°C).
A symbol has been developed by the
American Petroleum Institute (API)
to help you select the proper engine
oil. It will be included on the oil
container you purchase. The top
section of the symbol shows the oil
performance by the API designation. This should match the owner guide
recommendation. The center section will show the SAE viscosity grade
Changing the engine oil and oil filter
Your vehicle is equipped with an Intelligent Oil Life Monitor™ that
calculates the proper oil change service interval. When the message
center indicates:OIL CHANGE REQUIRED, change the engine oil and
oil filter. See theMessage centersection of theInstrument Cluster
chapter for more information.
Refer toMotorcraft part numberslater in this chapter for the engine oil
filter part number. This filter protects your engine by filtering harmful,
abrasive or sludge particles and particles significantly smaller than most
available “will-fit” filters.
-20
-100
10 20 30
40
38 32 27 21 16 10 4 -1 -7 -12
-18 -23 -2950 60
7080 9010 0
SAE VISCOSITY GRADES
EXPECTED TEMPERATURE RANGE
F˚
C˚
5W-401,2
0W-30 / 0W-4015W-40
2
10W-30 (Normal Usage)
APISERVICECJ-4/SMSAE10W-30
Maintenance and Specifications
42
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 43 of 90
To change the engine oil and oil filter:
1. Unscrew the oil filter and oil pan drain plug and wait for the oil to drain.
Note:The oil pan drain plug only requires 1/4 turn to removal/install. A
3/8 inch socket drive may be used to assist with removal/installation, but be
careful not to over-tighten the plug during installation.
2. Replace the filter.
3. Reinstall the oil pan drain plug.
4. Refill the engine with new oil. For the proper capacity, see
Maintenance product specifications and capacitiesin this chapter.
5. Reset the Intelligent Oil Life Monitor™. SeeMessage centerin the
Instrument Clusterchapter for more information.
WARNING:Do not handle a hot oil filter with bare hands.
WARNING:Continuous contact with used motor oil has caused
cancer in laboratory mice. Protect your skin by washing with
soap and water.
Engine lubrication for severe service operation
The following conditions define severe operation for which engine
operation with SAE 5W-40 API CJ-4 is recommended. Oil and oil filter
change intervals will be determined by the Intelligent Oil Life Monitor™
as noted previously.
•
frequent or extended idling (over 10 minutes per hour of normal driving)
•low-speed operation/stationary use
•if vehicle is operated in sustained ambient temperatures below -10°F
(-23°C) or above 100°F (38°C)
•frequent low-speed operation, consistent heavy traffic less than
25 mph (40 km/h)
•operating in severe dust conditions
•operating the vehicle off road
•towing a trailer over 1,000 miles (1,600 km)
•sustained, high-speed driving at Gross Vehicle Weight Rating
(maximum loaded weight for vehicle operation)
•
use of fuels with sulfur content other than ultra-low sulfur diesel (ULSD)
•use of high-sulfur diesel fuel
Maintenance and Specifications
43
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 44 of 90
ENGINE AND SECONDARY COOLING SYSTEM COOLANT
Checking engine coolant
The concentration (freeze point protection), additive strength (corrosion
inhibitor), and level of coolant should be checked at the mileage intervals
listed in thescheduled maintenance information.The coolant
concentration should be maintained at 50/50 coolant and water, which
equates to a freeze point of -36°C (-34°F). Coolant concentration testing
is possible with a hydrometer or antifreeze tester (such as the Rotunda
Battery and Antifreeze Tester, 0014–R1060). The level of coolant should
be maintained within the COLD FILL RANGE in the coolant reservoirs. If
the level falls below, add coolant per the instructions in theAdding
coolantsection.
Your vehicle was factory-filled with a 50/50 coolant and water
concentration. If the concentration of coolant falls below 40% or above
60%, the engine parts could become damaged or not work properly.A
50/50 mixture of coolant and water provides the following:
•freeze protection down to -36°C (-34°F).
•boiling protection up to 129°C (265°F).
•protection against rust and other forms of corrosion.
•
an accurate temperature readout from the engine coolant gauge.
When the engine is cold, check the level of coolant in the reservoirs. See
Identifying components in the engine compartmentfor the location of
the engine and secondary cooling system reservoirs.
•The coolant should be within the COLD FILL RANGE in the coolant
reservoirs.
•Refer to thescheduled maintenance informationfor service interval
schedules.
•Be sure to read and understandPrecautions when servicing your
vehiclein yourOwner’s Guide.
If the coolant has not been checked at the recommended interval, the
engine or secondary coolant reservoir may become low or empty. If
either reservoir is low or empty, add coolant to the reservoir(s). Refer to
Engine and secondary cooling system refill procedurein this chapter.
Note:Automotive fluids are not interchangeable; do not use engine
coolant or windshield washer fluid outside of its specified function and
vehicle location.
Maintenance and Specifications
44
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 45 of 90
Adding coolant
When adding coolant, make sure it is a 50/50 mixture of coolant and
distilled water. Add the mixture to the coolant reservoir(s),when the
engine is cool, until the appropriate fill level is obtained.
If you have to add more than 1.0 quart (1.0 liter) of coolant per month,
have your dealer check the cooling system. Your cooling system may
have a leak. Operating an engine with a low level of coolant can result in
engine overheating and possible engine damage.
Note:If coolant is added to bring the level within the COLD FILL
RANGE when the engine is not cold, the system will remain underfilled.
WARNING:Do not add coolant when the engine is hot. Steam and
scalding liquids released from a hot cooling system can burn you
badly. Also, you can be burned if you spill coolant on hot engine parts.
WARNING:Do not put coolant in the windshield washer fluid
container. If sprayed on the windshield, coolant could make it
difficult to see through the windshield.
•Do not mix coolants. Add the coolant type originally equipped
in your vehicle.Refer toMaintenance product specifications and
capacitiesin this chapter for the proper coolant type.
Note:Do not use stop leak pellets or cooling system sealants/additives
as they can cause damage to the engine cooling and/or heating systems.
This damage would not be covered under your vehicle’s warranty.
•A large amount of water without engine coolant may be added to the
engine cooling system only, in case of emergency, to reach a vehicle
service location. Avoid this procedure if delivery to the service location
requires heavy engine loads. In this instance, the cooling system(s)
must be drained, chemically cleaned with MotorcraftEngine Cooling
System Iron Cleaner, and refilled with a 50/50 mixture of coolant and
distilled water as soon as possible. Water alone (without coolant) can
cause damage from corrosion, overheating or freezing.DO NOTuse
this method for the secondary cooling system. The secondary cooling
system operates close to ambient temperature, and is susceptible to
freezing in any subfreezing environment, in the absence of coolant.
•
Do not use alcohol, methanol or brine or any engine coolants
mixed with alcohol or methanol antifreeze (coolant).Alcohol and
other liquids can cause engine damage from overheating or freezing.
Maintenance and Specifications
45
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 46 of 90
•Do not mix with recycled coolant unless from a Ford-approved
recycling process (seeUse of recycled engine coolantsection).
WARNING:To reduce the risk of personal injury, make sure the
engine is cool before unscrewing the coolant pressure relief cap.
The cooling system(s) are under pressure; steam and hot liquid can
come out forcefully when the cap is loosened slightly.
Add the proper mixture of coolant and distilled water to the cooling
system(s) by following these steps:
1. Before you remove the cap, turn the engine off and let it cool.
2. When the engine is cool, wrap a thick cloth around the cap. Slowly
turn cap counterclockwise until pressure begins to release.
3. Step back while the pressure releases.
4. When you are sure that all the pressure has been released, use the
cloth to turn it counterclockwise and remove the cap.
Engine and secondary cooling system refill procedure
The following procedure should be used when refilling the engine or
secondary cooling systems after it has been drained or become extremely
low.
1. Remove the pressure relief cap from the engine or secondary coolant
reservoir as previously outlined.
2. Slowly add a 50/50 mixture of coolant and distilled water to the
coolant reservoir until the coolant level is within the COLD FILL RANGE
as listed on the reservoir.
3. Reinstall the pressure relief cap.
4. Start and run the engine at 2,000 rpm for 2 minutes.
5. Shut engine off, and remove the pressure relief cap as previously
outlined.
6. If required, add a 50/50 mixture of coolant and distilled water to the
coolant reservoir until the coolant level is within the COLD FILL RANGE
as listed on the reservoir.
7. Engine cooling system: Repeat Step 3 until the coolant level has
stabilized (is no longer dropping after each step) AND the upper radiator
hose at the radiator is warm to the touch (indicating that the engine
thermostat is open and coolant is flowing through the radiator).
Secondary cooling system: Repeat Step 3 until the coolant level has
stabilized (is no longer dropping after each step) AND the lower
Maintenance and Specifications
46
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 47 of 90
passenger side of the secondary radiator is warm to the touch
(indicating secondary thermostat is open and coolant is flowing
through the entire system).
8. Reinstall the pressure relief cap. Shut the engine off and let it cool.
9. Check the coolant level in the reservoir before you drive your vehicle
the next few times (with the engine cool).
10. If necessary, add a 50/50 mixture of coolant and distilled water to the
coolant reservoir until the coolant level is within the COLD FILL RANGE
as listed on the reservoir. After any coolant has been added, check the
coolant concentration. SeeEngine and secondary cooling system
coolantearlier. If the concentration is not 50/50 (protection to
–34°F/–36°C), drain some coolant and adjust the concentration. It may
take several drains and additions to obtain a 50/50 coolant concentration.
Whenever coolant has been added, the coolant level in the coolant
reservoir should be checked the next few times you drive the vehicle. If
necessary, add enough 50/50 concentration of coolant and distilled water
to bring the liquid level to the proper level.
Coolant refill capacity
To find out how much fluid your vehicle’s cooling system can hold, refer
toMaintenance product specifications and capacitiesin this chapter.
Coolant additives
At specific mileage intervals of 15,000 miles (24,000 km), as listed in the
scheduled maintenance informationchapter, the coolant additive
should be checked. The optional message center, if equipped, will also
display the messageCHECK COOLANT ADDITIVEat this time. The
purpose of checking is to verify the correct concentration (freeze point
protection) and additive strength (corrosion inhibitor) levels of the
coolant for maximum engine performance and protection. Three
products are available for ensuring the life and health of the coolant: two
test kits and a coolant inhibitor additive:
•Rotunda 328-00007 (Matthew’s Water CoolCheck) – Evaluates water
quality (hardness, chloride, and pH) for 50/50 mixture of coolant and
distilled water. Use distilled water. If distilled water is unavailable,
water meeting the requirements of Rotunda 328-00007, is sufficient
for vehicle use. Using water that fails to meet the requirements can
lead to coolant passage scaling and degrade the engine’s durability and
performance.
Maintenance and Specifications
47
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 48 of 90
•Rotunda 328-00008 (Antifreeze Coolant ELC Contamination Kit) –
Evaluates the coolant concentration (freeze point protection) and
additive strength (corrosion inhibitor) for overall coolant health. Note
that the first step is to verify that the vehicle’s coolant concentration
is in the window of 40 – 60%. If the concentration falls outside of that
window, the evaluation of the corrosion inhibitor strength will not be
valid. If the report results in a pass the cooling system does not show
excessive contamination. No action is required. If the report results as
insufficient, the corrosion inhibitor (additive) strength of the coolant
is too low. Add entire contents of one bottle of MotorcraftSpecialty
Orange Engine Coolant Revitalizer to the coolant reservoir. The
coolant can be recharged with this additive up to two times before the
coolant must be changed-out. When exchanging the full coolant
volume, the system must be flushed and refilled with distilled water
and coolant concentrate (MotorcraftSpecialty Orange Engine
Coolant).
•MotorcraftSpecialty Orange Engine Coolant Revitalizer – Additive to
boost the corrosion inhibitor level based upon the test results of the
Antifreeze Coolant ELC Contamination Kit. The revitalizer may be
added two times over the life of the coolant. If additional dosages are
required, the cooling system must be flushed and refilled with distilled
water and coolant concentrate (MotorcraftSpecialty Orange
Coolant).
Refer toMaintenance product specifications and capacitiesin this
chapter for the proper coolant and additive specifications.
Coolant change
At specific mileage intervals, as listed in thescheduled maintenance
information,the coolant should be changed. The optional message
center, if equipped, will also display the message COOLANT CHANGE
REQUIRED at this time.
Refer toMaintenance product specifications and capacitiesin this
chapter for the proper coolant.
Maintenance and Specifications
48
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 49 of 90
AIR FILTER RESTRICTION GAUGE AND AIR FILTER
REPLACEMENT
Air filter restriction gauge:
The restriction gauge, located on
the upper housing of the air filter
assembly, measures the vacuum
inside the air filter. The more the air
filter is restricted (dirty, clogged),
the higher the vacuum reading
Check the air filter restriction gauge
whenever the hood is raised to
perform general engine maintenance
at least every 7,500 miles (12,000 km). If the vehicle is operated in
extremely dusty conditions, check and reset the gauge at least every
500 miles (800 km), or two weeks, whichever comes first.
Change the air filter when the gauge reads near the “change filter” line
and the chamber is filled with yellow. Engine performance and fuel
economy are adversely affected when the maximum restriction is
reached.
Blowing-out the air filter element with compressed air is not
recommended as the compressed air may damage the filter paper.
Note:It is not possible to determine the level of filter clogging by visual
appearance alone. A filter which appears to be dirty may actually have
several thousand miles (kilometers) of life remaining.
Use the underhood air filter restriction gauge to determine when
the air filter element needs to be changed.
Maintenance and Specifications
49
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
Page 50 of 90
After installation of the new filter
element, reset the gauge by pressing
the reset button on top of the
gauge.
Note:Vehicle operation in heavy
snowfall or extreme rain conditions
may feed excessive amounts of
snow/water into the air intake
system. This could plug/soak the air
filter with snow and may cause the
engine to lose power and possibly
shut down.
The following actions are recommend after operating the vehicle up to
200 miles (320 km) in heavy snowfall or extreme rain:
•Snow:At the earliest opportunity, open the hood and clear all the
snow and ice from the air filter housing inlet (do NOT remove the
foam filter) and reset the air filter restriction gauge.
•Extreme rain:The air filter will dry after about 15–30 minutes at
highway speeds. At the earliest opportunity, open the hood and reset
the air filter restriction gauge.
Air filter replacement:
When replacing the air filter element, use the Motorcraftair filter
element listed inMotorcraft part numberslater in this chapter.
WARNING:To reduce the risk of vehicle damage and/or
personal burn injuries do not start your engine with the air filter
removed and do not remove it while the engine is running.
Failure to use the correct air filter element may result in severe
engine damage.
Maintenance and Specifications
50
2011 Econoline(eco)
Supplement, 1st Printing
USA(fus)
