FORD TAURUS 1996 Owners Manual

162 [FV38300(ALL)05/91]
one third page art:0000441-BThe cargo net for the wagon
[FV38400(ALL)04/95]
Do not put more than 50 pounds (22 kg) in the
net. Any ropes or cords that you use must be as
strong as the cargo net or strong enough to
restrain a 50-pound (22 kg) object.
[FV38450(ALL)04/95]
This net is not designed to retain objects during
an accident.
% [FV38500(ALL)11/94]
Cargo Cover (If equipped)
[FV38600(ALL)01/89]
You can conceal luggage or cargo in the back of
your wagon with the cargo cover.
[FV38700(ALL)01/89]
To cover the back compartment:
[FV38800(ALL)02/95]
1. Fasten the cover into the molded pockets in
the trim panel. Make sure the cover is right
side up, so it unrolls from the top.
[FV38900(ALL)04/95]
2. Pull the end of the cover toward you and
hook it into the rear molded pockets in the
side trim panels in the rear, inserting the
right side first.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

163 [FV39000(ALL)04/95]
one third page art:0001471-A
The cargo cover
% [FV39200(ALL)11/94]
Luggage Rack
[FV39300(ALL)02/95]
You can move the rear luggage crossbar on top
of the vehicle to fit the item you need to carry.
The front crossbar does not move.
[FV39400(ALL)10/90]
To adjust the luggage rack:
[FV39500(ALL)02/95]
1. Load your luggage close to the front
crossbar. Do not carry more than 100 pounds
(45 kg) or cause the vehicle to exceed the
gross vehicle weight rating (GVWR), which
is shown on the Safety Compliance
Certification Label.
[FV39600(ALL)02/95]
2. Loosen the adjusting levers on the rear
crossbar by pushing them toward the center
of the vehicle.
[FV39700(ALL)10/90]
3. Slide the rear crossbar forward to hold your
luggage securely in place.
[FV39800(ALL)02/95]
4. Clamp the adjusting levers again by pulling
them toward the outside of the vehicle.
[FV39825(ALL)00/95]
Make sure that the rear crossbar pins are locked
in slots by pulling forward and back on each of
the outside supports. If the crossbar slides, push
or pull until you hear it click and feel it lock
into position.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

164 [FV39850(ALL)02/95]5. Secure luggage or cargo with rope (up to
3/8"), NOT ELASTIC CORD, using the tie
down loops provided. There are three loops
on each outside rail and one at each end of
the cross bars.
[FV39875(ALL)02/95]
quarter page art:0001381-B
The adjusting levers for the luggage rack
[FV39900(ALL)11/94]
Leave the rear crossbar in its original back
position when you are not using it to hold
luggage to reduce aerodynamic drag and
improve fuel economy.
% [FV40000(ALL)11/94]
The Second Seats
[FV40100(ALL)11/94]
Your vehicle is equipped with split-folding
second seats. One or both second seatbacks can
be folded down to provide additional cargo
space.
[FV40200(ALL)02/95]
To lower the seatback:
[FV40300(ALL)02/95]
1. Lift the seatback release handle on the upper
outboard corner of the seatback.
[FV40400(ALL)02/95]
2. Fold the seatback forward until it rests on
the cushion.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

165 [FV40500(ALL)05/95]
To raise the seatback:
[FV40700(ALL)02/95]
1. Lift the seatback rearward until it is in the
upright position. Push the center of the seat
until you hear it latch.
[FV40750(ALL)05/95]
2. Make sure the seatback is locked in position
by pushing forward and backward on it.
*
[FV40775(ALL)05/95]
RWARNING
Securely latch the seatback in the upright
position to prevent the seatback or objects
from being thrown forward during a
sudden stop or collision.
[FV40800(ALL)11/94]
The Third Seat
[FV40900(ALL)04/95]
The third seat faces the back of the wagon. For
height and weight limits, see the label on the
seat cushion. When the seat is down, the back
part of your wagon has a flat surface for
carrying cargo.
[FV41000(ALL)03/92]
To open up the seat:
[FV41100(ALL)04/95]
1. Unlock the floor panel with the key.
[FV41200(ALL)11/94]
2. Use the handle to fold the floor panel
toward the front of the car.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

166 [FV41250(ALL)04/95]
half page art:0001409-COpening the third seat in the rear of the wagon
[FV41270(ALL)04/95]
half page art:0000442-B
The third seat in a wagon
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

167 [FV41350(ALL)04/95]
3.Remove the cargo cover.The cargo cover
must be removed or the seatback cannot be
locked in the upright position.
[FV41450(ALL)11/94]
4. Lift the remote latch release on the left side
of the well and fold the remaining floor
panel toward the front of the car until it
latches. Make sure the seatback is locked in
the upright position by pushing forward and
backward on it.
[FV41500(ALL)03/92]
To close the seat:
[FV41600(ALL)02/95]
1. Ensure that the third row safety belts are
fully stowed, and belts located in notches.
[FV41700(ALL)11/94]
2. Lift the remote latch release and push the
seat down until it latches.
[FV41800(ALL)04/95]
3. Pull up on the handle and push the floor
panel into place.
[FV41850(ALL)05/95]
RWARNING
Be sure to keep the floor panel closed and
locked at all times. Unattended children
could possibly become trapped inside or
loose items could be thrown around.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

169
Electronic Sound Systems
% [AS10350(ALL)10/95]
full page art:0001446-B
Stereo Radio
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

170 [AS10401(ALL)10/95]
full page art:0001447-BStereo Radio with Cassette
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

171 [AS10550(ALL)10/95]
full page art:0001448-B
Stereo Cassette with CD-DJ
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

172
% [AS10600(ALL)04/95]
Stereo and Stereo Cassette Radios
*
[AS10650(ALL)08/95]
Using the Controls on Your New Radio
*
[AS10700(ALL)10/95]
How to turn the radio on and off
[AS10750(ALL)04/95]
Press the ªVOL PUSH ONº button to turn the
radio on. Press again to turn off.
*
[AS10800(ALL)10/95]
How to adjust the volume
[AS10825(ALL)02/95]
Turn the ªVOL PUSH ONº knob to the right to
increase the volume and to the left to decrease
the volume. Dots illuminate in the display to
show relative volume level.
[AS10840(ALL)09/95]
NOTE: If the volume is set above a certain
level when the ignition is turned off,
the volume will come back to a
ªnominalº listening level when the
ignition is turned back on. However, if
the radio power is turned off with the
ªVOL PUSH ONº button, the volume
will not change and will remain at the
level set when the radio is turned back
on.
*
[AS11000(ALL)10/95]
Selecting the AM or FM frequency band
[AS11125(ALL)04/95]
Press the ªAMº or ªFMº button to select the
desired frequency band or to stop/store cassette
tape (when a cassette is playing). Pressing the
ªFMº button more than once will alternate
between FM1 and FM2. These functions are used
with the station memory buttons described
underHow to tune radio stations.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com
