132 [FV05850(ALL)04/95]Autolock (If equipped)
*
[FV05900(ALL)02/95]
The Autolock feature is part of your remote
keyless entry system and is enabled at the
factory. With the Autolock feature enabled, all of
the doors will automatically lock when:
[FV05950(ALL)04/95]
q
the vehicle doors and liftgate are fully closed
*
[FV06001(ALL)09/95]
q
the ignition key is turned to the ON position
*
[FV06050(ALL)02/95]
q
the brake pedal is pressed
*
[FV06100(ALL)02/95]
q
you shift through (Reverse)
*
[FV06150(ALL)11/95]
q
one second has elapsed after the brake pedal
is released
*
[FV06200(ALL)09/95]
The Autolock feature will repeat when:
[FV06250(ALL)04/95]
q
a door is opened and then all doors and
liftgate are closed
[FV06300(ALL)12/95]
q
the brake pedal is released
*
[FV06400(ALL)02/95]
The doors may not lock automatically at the
correct time if the driver:
*
[FV06450(ALL)02/95]
q
shifts through gears without pressing the
brake
*
[FV06500(ALL)02/95]
q
shifts through gears quickly after starting the
vehicle
*
[FV06550(ALL)02/95]
q
releases their foot from the brake while
someone has stepped out of the vehicle for a
moment
*
[FV06575(ALL)04/95]
You can deactivate the system by using the
buttons for the keyless entry system if you don't
want to use the Autolock feature.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

133
*
[FV06600(ALL)05/95]
To deactivate the Autolock system:
*
[FV06650(ALL)06/95]
1. Enter your permanent five-digit entry code
(not the personal code you may have set).
*
[FV06700(ALL)09/95]
2. Within 5 seconds, press and hold 7/8.
*
[FV06750(ALL)09/95]
3. Within 5 more seconds, press and release
3/4.
*
[FV06800(ALL)09/95]
4. Release 7/8.
*
[FV06850(ALL)02/95]
To reactivate the Autolock system, simply repeat
the instructions for deactivating the system. By
re-entering the code that deactivates the
Autolock, the keyless entry system reinstates the
Autolock feature.
*
[FV06900(ALL)04/95]
You can also deactivate or reactivate the
Autolock feature by this method:
[FV06950(ALL)04/95]
1. Make sure the anti-theft system is not armed
or triggered, ignition is off, and all doors
and liftgate are closed.
*
[FV07000(ALL)02/95]
2. Turn the ignition key from OFF to RUN.
*
[FV07050(ALL)02/95]
3. Press the door power unlock button 3 times.
*
[FV07100(ALL)02/95]
4. Turn the ignition key from RUN to OFF.
*
[FV07150(ALL)02/95]
5. Press the door power unlock button 3 times.
*
[FV07200(ALL)02/95]
6. Turn the ignition key back to RUN within 30
seconds of step 2.
*
[FV07250(ALL)02/95]
7. The horn should chirp once. If not, wait 30
seconds and repeat steps 1 through 6.
*
[FV07300(ALL)02/95]
8. Press the door power unlock button.
*
[FV07350(ALL)02/95]
9. Press the door power lock button.
*
[FV07400(ALL)02/95]
10. The horn will chirp once if the Autolock
feature was deactivated, twice (one short
chirp followed by a long chirp) if the
Autolock feature was activated.
*
[FV07450(ALL)02/95]
11. Turn the ignition OFF.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

134
*
[FV07550(ALL)03/95]
Remote Entry System (If equipped)
*
[FV07600(ALL)02/95]
If your vehicle has the remote entry system, you
can lock or unlock the vehicle doors and liftgate
without using a key. The remote also has a
personal alarm feature. The buttons for the
system are located on the two hand held
transmitters that came with your vehicle.
*
[FV07650(ALL)06/95]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
*
[FV07700(ALL)02/95]
The remote entry features only operate with the
ignition in the OFF position.
[FV07751(ALL)02/95]
one third page art:0001000-A
Remote entry transmitter
%*
[FV07801(ALL)02/95]
Unlocking the doors with the remote entry
system
*
[FV07851(ALL)02/95]
To unlock the driver's door, press the UNLOCK
button.
[FV07901(ALL)12/95]
To unlock the other doors and liftgate (wagon),
press the UNLOCK button a second time, within
five seconds after the first UNLOCK.
[FV07910(ALL)04/95]
To open the trunk (sedan), press the TRUNK
button.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

135 [FV07920(ALL)04/95]
To unlock the liftgate (wagon), press the TRUNK
button. To open the liftgate, you must press the
liftgate release located above the license plate.
*
[FV07951(ALL)02/95]
Locking the doors with the remote entry
system
[FV08001(ALL)12/95]
To lock all the doors and liftgate (wagon), press
the LOCK button. This will also arm the factory
installed Anti-Theft system.
[FV08051(ALL)04/95]
If you would like a signal that the doors are
being locked, press the LOCK button again
within five seconds. If all doors and the liftgate
are completely closed, the doors and liftgate will
lock again, the horn will chirp and the external
lamps will flash. If a door or the liftgate is open
or ajar, the horn will give two short chirps
warning you that a door or the liftgate is open.
%*
[FV08100(ALL)02/95]
Remote entry personal alarm
*
[FV08151(ALL)02/95]
If you wish to activate the remote entry system
personal alarm, press the PANIC button. This
will honk the horn and flash the lights for
approximately 2 minutes 45 seconds. You can
turn it off by pressing the PANIC button again
from the transmitter or by turning the ignition
to the ON or ACCESSORY position.
*
[FV08200(ALL)02/95]
When you use the remote entry UNLOCK or
PANIC buttons, the illuminated entry system
turns on the vehicle's interior lights for 25
seconds. You can turn these lights off with the
remote entry LOCK button or by turning the
ignition to the ON or ACCESSORY position.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

136 [FV08251(ALL)04/95]THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
%*
[FV08300(ALL)04/95]
Arming and Disarming the Alarm System
with Remote Entry
*
[FV08351(ALL)04/95]
Your Remote Entry System will automatically
arm the factory installed Anti-Theft System when
the doors are locked, and automatically disarm it
when the doors are unlocked. The remote will
also reset the anti-theft alarm (when the driver's
door is unlocked or the PANIC button is pressed
on a programmed remote entry transmitter) if it
was triggered.
*
[FV08400(ALL)04/95]
The remote entry system may not arm and
disarm non-factory installed anti-theft systems.
%*
[FV08451(ALL)02/95]
Replacing the batteries
*
[FV08500(ALL)02/95]
The remote entry transmitter is powered by two
coin type three-volt lithium 2016
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

137
*
[FV08551(ALL)02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
*
[FV08600(ALL)02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
[FV08651(ALL)02/95]
quarter page art:0020790-A
Replacing the batteries
%*
[FV08700(ALL)02/95]
Replacing lost transmitters
*
[FV08751(ALL)06/95]
In the event a transmitter is lost, you should
take all your vehicle's transmitters to your
dealer to have the remote entry system
deprogrammed for the lost transmitter. This is
necessary to prevent further unauthorized use of
the lost transmitter.
*
[FV08800(ALL)02/95]
You can also purchase additional transmitters
(up to 4 transmitters can be used) from your
dealer. You will need to take all your
transmitters to the dealer so they can program
them to the remote entry system all at the same
time.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

138 [FV08851(ALL)04/95]Illuminated Entry System
[FV08900(ALL)10/95]
This system will provide illumination of the
vehicle's interior courtesy lamps when either
outside driver's door keypad is pressed or when
the remote entry system is used to unlock the
door or sound the personal alarm. The system
will automatically turn off after approximately
25 seconds or when the ignition is turned to the
RUN or ACC position.
*
[FV08951(ALL)09/95]
NOTE: The inside lights will not turn off if
you have turned them on with the
dimmer thumbwheel or if any door is
open.
[FV09551(ALL)04/95]
Perimeter Anti-Theft System (If equipped)
*
[FV09600(ALL)05/95]
When armed, this system helps protect your
vehicle against break-ins or theft.
%*
[FV09651(ALL)05/95]
When an unauthorized entry occurs, the system
triggers and will:
*
[FV09700(ALL)02/95]
q
flash the headlamps, parking lamps, and theft
indicator lamp
*
[FV09751(ALL)06/95]
q
honk the horn
%*
[FV09801(ALL)05/95]
Arming the system
*
[FV09851(ALL)04/95]
The system is ready to arm any time the ignition
switch is turned OFF and the alarm is not
triggered or sounding. Any of the following
events will prearm the anti-theft system:
[FV09900(ALL)04/95]
q
Pressing the remote entry transmitter LOCK
button to lock the doors (with the doors open
or closed).
[FV09951(ALL)10/95]
q
Pressing the 7/8 and 9/0 buttons on the
Keyless Entry Keypad at the same time to
lock the doors (with the doors open or
closed).
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

139
*
[FV10001(ALL)04/95]
q
Opening a door and pressing the power door
lock button to lock the doors.
[FV10050(ALL)04/95]
q
Turning the driver's or front passenger's door
key to the LOCK position to centrally lock all
doors (with the doors open or closed).
[FV10100(ALL)12/95]
If a door or liftgate (wagon) is open, the
anti-theft system is prearmed and waiting for all
doors to close. The THEFT inidcator in the
instrument panel will light continuously while
the system is prearmed.
[FV10201(ALL)12/95]
Once all doors and liftgate (wagon) are closed, if
any were open, the system will begin a 30
second countdown to become armed. The 30
second countdown allows people who may still
be in the vehicle time to exit without triggering
the alarm. The THEFT indicator will glow
steadily until the system is armed. When the
system is armed, the THEFT indicator will begin
to flash with short flashes every 2 seconds until
the system is triggered or disarmed.
[FV10251(ALL)12/95]
Remember, all doors and liftgate (wagon) must
be fully closed for the anti-theft system to arm.
If a door or liftgate (wagon) has been left open
or ajar, and you press the remote entry
transmitter twice to confirm the doors are
locked, two short horn chirps will warn you that
the anti-theft system is not arming.
*
[FV10301(ALL)05/95]
The anti-theft system is designed to work with
the factory installed remote entry system. It may
not work with other remote entry systems.
*
[FV10351(ALL)02/95]
When you get a single horn chirp by pressing
the LOCK button twice within 5 seconds on
your remote entry transmitter, you can be
assured that all doors are locked and the
anti-theft system is arming.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

140 [FV10400(ALL)04/95]Disarming the system
*
[FV10451(ALL)10/95]
An armed or activated system can be disarmed
if you:
*
[FV10501(ALL)04/95]
q
Unlock the doors by pressing the remote
entry transmitter UNLOCK button.
*
[FV10551(ALL)04/95]
q
Unlock the doors by entering the unlock code
on the keyless entry keypad.
[FV10601(ALL)12/95]
q
Unlock any door or the liftgate (wagon) with
a key.
*
[FV10651(ALL)02/95]
q
Turn ignition to the ON or ACC position.
*
[FV10700(ALL)04/95]
q
Pressing the remote entry PANIC button will
disarm the anti-theft system only when the
anti-theft alarm is triggered and sounding.
*
[FV10751(ALL)02/95]
When unlocking the vehicle with a key, turn the
key all the way to the end of its travel or the
system may not disarm.
[FV10800(ALL)09/95]
NOTE: the flashing lights and honking horn
will shut off automatically within 2
minutes 45 seconds after the system is
triggered. It will trigger again if
another intrusion occurs.
[FV10802(ALL)04/95]
Coded Key Anti-Theft System
[FV10806(ALL)10/95]
If your vehicle is equipped with the coded key
anti-theft system, you can only use an
electronically coded key to start the vehicle.
During each vehicle start sequence, the coded
key is ªreadº by the anti-theft system. If the
key's ID code matches that in the anti-theft
system, the vehicle is enabled to start. If the
key's ID code does not match the anti-theft
system, or if no coded key is detected, then the
vehicle is not able to start. Your vehicle was
equipped with two electronically coded keys.
The coded ignition key is larger than normal
due to the electronics located in the head of the
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

141
key. Additional spare keys, maximum of 14, can
be purchased either through your dealership or
selected retailers. Be sure to purchase only coded
keys with a Ford or Mercury logo on it to
ensure proper functionality. If both supplied
keys are lost or stolen or only one key has been
lost and you want to ensure that key will not
start the vehicle, the vehicle must be taken to
the dealership for re-initialization. (All keys must
be brought to the dealer, if any.)
[FV10808(ALL)04/95]
THEFT indicator
*
[FV10810(ALL)10/95]
The indicator provides system proveout and
operating status. The system activates the
indicator when the ignition switch is placed in
the ON or START position. This indicator helps
to determine possible fault conditions and/or
normal operating proveout. The system will
illuminate the indicator for two (2) seconds then
go out to acknowledge normal operating
conditions. If the indicator does not illuminate at
key ON or flashes, have the system serviced.
*
[FV10812(ALL)10/95]
Spare Key Programming Procedure
*
[FV10814(ALL)10/95]
Two electronically coded keys were supplied
with your vehicle, use one of these with the
procedure below:
*
[FV10816(ALL)10/95]
q
Using a coded key that you can start your
engine with, turn the ignition from the ON to
the OFF position.
*
[FV10820(ALL)10/95]
q
Within 15 seconds, insert a new key into the
ignition and turn it to ON or START. The
vehicle does not have to be started.
*
[FV10825(ALL)10/95]
If the key has been coded, the theft indicator
will illuminate for two seconds. The key can
then be used to start the vehicle.
*
[FV10826(ALL)10/95]
Repeat until all chosen keys have been coded
(max=16).
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com
