FORD TAURUS 1996 Owners Manual

203
*
[DR17000(ALL)09/95]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[DR17100(ALL)10/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
% [DR17350(ALL)02/95]
Anti-lock Brake System (ABS)
(If equipped)
*
[DR17450(ALL)05/95]
If your vehicle is equipped with the anti-lock
brake system (ABS), the wheels will not lock and
slide when you press down hard on the brake
pedal. The ABS automatically starts releasing
and reapplying the front brakes independently
and the rear brakes together whenever your
vehicle's wheels start to lock. When this
happens, you will feel the brake pedal pulsate.
This is an indication that the ABS is working
correctly and is normal.
*
[DR17500(ALL)05/95]
If the brake pedal is applied while the vehicle is
driven over uneven road surfaces, the ABS may
cycle and the driver may sense a pulsation in
the brake pedal, accompanied by a slight up and
down movement of the pedal height and a
clicking sound. This may also happen when
driving on an inclined surface such as a
driveway while making a sharp turn. This is a
normal condition.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

204
*
[DR17600(ALL)05/95]
Each time you turn the ignition key to the ON
position, the ABS will function through one test
cycle. When this happens, the ABS light will
come on for up to five seconds. If the light stays
on longer than five seconds, shut off the engine
and restart. If it remains on, it means the ABS is
disabled and should be serviced immediately to
restore the benefits of the anti-lock feature.
Normal braking is not affected unless the red
BRAKE system warning light is also lit.
*
[DR17650(ALL)05/95]
ABS has self-check capabilities. As described
above, the system turns on the ABS light each
time you start your engine. After the engine is
started and the ABS light turns off, the system
performs another test the first time the vehicle
reaches 4-9 mph (6-15 km/h). The system turns
on the ABS pump motor for approximately 1/2
second. At this time, a mechanical noise may be
heard. This is a normal part of the self-check
feature. If a malfunction is found during this
check the ABS light will come on.
[DR17675(ALL)02/95]
Vehicles with ABS are identified with a label on
the front door pillar.
*
[DR17700(ALL)08/95]
Ford Motor Company has not found any
negative effects of mobile radio transmitting
equipment installed on vehicles with the ABS
system providing that the radio is installed
according to the radio manufacturer's
instructions. However, if you have had a mobile
radio transmitter installed and the ABS light
comes on (at any time other than immediately
after turning the key to the ON position) have
your mobile radio dealer inspect the radio
installation. Also, if the ABS system is activated
other than during maximum braking, have your
mobile radio installation checked.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

205 %
*
[DR17800(ALL)03/95]
Parking Brake
*
[DR17900(ALL)01/95]
The parking brake should be used whenever
you park your vehicle.
[DR18000(ALL)01/95]
This brake is suspended just below the bottom
of the instrument panel to the left of the brake
pedal.
[DR18300(ALL)11/94]
one third page art:0001391-A
The parking brake and parking brake release
*
[DR18420(ALL)06/95]
RWARNING
Always set the parking brake fully and
make sure the gearshift is securely latched
in P (Park).
*
[DR18700(ALL)01/93]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
*
[DR18750(ALL)11/91]
RWARNING
To prevent personal injury, do not release
the parking brake while outside the
vehicle.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

206
*
[DR19000(ALL)06/95]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
*
[DR19050(ALL)03/95]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
%
*
[DR19100(ALL)01/95]
Driving Under Special Conditions
%*
[DR19200(ALL)01/95]
Tips for Safe Driving
*
[DR19300(ALL)07/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR19400(ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
%*
[DR19750(ALL)01/95]
Driving in Bad Weather
%*
[DR19800(ALL)01/95]
Slippery roads
*
[DR19900(ALL)03/95]
On some slippery road surfaces, front-wheel
drive may provide better acceleration than
rear-wheel drive. However, this does not mean
that your vehicle can stop any faster or any
better than a vehicle with rear-wheel drive.
Exercise the same caution while driving on
slippery roads with your front-wheel drive
vehicle as you would with a rear-wheel drive
vehicle.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

207
*
[DR20100(ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
*
[DR20200(ALL)01/95]
q
Drive slower than you normally would.
*
[DR20400(ALL)01/95]
q
Give your vehicle more distance to stop.
*
[DR20500(ALL)03/92]
q
Pump the brake pedal steadily and evenly to
avoid locking your wheels. (Does not apply
to vehicles with anti-lock brakes.)
*
[DR20600(ALL)02/93]
q
Consider using one of the lower gears.
*
[DR20750(ALL)07/95]
RWARNING
To avoid skidding and losing control on
slippery roads, do not downshift into 1
(First) when you are moving faster than
20 mph (30 km/h).
*
[DR20775(ALL)03/95]
RWARNING
If your vehicle has speed control, do not
use it on slippery roads. You could lose
control of your vehicle and could injure
someone.
*
[DR20850(ALL)01/95]
If your vehicle gets stuck (for example, in mud
or snow), you may try to ªrockº it out of the
spot. Shift, in a steady rhythm, between forward
and reverse gears. While in each gear, press
lightly on the accelerator and release.
*
[DR20900(ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(55 km/h). The tires may fail and injure a
passenger or bystander.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

208
*
[DR21000(ALL)03/95]
By moving the vehicle backward and forward,
you may gain enough momentum to move out
of the spot. Do not rock the vehicle for more
than a few minutes. This may overheat the
engine, damage the transaxle, or damage the
tires. If you are still stuck after a minute or two
of rocking, call for a tow truck.
%*
[DR21200(ALL)01/95]
High water
*
[DR21300(ALL)01/95]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel rims.
*
[DR21400(ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[DR21500(ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
%
*
[DR21600(ALL)03/95]
Driving With a Heavy Load
*
[DR21700(ALL)01/95]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
%*
[DR21800(ALL)01/95]
You can find your vehicle's GVWR and GAWR
on the Safety Compliance Certification Label on
the left front door lock facing or on the door
latch post pillar.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

209
*
[DR21900(ALL)08/95]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limits than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
*
[DR22000(ALL)02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
%*
[DR22005(ALL)01/95]
Limiting Your Vehicle's Load
*
[DR22010(ALL)01/95]
The load that you add to your vehicle must not
exceed the maximum load stated on the Safety
Compliance Certification Decal attached to the
left front door pillar.
*
[DR22015(ALL)01/95]
To figure the weight of your vehicle's load, add
the weights of:
*
[DR22020(ALL)01/95]
q
the driver and passengers
*
[DR22025(ALL)01/95]
q
luggage and any other items that you put in
your vehicle
*
[DR22030(ALL)01/95]
q
the tongue load of the loaded trailer
*
[DR22035(ALL)01/95]
q
the weight of any equipment that has been
added to your vehicle since it was delivered
to your dealer
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

210
*
[DR22040(ALL)01/95]
If you do not know the actual weights of these
items, use the following procedure to figure the
weight of a load:
*
[DR22045(ALL)01/95]
1. Weigh your vehicle without the driver,
passengers and luggage. You might take
your vehicle to a shipping company or an
inspection station for trucks.
*
[DR22050(ALL)01/95]
2. Then weigh your vehicle with the driver,
passengers and luggage.
*
[DR22055(ALL)01/95]
3. Subtract the first reading from the second to
figure the total weight of the load.
*
[DR22060(ALL)01/95]
After determining this load, you must also make
sure that the total weight of your vehicle, plus
the load it carries, is less than its GVWR. Also,
make sure that the weight your vehicle carries
over each axle is less than the GAWR for the
respective axle.
*
[DR22065(ALL)01/95]
You can find the GVWR and GAWR on the
Safety Compliance Certification Label on the left
front door lock facing or the door latch post
pillar.
*
[DR22070(ALL)01/95]
If your vehicle exceeds the GVWR, remove cargo
from your vehicle accordingly. If your vehicle
exceeds the GAWR for either axle, shift the load
or remove cargo accordingly.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

211
%*
[DR22100(ALL)04/95]
Trailer Towing
[DR22125(ALL)04/95]
Your vehicle is classified as a light duty towing
vehicle. The amount of weight that you can
safely tow depends on the type of engine in
your vehicle. See the following charts:
[DR22150(ALL)04/95]
sixteen pica chart:0000489-H[DR22190(ALL)10/95]
fourteen pica chart:0001436-CFile:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

212
*
[DR22200(ALL)01/95]
Your vehicle does not come from the factory
fully equipped to tow. No towing packages are
available through Ford or Lincoln/Mercury
dealers.
*
[DR22300(ALL)01/95]
Because towing a trailer puts extra strain on
your vehicle, you must follow certain
precautions for your safety and the good of your
vehicle:
*
[DR25800(ALL)11/92]
q
Stay within the load limits when you tow.
(SeeKnowing Your Vehicle's Load Limits.)
*
[DR25900(ALL)01/95]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[DR26000(ALL)01/95]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
*
[DR26100(ALL)01/95]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
*
[DR26150(ALL)05/94]
Do not tow a trailer until your vehicle has been
driven at least 500 miles (800 km).
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com
