STEERING
Your vehicle is equipped with power steering. Power steering uses energy
from the engine to help steer the vehicle.
To prevent damage to the power steering pump:
²Never hold the steering wheel to the extreme right or the extreme left
for more than a few seconds when the engine is running.
²Do not operate the vehicle with a low power steering pump fluid level
(below the MIN mark on the reservoir).
If the power steering system breaks down (or if the engine is turned
off), you can steer the vehicle manually, but it takes more effort.
If the steering wanders or pulls, the condition could be caused by any of
the following:
²underinflated tire(s) on any wheel(s)
²uneven vehicle loading
²high crown in center of road
²high crosswinds
²wheels out of alignment
²loose or worn suspension components
Speed sensitive steering
The steering in your vehicle is speed sensitive. At high speeds, steering
assist will decrease to improve steering feel. At lower speeds,
maneuverability will be increased.
If the amount of effort required to steer your vehicle changes while
driving at a constant vehicle speed, have the power steering system
checked by your dealer or a qualified service technician.
AUTOMATIC TRANSMISSION OPERATION
Brake-shift interlock
This vehicle is equipped with a brake-shift interlock feature that prevents
the gearshift lever from being moved from P (Park) when the ignition is
in the RUN position unless brake pedal is depressed.
Driving
140

TRANSMISSION FLUID
Checking automatic transmission fluid
The 5R55N transmission does not have a transmission fluid dipstick.
Refer to your scheduled maintenance guide for scheduled intervals for
fluid checks and changes. Your transmission does not consume fluid.
However, the fluid level should be checked if the transmission is not
working properly, i.e., if the transmission slips or shifts slowly or if you
notice some sign of fluid leakage.
Transmission fluid should be checked and, if required, fluid
should be added by a qualified technician.
Before adding any fluid, make sure the correct type is used. Use only
MERCONtV automatic transmission fluid. The type of fluid used is
indicated on the transmission fluid pan, extension housing and also in
theLubricant specificationssection in this chapter.
Use of a non-approved automatic transmission fluid may cause
internal transmission component damage and void the warranty.
AIR FILTER MAINTENANCE
Refer to the scheduled maintenance guide for the appropriate intervals
for changing the air filter element.
When changing the air filter element, use only the Motorcraft air filter
element listed. Refer toMotorcraft Part Numbers.
Note:Do not start your engine with the air cleaner removed and do not
remove it while the engine is running.
Maintenance and specifications
221

Fluid Ford Part
NameApplication Capacity
Windshield
washer fluidUltra-Clear
Windshield
Washer
ConcentrateAll Fill to line on
reservoir
1Use only brake fluids certified to meet Ford specifications. Refer to
Lubricant Specificationsin this chapter. DOT 3 fluid is recommended.
However, if DOT 3 is not available, DOT 4 fluid can be used.
2Add the coolant type originally equipped in your vehicle.
3Your vehicle's rear axle is filled with a synthetic rear axle lubricant and
is considered lubricated for life. These lubricants do not need to be
checked or changed unless a leak is suspected, service is required or the
axle assembly has been submerged in water. The axle lubricant should
be changed any time the rear axle has been submerged in water. Fill 6
mm to 14 mm (1/4 inch to 9/16 inch) below bottom of fill hole.
4Ensure the correct automatic transmission fluid is used. MERCONtand
MERCONtV are not interchangeable. DO NOT MIX MERCONtand
MERCONtV. Refer to the scheduled maintenance guide to determine
the correct service interval.
5Approximate dry capacity, includes cooler and tubes. Fluid level should
be checked by a qualified service technician.
LUBRICANT SPECIFICATIONS
Item Ford part
nameFord part
numberFord
specification
Brake fluid High
Performance
DOT 3 Motor
Vehicle Brake
Fluid
1
PM-1 ESA-M6C25-A
and DOT 3
Door
weatherstripsSilicone
LubricantF7AZ-19G208-BA
and
F5AZ-19553-AAESR-M13P4-A
Maintenance and specifications
229

A
Accessory delay ..........................64
Air bag supplemental restraint
system ................................109, 119
and child safety seats ............110
description ......................109, 119
disposal ....................................122
driver air bag ..................111, 120
indicator light ...........12, 113, 121
operation .........................111, 120
passenger air bag ...........111, 120
passenger deactivation
switch ......................................114
side air bag ..............................119
Air cleaner filter .......221±222, 227
Air conditioning ..........................35
Air filter, cabin ............................48
Antifreeze
(see Engine coolant) ................202
Anti-lock brake system
(see Brakes) ......................136±137
Anti-theft system ........................94
arming the system ....................94
disarming a triggered system ..94
Automatic transmission
driving an automatic
overdrive .................................141
fluid, adding ............................221
fluid, checking ........................221
fluid, refill capacities ..............228
fluid, specification ..................231
Auxiliary power point .................63
Axle
lubricant specifications ..229, 231
refill capacities ........................228B
Battery .......................................200
acid, treating emergencies .....200
charging system warning
light ............................................13
jumping a disabled battery ....169
maintenance-free ....................200
replacement, specifications ...227
servicing ..................................200
Belt minder ...............................104
Brakes ........................................136
anti-lock ...........................136±137
anti-lock brake system
(ABS) warning light .........12, 137
brake warning light ..................12
fluid, checking and adding ....220
fluid, refill capacities ..............228
fluid, specifications .........229, 231
lubricant specifications ..229, 231
parking ....................................138
shift interlock ..........................140
Break-in period .............................6
C
Capacities for refilling fluids ....228
Cassette tape player ...................19
Certification Label ....................233
Child safety restraints ..............122
child safety belts ....................122
Child safety seats ......................123
attaching with tether straps ..127
in front seat ............................125
in rear seat ..............................125
LATCH .....................................130
Cleaning your vehicle
engine compartment ..............188
exterior ....................................192
Index
237

instrument cluster lens ..........191
instrument panel ....................191
interior .....................................191
plastic parts ....................189±190
safety belts ..............................192
washing ....................................187
waxing .....................................187
wheels ......................................188
windows ..................................192
wiper blades ............................190
Clock ............................................33
Console ........................................83
Controls
power seat .................................97
steering column ........................70
Convertible ..................................72
cleaning .....................................76
installation of the boot .............73
lowering the convertible top ...72
raising the convertible top ......74
Coolant
checking and adding ..............202
coolant temperature light ........13
refill capacities ................206, 228
specifications ..................229, 231
Cruise control (see Speed
control) ........................................66
Customer Assistance ................153
Ford accessories for your
vehicle .....................................193
Ford Extended Service
Plan ..........................................179
Getting assistance outside
the U.S. and Canada ..............183
Getting roadside assistance ...153
Getting the service
you need .................................177
Ordering additional owner's
literature .................................184The Dispute Settlement
Board .......................................180
Utilizing the
Mediation/Arbitration
Program ...................................183
D
Daytime running lamps
(see Lamps) ................................49
Defrost
rear window ..............................48
Dipstick
automatic
transmission fluid ...................221
engine oil .................................197
Doors
door ajar warning .....................15
lubricant specifications ..........229
Driving under special
conditions
through water .........................146
Dual automatic temperature
control (DATC) ...........................35
E
Emergencies, roadside
jump-starting ..........................169
Emission control system ..........217
Engine ........................................231
check engine/service engine
soon light ..................................10
cleaning ...................................188
coolant .....................................202
fail-safe coolant ......................207
idle speed control ...................200
lubrication
specifications ..................229, 231
Index
238

turning on and off ....................49
warning chime ..........................15
Heating ........................................35
Hood ..........................................196
I
Ignition ...............................132, 231
Infant seats
(see Safety seats) .....................123
Inspection/maintenance (I/M)
testing ........................................218
Instrument panel
cleaning ...................................191
cluster ................................10, 191
lighting up panel and
interior .......................................50
J
Jack ............................................164
positioning ...............................164
storage .....................................164
Jump-starting your vehicle ......169
K
Keyless entry system
autolock .....................................90
Keys .......................................91, 93
key in ignition chime ...............15
positions of the ignition .........132
L
Lamps
autolamp system .......................49
bulb replacement
specifications chart ..................53cargo lamps ...............................50
daytime running light ...............49
headlamps .................................49
headlamps, flash to pass ..........50
instrument panel, dimming .....50
interior lamps .....................52, 54
replacing bulbs ....... 53±54, 56±59
Lane change indicator
(see Turn signal) ........................52
Lights, warning and indicator ....10
air bag ........................................12
anti-lock brakes (ABS) ....12, 137
brake ..........................................12
bulb warning .............................15
charging system ........................13
check engine .............................10
cruise indicator .........................14
door ajar ....................................15
fuel cap light .............................11
high beam .................................15
low coolant ................................13
low fuel ......................................14
low washer fluid .......................14
oil pressure ...............................13
safety belt .................................13
speed control ............................70
traction control active ..............14
transmission PRNDL
indicator ....................................12
turn signal indicator .................14
Load limits .................................146
GAWR ......................................146
GVWR ......................................146
trailer towing ..........................146
Locks
autolock .....................................90
doors ..........................................84
Lubricant specifications ...229, 231
Lug nuts, anti-theft ...................169
Index
240

Lumbar support, seats ...............96
M
Manual transmission
fluid capacities ........................228
lubricant specifications ..........231
Master lighting switch ................49
Mirrors
side view mirrors (power) .......65
Motorcraft parts ................214, 227
O
Octane rating ............................212
Odometer .....................................17
Oil (see Engine oil) ..................197
P
Panic alarm feature, remote
entry system ................................88
Parking brake ............................138
Parts (see Motorcraft parts) ....227
Power distribution box
(see Fuses) .......................159, 162
Power door locks ..................84, 90
Power steering ..........................140
fluid, checking and adding ....219
fluid, refill capacity ................228
fluid, specifications .........229, 231
R
Rear window defroster ...............48
Relays ........................................156
Remote entry system ...........86, 88illuminated entry ......................89
locking/unlocking doors .....84, 87
opening the trunk .....................87
panic alarm ...............................88
replacement/additional
transmitters ...............................89
replacing the batteries .............88
S
Safety belts (see Safety
restraints) ......................15, 99±103
Safety defects, reporting ..........186
Safety restraints ..................99±103
belt minder .............................104
cleaning the safety
belts .................................108, 192
extension assembly ................108
for adults .........................100±103
for children .............................122
warning light and
chime ...........................13, 15, 104
Safety seats for children ..........123
Seat belts
(see Safety restraints) ...............99
Seats ............................................95
child safety seats ....................123
cleaning ...................................191
SecuriLock passive anti-theft
system ....................................91, 93
Servicing your vehicle ..............195
Spark plugs,
specifications .....................227, 231
Specification chart,
lubricants ...........................229, 231
Speed control ..............................66
Speedometer ...............................17
Index
241

Starting your vehicle ........132±134
jump starting ..........................169
Steering
speed sensitive .......................140
Steering wheel
controls ......................................70
tilting .........................................62
T
Tachometer .................................18
Tires ...........................164, 223±225
changing ..........................164±165
checking the pressure ............225
replacing ..................................226
rotating ....................................225
snow tires and chains ............227
tire grades ...............................224
treadwear ................................224
Towing .......................................148
recreational towing .................152
trailer towing ..........................148
wrecker ....................................176
Traction control ........................138
active light ................................14
Transmission .......................12, 140
fluid, checking and adding
(automatic) .............................221
fluid, refill capacities ..............228
lubricant specifications ..229, 231manual operation ......................12
Trip odometer .............................18
Trunk ...........................................84
remote release ....................65, 87
Turn signal ......................14, 16, 52
V
Vehicle dimensions ...................231
Vehicle Identification Number
(VIN) ..........................................233
Vehicle loading ..........................146
Ventilating your vehicle ...........136
W
Warning chimes .....................15±16
Warning lights (see Lights) .......10
Water, Driving through .............146
Windows
power .........................................63
Windshield washer fluid and
wipers
checking and cleaning ........60±61
operation ...................................60
replacing wiper blades .............61
Wrecker towing .........................176
Index
242
