Table of ContentsIntroduction..................... 1
Instrumentation.................... 7
Audio........................ 41
Controls and Features................. 81
Seating and Safety Restraints............. 147
Starting...................... 217
Driving...................... 223
Roadside Emergencies................ 247
Maintenance and Care................ 279
Capacities and Specifications............. 333
Reporting Safety Defects............... 339
Customer Assistance................ 341
Accessories..................... 351
Quick Index.................... 357
Index........................ 367
Service Station Information............. 388
File:01wnpis.ex
Update:Thu Jul 18 10:53:43 1996
Page 4 of 385
1
Introduction
*
[II00200(ALL)01/96]
Ford's Commitment to You
*
[II00300(ALL)01/96]
At Ford Motor Company, excellence is the continuous
commitment to achieve the best result possible. It is dedication
to learning what you want, determination to develop the right
concept, and execution of that concept with care, precision, and
attention to detail. In short, excellence means being the standard
by which others are judged.
*
[II00400(ALL)01/96]
Our Guiding Principles
*
[II00500(ALL)01/96]
n
Quality comes first.For your satisfaction, the quality of our
products and services must be our number one priority.
*
[II00600(ALL)01/96]
n
You are the focus of everything we do.Our work must be
done with you in mind, providing better products and
services than our competition.
*
[II00700(ALL)01/96]
n
Continuous improvement is essential to our success.We
must strive for excellence in everything we do: in our
products Ð in their safety and value Ð and in our services,
our human relations, our competitiveness, and our
profitability.
*
[II00800(ALL)01/96]
n
Employee involvement is our way of life. We are a team.
We must treat one another with trust and respect.
*
[II00900(ALL)01/96]
n
Dealers and suppliers are our partners.We must maintain
mutually beneficial relationships with dealers, suppliers, and
our other business associates.
*
[II01000(ALL)01/96]
n
Integrity is never compromised.Our conduct worldwide
must be pursued in a manner that is socially responsible and
commands respect for its integrity and for its positive
contributions to society.
File:02wniis.ex
Update:Mon Jul 8 14:10:59 1996
Page 5 of 385
2
*
[II01100(ALL)03/96]
Things to Know About Using This Guide
*
[II01200(ALL)03/96]
Congratulations on the purchase of your new vehicle. This
guide has information about the equipment and the options for
your new vehicle. You may not have bought all of the options
available to you. If you do not know which information applies
to your vehicle, talk to your dealer.
*
[II01300(ALL)03/96]
This guide describes equipment and gives specifications for
equipment that was in effect when this guide was approved for
printing. Ford may discontinue models or change specifications
or design without any notice and without incurring obligation.
*
[II01400(ALL)03/96]
NOTES and WARNINGS
*
[II01500(ALL)02/96]
NOTESgive you additional information about the subject
matter you are referencing.
*
[II01600(ALL)01/96]
WARNINGSremind you to be especially careful in those areas
where carelessness can cause damage to your vehicle or
personal injury to yourself, your passengers or other people.
Please read allWARNINGScarefully.
*
[II01700(ALL)01/96]
RWARNING
*
[II01800(ALL)01/96]
Finding Information in This Guide
*
[II01900(ALL)12/95]
After you have read this guide once, you will probably return
to it when you have a specific question or need additional
information. To help you find specific information quickly, you
can use the Quick Index or the Index.
*
[II02000(ALL)03/96]
TheQuick Indexat the end of the book provides a page
number following each item which indicates where detailed
information can be found.
File:02wniis.ex
Update:Mon Jul 8 14:10:59 1996
Page 6 of 385
Introduction
3
*
[II02100(ALL)01/96]
To use theIndex, turn to the back of the book and search in the
alphabetical listing for the word that best describes the
information you need. If the word you chose is not listed, think
of other related words and look them up. We have designed the
Index so that you can find information under a technical term.
%*
[II02200(ALL)01/96]
Canadian Owners Ð French Version
*
[II02300(ALL)01/96]
French Owner Guides can be obtained from your dealer or by
writing to Ford Motor Company of Canada, Limited, Service
Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y
4G3.
%*
[II02400(ALL)05/96]
Your Maintenance Schedule Booklet
*
[II02500(ALL)03/96]
TheMaintenance Schedulebooklet lists the services that are most
important for keeping your vehicle in good condition. A record
log is also provided to help you keep track of all services
performed.
%*
[II02600(ALL)01/96]
About the Warranties
*
[II02700(ALL)01/96]
Your vehicle is covered by three types of warranties:Basic
Vehicle Warranty,Extended Warrantieson certain parts, and
Emissions Warranties.
%*
[II02800(ALL)01/96]
Read yourWarranty Information Bookletcarefully to find out
about your vehicle's warranties and your basic rights and
responsibilities.
*
[II02900(ALL)03/96]
If you lose yourWarranty Information Booklet,you can get a new
one free of charge. Contact any Ford or Lincoln-Mercury dealer,
or refer to the addresses and phone numbers on the first page
of this Owner's Guide.
File:02wniis.ex
Update:Mon Jul 8 14:10:59 1996
Page 7 of 385
4
%*
[II03000(ALL)05/96]
Ford Extended Service Plan
*
[II03100(ALL)05/96]
If you bought your vehicle in the U.S., you can buy a Ford
Extended Service Plan for your vehicle. This optional contract
provides service protection for a longer period of time than the
basic warranty that comes with your vehicle.
*
[II03200(ALL)05/96]
You do not have to buy this option when you buy your vehicle.
However, your option to purchase the Ford Extended Service
Plan runs out after 18 months or 18,000 miles. See your dealer
for more details about the Ford Extended Service Plan.
*
[II03300(ALL)05/96]
If you purchased a Canadian vehicle and did not take
advantage of the Ford Extended Service Plan at the time of
purchase, you may still be eligible. See your dealer for the
details.
%*
[II03400(ALL)01/96]
Breaking Your Vehicle In
*
[II03500(ALL)01/96]
Your new vehicle goes through an adjustment or break-in
period during the first 1,000 miles (1,600 km) that you drive it.
During the break-in period, you need to pay careful attention to
how you drive your vehicle.
%*
[II03600(ALL)01/96]
n
Avoid sudden stops.Because your vehicle has new brake
linings, you should take these steps:
*
[II03700(ALL)01/96]
Ð Watch traffic carefully so that you can anticipate when to
stop.
*
[II03800(ALL)01/96]
Ð Begin braking well in advance.
*
[II03900(ALL)01/96]
Ð Apply the brakes gradually.
*
[II04000(ALL)01/96]
The break-in period for new brake linings lasts for 100 miles
(160 km) of city driving or 1,000 miles (1,600 km) of
highway driving.
File:02wniis.ex
Update:Mon Jul 8 14:10:59 1996
Page 8 of 385
Introduction
5
*
[II04100(ALL)05/96]
n
Wheel lug nuts must be retightened to proper torque
specifications at 500 miles/800 km of new vehicle operation.
Proper torque specifications are provided in this guide. Also
retighten to proper torque specifications at 500 miles/800 km
after any wheel change or any other time the wheel lug nuts
have been loosened.
%*
[II04200(ALL)03/96]
n
Use only the type of engine oil that Ford recommends.See
Engine oil recommendationsin the Index. Do not use special
ªbreak-inº oils.
*
[II04300(ALL)03/96]
Your vehicle is equipped with an Electronic Powertrain Control
Module that limits engine and/or vehicle speeds with a cut-out
mode to promote durability.
File:02wniis.ex
Update:Mon Jul 8 14:10:59 1996
Page 9 of 385
7
Instrumentation
%*
[IS00200(ALL)01/96]
The instrument panel (dashboard) on your vehicle is divided
into several different sections. The illustrations on the following
pages show the major parts of the instrument panel that are
described in this chapter. Some items shown may not be on all
vehicles.
*
[IS00300(ALL)05/96]
Your vehicle has one of the following clusters:
[IS00400(ALL)12/95]
n
Mechanical Cluster
[IS00500(ALL)12/95]
n
Mechanical Cluster with a tachometer
[IS00600(ALL)12/95]
n
Electronic Cluster
*
[IS00700(ALL)01/96]
If you are not sure which cluster your vehicle has, check the
diagrams on the following pages.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996
Page 10 of 385
8
[IS00800(ALL)01/96]
33-1/2 pica art:0050063-E
The instrument panel
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996
