Page 41 of 385
Instrumentation
39
% [IS20400(ALL)01/96]
Anti-Theft Active Indicator Light
[IS20500(ALL)07/96]
This indicator is used in the optional Anti-Theft System. See
ªAnti-Theft Systemº in theControls and Featureschapter of this
Owner Guide.
[IS20600(ALL)01/96]
6 pica art:0050123-B
The anti-theft active indicator light
[IS20700(ALL)01/96]
Air Suspension Warning Light
[IS20800(ALL)01/96]
6 pica art:0050227-A
The air suspension warning light
[IS20900(ALL)01/96]
The warning light for the Air Suspension indicates one of two
things:
[IS21000(ALL)01/96]1.
The service switch (located in the jack storage area) is in the
ªoffº position.
[IS21100(ALL)01/96]2.
A system malfunction has occurred electronically disabling
Air Suspension function.
[IS21200(ALL)01/96]
NOTE: If the switch is returned to or in the ªONº position
and the light does not go out after recycling the
ignition switch OFF/ON, the Air Suspension should
be checked by a qualified service technician.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996
Page 42 of 385
41
Electronic Sound Systems
[AS01100(ALL)04/95]
33-1/2 pica
art:0060674-B
The Compact Disc Radio
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 43 of 385
42
%*
[AS01175(ALL)10/95]
Compact Disc Radio
*
[AS01250(ALL)10/95]
The Compact Disc Radio combines the Electronic Stereo Radio
with the Ford Compact Disc Player.
*
[AS01300(ALL)08/95]
Using the Controls on Your New Radio/CD Player
*
[AS01400(ALL)04/92]
Most of the features of this unit work for both radio and CD
operation, depending on which mode the unit is in. Also, some
of the buttons control several different functions, so be sure to
read all of the operating instructions carefully.
*
[AS01500(ALL)03/96]
How to turn the radio on and off
*
[AS01600(ALL)10/95]
Press the ªPOWERº button to turn the radio on. Press it again
to turn it off.
*
[AS01625(ALL)03/96]
How to adjust the volume
*
[AS01650(ALL)03/96]
Press the (R/S) side of the ªVOLº button to increase/decrease
the volume. Bars illuminate in the display to show the relative
volume level.
*
[AS01675(ALL)02/96]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off, the volume will remain
in the position it was set at when radio power was
switched off.
*
[AS01700(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS01800(ALL)10/95]
Push the ªAM/FMº button to select the desired frequency band.
When in the radio mode, pushing the button more than once
will alternate between AM, FM1 and FM2. These functions are
used with the station memory buttons described underHow to
tune radio stations.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 44 of 385
Electronic Sound Systems
43
%*
[AS01900(ALL)03/96]
How to tune radio stations
*
[AS02000(ALL)10/95]
There are four ways for you to tune in a particular station. You
can manually locate the station using the ªSCAN/TUNEº
button, ªSEEKº the station, ªSCANº to the station or select the
station by using the memory buttons, which you can set to any
desired frequency. These four methods are described below.
*
[AS02100(ALL)10/95]
n
Using the ªSCAN/TUNEº button to manually tune
*
[AS02200(ALL)04/96]
You can change the frequency up or down one increment at
a time (FM changes in increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the ªSCAN/TUNEº
button twice (display shows ªTUNEº), then Ðwithin
approximately five secondsÐpressing and releasing either
the top
aor bottom
bhalf of the ªSEEKº button. To
change frequencies quickly, press andhold downeither the
top or bottom half of the ªSEEKº button. While you are
manually tuning, the display will show a blinking ªMº.
*
[AS02300(ALL)03/96]
Manual tuning adjusts your radio to any allowable broadcast
frequency, whether or not a station is present on that
frequency. (SeeAll About Radio Frequenciesin this section.)
*
[AS02400(ALL)04/96]
n
Using the ªSEEKº function
*
[AS02500(ALL)04/96]
This feature on your radio allows you to automatically select
listenable stations up or down the frequency band. Press the
top
ahalf of the ªSEEKº button to select the next listenable
station up the frequency band. Press the bottom
bhalf of
the button to select the next listenable station down the
frequency band. By pressing and holding the button,
listenable stations can be passed over to reach the desired
station.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 45 of 385
44
*
[AS02600(ALL)02/96]
n
Using the ªSCAN/TUNEº button to scan radio stations
*
[AS02700(ALL)04/96]
Pressing the ªSCAN/TUNEº button once enters the scan
mode (display will indicate ªSCNº). Pushing the top
ahalf
of the ªSEEKº button will begin the scan mode up the
frequency band, stopping on each listenable station for
approximately five seconds. Pushing the bottom
bhalf of
the ªSEEKº button will begin the scan mode down the
frequency band, again stopping on each listenable station for
approximately five seconds.
*
[AS02800(ALL)03/96]
To stop the scan mode on the presently sampled station,
press the ªSCAN/TUNEº button again.
*
[AS03000(ALL)03/96]
n
Setting the station MEMORY PRESET buttons
%*
[AS03100(ALL)06/96]
Your radio is equipped with 5 station memory buttons.
These buttons can be used to select up to 5 preset AM
stations and 10 FM stations (5 in FM1 and 5 in FM2). Follow
the easy steps below to set these buttons to the desired
frequencies.
*
[AS03200(ALL)06/96]1.
Select a band, then select a frequency.
*
[AS03400(ALL)06/96]2.
Press one of the memory preset buttons and hold the button
until the sound returns. That station is now held in memory
on that button.
*
[AS03500(ALL)06/96]3.
Follow the two steps above for each station memory preset
button you want to set.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 46 of 385
Electronic Sound Systems
45
[AS03600(ALL)04/92]
Using the Automatic Memory Load and Automatic
Memory Store features
[AS03700(ALL)09/95]
NOTE: If no stations are in memory presets, you can activate
the feature by pressing and holding the ªAUTO
PRESETº button for approximately three seconds.
Auto Memory Load sets all memory buttons in AM,
FM1 and FM2 sequentially by seeking out the first
five strong stations for the respective band and storing
them in memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM band.)
*
[AS03800(ALL)05/96]
With Auto Memory Store, you can continually set strong
stations into your memory buttons without losing your existing
memory presets, which is especially helpful while traveling.
Your radio will automatically set your memory buttons to the
strong local stations so you don't have to continually manually
tune to existing stations.
*
[AS03900(ALL)02/96]
Activate Auto Memory Store by pushing the ªAUTO PRESETº
button once. Your radio will set the first five strong stations of
the band you are in (AM, FM1 or FM2) into the memory
buttons. The display will show ªAUTO,º then run through the
frequencies, stopping momentarily on the stations being set into
the memory buttons. The radio is now in the ªAUTOº mode
and the display will show ªAUTOº each time a preset is
activated.
*
[AS04000(ALL)10/95]
NOTE: If there are fewer than five strong stations in the
frequency band, the remaining unfilled buttons will
store the last strong station detected on the band.
*
[AS04100(ALL)03/96]
After all stations have been filled, the radio will begin playing
the station stored on memory button 1.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 47 of 385
46
*
[AS04200(ALL)02/96]
To deactivate the Auto Memory Store mode and return to the
manually-set memory button stations (or those stations set using
Auto Memory Load), simply push the ªAUTO PRESETº button.
Display will show ªAUTOº then ªOFF.º The next time Auto
Memory Store is activated on that band, the radio will store the
next set of five strong stations.
*
[AS04400(ALL)08/95]
Using the ªAUDIOº button to adjust the tone balance
and speaker output
*
[AS04500(ALL)02/96]
n
Increasing or decreasing bass response
*
[AS04600(ALL)08/95]
Push the ªAUDIOº button repeatedly until the display reads
ªBASS.º Push the ª+º side of the ªVOLº button to increase
bass (more ªlowsº), and push the ª-º side to decrease bass
(less ªlowsº).
*
[AS04700(ALL)02/96]
n
Increasing or decreasing treble response
*
[AS04800(ALL)08/95]
Push the ªAUDIOº button repeatedly until the display reads
ªTREB.º Push the ª+º side of the ªVOLº button to increase
treble (more ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
*
[AS05100(ALL)02/96]
n
Adjusting speaker balance
*
[AS05200(ALL)08/95]
Balance control allows you to adjust the sound distribution
between the right and left speakers. Push the ªAUDIOº
button repeatedly until the display reads ªBAL.º Push the
ª+º side of the ªVOLº button to shift the sound to the right
speakers, and push the ª-º side to shift the sound to the left
speakers.
*
[AS05300(ALL)04/96]
n
Adjusting speaker fader
*
[AS05400(ALL)08/95]
Fade control allows you to adjust the sound distribution
between the front and rear speakers. Push the ªAUDIOº
button repeatedly until the display reads ªFADE.º Push the
ª+º side of the ªVOLº button to shift the sound to the front
speakers, and push the ª-º side to shift the sound to the rear
speakers.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 48 of 385
Electronic Sound Systems
47
[AS05500(ALL)09/95]
NOTE: Illuminated bars in the display show relative levels of
bass and treble and positions of speaker balance and
fader functions for five seconds after adjustments are
made, then revert to volume level set.
%*
[AS05600(ALL)08/95]
Clock operation
*
[AS05700(ALL)08/95]
When in the radio mode, push the ªCLOCKº button to switch
from radio frequency to clock. Only the clock numerals will be
displayed in the clock mode Ð there is no A.M./P.M.
indication. When in the clock mode, the time will be displayed
until the button is pushed again. However, if you retune the
radio while it is in the clock mode, the new radio frequency
will be displayed for approximately ten seconds and then
change back to clock.
*
[AS05800(ALL)08/95]
When in the CD mode, push the ªCLOCKº button to change
the display from elapsed time mode to track number mode to
clock mode. If the CD track selection is changed when you are
in the clock or elapsed time mode, the new track number will
be displayed for approximately ten seconds and then revert
back to the previous mode.
*
[AS05900(ALL)08/95]
To set the clock, simultaneously press the ªCLOCKº button and
either the bottom (
b) half of the ªSEEKº button to set hours,
or the top (
a) half of the ªSEEKº button to set minutes.
[AS06000(ALL)04/96]
NOTE: The clock can be set with the radio and/or ignition on
or off.
%*
[AS07000(ALL)10/95]
Using the Controls on Your New Compact Disc Player
*
[AS07100(ALL)03/96]
Your new Ford Compact Disc Player is capable of playing 12
cmor8 cm discs, without an adapter. The player operates when
the power is on and a disc is inserted (label side up). Handle
the disc by its edge only. (Be sure to read and follow all of the
care and cleaning instructions underHow To Take Care of and
Clean Your CD Player and Discs.)
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 49 of 385
48
*
[AS07200(ALL)09/95]
NOTE: If after you insert a disc, the disc is ejected and
ªERRORº begins scrolling in the display, remove the
disc and reinsert it right side up (label side up).
*
[AS07300(ALL)08/95]
The digital display on your CD player will either show the
track (selection) number or the elapsed time. (The display mode
can be selected by pressing the ªCLOCKº button.) Indicators for
play (
a), stop (
X) and compression on (ªCº) are also in the
display. (These features are described later.)
*
[AS07400(ALL)10/95]
Once a disc is inserted, operation of the CD player will override
that of the radio.
*
[AS07500(ALL)09/95]
NOTE: The volume, bass, treble, balance and fader controls
on the radio are also used with the CD player. Refer
to earlier operating instructions on these controls.
*
[AS07600(ALL)04/96]
How to insert a disc and begin play
*
[AS07700(ALL)10/95]
Insert one disc,label side upinto the disc opening. When
inserted, the disc automatically loads into the unit and play
starts at the beginning of the first track (selection).
*
[AS07800(ALL)04/96]
When the disc reaches the end, the disc player automatically
returns to the beginning of the disc and resumes playing.
[AS07900(ALL)04/96]
NOTE: Once a disc is inserted, the disc opening is secured to
prevent the accidental insertion of a second disc.
[AS08000(ALL)09/95]
NOTE: The CD player has heat protection circuitry to protect
the laser diode. If the temperature of the player
reaches167ÊF (75ÊC), theheat detection circuit will
shut off the player and ªTOO HOTº will scroll in the
display for five seconds (radio will resume playing).
When the temperature returns to normal operating
range, the CD player will again be operational.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
Page 50 of 385
Electronic Sound Systems
49
*
[AS08100(ALL)10/95]
How to stop and restart the CD player
*
[AS08200(ALL)04/96]
When a disc is loaded, the unit automatically enters the play
mode and the play indicator
ailluminates. To stop
temporarily, press the ªPLAY/STOPº button or the ªAM/FMº
button. The stop indicator
Xin the display illuminates and
operation returns to the radio mode. To resume CD play, press
the ªPLAY/STOPº button once again.
*
[AS08300(ALL)10/95]
NOTE: If the ignition key is turned OFF during play and
then is set to the ON or ACCESSORY position, the
CD player will resume playing in the mode it was in
when ignition was turned off.
*
[AS08400(ALL)05/96]
How to fast forward or reverse your CD player
*
[AS08500(ALL)10/95]
To quickly search for a particular point in a selection, press the
ªFFº button (to fast forward) or the ªREVº button (to reverse).
While either button is pressed, the disc goes forward or
backward at two different speeds depending on how long the
button is held down. (Pressing either button for more than three
seconds will speed up the process.) Release the button at the
desired point (found by watching the elapsed playing time in
the display or by listening to the sound during fast forward or
reverse). When you have reached the beginning of track 1, the
CD player will begin playing.
*
[AS08600(ALL)10/95]
When you have reached the end of the disc by keeping the fast
forward button pressed, the display will show ªENDº and the
player will go into pause mode. Push the ªPLAY/STOPº button
to begin playing the first track of the disc, press the ªREVº
button to back up from the end of the disc, or use the ªSEEKº
function to locate a desired track.
*
[AS08610(ALL)08/95]
Using the ªSEEKº feature
[AS08620(ALL)10/94]
Press the top (
a) of the ªSEEKº button once to repeat the
current playing selection. Press the bottom (
b) of the ªSEEKº
button to advance to the next selection.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
