FORD WINDSTAR 1997 1.G Owners Manual

Maintenancean dCare
301
*WARNING
Th egase saroun dthebatter ycan explod eif expose dto
WARNING
Batterie scontai nsulfuri caci dwhic hburn sskin ,eyes,

302
WARNING
Applyingtoo muc hpressur eon theend swhe nliftin ga

Maintenance and Care
303
[MC16700(ALL)07/96]
Wiper Blade Replacement
*
[MC16800(ALL)01/96]
If the wipers still do not work properly after you clean them,
you may need to replace the wiper blade assembly. When
replacing the wiper blade assembly always use a Motorcraft part
or equivalent.
*
[MC16900(ALL)08/95]
To replace the wiper blades:
*
[MC17000(ALL)01/96]1.
Pull the wiper arm away from the windshield and into the
lock position.
[MC17100(ALL)01/96]2.
Turn the blade at an angle from the wiper arm. Squeeze the
lock tabs of the plastic clip together to release the blade and
pull the wiper blade down toward the windshield to remove
it from the arm.
*
[MC17200(ALL)08/95]3.
Attach a new wiper blade to the wiper arm and press it into
place until you hear it click.
%*
[MC17300(ALL)01/96]
Tires
[MC17400(ALL)04/96]
Look at your tires each time you fill your fuel tank. If one tire
looks lower than the others, check the pressure in all of them.
[MC17500(ALL)01/96]
n
Keep your tires inflated to the recommended pressures. See
Checking the pressure of the tireslater in this chapter.
*
[MC17600(ALL)01/96]
n
Stay within the recommended load limits. SeeDriving with a
heavy loadin the Index.
*
[MC17700(ALL)03/96]
n
Make sure the weight of your load is evenly distributed.
*
[MC17800(ALL)03/96]
n
Adjust tire pressure to recommended specifications found on
the Safety Compliance Certification Label.
*
[MC17900(ALL)03/96]
If you do not take these precautions, your tires may fail or go
flat.
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

304
WARNING
Alwaysobe yposte dspee dlimits .If yo udriv etoo fast
WARNING
Improperl yinflate dtire sca n affec tvehicl ehandlin gand

Maintenance and Care
305
[MC18500(ALL)01/96]
10-1/2 pica
art:0050224-A
Rotating the tires
*
[MC18600(ALL)01/96]
If your vehicle has the optional full-size spare tire, you may
rotate the spare tire into the rotation pattern.
[MC18700(ALL)01/96]
If your vehicle has aluminum wheels, you may remove the
full-size (if equipped) spare tire from the wheel and remount it
on an aluminum wheel to rotate the spare tire into your
vehicle's rotation pattern.
%*
[MC18800(ALL)01/96
]
Replacing the Tires
*
[MC18900(ALL)01/96]
Replace tires that show wear bands. When your tire shows a
wear band, it has only 1/16 of an inch (1.59 mm) of tread left.
*
[MC19000(ALL)01/96]
7-1/2 pica art:0040200-A
A worn-out tire
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

306
WARNING
Whenreplacin gful lsiz etires ,neve rmi xradial,
WARNING
Mak esur etha tal lreplacemen ttire sar e of th esam esize,
WARNING
Do no treplac eyou rtire swit hªhig hperformance ºtires
WARNING
Us eof aftermarke twhee lassemblie sma ydamag eyour
WARNING
Failur eto follo wthes eprecaution sma yadversel yaffect

Maintenance and Care
307
*
[MC19700(ALL)01/96]
Tires that are larger or smaller than your vehicle's original tires
may affect the accuracy of your speedometer and odometer.
%*
[MC19800(ALL)01/96
]
Information About Tire Quality Grades
*
[MC19900(ALL)01/96]
New vehicles are fitted with tires that have their Tire Quality
Grade (described below) molded into the tire's sidewall. These
Tire Quality Grades are determined by standards that the
United States Department of Transportation has set.
*
[MC20000(ALL)01/96]
Tire Quality Grades apply to new pneumatic tires for use on
this vehicle. They do not apply to deep tread, winter-type snow
tires, space-saver or temporary use spare tires, tires with
nominal rim diameters of 10 to 12 inches (254-305 mm) or
limited production tires as defined in Title 49 Code of Federal
Regulations Part 575.104(c)(2).
*
[MC20100(ALL)01/96]
U.S. Department of Transportation Ð Tire quality grades:The
U.S. Department of Transportation requires Ford to give you the
following information about tire grades exactly as the
government has written it.
%*
[MC20200(ALL)01/96
]
Treadwear
*
[MC20300(ALL)01/96]
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a
specified government test course. For example, a tire graded 150
would wear one and one-half (1 1/2) times as well on the
government course as a tire graded 100. The relative
performance of tires depends upon the actual conditions of their
use, however, and may depart significantly from the norm due
to variations in driving habits, service practices and differences
in road characteristics and climate.
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

308
*
[MC20400(ALL)01/96]
Traction A B C
*
[MC20500(ALL)01/96]
The traction grades, from highest to lowest, are A, B, and C,
and they represent the tire's ability to stop on wet pavement as
measured under controlled conditions on specified government
test surfaces of asphalt and concrete. A tire marked C may have
poor traction performance. Warning: The traction grade assigned
to this tire is based on braking (straight ahead) traction tests
and does not include cornering (turning) traction.
*
[MC20600(ALL)01/96]
Temperature A B C
[MC20700(ALL)01/96]
The temperature grades are A (the highest), B, and C,
representing the tire's resistance to the generation of heat and
its ability to dissipate heat when tested under controlled
conditions on a specified indoor laboratory test wheel. Sustained
high temperature can cause the material of the tire to
degenerate and reduce tire life, and excessive temperature can
lead to sudden tire failure. The grade C corresponds to a level
of performance which all passenger car tires must meet under
the Federal Motor Vehicle Safety Stadard No. 109. Grades B and
A represent higher levels of performance on the laboratory test
wheel than the minimum required by law. Warning: The
temperature grade for this tire is established for a tire that is
properly inflated and not overloaded. Excessive speed,
underinflation, or excessive loading, either separately or in
combination, can cause heat buildup and possible tire failure.
%*
[MC20800(ALL)01/96
]
Snow Tires and Chains
*
[MC20900(ALL)03/96]
The tires on your vehicle have all-weather treads that provide
traction in rain or snow. However, during the winter months in
some climates, you may need to use snow tires and occasionally
chains for your tires.
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

Maintenancean dCare
309
WARNING
Whe nusin gsno wtires ,mak esur ethe yare th esam esize

310
WARNING
Thefue lsyste mma ybe unde rpressure .If th efue lca p is
WARNING
Tur nthefue lca p 3/4 of a tur nto reliev ean ypressure
