FORD WINDSTAR 1997 1.G Owners Manual

Maintenancean dCare
281
WARNING
Do no tstar tyou rengin ewit htheaircleane rremoved
[MC03000(ALL)01/96] 2.G o to thefron tof th evehicl ean dreleas eth esecondary

282
[MC03200(ALL)01/96]
24 pica art:0050028-B
Propping the hood
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

Maintenance and Care
283
*
[MC03300(ALL)01/96]
To close the hood:
*
[MC03400(ALL)01/96]1.
Remove the prop rod from the slotted hole in the hood.
Place the rod in its retaining clip and close the hood with
enough force to make it latch. Be sure to oil the hood latch
every six months to maintain smooth operation.
*
[MC03500(ALL)01/96]2.
Try to lift the hood after closing it to be sure it is securely
latched.
%*
[MC03600(ALL)03/96]
Engine Compartment
[MC03700(ALL)01/96]
Your vehicle has a 3.0 liter SFI, V-6 engine or an optional 3.8
liter SFI, V-6 engine. The following illustrations show diagrams
of your engine and where you can find items you should
service regularly.
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

284
[MC03800(ALL)01/96]
33-1/2 pica
art:0050234-B
The engine compartment (3.0 liter only)
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

Maintenance and Care
285
[MC03900(ALL)01/96]
33-1/2 pica
art:0050038-C
The engine compartment (3.8 liter only)
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

286
[MC04000(ALL)04/96]
What to Check When You Stop at a Service
Station
%*
[MC04100(ALL)01/96]
Engine Oil Recommendations
*
[MC04200(ALL)01/96]
We recommend using Motorcraft oil or an equivalent oil
meeting Ford Specification WSS-M2C153-F and displaying the
American Petroleum Institute CERTIFICATION MARK on the
front of the container.
[MC04300(ALL)04/96]
Use only engine oils displaying the American Petroleum
Institute CERTIFICATION MARK on the front of the container:
*
[MC04400(ALL)01/96]
10-1/2 pica
art:0001314-A
The API Certification Mark
*
[MC04500(ALL)01/96]
Neveruse:
*
[MC04600(ALL)01/96]
n
ªNon-Detergentº oils
*
[MC04700(ALL)02/96]
n
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC04800(ALL)01/96
]
n
Additional engine oil additives, oil treatments or engine
treatments
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

Maintenance and Care
287
%*
[MC04900(ALL)03/96
]
Engine oils with anSAE 5W-30viscosity arePREFERREDfor
your vehicle. They provide the best engine performance, fuel
economy and engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[MC05000(ALL)03/96
]
Synthetic engine oils which are CERTIFIED and of the preferred
viscosity may be used in your engine. The engine oil and oil
filter must still be changed according to the maintenance
schedule.
%*
[MC05100(ALL)01/96
]
Checking and Adding Engine Oil
*
[MC05200(ALL)01/96]
Since the proper amount of engine oil is important for safe
engine operation, check the oil using the dipstick each time you
put fuel in your vehicle. Remember the engine must be off, the
oil must be warm and the vehicle must be parked on level
ground.
%*
[MC05300(ALL)01/96
]
Checking the engine oil level:
*
[MC05400(ALL)01/96]1.
Turn the engine off after it has warmed up and allow a few
minutes for the engine oil to drain back into the oil pan.
*
[MC05500(ALL)01/96]2.
Set the parking brake, making sure the gearshift is securely
latched in P (Park).
*
[MC05600(ALL)01/96]3.
Open the hood. Protect yourself from engine heat.
[MC05700(ALL)01/96]4.
Locate the dipstick labelled ªEngine Oilº and carefully pull it
out of the engine.
*
[MC05800(ALL)01/96]5.
Wipe the dipstick clean and put it back into position, making
sure it is fully seated.
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

288
[MC05900(ALL)01/96]
7-1/2 pica art:0050073-D
Engine oil dipstick
*
[MC06000(ALL)01/96]6.
Carefully, pull the dipstick out again. If the oil level is below
the ªADD 1 QT.º line, add engine oil as necessary. If the oil
level is beyond the letter ªFº in FULL, engine damage or
high oil consumption may occur and some oil must be
removed from the engine.
*
[MC06100(ALL)01/96]7.
Put the dipstick back in and make sure it is fully seated.
*
[MC06200(ALL)01/96]
It may be necessary to add some oil between oil changes. Make
sure you use a CERTIFIED engine oil of the preferred viscosity.
Your vehicle's warranty coverage may not apply if engine
damage is caused by the use of improper engine oil.
*
[MC06300(ALL)01/96]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
%*
[MC06400(ALL)01/96
]
Changing the Engine Oil and the Oil Filter
*
[MC06500(ALL)05/96]
Refer to theMaintenance Schedulebooklet for additional
information.
%*
[MC06600(ALL)05/96
]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996

Maintenancean dCare
289
WARNING
Continuou scontac twit hUSE Dmoto roi lha scaused
WARNING
Brak eflui dis toxic.

290
*WARNING
If yo uus ea brak eflui dtha tis no tDO T3, yo uwill
WARNING
Do no tle tth ereservoi rfo rth emaste rcylinde rru n dry.
