FORD WINDSTAR 1998 1.G Owner's Manual

Instrumentation
19
[IS08300(ALL)12/95]
6 pica art:0050154-B
The high beam indicator light
% [IS08400(ALL)09/96]
Low Windshield Washer Fluid Level Warning
(If equipped)
[IS08500(ALL)08/96]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[IS08600(ALL)08/96]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[IS08700(ALL)08/96]
6 pica art:0050062-B
The low windshield washer indicator light
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

20
% [IS09200(ALL)09/96]
Low Fuel Indicator Light (If equipped)
[IS09300(ALL)12/95]
This light comes on when your fuel gauge indicates
approximately 1/16 of a tank. The ignition must be turned to
ON in order for this light to come on.
[IS09400(ALL)12/95]
6 pica art:0050189-A
The low fuel indicator light
[IS09500(ALL)08/96]
Cruise Control Indicator
[IS09600(ALL)08/96]
A CRUISE light is displayed in the instrument cluster when the
speed control system is engaged. The display will turn off when
the brake pedal is pressed or if speed control is shut off.
[IS09700(ALL)08/96]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
[IS09800(ALL)09/96]
6 pica art:0051002-A
The speed control light
*
[IS10200(ALL)04/96]
Gauges
%*
[IS10400(ALL)08/96]
Fuel Gauge
[IS10500(ALL)12/95]
The fuel gauge displays approximately how much fuel is in the
fuel tank only when the ignition is ON. For proper fuel gauge
indication after adding fuel, the ignition should be in the OFF
position while the vehicle is being refueled.
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

Instrumentation
21
[IS10600(ALL)12/95]
The fuel gauge indicator may also vary slightly when the
vehicle is in motion. With the ignition OFF, the fuel gauge
indicator may drift from the ignition ON position as well.
[IS10700(ALL)12/95]
10-1/2 pica
art:0050235-A
Fuel gauge Ð base cluster
[IS10800(ALL)08/96]
10-1/2 pica
art:0050126-D
The engine coolant temperature and fuel gauge
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

22
%*
[IS11400(ALL)08/96]
Engine Coolant Temperature Gauge
*
[IS11500(ALL)02/96]
This gauge indicates the temperature of the engine coolant, not
the coolant level. If the coolant is not at its proper level or
mixture, the gauge indication will not be accurate.
[IS11600(ALL)01/96]
10-1/2 pica
art:0050236-A
Engine coolant temperature gauge Ð base cluster
[IS11700(ALL)01/96]
The pointer moves from the C (cold) mark into the NORMAL
band as the engine coolant warms up. It is acceptable for the
pointer to fluctuate within the normal band under normal
driving conditions. Under certain driving conditions such as
heavy stop and go traffic, or driving up hills in hot weather, the
pointer may indicate at the top of the NORMAL band. This is
also acceptable.
*
[IS11800(ALL)04/96]
If, under any circumstances, the pointer moves above the
NORMAL band, the engine is overheating and continued
operation may cause engine damage.
*
[IS11900(ALL)08/96]
If your engine overheats:
*
[IS12000(ALL)08/96]1.
Pull off the road as soon as it is safely possible.
*
[IS12100(ALL)08/96]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

Instrumentation
23
*
[IS12200(ALL)08/96]3.
Let the engine cool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
[IS12300(ALL)08/96]4.
Check the coolant level following the instructions on
checking and adding coolant to your engine in this Owner
Guide. Seeengine coolantin the index. If you do not follow
these instructions, you or others could be injured.
*
[IS12400(ALL)08/96]
If the coolant continues to overheat, have the coolant system
serviced as soon as possible.
%*
[IS13600(ALL)08/96]
Speedometer
*
[IS13700(ALL)03/96]
The speedometer tells you how many miles (kilometers) per
hour your vehicle is moving.
%*
[IS14200(ALL)08/96]
Odometer
*
[IS14300(ALL)01/96]
The odometer records the total distance the vehicle has been
driven.
%*
[IS14700(ALL)01/96]
Trip Odometer
%*
[IS14800(ALL)05/96]
The trip odometer records the distance of individual trips.
Before each trip, set the trip odometer to zero by pushing the
reset control.
[IS14900(ALL)01/96]
10-1/2 pica
art:0050155-C
The speedometer, odometer and trip odometer
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

24
% [IS15000(ALL)04/96]
Tachometer (If equipped)
*
[IS15100(ALL)03/96]
The tachometer will show you the engine's speed measured in
revolutions per minute (RPM).
*
[IS15200(ALL)03/96]
The tachometer may move slightly when the key is placed in
the ACC or ON position, with the engine off. This is normal
and does not affect the performance of the tachometer when the
engine is running.
[IS15300(ALL)01/96]
Some vehicles are equipped with an engine speed (RPM)
limiting device that is contained within the Electronic Engine
Control Module. The purpose of this device is to maintain peak
engine speed (RPM) below a specified limit. (Engine speed
limits may vary based on engine size.)
*
[IS15400(ALL)03/96]
If you are experiencing an ªengine cut-outº condition at high
speeds, it may be the result of this limiting device. It is a
normal condition and can be avoided by reducing
vehicle/engine speed.
[IS15500(ALL)01/96]
10-1/2 pica
art:0050168-B
The tachometer
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

Instrumentation
25
% [IS19200(ALL)01/96]
Auxiliary Warning Module (If equipped)
[IS19300(ALL)01/96]
An additional bank of indicator and warning lights is located
above the driver's side vent, just to the right of the steering
wheel. The light(s) located in this module are described and
illustrated below.
[IS19400(ALL)08/96]
13-1/2 pica
art:0050122-H
The auxiliary warning module
% [IS19500(ALL)01/96]
Traction Control Active Light
[IS19600(ALL)01/96]
This light comes on when the Traction Control system begins
applying and releasing the brakes and adjusting the engine
characteristics to limit a wheelspin condition. You may feel
some steering changes and hear some noise, but this is normal.
[IS19700(ALL)01/96]
one inch art:0050274-AFile:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

26
[IS19800(ALL)01/96]
The Traction Control light will stay on for a minimum of four
seconds.
[IS19900(ALL)07/96]
Traction Control Off Light
[IS20000(ALL)01/96]
This light comes on when the Traction Control system is not
operating. In some conditions, you may want to turn Traction
Control off, such as when rocking your vehicle out of deep
snow or mud.
[IS20100(ALL)07/96]
one inch art:0050275-B[IS20200(ALL)01/96]
Traction Control will automatically turn off to prevent the
brakes from overheating. The system will turn back on once the
brakes have cooled down.
[IS20300(ALL)01/96]
NOTE: If the TRAC OFF light is flashing repeatedly, it means
that there is a Traction Control system malfunction
and the system is inoperative. Contact your dealer for
service as soon as possible.
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

Instrumentation
27
% [IS20400(ALL)01/96]
Anti-Theft Active Indicator Light
[IS20500(ALL)07/96]
This indicator is used in the optional Anti-Theft System. See
ªAnti-Theft Systemº in theControls and Featureschapter of this
Owner Guide.
[IS20600(ALL)01/96]
6 pica art:0050123-B
The anti-theft active indicator light
[IS20700(ALL)01/96]
Air Suspension Warning Light
[IS20800(ALL)01/96]
6 pica art:0050227-A
The air suspension warning light
[IS20900(ALL)01/96]
The warning light for the Air Suspension indicates one of two
things:
[IS21000(ALL)01/96]1.
The service switch (located in the jack storage area) is in the
ªoffº position.
[IS21100(ALL)01/96]2.
A system malfunction has occurred electronically disabling
Air Suspension function.
[IS21200(ALL)01/96]
NOTE: If the switch is returned to or in the ªONº position
and the light does not go out after recycling the
ignition switch OFF/ON, the Air Suspension should
be checked by a qualified service technician.
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

29
Electronic Sound Systems
[AS01100(ALL)04/95]
33-1/2 pica
art:0060674-B
The Compact Disc Radio
