FORD WINDSTAR 1998 1.G Owners Manual

302other gasolines, the performance of the emission control devices
and systems may be adversely affected. Repair of damage
caused by using a fuel that your vehicle was not designed for
may not be covered by your warranty.
*
[MC24400(ALL)08/96]
Octane recommendations
[MC24500(ALL)08/96]
Your vehicle is designed to use regular gasoline with an
(R+M)/2 octane rating of 87. We do not recommend gasolines
labeled as ºregularª in high altitude areas that are sold with
octane ratings of 86 or even less.
*
[MC24600(ALL)08/96]
6 pica art:0040193-A
Typical octane rating label
*
[MC24601(ALL)08/96]
Do not be concerned if your vehicle sometimes knocks lightly.
However, if it knocks heavily under most driving conditions on
the recommended octane fuel, see your dealer or a qualified
service technician to prevent any engine damage.
%*
[MC24900(ALL)05/96]
Fuel quality
*
[MC25000(ALL)08/96]
If you are experiencing starting, rough idle or hesitation
problems, try a different brand of fuel. If the condition persists,
see your dealer or a qualified service technician.
*
[MC25100(ALL)08/96]
The American Automobile Manufacturers Association (AAMA)
issued a gasoline specification to provide information on high
quality fuels that optimize the performance of your vehicle. We
recommend the use of gasolines that meet the AAMA
specification if they are available.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

Maintenance and Care
303
*
[MC25200(ALL)08/96]
It should not be necessary to add any aftermarket products to
your fuel tank if you continue to use a high-quality fuel.
*
[MC25300(ALL)08/96]
Cleaner air
*
[MC25400(ALL)08/96]
Ford approves the use of gasolines to improve air quality,
including reformulated gasolines, that contain oxygenates such
as a maximum of 10% ethanol or 15% MTBE. There should be
no more than 5% methanol with cosolvents and additives to
protect the fuel system.
%*
[MC26300(ALL)01/96]
Safety Information Relating to Automotive Fuels
*
[MC26400(ALL)01/96]
RWARNING
Automotive fuels can cause serious injury or death if
misused or mishandled.
*
[MC26500(ALL)01/96]
Gasoline and other automotive fuels are extremely flammable.
Turn your vehicle off and do not smoke while refueling your
vehicle. Keep sparks and other sources of ignition away from
fuels.
[MC26600(ALL)01/96]
Automotive fuels can be harmful or fatal if swallowed. Never
attempt to siphon any fuel by mouth.
[MC26700(ALL)01/96]
If any fuel is swallowed, call a physician or poison control
center immediately.Do not delay calling a physician merely
because no adverse effects are noticed at first; the toxic effects
of fuels may not become apparent for many hours.
*
[MC26800(ALL)01/96]
If gasoline is swallowed, do not induce vomiting. If a
gasoline-methanol blend is swallowed, induce vomiting under
the direction of a physician or poison control center.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

304
[MC26900(ALL)01/96]
Gasoline and gasoline-methanol blends may contain small
amounts of carcinogens, such as benzene. Long-term exposure to
unleaded gasoline vapors has caused cancer in laboratory
animals. Excessive inhalation of fuel vapors can cause headache,
dizziness, nausea, poor coordination, and other symptoms which
could interfere with your ability to safely operate your vehicle.
Avoid breathing vapors while refueling. If fuel vapors are
inhaled in excessive quantities, move the victim to fresh air and
seek medical attention.
[MC27000(ALL)04/96]
Fuels can also be harmful if absorbed through the skin. Be
careful not to splash fuel on yourself or your clothing. If fuel is
splashed on the skin, promptly remove contaminated clothing
and wash the skin thoroughly with soap and water.
*
[MC27100(ALL)01/96]
Fuels can cause severe eye irritation and possibly eye damage. If
fuel is splashed in the eyes, remove contact lenses (if worn),
flush with large amounts of water for 15 minutes, and seek
medical attention.
*
[MC27200(ALL)01/96]
If you are taking the medication ºAntabuseª or other forms of
disulfiram for the treatment of alcoholism, vapor or skin contact
with a gasoline-methanol blend may cause the same kind of
adverse reaction as drinking an alcoholic beverage. In sensitive
individuals, serious personal injury or sickness could result.
Consult a physician promptly if you experience an adverse
reaction.
*
[MC27300(ALL)08/95]
NOTE: Avoid running out of fuel because this situation may
have an adverse effect on modern powertrain
components.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

Maintenance and Care
305
%*
[MC27400(ALL)01/96]
Running Out of Fuel
*
[MC27500(ALL)08/96]
If your vehicle runs out of fuel, try to stop on level ground
away from traffic. Add at least one gallon (4 liters) of fuel to
start your vehicle again. If your vehicle is not on level ground,
you may need as much as five gallons (20 liters) of fuel to start
it.
[MC27600(ALL)01/96]
You may need to turn the ignition to START several times
before engaging the starter (leaving it in that position several
seconds each time) before the fuel system starts to pump fuel
from the tank to the engine.
%*
[MC27700(ALL)03/96]
Fuel Economy
*
[MC27800(ALL)01/96]
Fuel economy is an estimate of the efficiency of your vehicle
and can be calculated as Miles Per Gallon (MPG) or Liters Per
100 Kilometers (L/100K).
[MC27900(ALL)01/96]
To calculate the fuel economy:
*
[MC28000(ALL)01/96]1.
Fill the tank completely and record the initial odometer
reading.
*
[MC28100(ALL)01/96]2.
Every time you buy fuel record the amount (in gallons or
liters) purchased.
[MC28200(ALL)01/96]3.
Divide the total number of miles that you have driven by
the total number of gallons that your vehicle has used. This
will give you the average numbers of miles per gallon.
[MC28300(ALL)01/96]
In metric, multiply the number of liters used by 100 and
divide the answer by the number of kilometers traveled. This
will give you the number of liters used per 100 km.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

306
*
[MC28400(ALL)01/96]
Comparisons With Environmental Protection Agency
(EPA) Fuel Economy Estimates
[MC28500(ALL)01/96]
EPA fuel economy figures are obtained from laboratory tests
under simulated road conditions and therefore are estimates
which may not reflect the actual conditions you experience. The
tests also do not exactly duplicate your personal style of
driving, including all your stops, starts, and lane changes. Other
factors that may affect fuel economy include using the air
conditioning, driving speed, vehicle load and tire inflation
pressure. The EPA fuel economy estimate is not a guarantee
that you will achieve the fuel economy shown.
%*
[MC28600(ALL)01/96]
Improving Fuel Economy
[MC28700(ALL)01/96]
You can improve the fuel economy for your vehicle in three
ways:
[MC28800(ALL)07/96]1.
Maintain your vehicle effectively. A well-tuned, properly
maintained vehicle gives you better fuel economy. Follow the
schedules for maintaining your vehicle that are in the
Maintenance Schedulebooklet.
[MC28900(ALL)04/96]2.
Drive your vehicle efficiently. Change your driving habits to
conserve fuel:
[MC29000(ALL)04/96]
n
Do not drive with your foot on the brake.
[MC29100(ALL)04/96]
n
Watch traffic so that you do not have to stop suddenly.
[MC29200(ALL)01/96]
n
Do not accelerate suddenly. Drive at a steady speed
whenever you can.
[MC29300(ALL)04/96]
n
Do not let the engine idle for a long time.
[MC29400(ALL)01/96]
n
Do not carry loads that are too heavy. To find out the limits
for the loads that your vehicle can carry, seeDriving with a
heavy loadin the Index.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

Maintenance and Care
307
[MC29500(ALL)01/96]
n
Keep the tires properly inflated. To find out the
recommended tire pressure, seeChecking the pressure of the
tireslater in this chapter.
[MC29600(ALL)01/96]
n
Use your air conditioning system wisely. To find out about
fuel economy and air conditioning, seeClimate control systems
in the Index.
[MC29700(ALL)01/96]
In addition to your individual driving habits, optional
equipment, such as air conditioning, can have a significant effect
on fuel economy. Various aftermarket add-on items that increase
aerodynamic drag can also reduce fuel economy.
%*
[MC29800(ALL)01/96]
Emission Control System
*
[MC29900(ALL)01/96]
Your vehicle is equipped with a catalytic converter which
enables your vehicle to comply with applicable exhaust emission
requirements.
*
[MC30000(ALL)01/96]
To make sure that the catalytic converter and the other emission
control parts continue to work properly:
*
[MC30100(ALL)01/96]
n
Use only unleaded fuel.
*
[MC30200(ALL)01/96]
n
Avoid running out of fuel.
*
[MC30300(ALL)01/96]
n
Never turn off the ignition while your vehicle is moving,
especially at high speeds.
[MC30400(ALL)07/96]
n
Have the services listed in yourMaintenance Schedulebooklet
performed according to the specified schedule. The scheduled
maintenance services are required because they are
considered essential to the life and performance of your
vehicle and to its emission system.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

308
*
[MC30500(ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in dry grass or
other dry ground cover. The emission system heats up
the engine compartment and exhaust system, which can
start a fire.
*
[MC30600(ALL)01/96]
RWARNING
Do not remove the floor carpet in your vehicle. Emission
controls cause high exhaust temperatures under the floor.
*
[MC30700(ALL)05/96]
RWARNING
Exhaust leaks may result in the entry of harmful and
potentially lethal fumes into the passenger compartment.
Under extreme conditions excessive exhaust temperatures
could damage the fuel system, the interior floor covering,
or other vehicle components, possibly causing a fire.
*
[MC30900(ALL)01/96]
Watch for fluid leaks, strange odors, smoke and loss of oil
pressure. Also watch for the charge warning light, the check
engine light, or the temperature warning light. These sometimes
indicate that the emission system is not working properly.
*
[MC31000(ALL)01/96]
Do not make any unauthorized changes to your vehicle or
engine. Changes that cause more unburned fuel to reach the
exhaust system can increase the temperature of the engine or
exhaust system.
*
[MC31100(ALL)01/96]
By law, anyone who manufactures, repairs, services, sells, leases
vehicles, trades vehicles, or supervises a fleet of vehicles is not
permitted to intentionally remove an emission control device or
prevent it from working. In some of the United States and in
Canada, vehicle owners may be liable if their emission control
device is removed or is prevented from working.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

Maintenance and Care
309
%*
[MC31200(ALL)01/96
]
In general, maintenance, replacement, or service of the emission
control devices or systems in your new Ford Motor Company
vehicle or engine may be performed at your expense by any
automotive repair establishment or individual using automotive
parts equivalent to those with which your vehicle or engine was
originally equipped.
*
[MC31300(ALL)01/96]
Ford strongly recommends the use of genuine Ford replacement
parts. If other than Ford or Motorcraft parts or Ford authorized
remanufactured parts are used for maintenance replacements or
for the service of components affecting emission control, such
non-Ford parts should be equivalent to genuine Ford Motor
Company parts in performance and durability. It is the owner's
responsibility to determine the equivalency of such parts. Please
consult your warranty booklet for complete warranty
information.
*
[MC31400(ALL)08/95]
Never use a metal exhaust collector when you service your
vehicle. If the metal collector contacts any of your vehicle's
plastic trim or bumper parts they could melt or deform.
*
[MC31500(ALL)01/96]
Do not drive your vehicle if it does not operate properly. See
your dealer if the engine runs on for more than five seconds
after you shut it off or if it misfires, surges, stalls, or backfires.
*
[MC31600(ALL)01/96]
Information about your vehicle's emissions control system is on
the Vehicle Emission Control Information decal located on or
near the engine. This decal identifies engine displacement and
gives some tune-up specifications.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

310
%*
[MC31700(ALL)03/96
]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
*
[MC31800(ALL)07/96]
In some localities it may become a legal requirement to pass an
Inspection/Maintenance (I/M) test of the On-Board Diagnostic
(OBD) II system. If the vehicle's powertrain system or its battery
has just been serviced, the OBD II system is reset to a not ready
for I/M testing condition. To prepare for I/M testing, the law
specifies that additional mixed city and highway driving is
required to complete the check of the OBD II system.
*
[MC31825(ALL)07/96]
The driving modes required to reach the ready condition consist
of a minimum of 30 minutes of city and highway driving as
described below:
*
[MC32000(ALL)07/96]
n
At least twenty minutes driving in stop and go, city type
traffic with at least four idle periods.
*
[MC32100(ALL)07/96]
n
At least ten minutes of driving on an expressway or
highway.
*
[MC32200(ALL)07/96]
Before completing the above driving modes, the engine must be
warmed up and at operating temperature. Once started, the
vehicle must not be turned off during these driving modes.
[MC33200(ALL)01/96]
Lights
*
[MC33300(ALL)01/96]
It is a good idea to check the operation of the following lights
frequently:
*
[MC33400(ALL)01/96]
n
headlamps
*
[MC33500(ALL)01/96]
n
tail lamps
*
[MC33600(ALL)01/96]
n
brakelamps
*
[MC33700(ALL)01/96]
n
hazard flasher
*
[MC33800(ALL)01/96]
n
turn signals
*
[MC33900(ALL)05/96]
n
license plate lamps
*
[MC34000(ALL)01/96]
n
fog lamps
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996

Maintenance and Care
311
%*
[MC34100(ALL)01/96]
The alignment of your headlamps should be checked if:
*
[MC34200(ALL)01/96]
n
oncoming motorists frequently signal you to turn off your
vehicle's high beams when you do not have the high beams
on
*
[MC34300(ALL)01/96]
n
the headlamps do not seem to give you enough light to see
clearly at night
*
[MC34400(ALL)01/96]
n
the headlamp beams are not pointed slightly down and to
the right
% [MC34500(ALL)04/96]
Replacing the Headlamp Bulb
*
[MC34600(ALL)03/96]
The headlamps on your vehicle use replaceable bulbs. When the
lamp burns out, simply replace the bulb, rather than the whole
lamp.
*
[MC34700(ALL)01/96]
RWARNING
Handle a halogen headlamp bulb carefully and keep out
of children's reach. Grasp the bulb only by its plastic
base and do not touch the glass. The oil from your hand
could cause the bulb to break the next time the
headlamps are operated.
*
[MC34800(ALL)01/96]
Do not remove the burned out bulb unless you can immediately
replace it with a new one. If a bulb is removed for an extended
period of time, contaminants may enter the headlamp and affect
its performance.
[MC34900(ALL)04/96]
To remove the headlamp bulb:
*
[MC35000(ALL)01/96]1.
Make sure that the engine is off and the headlamp switch on
the instrument panel is in the OFF position.
[MC35100(ALL)01/96]2.
Lift the hood and locate the headlamp bulb installed in the
rear of the headlamp. Remove the electrical connector from
the bulb by pulling the connector away from the bulb
assembly.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996
