GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-14608671) - 2021 - CRC - 10/26/20
360 Technical Data
ApplicationCapacities
Metric English
I3.6L V6 Engine with Rear HVAC 12.0 L
12.7 qt
I3.6L V6 Engine with Heavy Duty Cooling System 10.5 L
11.1 qt
I3.6L V6 Engine with Rear HVAC and Heavy Duty Cooling System 12.2 L
12.9 qt
Engine Oil with Filter I2.0L L4 Engine 5.0 L
5.3 qt
I2.5L L4 Engine 4.7 L
5.0 qt
I3.6L V6 Engine 5.7 L
6.0 qt
Fuel Tank IFront-Wheel Drive 73.4 L
19.4 gal
IAll-Wheel Drive 82.1 L
21.7 gal

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-14608671) - 2021 - CRC - 10/26/20
Technical Data 361
ApplicationCapacities
Metric English
Wheel Nut Torque 190 Y140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual. Recheck fluid level
after filling.
*Engine cooling system capacity values are based on the entire cooling system and its components.
Engine Specifications
Engine VIN CodeTransmission Spark Plug Gap
2.0L L4 Engine (LSY) 4Automatic 0.65–0.75 mm (0.026–0.030 in)
2.5L L4 Engine (LCV) AAutomatic 0.95–1.10 mm (0.037–0.043 in)
3.6L V6 Engine (LGX) SAutomatic 0.80–0.90 mm (0.031–0.035 in)
Spark plug gaps are preset by the manufacturer. Re-gapping the spark plug is not recommended and can damage the spark plug.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-14608671) - 2021 - CRC - 10/26/20
362 Technical Data
Engine Drive Belt Routing
2.0L L4 Engine
2.5L L4 Engine
3.6L V6 Engine

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-14608671) - 2021 - CRC - 10/26/20
Customer Information 371
with that company. In such cases, you can
have control of the repair and parts choices
as long as the cost stays within reasonable
limits.
Publication Ordering Information
Service Manuals
Service manuals have the diagnosis and
repair information on the engine,
transmission, axle, suspension, brakes,
electrical system, steering system, body, etc.
Customer Literature
Owner’s manuals are written specifically for
owners and are intended to provide basic
operational information about the vehicle.
The owner’s manual includes the
Maintenance Schedule for all models.
Customer literature publications available for
purchase include owner’s manuals, warranty
manuals, and portfolios. Portfolios include an
owner’s manual, warranty manual,
if applicable, and zip lock bag or pouch.
Current and Past Models
Service manuals and customer literature are
available for many current and past model
year GM vehicles.To order, call 1-800-551-4123 Monday–Friday,
8:00 a.m.–6:00 p.m. eastern time
For credit card orders only (VISA,
MasterCard, or Discover), see Helm, Inc. at:
www.helminc.com.
To order by mail, write to:
Helm, Incorporated
Attention: Customer Service
47911 Halyard Drive
Plymouth, MI 48170
Make checks payable in U.S. funds.
Radio Frequency Statement
This vehicle uses license-exempt transmitters
/ receivers / systems that operate on a
radio frequency that complies with Part 15/
Part 18 of the Federal Communications
Commission (FCC) rules and with Innovation,
Science and Economic Development (ISED)
Canada's license-exempt RSS(s) / RSP-100 /
ICES-GEN.
Operation is subject to the following two
conditions:
1. The device may not cause harmful interference. 2. The device must accept any interference
received, including interference that may
cause undesired operation of the device.
Changes or modifications to any of these
systems by other than an authorized service
facility could void authorization to use this
equipment.
Reporting Safety Defects
Reporting Safety Defects to the
United States Government
If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you should
immediately inform the National
Highway Traffic Safety Administration
(NHTSA) in addition to notifying General
Motors.
If NHTSA receives similar complaints, it
may open an investigation, and if it
finds that a safety defect exists in a
group of vehicles, it may order a recall
and remedy campaign. However, NHTSA
cannot become involved in individual
problems between you, your dealer,
or General Motors.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-14608671) - 2021 - CRC - 10/26/20
372 Customer Information
To contact NHTSA, you may call the
Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY: 1-800-424-9153); go
tohttp://www.safercar.gov; or
write to:
Administrator, NHTSA
1200 New Jersey Avenue, S.E.
Washington, D.C. 20590
You can also obtain other information
about motor vehicle safety from
http://www.safercar.gov
.
Reporting Safety Defects to the
Canadian Government
If you live in Canada, and you believe
that the vehicle has a safety defect,
notify Transport Canada immediately,
and notify General Motors of Canada
Company. Call Transport Canada at
1-800-333-0510; go to:
www.tc.gc.ca/recalls (English)
www.tc.gc.ca/rappels (French) or write to:
Transport Canada
Motor Vehicle Safety Directorate
Defect Investigations and Recalls
Division
80 Noel Street
Gatineau
,QC J8Z 0A1
Reporting Safety Defects to
General Motors
In addition to notifying NHTSA (or Transport
Canada) in a situation like this, notify
General Motors.
In the U.S., call 1-800-462-8782, or write:
GMC Customer Assistance Center
P.O. Box 33172
Detroit, MI 48232-5172
In Canada, call 1-800-263-3777 (English) or
1-800-263-7854 (French), or write:
General Motors of Canada Company
Customer Care Centre, Mail Code:
CA1-163-005
1908 Colonel Sam Drive
Oshawa, Ontario L1H 8P7In Mexico, call 800-466-0812 or
800-466-0801.
In other Central America and Caribbean
Countries, call 52-555-901-2369.
Vehicle Data Recording and
Privacy
The vehicle has a number of computers that
record information about the vehicle’s
performance and how it is driven or used.
For example, the vehicle uses computer
modules to monitor and control engine and
transmission performance, to monitor the
conditions for airbag deployment and
deploy them in a crash, and, if equipped, to
provide antilock braking to help the driver
control the vehicle. These modules may
store data to help the dealer technician
service the vehicle or to help GM improve
safety or features. Some modules may also
store data about how the vehicle is
operated, such as rate of fuel consumption
or average speed. These modules may retain
personal preferences, such as radio presets,
seat positions, and temperature settings.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-14608671) - 2021 - CRC - 10/26/20
376 OnStar
.Receive a Diagnostic check of the vehicle's
key operating systems.
.Receive Roadside Assistance.
.Manage Wi-Fi Settings, if equipped.
Press
>to get a priority connection to an
OnStar Advisor available 24/7 to:
.Get help for an emergency.
.Be a Good Samaritan or respond to an
AMBER Alert.
.Get assistance in severe weather or other
crisis situations and find evacuation
routes.
OnStar Services
Emergency
Emergency Services require an active safety
and security plan. With Automatic Crash
Response, built-in sensors can automatically
alert a specially trained OnStar Advisor who
is immediately connected in to the vehicle
to help.
Press
>for a priority connection to an
OnStar Advisor who can contact emergency
service providers, direct them to your exact
location, and relay important information. With OnStar Crisis Assist, specially trained
Advisors are available 24 hours a day, 7 days
a week, to provide a central point of
contact, assistance, and information during a
crisis.
With Roadside Assistance, Advisors can
locate a nearby service provider to help with
a flat tire, a battery jump, or an empty
gas tank.
Security
If equipped, OnStar provides these services:
.With Stolen Vehicle Assistance, OnStar
Advisors can use GPS to pinpoint the
vehicle and help authorities quickly
recover it.
.With Remote Ignition Block, if equipped,
OnStar can block the engine from being
restarted.
.With Stolen Vehicle Slowdown,
if equipped, OnStar can work with law
enforcement to gradually slow the
vehicle down.
Theft Alarm Notification
If equipped, if the doors are locked and the
vehicle alarm sounds, a notification by text,
e-mail, or phone call will be sent. If the
vehicle is stolen, an OnStar Advisor can work
with authorities to recover the vehicle.
OnStar Additional
Information
In-Vehicle Audio Messages
Audio messages may play important
information at the following times:
.Prior to vehicle purchase. PressQto set
up an account.
.After change in ownership and at
90 days.
Transferring Service
PressQto request account transfer
eligibility information. The Advisor can
cancel or change account information.
Selling/Transferring the Vehicle
Call 1-888-4ONSTAR (1-888-466-7827)
immediately to terminate your OnStar or
connected services if the vehicle is disposed
of, sold, transferred, or if the lease ends.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-14608671) - 2021 - CRC - 10/26/20
Index 383
IndexA
Accessories and Modifications . . . . . . . . . . . 268
Accessory Power . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Active Fuel Management . . . . . . . . . . . . . . . . 219
Adaptive Cruise Control . . . . . . . . . . . . . . . . . . 232
Add-On Electrical Equipment . . . . . . . . . . . . . 266
Additional InformationOnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
Additional Maintenance and Care . . . . . . . . . 351
Adjustments Lumbar, Front Seats . . . . . . . . . . . . . . . . . . . . 38
Agreements Trademarks and License . . . . . . . . . . . . . . . 183
Air Cleaner/Filter, Engine . . . . . . . . . . . . . . . . 279
Air Conditioning . . . . . . . . . . . . . . . . . . . . .192, 196
Air Filter
Life System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Air Filter, Passenger Compartment . . . . . . . 197
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
How Does an Airbag Restrain? . . . . . . . . . . 58
Passenger Sensing System . . . . . . . . . . . . . . 59
What Makes an Airbag Inflate? . . . . . . . . . 58
What Will You See after an AirbagInflates? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
When Should an Airbag Inflate? . . . . . . . . 57
Where Are the Airbags? . . . . . . . . . . . . . . . . 55 Airbags
Adding Equipment to the Vehicle . . . . . . . 63
Passenger Status Indicator . . . . . . . . . . . . . 106
Readiness Light . . . . . . . . . . . . . . . . . . . . . . . . 105
Servicing Airbag-Equipped Vehicles . . . . . . 63
System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Alarm
Vehicle Security . . . . . . . . . . . . . . . . . . . . . . . . 25
Alert Lane Change . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Side Blind Zone (SBZA) . . . . . . . . . . . . . . . . . 250
All-Season Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 301
All-Terrain Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 302
All-Wheel Drive . . . . . . . . . . . . . . . . . . . . . 224, 289
AM-FM Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Antenna Multi-band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Antilock Brake System (ABS) . . . . . . . . . . . . . 224 Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . 110
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 341
Apple CarPlay and Android Auto . . . . . . . . . . 173
Armrest Storage . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Assistance Program, Roadside . . . . . . . . . . . . 366
Assistance Systems for Driving . . . . . . . . . . 245
Assistance Systems for Parking and Backing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-14608671) - 2021 - CRC - 10/26/20
384 Index
AudioBluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Auto Stop Stop/Start System . . . . . . . . . . . . . . . . . . . . . 215
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . . . . . . . . 28
Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Emergency Braking (AEB) . . . . . . . . . . . . . . 247
Headlamp System . . . . . . . . . . . . . . . . . . . . . 133
Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Transmission Fluid . . . . . . . . . . . . . . . . . . . . . 279
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . . . . . . . . . 223
Avoiding Untrusted Media Devices . . . . . . . .147
B
Battery Exterior Lighting Battery Saver . . . . . . . . . 137
Load Management . . . . . . . . . . . . . . . . . . . . . 136
Power Protection . . . . . . . . . . . . . . . . . . . . . . . 137
Battery - North America . . . . . . . . . . . . 288, 332
Blade Replacement, Wiper . . . . . . . . . . . . . . . 290
Bluetooth
Overview . . . . . . . . . . . . . . . . . . . . . . . . . 168, 169
Bluetooth Audio . . . . . . . . . . . . . . . . . . . . . . . . . 150
Brake Electric Boost . . . . . . . . . . . . . . . . . . . . . . . . . . 224
Parking, Electric . . . . . . . . . . . . . . . . . . . . . . . . 224 Brake (cont'd)
System Warning Light . . . . . . . . . . . . . . . . . 108
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287 Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Automatic Emergency (AEB) . . . . . . . . . . . 247
Braking System Front Pedestrian (FPB) . . . . . . . . . . . . . . . . . 248
Break-In, New Vehicle . . . . . . . . . . . . . . . . . . . . . 212
Bulb Replacement Halogen Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . 292
Headlamp Aiming . . . . . . . . . . . . . . . . . . . . . . 292
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Buying New Tires . . . . . . . . . . . . . . . . . . . . . . . . . 315
C
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
California
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . . . . . . . . . . 268
California Proposition 65 Warning . . . . . . . . . . . . . . . . . . 268, 288, 332, Back Cover
Canadian Vehicle Owners . . . . . . . . . . . . . . . . . . . 1
Capacities and Specifications . . . . . . . . . . . . . 359 Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . . . . . . . . . . 219
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . . 208
Cargo Management System . . . . . . . . . . . . . . . . . . . 85
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Caution, Danger, and Warning . . . . . . . . . . . . . .2
Center Console Storage . . . . . . . . . . . . . . . . . . . 84
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .318
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Charging System Light . . . . . . . . . . . . . . . . . . . 107
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Child Restraints Infants and Young Children . . . . . . . . . . . . . 66
Lower Anchors and Tethers forChildren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Older Children . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Securing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78, 80
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Cleaning Exterior Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 337
Interior Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 341

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-14608671) - 2021 - CRC - 10/26/20
Index 385
Climate Control SystemsDual Automatic . . . . . . . . . . . . . . . . . . . . . . . . 192
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Cluster, Instrument . . . . . . . . . . . . . . . . . . 97, 100
Collision Damage Repair . . . . . . . . . . . . . . . . . 369
Compact Spare Tire . . . . . . . . . . . . . . . . . . . . . . . 331
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Compressor Kit, Tire Sealant . . . . . . . . . . . . . 320
Connected Services Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 381
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 382
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380
Connections
Connected Services . . . . . . . . . . . . . . . . . . . . 381
Control Hill Descent . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Traction and Electronic Stability . . . . . . . 226
Control Light
Hill Descent . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Control of a Vehicle . . . . . . . . . . . . . . . . . . . . . 201
Controls Steering Wheel . . . . . . . . . . . . . . . . . . . . . . . . 140
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Coolant
Engine Temperature Gauge . . . . . . . . . . . . 104
Engine Temperature Warning Light . . . . . 112
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192, 196
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . .281
Courtesy Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Courtesy Transportation Program . . . . . . . . 368
Coverage Explanations . . . . . . . . . . . . . . . . . . . 163
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 230 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Cruise Control, Adaptive . . . . . . . . . . . . . . . . . 232
Customer Assistance . . . . . . . . . . . . . . . . . . . . . 365
Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 365
Text Telephone (TTY) Users . . . . . . . . . . . . 365
Customer Information Publications Ordering Information . . . . . . 371
Customer Satisfaction Procedure . . . . . . . . . 363
Cybersecurity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373
D
Damage Repair, Collision . . . . . . . . . . . . . . . . . 369
Danger, Warning, and Caution . . . . . . . . . . . . . .2
Data Collection Infotainment System . . . . . . . . . . . . . . . . . . 374
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374
Data Recorders, Event . . . . . . . . . . . . . . . . . . . 373
Database Coverage Explanations . . . . . . . . . 163 Daytime Running Lamps (DRL) . . . . . . . . . . . . 133
Defensive Driving . . . . . . . . . . . . . . . . . . . . . . . . 201
Delayed Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Diagnostics
Connected Services . . . . . . . . . . . . . . . . . . . . 382
Distracted Driving . . . . . . . . . . . . . . . . . . . . . . . . 200
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Door
Ajar Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Delayed Locking . . . . . . . . . . . . . . . . . . . . . . . . . 17
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Drive Belt Routing, Engine . . . . . . . . . . . . . . . 362
Drive Systems All-Wheel Drive . . . . . . . . . . . . . . . . . . . 224, 289
Driver Teen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Driver Assistance Systems . . . . . . . . . . . . . . . 239
Driver Information Center (DIC) . . . . . . . 115, 117
Driver Mode Control . . . . . . . . . . . . . . . . . . . . . 228
Driving Assistance Systems . . . . . . . . . . . . . . . . . . . . 245
Better Fuel Economy . . . . . . . . . . . . . . . . . . . 200
Characteristics and Towing Tips . . . . . . . . 256
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Hill and Mountain Roads . . . . . . . . . . . . . . 207
If the Vehicle is Stuck . . . . . . . . . . . . . . . . . 209

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-14608671) - 2021 - CRC - 10/26/20
386 Index
Driving (cont'd)Impaired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Loss of Control . . . . . . . . . . . . . . . . . . . . . . . . 203
Off-Road . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 203
Vehicle Load Limits . . . . . . . . . . . . . . . . . . . . 209
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
E
Electric Brake Boost . . . . . . . . . . . . . . . . . . . . . . 224
Electric Parking Brake . . . . . . . . . . . . . . . . . . . . 224
Electric Parking Brake Light . . . . . . . . . . . . . . 109
Electrical Equipment, Add-On . . . . . . . . . . . . 266
Electrical SystemEngine Compartment Fuse Block . . . . . . . 293
Fuses and Circuit Breakers . . . . . . . . . . . . . 293
Instrument Panel Fuse Block . . . . . . . . . . . 296
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Rear Compartment Fuse Block . . . . . . . . . 298
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . . . . . . 279
Check Light (Malfunction Indicator) . . . . 107
Compartment Overview . . . . . . . . . . . . . . . . . 271 Engine (cont'd)
Coolant Temperature Gauge . . . . . . . . . . . 104
Coolant Temperature Warning Light . . . . 112
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . 281
Drive Belt Routing . . . . . . . . . . . . . . . . . . . . . 362
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Oil Life System . . . . . . . . . . . . . . . . . . . . . . . . 278
Oil Pressure Light . . . . . . . . . . . . . . . . . . . . . . . 113
Overheating . . . . . . . . . . . . . . . . . . . . . . . . . . . 285
Power Messages . . . . . . . . . . . . . . . . . . . . . . . 123
Running While Parked . . . . . . . . . . . . . . . . . 220
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
Engine Air Filter Life System . . . . . . . . . . . . . 279
Engine Oil Temperature Gauge . . . . . . . . . . . . . . . . . . . . 103
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Equipment, Towing . . . . . . . . . . . . . . . . . . . . . . 262
Event Data Recorders . . . . . . . . . . . . . . . . . . . . 373
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Extended Parking . . . . . . . . . . . . . . . . . . . . . . . . 219
Extender, Seat Belt . . . . . . . . . . . . . . . . . . . . . . . .53
Exterior Lamp Controls . . . . . . . . . . . . . . . . . . . . 131
Exterior Lamps Off Reminder . . . . . . . . . . . . . 132
Exterior Lighting Battery Saver . . . . . . . . . . . 137
F
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . . . . . . 279
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Flashers, Hazard Warning . . . . . . . . . . . . . . . . .134
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 319 Changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 326
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 343
Fluid Automatic Transmission . . . . . . . . . . . . . . . 279
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
Fog Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Forward Collision Alert (FCA) System . . . . 245
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 371
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Front Pedestrian Braking (FPB) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Heated and Ventilated . . . . . . . . . . . . . . . . . . 41
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Economy, Driving for Better . . . . . . . . . . . 200
Filling a Portable Fuel Container . . . . . . . 256
