remote start GMC SAVANA 2021 User Guide

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
Vehicle Care 237
To avoid the possibility of the vehicles
rolling, set the parking brake firmly on
both vehicles involved in the jump start
procedure. Put an automatic transmission
in P (Park) or a manual transmission in
Neutral before setting the parking brake.
Caution
If any accessories are left on or plugged
in during the jump starting procedure,
they could be damaged. The repairs
would not be covered by the vehicle
warranty. Whenever possible, turn off or
unplug all accessories on either vehicle
when jump starting.
3. Turn the ignition off on both vehicles. Unplug unnecessary accessories plugged
into the cigarette lighter or the accessory
power outlet. Turn off the radio and all
lamps that are not needed. This will
avoid sparks and help save both
batteries. And it could save the radio!
4. Open the hoods and locate the positive (+) and negative (−) terminal
locations of the other vehicle.
On your van, use the unpainted radio
antenna bracket as a remote negative (−)
terminal.
{Warning
Using a match near a battery can cause
battery gas to explode. People have been
hurt doing this, and some have been
blinded. Use a flashlight if you need
more light.
Battery fluid contains acid that can burn
you. Do not get it on you. If you
accidentally get it in your eyes or on
your skin, flush the place with water and
get medical help immediately.
{Warning
Fans or other moving engine parts can
injure you badly. Keep your hands away
from moving parts once the engine is
running.
5. Check that the jumper cables do not have loose or missing insulation. If they
do, you could get a shock. The vehicles
could be damaged too.
Before you connect the cables, here are
some basic things you should know.
Positive (+) will go to positive (+) or to a
remote positive (+) terminal if the vehicle has one. Negative (−) will go to an
unpainted metal part or to a remote
negative (−) terminal if the vehicle has
one. On your van, use the unpainted
radio antenna bracket as a remote
negative (−) terminal.
Do not connect positive (+) to
negative (−) or you will get a short that
would damage the battery and maybe
other parts too. And do not connect the
negative (−) cable to the negative (−)
terminal on the dead battery because
this can cause sparks.
6. Connect the red positive (+) cable to the
positive (+) terminal of the dead battery.
Use a remote positive (+) terminal if the
vehicle has one. Do not let the other end

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
238 Vehicle Care
touch metal. Connect it to the
positive (+) terminal of the good battery.
Use a remote positive (+) terminal if the
vehicle has one.
7. Now connect the black negative (−) cable to the negative (−) terminal of the good
battery. Use a remote negative (−)
terminal if the vehicle has one.
Do not let the other end touch anything
until the next step. The other end of the
negative (−) cable does not go to the
dead battery. It goes to a heavy,
unpainted metal engine part or to a
remote negative (−) terminal on the
vehicle with the dead battery. On your
van, use the unpainted radio antenna
bracket as a remote negative (−)
terminal.
8. Connect the other end of thenegative (−) cable to the negative (−)
terminal location on the vehicle with the
dead battery. On your van, use the
unpainted radio antenna bracket as a
remote negative (−) terminal.
Caution
The vehicle uses the unpainted radio
antenna bracket as a remote negative (-)
terminal. Move the antenna coaxial cable
out of the way before clamping the
negative jumper cable to the fixed
antenna bracket. Avoid touching the
negative cable clamp to the air
conditioning line. Failure to do either of
(Continued)
Caution (Continued)
these could damage the vehicle. The
repairs would not be covered by the
vehicle warranty.
9. Now start the vehicle with the good battery and run the engine for a while.
10. Try to start the vehicle that had the dead battery. If it will not start after a
few tries, it probably needs service.
Caution
If the jumper cables are connected or
removed in the wrong order, electrical
shorting may occur and damage the
vehicle. The repairs would not be covered
by the vehicle warranty. Always connect
and remove the jumper cables in the
correct order, making sure that the cables
do not touch each other or other metal.
Jumper Cable Removal
Reverse the sequence exactly when
removing the jumper cables.
After starting the disabled vehicle and
removing the jumper cables, allow it to idle
for several minutes.

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
266 Customer Information
Services Provided
.Emergency Fuel Delivery:Delivery of
enough fuel for the vehicle to get to the
nearest service station.
.Lock-Out Service: Service to unlock the
vehicle if you are locked out. A remote
unlock may be available if you have
OnStar. For security reasons, the driver
must present identification before this
service is given.
.Emergency Tow from a Public Road or
Highway: Tow to the nearest GMC dealer
for warranty service, or if the vehicle was
in a crash and cannot be driven.
Assistance is not given when the vehicle
is stuck in the sand, mud, or snow.
.Flat Tire Change: Service to change a flat
tire with the spare tire. The spare tire,
if equipped, must be in good condition
and properly inflated. It is the owner's
responsibility for the repair or
replacement of the tire if it is not covered
by the warranty.
.Battery Jump Start: Service to jump start
a dead battery.
.Trip Interruption Benefits and Assistance:
If your trip is interrupted due to a
warranty event, incidental expenses may
be reimbursed within the Powertrain warranty period. Items considered are
reasonable and customary hotel, meals,
rental car, or a vehicle being delivered
back to the customer, up to 500 miles.
Services Not Included in Roadside
Assistance
.Impound towing caused by violation of
any laws
.Legal fines
.Mounting, dismounting, or changing of
snow tires, chains, or other traction
devices
Service is not provided if a vehicle is in an
area that is not accessible to the service
vehicle or is not a regularly traveled or
maintained public road, which includes ice
and winter roads. Off-road use is not
covered.
Services Specific to Canadian-Purchased
Vehicles
.Fuel Delivery: Reimbursement is up to 7 L.
Diesel fuel delivery may be restricted.
Propane and other fuels are not provided
through this service.
.Lock-Out Service: Vehicle registration is
required.
.Trip Interruption Benefits and Assistance:
Must be over 150 km from where your
trip was started to qualify.
Pre-authorization, original detailed
receipts, and a copy of the repair orders
are required. Once authorization has been
received, the Roadside Assistance advisor
will help to make arrangements and
explain how to receive payment.
.Alternative Service: If assistance cannot
be provided right away, the Roadside
Assistance advisor may give permission to
get local emergency road service. You will
receive payment, up to $100, after
sending the original receipt to Roadside
Assistance. Mechanical failures may be
covered, however any cost for parts and
labor for repairs not covered by the
warranty are the owner’s responsibility.
Scheduling Service Appointments
When the vehicle requires warranty service,
contact your dealer and request an
appointment. By scheduling a service
appointment and advising the service
consultant of your transportation needs,
your dealer can help minimize your
inconvenience.

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
274 OnStar
.Receive a Diagnostic check of the vehicle's
key operating systems.
.Receive Roadside Assistance.
.Manage Wi-Fi Settings, if equipped.
Press
>to get a priority connection to an
OnStar Advisor available 24/7 to:
.Get help for an emergency.
.Be a Good Samaritan or respond to an
AMBER Alert.
.Get assistance in severe weather or other
crisis situations and find evacuation
routes.
OnStar Services
Emergency
Emergency Services require an active safety
and security plan. With Automatic Crash
Response, built-in sensors can automatically
alert a specially trained OnStar Advisor who
is immediately connected in to the vehicle
to help.
Press
>for a priority connection to an
OnStar Advisor who can contact emergency
service providers, direct them to your exact
location, and relay important information. With OnStar Crisis Assist, specially trained
Advisors are available 24 hours a day, 7 days
a week, to provide a central point of
contact, assistance, and information during a
crisis.
With Roadside Assistance, Advisors can
locate a nearby service provider to help with
a flat tire, a battery jump, or an empty
gas tank.
Security
If equipped, OnStar provides these services:
.With Stolen Vehicle Assistance, OnStar
Advisors can use GPS to pinpoint the
vehicle and help authorities quickly
recover it.
.With Remote Ignition Block, if equipped,
OnStar can block the engine from being
restarted.
.With Stolen Vehicle Slowdown,
if equipped, OnStar can work with law
enforcement to gradually slow the
vehicle down.
Theft Alarm Notification
If equipped, if the doors are locked and the
vehicle alarm sounds, a notification by text,
e-mail, or phone call will be sent. If the
vehicle is stolen, an OnStar Advisor can work
with authorities to recover the vehicle.
OnStar Additional
Information
In-Vehicle Audio Messages
Audio messages may play important
information at the following times:
.Prior to vehicle purchase. PressQto set
up an account.
.After change in ownership and at
90 days.
Transferring Service
PressQto request account transfer
eligibility information. The Advisor can
cancel or change account information.
Selling/Transferring the Vehicle
Call 1-888-4ONSTAR (1-888-466-7827)
immediately to terminate your OnStar or
connected services if the vehicle is disposed
of, sold, transferred, or if the lease ends.

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
276 OnStar
Languages
The vehicle can be programmed to respond
in multiple languages. Press
Qand ask for
an Advisor. Advisors are available in English,
Spanish, and French. Available languages
may vary by country.
Potential Issues
OnStar cannot perform Remote Door Unlock
or Stolen Vehicle Assistance after the vehicle
has been off continuously for 10 days
without an ignition cycle. If the vehicle has
not been started for 10 days, OnStar can
contact Roadside Assistance or a locksmith
to help gain access to the vehicle.
Global Positioning System (GPS)
.Obstruction of the GPS can occur in a
large city with tall buildings; in parking
garages; around airports; in tunnels and
underpasses; or in an area with very
dense trees. If GPS signals are not
available, the OnStar system should still
operate to call OnStar. However, OnStar
could have difficulty identifying the exact
location.
.In emergency situations, OnStar can use
the last stored GPS location to send to
emergency responders. A temporary loss of GPS can cause loss of
the ability to send a Turn-by-Turn
Navigation route. The Advisor may give a
verbal route or may ask for a call back after
the vehicle is driven into an open area.
Cellular and GPS Antennas
Cellular reception is required for OnStar to
send remote signals to the vehicle. Do not
place items over or near the antenna to
prevent blocking cellular and GPS signal
reception.
Unable to Connect to OnStar Message
If there is limited cellular coverage or the
cellular network has reached maximum
capacity, this message may come on. Press
Qto try the call again or try again after
driving a few miles into another
cellular area.
Vehicle and Power Issues
OnStar services require a vehicle electrical
system, wireless service, and GPS satellite
technologies to be available and operating
for features to function properly. These
systems may not operate if the battery is
discharged or disconnected.
Add-on Electrical Equipment
The OnStar system is integrated into the
electrical architecture of the vehicle. Do not
add any electrical equipment. See Add-On
Electrical Equipment 0176. Added electrical
equipment may interfere with the operation
of the OnStar system and cause it to not
operate.
Vehicle Software Updates
OnStar or GM may remotely deliver
software updates or changes to the vehicle
without further notice or consent. These
updates or changes may enhance or
maintain safety, security, or the operation
of the vehicle or the vehicle systems.
Software updates or changes may affect or
erase data or settings that are stored in the
vehicle, such as saved navigation
destinations or pre-set radio stations.
Neither OnStar nor GM is responsible for
any affected or erased data or settings.
These updates or changes may also collect
personal information. Such collection is
described in the OnStar privacy statement or
separately disclosed at the time of
installation. These updates or changes may
also cause a system to automatically
communicate with GM servers to collect
information about vehicle system status,

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
Connected Services 279
PressQ, then ask the Advisor to download
directions to the vehicle’s navigation system,
if equipped. After the call ends, the
navigation screen will provide prompts to
begin driving directions. Routes that are sent
to the navigation screen can only be
canceled through the navigation system.
See www.onstar.com (U.S.) or www.onstar.ca
(Canada).
Connections
The following services help with staying
connected.
For coverage maps, see www.onstar.com
(U.S.) or www.onstar.ca (Canada).
Ensuring Security
.Change the default passwords for the
Wi-Fi hotspot and myGMC mobile
application. Make these passwords
different from each other and use a
combination of letters and numbers to
increase the security.
.Change the default name of the SSID
(Service Set Identifier). This is your
network’s name that is visible to other
wireless devices. Choose a unique name
and avoid family names or vehicle
descriptions. Wi-Fi Hotspot (If Equipped)
The vehicle may have a built-in Wi-Fi
hotspot that provides access to the Internet
and web content at 4G LTE speed. Up to
seven mobile devices can be connected.
A data plan is required. Use the in-vehicle
controls only when it is safe to do so.
1. To retrieve Wi-Fi hotspot information, press
=to open the OnStar app on the
infotainment display, then select Wi-Fi
Hotspot. On some vehicles, touch Wi-Fi
or Wi-Fi Settings on the screen.
2. The Wi-Fi settings will display the Wi-Fi hotspot name (SSID), password, and on
some vehicles, the connection type (no
Internet connection, 3G, 4G, 4G LTE), and
signal quality (poor, good, excellent). The
LTE icon shows connection to Wi-Fi. It is
possible that the icon may not illuminate
even though the vehicle has an active
connection.
3. To change the SSID or password, press
Qor call 1-888-4ONSTAR to connect
with an Advisor. On some vehicles, the
SSID and password can be changed in
the Wi-Fi Hotspot menu. After initial set-up, your vehicle’s Wi-Fi
hotspot will connect automatically to your
mobile devices. Manage data usage by
turning Wi-Fi on or off on your mobile
device, using the myGMC mobile app, or by
contacting an OnStar Advisor. On some
vehicles, Wi-Fi can also be managed from
the Wi-Fi Hotspot menu.
MyGMC Mobile App (If Available)
Download the myGMC mobile app to
compatible Apple and Android smartphones.
GMC users can access the following services
from a smartphone:
.Remotely start/stop the vehicle,
if factory-equipped.
.Lock/unlock doors, if equipped with
automatic locks.
.Activate the horn and lamps.
.Check the vehicle’s fuel level, oil life,
or tire pressure, if factory-equipped with
the Tire Pressure Monitor System.
.Send destinations to the vehicle.
.Locate the vehicle on a map (U.S.
market only).
.Turn the vehicle's Wi-Fi hotspot on/off,
manage settings, and monitor data
consumption, if equipped.
.Locate a dealer and schedule service.

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
280 Connected Services
.Request Roadside Assistance.
.Set a parking reminder with pin drop,
take a photo, make a note, and set a
timer.
.Connect with GMC on social media.
Features are subject to change. For myGMC
mobile app information and compatibility,
see my.gmc.com.
An active OnStar or connected service plan
may be required. A compatible device,
factory-installed remote start, and power
locks are required. Data rates apply. See
www.onstar.com for details and system
limitations.
Remote Services
Contact an OnStar Advisor to unlock the
doors or sound the horn and flash the
lamps.
Marketplace
OnStar Advisors can provide offers from
restaurants and retailers on your route, help
locate hotels, or book a room. These services
vary by market.
Diagnostics
By monitoring and reporting on the vehicle's
key systems, OnStar Advanced Diagnostics,
if equipped, provides a way to keep up on
maintenance. Capabilities vary by model.
See www.onstar.com for details and system
limitations. Features are subject to change.
For updates on feature capabilities, see
my.gmc.com. Message and data rates may
apply.

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
Index 285
General Information (cont'd)Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Glass, Enhanced Technology . . . . . . . . . . . . . . . 21
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Hazard Warning Flashers . . . . . . . . . . . . . . . . . 92
Head Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . 202
Daytime Running Lamps (DRL) . . . . . . . . . . 91
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
High-Beam On Light . . . . . . . . . . . . . . . . . . . . 81
High/Low Beam Changer . . . . . . . . . . . . . . . 91
Heated Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Heater Engine Coolant . . . . . . . . . . . . . . . . . . . . . . . . 138
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . 119, 121, 122
High-Beam On Light . . . . . . . . . . . . . . . . . . . . . . .81
Hill and Mountain Roads . . . . . . . . . . . . . . . . 129
Hill Start Assist (HSA) . . . . . . . . . . . . . . . . . . . . 146
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
How to Wear Seat Belts Properly . . . . . . . . . 29 HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119, 121, 122
I
Idle System
Fast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Ignition Positions . . . . . . . . . . . . . . . . . . . . . . . . . 135
Ignition Transmission Lock Check . . . . . . . . 201
Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Indicator Vehicle Ahead . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Infants and Young Children, Restraints . . . . 47
Information Publication Ordering . . . . . . . . . . . . . . . . . . . 269
Infotainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Infotainment System . . . . . . . . . . . . . . . . . . . . 272
Instrument Cluster . . . . . . . . . . . . . . . . . . . . . . . . . 71
Instrument Panel Overview . . . . . . . . . . . . . . . . 4
Interior Rearview Mirrors . . . . . . . . . . . . . . . . . .19
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
J
Jump Starting - North America . . . . . . . . . . . 236
K
Keyless Entry Remote (RKE) System . . . . . . . . . . . . . . . . . . . . 8
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
L
Labeling, Tire Sidewall . . . . . . . . . . . . . . . . . . . . 212 Lamps
Daytime Running (DRL) . . . . . . . . . . . . . . . . . 91
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Exterior Controls . . . . . . . . . . . . . . . . . . . . . . . . 90
Exterior Lamps Off Reminder . . . . . . . . . . . 90
Exterior Lighting Battery Saver . . . . . . . . . 95
License Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Malfunction Indicator (Check
Engine) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Taillamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Lamps, Bulb Replacement . . . . . . . . . . . . . . . . 202
Lane Departure Warning (LDW) . . . . . . . . . . . 157
Lane Departure Warning Light . . . . . . . . . . . . 79
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . . . . . . . 31
LATCH System Replacing Parts after a Crash . . . . . . . . . . . 58
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Lighter, Cigarette . . . . . . . . . . . . . . . . . . . . . . . . . 70
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Illumination Control . . . . . . . . . . . . . . . . . . . . 93
Lights
Airbag On-Off . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Airbag Readiness . . . . . . . . . . . . . . . . . . . . . . . 74

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
Index 287
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
OnStar Additional Information . . . . . . . . . . . 274
OnStar Emergency . . . . . . . . . . . . . . . . . . . . . . . 274
OnStar Overview . . . . . . . . . . . . . . . . . . . . . . . . . 273
OnStar Security . . . . . . . . . . . . . . . . . . . . . . . . . . 274
OnStar System . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
OperationInfotainment System . . . . . . . . . . . . . . . . . . 100
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Overheating, Engine . . . . . . . . . . . . . . . . . . . . . 194
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97, 99
Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . 4
P
ParkShifting Into . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Shifting Out of . . . . . . . . . . . . . . . . . . . . . . . . 140
Park Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Brake and P (Park) Mechanism
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Over Things That Burn . . . . . . . . . . . . . . . . . . 141
Perchlorate Materials Requirements, California . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 Phone
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Power Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Protection, Battery . . . . . . . . . . . . . . . . . . . . . . 95
Retained Accessory (RAP) . . . . . . . . . . . . . . 138
Seat Adjustment . . . . . . . . . . . . . . . . . . . . . . . . 23
Steering Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Pregnancy, Using Seat Belts . . . . . . . . . . . . . . .35
Privacy Vehicle Data Recording . . . . . . . . . . . . . . . . . 271
Program Courtesy Transportation . . . . . . . . . . . . . . . 267
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . . . . . . .158
Proposition 65 Warning, California . . . . . . . . . . . . . . . . . . . . .178, 198, 236, Back Cover
Publication Ordering Information . . . . . . . . 269
R
Radio Frequency Statement . . . . . . . . . . . . . . 270
Radio Reception . . . . . . . . . . . . . . . . . . . . . . . . . 103
Radios
AM-FM Radio . . . . . . . . . . . . . . . . . . . . . . . . . . 101 Radios (cont'd)
Satellite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Reading Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199 Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Rear Climate Control System . . . . . . . . . . . . . 122
Rear Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Rear Heating System . . . . . . . . . . . . . . . . . . . . . 121
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Rear Vision Camera (RVC) . . . . . . . . . . . . . . . . . 152
Rear Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Rearview Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . .19
Reclining Seatbacks . . . . . . . . . . . . . . . . . . . . . . . .23
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Recommended Fluids and Lubricants . . . . . 255
Records
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Recreational Vehicle Towing . . . . . . . . . . . . . 239
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Remote Keyless Entry (RKE) System . . . . . . . 8
Remote Vehicle Start . . . . . . . . . . . . . . . . . . . . . 10
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Replacing Airbag System . . . . . . . . . . . . . . . . . . 45

GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-14583543) -
2021 - crc - 7/10/20
288 Index
Replacing LATCH System Parts after aCrash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Reporting Safety Defects Canadian Government . . . . . . . . . . . . . . . . . 270
General Motors . . . . . . . . . . . . . . . . . . . . . . . . . 271
U.S. Government . . . . . . . . . . . . . . . . . . . . . . . 270
Restraints Where to Put . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Retained Accessory Power (RAP) . . . . . . . . . .138
Roads
Driving, Wet . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Roadside Assistance Program . . . . . . . . . . . . 265
Rotation, Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Routing, Engine Drive Belt . . . . . . . . . . . . . . . 261
Running the Vehicle While Parked . . . . . . . . 141
S
Safety Defects Reporting Canadian Government . . . . . . . . . . . . . . . . . 270
General Motors . . . . . . . . . . . . . . . . . . . . . . . . . 271
U.S. Government . . . . . . . . . . . . . . . . . . . . . . . 270
Safety Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Safety System Check . . . . . . . . . . . . . . . . . . . . . .35
Satellite Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Scheduling Appointments . . . . . . . . . . . . . . . . 266
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Seat Belts (cont'd)
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
How to Wear Seat Belts Properly . . . . . . . 29
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . . . . . 31
Reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Replacing after a Crash . . . . . . . . . . . . . . . . . 36
Use During Pregnancy . . . . . . . . . . . . . . . . . . 35
Seats Adjustment, Front . . . . . . . . . . . . . . . . . . . . . . 22
Head Restraints . . . . . . . . . . . . . . . . . . . . . . . . . 22
Power Adjustment, Front . . . . . . . . . . . . . . . 23
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Reclining Seatbacks . . . . . . . . . . . . . . . . . . . . . 23
Securing Child Restraints . . . . . . . . . . . . . . 58, 60
Security Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Vehicle Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Accessories and Modifications . . . . . . . . . 178
Climate Control System . . . . . . . . . . . . . . . . . 119
Doing Your Own Work . . . . . . . . . . . . . . . . . 179
Maintenance Records . . . . . . . . . . . . . . . . . . 257
Maintenance, General Information . . . . . 248
Parts Identification . . . . . . . . . . . . . . . . . . . . . 258
Scheduling Appointments . . . . . . . . . . . . . . 266 Services
Special Application . . . . . . . . . . . . . . . . . . . . . 253
Servicing the Airbag . . . . . . . . . . . . . . . . . . . . . . 44
Shift Lock Control Function Check, Automatic Transmission . . . . . . . . . . . . . . . . 201
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Out of Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Side Blind Zone Alert (SBZA) . . . . . . . . . . . . . . 155
Side Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sidemarker Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . 202
Signals, Turn and Lane-Change . . . . . . . . . . . . 92
Sliding Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Special Application Services . . . . . . . . . . . . . . 253
Specifications and Capacities . . . . . . . . . . . . . 258
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
StabiliTrak OFF Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Start Assist, Hill . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Start Vehicle, Remote . . . . . . . . . . . . . . . . . . . . . 10
Starter Switch Check . . . . . . . . . . . . . . . . . . . . . 200
Starting the Engine . . . . . . . . . . . . . . . . . . . . . . 136
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127 Fluid, Power . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Wheel Adjustment . . . . . . . . . . . . . . . . . . . . . . 65
Wheel Controls . . . . . . . . . . . . . . . . . . . . . . . . . 66
