GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9955936) - 2017 - crc - 7/5/16
Vehicle Care 301
Turn the pressure cap slowly
counterclockwise about one full
turn. If a hiss is heard, wait for
that to stop. A hiss means
there is still some pressure left.
2. Keep turning the pressure cap slowly, and remove it.
3. Fill the coolant surge tank with the proper mixture to the FULL
COLD mark.
4. With the coolant surge tank pressure cap off, start the
engine and let it run until the
engine coolant temperature
gauge indicates approximately
90 °C (195 °F).
By this time, the coolant level
inside the coolant surge tank
may be lower. If the level is
lower, add more of the proper
mixture to the coolant surge
tank until the level reaches the
FULL COLD mark.
5. Replace the pressure cap tightly. 6. Verify coolant level after the
engine is shut off and the
coolant is cold. If necessary,
repeat coolant fill procedure
Steps 1–6.
Caution
If the pressure cap is not tightly
installed, coolant loss and
possible engine damage may
occur. Be sure the cap is properly
and tightly secured.
Engine Overheating
Caution
Running the engine without
coolant may cause damage or a
fire. Vehicle damage would not be
covered by the vehicle warranty.
The vehicle has several indicators
to warn of engine overheating. There is a coolant temperature
gauge in the vehicle's instrument
cluster. See
Engine Coolant
Temperature Gauge 0139.
In addition, there are ENGINE
OVERHEATED STOP ENGINE,
ENGINE OVERHEATED IDLE
ENGINE, and ENGINE POWER IS
REDUCED messages in the Driver
Information Center (DIC). See
Engine Cooling System Messages
0 161 andEngine Power
Messages 0162.
If the decision is made not to lift the
hood when this warning appears,
get service help right away.
If the decision is made to lift the
hood, make sure the vehicle is
parked on a level surface.
Check to see if the engine cooling
fan(s) are running. If the engine is
overheating, the fans should be
running. If they are not, do not
continue to run the engine, and
have the vehicle serviced.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9955936) - 2017 - crc - 7/5/16
304 Vehicle Care
Caution (Continued)
.When using concentrated
washer fluid, follow the
manufacturer instructions for
adding water.
. Fill the washer fluid tank
only three-quarters full when
it is very cold. This allows
for fluid expansion if
freezing occurs, which could
damage the tank if it is
completely full.
Brakes
Disc brake pads have built-in wear
indicators that make a high-pitched
warning sound when the brake pads
are worn and new pads are needed.
The sound can come and go or can
be heard all the time when the
vehicle is moving, except when
applying the brake pedal firmly.
{Warning
The brake wear warning sound
means that soon the brakes will
not work well. That could lead to
a crash. When the brake wear
warning sound is heard, have the
vehicle serviced.
Caution
Continuing to drive with worn-out
brake pads could result in costly
brake repair.
Some driving conditions or climates
can cause a brake squeal when the
brakes are first applied or lightly
applied. This does not mean
something is wrong with the brakes.
Properly torqued wheel nuts are
necessary to help prevent brake
pulsation. When tires are rotated,
inspect brake pads for wear and
evenly tighten wheel nuts in the proper sequence to torque
specifications. See
Capacities and
Specifications 0389.
Brake pads should be replaced as
complete sets.
Brake Pedal Travel
See your dealer if the brake pedal
does not return to normal height,
or if there is a rapid increase in
pedal travel. This could be a sign
that brake service may be required.
Replacing Brake System Parts
Always replace brake system parts
with new, approved replacement
parts. If this is not done, the brakes
may not work properly. The braking
performance expected can change
in many other ways if the wrong
replacement brake parts are
installed or if parts are improperly
installed.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9955936) - 2017 - crc - 7/5/16
Service and Maintenance 383
of leaking, blown seals,
or damage, and can advise
when service is needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel,
and can reduce the risk of tire
failure.
. Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the
rubber; cracks or cuts in the
tread or sidewall; or a bulge or
split in the tire.
. Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also
provide tire/wheel balancing
services to ensure smooth
vehicle operation at all speeds.
Your dealer sells and services
name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For information on how to clean and
protect the vehicle’s interior and
exterior, see
Interior Care 0369 and
Exterior Care 0365.
Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver
optimal wear and performance.
. Signs that the alignment may
need to be adjusted include
pulling, improper vehicle
handling, or unusual tire wear.
. Your dealer has the required
equipment to ensure proper
wheel alignment.
Windshield
For safety, appearance, and the
best viewing, keep the windshield
clean and clear.
. Signs of damage include
scratches, cracks, and chips.
. Trained dealer technicians can
inspect the windshield and
recommend proper replacement
if needed. Wiper Blades
Wiper blades need to be cleaned
and kept in good condition to
provide a clear view.
.
Signs of wear include streaking,
skipping across the windshield,
and worn or split rubber.
. Trained dealer technicians can
check the wiper blades and
replace them when needed.

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9955936) - 2017 - crc - 7/5/16
Index 419
Fluid (cont'd)Four-Wheel Drive
Transfer Case . . . . . . . . . . . . . . . 233
Washer . . . . . . . . . . . . . . . . . . . . . . . 303
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 186 Bulb Replacement . . . . . . . . . . . . 313
Folding Mirrors . . . . . . . . . . . . . . . . . . 55
Forward Automatic Braking . . . . . 257
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 255
Four-Wheel Drive . . . . . . . . . . 233, 306
Four-Wheel-Drive Light . . . . . . . . . 146
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 401
Front Axle . . . . . . . . . . . . . . . . . . . . . . 307
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Front Seats
Heated and Ventilated . . . . . . . . . . 68
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263 Additives . . . . . . . . . . . . . . . . . . . . . 264
Economy Driving . . . . . . . . . . . . . . . 26
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 267
Filling the Tank . . . . . . . . . . . . . . . 265
Foreign Countries . . . . . . . . . . . . 264
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 137
Low Fuel Warning Light . . . . . . . 150 Fuel (cont'd)
Management, Active . . . . . . . . . . 226
Requirements, California . . . . . 264
System Messages . . . . . . . . . . . . 162
Full-Size Spare Tire . . . . . . . . . . . . 356
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . 316 Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 316
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . 320, 323
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 325
G
Garage Door Opener . . . . . . . . . . . 177Programming . . . . . . . . . . . . . . . . . 177
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 139
Engine Oil Pressure . . . . . . . . . . 138
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Odometer . . . . . . . . . . . . . . . . . . . . . 137
Speedometer . . . . . . . . . . . . . . . . . 137
Tachometer . . . . . . . . . . . . . . . . . . . 137
Transmission Temperature . . . . 140
Trip Odometer . . . . . . . . . . . . . . . . 137
Voltmeter . . . . . . . . . . . . . . . . . . . . . 140
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 133 General Information
Service and Maintenance . . . . . 374
Towing . . . . . . . . . . . . . . . . . . . . . . . . 268
Vehicle Care . . . . . . . . . . . . . . . . . . 284
Glass Replacement . . . . . . . . . . . . . 312
Glove Box . . . . . . . . . . . . . . . . . . . . . . 120
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 395
H
Hazard Warning Flashers . . . . . . . 185
Head Restraints . . . . . . . . . . . . . . . . . 63
Head-up Display . . . . . . . . . . . . . . . . 155
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 312
Automatic . . . . . . . . . . . . . . . . . . . . . 184
Bulb Replacement . . . . . . . . . . . . 313
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 184
Flash-to-Pass . . . . . . . . . . . . . . . . . 183
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 313
High-Beam On Light . . . . . . . . . . 150
High/Low Beam Changer . . . . . 183
Lamps On Reminder . . . . . . . . . 151
Heated
Rear Seats . . . . . . . . . . . . . . . . . . . . . 70
Steering Wheel . . . . . . . . . . . . . . . 125

GMC Yukon/Yukon XL/Denali Owner Manual (GMNA-Localizing-U.S./
Canada/Mexico-9955936) - 2017 - crc - 7/5/16
422 Index
Mirrors (cont'd)Folding . . . . . . . . . . . . . . . . . . . . . . . . . 55
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 55
Manual Rearview . . . . . . . . . . . . . . . 57
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Tilt in Reverse . . . . . . . . . . . . . . . . . . 56
Mirrors, Interior Rearview . . . . . . . . 57
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 335
N
Navigation
OnStar®. . . . . . . . . . . . . . . . . . . . . . 407
Net, Convenience . . . . . . . . . . . . . . 122
New Vehicle Break-In . . . . . . . . . . . 216
Noise Control System . . . . . . . . . . 308
O
Object Detection System Messages . . . . . . . . . . . . . . . . . . . . . 163
Odometer . . . . . . . . . . . . . . . . . . . . . . . 137 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Off-Road . . . . . . . . . . . . . . . . . . . . . . . 203 Driving . . . . . . . . . . . . . . . . . . . . . . . . 203
Recovery . . . . . . . . . . . . . . . . . . . . . 202
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 290
Engine Oil Life System . . . . . . . 292
Engine Oil Pressure Gauge . . . 138 Oil (cont'd)
Messages . . . . . . . . . . . . . . . . . . . . 161
Pressure Light . . . . . . . . . . . . . . . . 149
Older Children, Restraints . . . . . . . 98
Online Owner Center . . . . . . . . . . . 394
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 403
OnStar
®Additional
Information . . . . . . . . . . . . . . . . . . . . 410
OnStar
®Connections . . . . . . . . . . . 407
OnStar®Diagnostics . . . . . . . . . . . . 409
OnStar®Emergency . . . . . . . . . . . . 406
OnStar®Navigation . . . . . . . . . . . . . 407
OnStar®Overview . . . . . . . . . . . . . . 405
OnStar®Security . . . . . . . . . . . . . . . 406
Operation Fog Lamps . . . . . . . . . . . . . . . . . . . 186
Ordering Service Publications . . . . . . . . . . 400
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 130
Overheating, Engine . . . . . . . . . . . . 301
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 224
Shifting Out of . . . . . . . . . . . . . . . . 225
Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . 237 Parking (cont'd)
Brake and P (Park)
Mechanism Check . . . . . . . . . . 310
Extended . . . . . . . . . . . . . . . . . . . . . 226
Over Things That Burn . . . . . . . 225
Parking Assist . . . . . . . . . . . . . . . . . . 252
Parking or Backing Assistance Systems . . . . . . . . . . 252
Passenger Airbag Status
Indicator . . . . . . . . . . . . . . . . . . . . . . 142
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Passenger Sensing System . . . . . 92
Perchlorate Materials Requirements, California . . . . . . 284
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . 170
Power
Door Locks . . . . . . . . . . . . . . . . . . . . . 42
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Outlets . . . . . . . . . . . . . . . . . . . . . . . 130
Protection, Battery . . . . . . . . . . . . 189
Retained Accessory (RAP) . . . 223
Seat Adjustment . . . . . . . . . . . . . . . . 64
Windows . . . . . . . . . . . . . . . . . . . . . . . 58
Power Assist Steps . . . . . . . . . . . . . . 49
Pregnancy, Using Safety Belts . . . 83
