GMC YUKON XL DENALI 2001 Owners Manual

2-84 Fuel

Each press of the FUEL button will change the
display between the fuel remaining range, average
fuel economy, instantaneous fuel economy and a
blank display.

The average fuel economy can be reset using the
RESET button.
Trip
Each press of the TRIP button will change the
display between personal trip computer, business trip
computer, timer, vehicle history, annual mileage and a
blank display.
Personal Trip Computer and Business
Trip Computer

Each press of the arrow button will change the
display between turn on/off, trip odometer, fuel used,
average fuel economy and average speed.

The ON/OFF button will turn the trip computer on
and off. The information on the trip computer only
gets updated when it is turned on. The personal and
business computers are independent, i.e. turning one
of them on does not turn the other off.
All information associated with the trip computer
will be reset when the RESET button is pressed.

If the RESET button is pressed and held for more
than two seconds, all of the trip computer settings
will reset starting from the last ignition cycle
(turning the ignition from OFF to RUN). This
feature is for someone who has forgotten to reset the
trip computer when pulling out of the driveway and
does not realize it until after driving for awhile.
Timer

Each press of the ON/OFF button will turn the timer
on or off.

The RESET button will reset the timer to 00:00:00.

If turned on, the timer will accumulate whenever
the SIC is powered (the engine does not have to
be running).

The timer will rollover after 99:59:59.

2-85
Vehicle History Last 15 Days

The first press of the arrow button will display the
maximum speed and accumulated mileage for the
current day.

Every press of the arrow button after will display the
maximum speed and accumulated mileage for the
previous day.

This feature requires the date and time to be set
correctly. Refer to the setting of day/date/time under
the MENU button explained later in this section.
Annual Mileage

The annual mileage displayed is the mileage
accumulated since the annual mileage was reset.

Pressing the RESET button will reset the annual
mileage to 0.

Pressing the arrow button will display the ratio of
personal trip computer mileage to annual mileage as
a percent.

Pressing the arrow button again will display the ratio
of business trip computer mileage to annual mileage
as a percent.Menu
Press the MENU button to choose a feature you would
like to personalize (the features are listed below). Each
press of the button will display a new item that can be
personalized. Use the arrow button to choose the setting
you would like to use within the chosen feature. For
example: Say you would like to personalize the
automatic door locks so that the automatic locking
feature is disabled. You would do the following:
1. First press the MENU button until you reach the
Automatic Door Lock screen.
2. Next, press the arrow button until you find the
Disabled setting.
3. The setting is now actually set without having to
do anything else. You can do one of three things at
this point:

You can leave the personalization mode by
pressing FUEL or TRIP. The SIC will then
display the day/date.

2-86

You can just let the SIC exit the personalization
mode on its own by waiting approximately
15 seconds without touching any buttons.
The SIC will then display the day/date.

Or you can press the MENU key to move on to
the next programmable feature.
The following is a list of the personal settings that can
be changed:
Automatic Door Lock

Enabled: Doors automatically lock when vehicle
speed is above 15 mph for two seconds.

Disabled: Doors do not lock automatically.
Automatic Door Unlock

Driver: Driver's door unlocks when the key is
removed from the ignition.

All: All doors unlock when the key is removed from
the ignition.

Disabled: Doors do not unlock automatically.Remote Lock Feedback

Horn: Horn chirps on second press of the LOCK
button on the keyless entry transmitter.

Lamps: Parking lamps flash on each press of the
LOCK button on the keyless entry transmitter.

Horn and Lamps: Parking lamps flash on each
press, horn chirps on second press of UNLOCK on
the keyless entry transmitter.

None: No horn or lamp feedback to the LOCK
button on the keyless entry transmitter.
Remote Unlock Feedback

Horn: Horn chirps on second press of the UNLOCK
button on the keyless entry transmitter.

Lamps: Parking lamps flash on each press of the
UNLOCK button on the keyless entry transmitter.

Horn and Lamps: Parking lamps flash on each
press, horn chirps on the second press of the
UNLOCK button on the keyless entry transmitter.

None: No horn or lamp feedback will occur when
the UNLOCK button on the keyless entry transmitter
is pressed.

2-87
Headlamp Delay

None: Headlamps do not stay on after the ignition is
turned to OFF.

10/20/30/60/120/180 Seconds: Amount of time
headlamps stay on after the ignition is turned to
OFF when it is dark (switch must be in auto
headlamp position).
Perimeter Lamps

Enabled: Parking lamps, headlamps and puddle
lamps turn on for 40 seconds with the UNLOCK
button on the keyless entry transmitter. This feature
only operates when it is dark.

Disabled: Feature disabled, no perimeter lamps will
come on.Alarm Warning

Horn: Horn will sound when alarm is active.

Lamps: Headlamps and park lamps will cycle on
and off when alarm is activated.

Horn and Lamps : Horn and lamps will alternate
when the alarm is activated.

None: No alarm warning will come on.
Language

English: All information displayed in English.

French: All information displayed in French.

Spanish: All information displayed in Spanish.

Arabic: All information displayed in Arabic.
Display Units

English: Units displayed in English units.

Metric: Units displayed in metric units.

2-88
Day/Date/Time

The RESET button will enable the operator to reset
the day/date/time. Each press of the RESET button
will scroll through the following: set year, set month,
set day, set hour, set minutes and set AM/PM.

Whichever is currently selected (i.e. year, month,
day, etc.) will flash. The arrow button is then used to
adjust the value. Each press of the arrow button will
change the value by one. If the arrow button is
pushed and held, the value will keep changing until
the button is released.

While in menu mode, the SIC will display the
day/date if no buttons have been pressed for more
than 15 seconds.Language and Personalization Reset
1. Press and hold the MENU button. After two seconds,
the display will begin cycling through the languages
at one second intervals. Release the MENU button
when the desired language is displayed.
2. The previous action will also reset the
personalization values to their factory default
settings which are as follows:

Automatic Door Lock: Disabled

Automatic Door Unlock: All

Remote Lock Feedback: Horn

Remote Unlock Feedback: Lamps

Headlamp Delay: 30 seconds

Perimeter Lamps: Enabled

Alarm Warning: Horn and Lamps

Display Units: English

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Electronic Climate Control System
3
-8 Air Conditioning
3
-8 Heating
3
-9 Defogging and Defrosting
3
-9 Rear Window Defogger
3
-10 Ventilation System
3
-11 Audio Systems
3
-11 Setting the Clock
3
-11 AM-FM Stereo with Cassette Tape Player3
-16 Rear Seat Audio (RSA)
3
-18 Compact Disc Changer
3
-21 Theft-Deterrent Feature
3
-23 Audio Steering Wheel Control
3
-24 Understanding Radio Reception
3
-24 Tips About Your Audio System
3
-25 Care of Your Cassette Tape Player
3
-26 Care of Your Compact Discs
3
-26 Care of Your Compact Disc Changer
3
-26 Fixed Mast Antenna

3-2
Comfort Controls
Electronic Climate Control System
Fan Knob
The knob on the left side of the electronic climate
control panel regulates the fan speed. To manually
increase airflow, move the knob clockwise. To manually
decrease airflow, move it counterclockwise.
OFF: If the knob is in OFF, outside air will still enter
the vehicle, and will be directed based on the position
of the mode knob.
AUTO: If the knob is in AUTO, the fan speed will vary
as the system maintains the selected temperature.When both the fan knob and mode knobs are in the
AUTO position, the system will then automatically
maintain the desired cabin temperature as selected
by the temperature knob. Manual operation is
also available.
Temperature Knob
The middle knob on the control panel lets you select
the desired air temperature in your vehicle. This knob
will allow you to adjust the interior air temperature
independent of the function knob setting. Move the
knob clockwise toward 82 for warmer air. Move the
knob counterclockwise toward 66 for cooler air. When
the system is set for automatic operation, sensors will
control the fan speed.
Full Hot: If you turn the temperature knob past 82
F
(28
C), the system will go into the ªfull hotº mode.
The system will remain at that maximum heating setting
and the fan will blow at the speed the fan knob is set to.
If the fan is in AUTO, it will run at full speed.
Full Cold: If you turn the temperature knob past 66
F
(19
C), the system will go into the ªfull coldº mode.
The system will remain at that maximum cooling setting
and the fan will blow at the speed the fan knob is set to.
If the fan is in AUTO, it will run at full speed.

3-3
Mode Knob - Automatic Operation
The right knob on the control panel allows you to
choose the direction of air delivery. When the system
is set in AUTO mode, sensors will control the air
delivery mode. Air will come primarily from the floor
or instrument panel outlets, with some air directed to
the windshield to prevent fogging.
When the system is in AUTO mode, the air conditioning
light will turn on, and the recirculation and outside air
lights turn off. With the system in full auto control
(both the fan and mode knobs in AUTO), you still
have the ability to override any function. However,
continually overriding the outside air or the A/C
compressor will limit the ability of the system to
cool the vehicle quickly.
If you push a button for a function which is not
available, the light next to that button will flash
three times to alert you that it's not available.
To find your comfort zone, start with the 74
F (23
C)
setting and allow about 20 minutes for the system to
adjust the temperature if necessary.With the automatic setting, the air conditioning
compressor automatically cycles when needed to cool
the air. In cold weather, when the system senses the need
for heat, the airflow will be directed out of the floor
outlets. As the interior temperature approaches a desired
setting, the fan speed will decrease. To maintain interior
comfort, the airflow will adjust between the instrument
panel air outlets and floor outlets. On bright sunny days
in cool weather, the airflow may come out of the air
conditioning and floor outlets (bi
-level mode) to
maintain comfort and prevent stuffiness.
To avoid blowing cold air in cold weather, the system
will delay turning on the fan until warm air is available.
The length of delay depends on the outside air
temperature, engine coolant temperature or the time
since the engine was last started. As the coolant warms
up, the fan speed will gradually increase and air will
flow from the heater outlets, with some airflow to
the windshield to prevent fogging under most
normal conditions.
Be careful not to put anything over the solar sensor
located around the center of the instrument panel.
This sensor is used by the automatic system to
regulate temperature.

3-4
Mode Knob - Manual Operation
The right knob on the control panel allows you to
choose the direction of air delivery.
You can choose to set the climate control system
operations yourself, or let the system work for you
by placing the system in AUTO mode. See ªMode
Knob
- Automatic Operationº earlier in this section.
VENT: This setting directs most of the air through
the instrument panel outlets and a small amount through
the floor outlets.
BI-LEVEL: This setting delivers air through the
floor outlets as well as the instrument panel outlets.
HEATER: This setting directs most of the
warmed air through the floor outlets and some air
through the windshield defroster outlets.
BLEND: This setting divides airflow equally
between the heater floor outlet and the windshield
defroster outlets. The air conditioning compressor may
run to dehumidify the air to prevent window fogging.
DEFROST: This setting directs most air through
the windshield defroster outlets and some through the
outlets. The air conditioning compressor may run to
dehumidify the air to prevent window fogging.
OUTSIDE AIR: This setting should be used
for normal system operation and directs the system
to use outside air. Using outside air will limit stale air
odors and help to prevent excessively humid interior air
(from wet boots or clothing or maximum passenger
loads) from being redirected onto windows.
Pressing the outside air button will cancel the
recirculation button.
RECIRCULATION: This setting limits the
amount of outside air entering the vehicle to a very small
amount. This will be helpful to limit odors entering the
vehicle and will assist in reaching comfort in very hot
temperature conditions. Pressing recirculation will cause
the system to recirculate interior air continuously and
may cause the vehicle windows to fog if the passenger
compartment floor is excessively wet.

3-5
Pressing the recirculation button will cancel outside
air operation. To return to normal system operation and
to prevent stale passenger compartment air, be sure to
return to the outside air position.
Recirculation will not be available in heater, blend or
defrost modes to help reduce window fogging. If the
recirculation button is pressed in theses modes, the
indicator light for recirculation will flash three times
indicating that forced outside air is activated and
recirculation is not available.
If the air conditioning system is activated and system
demand is high in situations such as city traffic, idling,
or very hot weather, the system will automatically
switch from outside air to recirculation. The indicator
light will not change. After demand on the system is
not so great, the system will return back to outside air. A/C: Press this button to turn the air
conditioning on and off. The system will cool and
dehumidify the air inside the vehicle when the A/C light
is on. When in AUTO, the A/C is automatically engaged
when necessary.
Air conditioning will be automatically disabled when
the outside temperature drops below a level at which air
conditioning is ineffective.
Rear Air Conditioning and Heating Systems
Your vehicle is equipped with a rear heating and air
conditioning system that can increase and decrease
airflow and temperature based on passenger needs.
Vehicles equipped with a sunroof will have the manual
control heating and air conditioning system. Vehicles
without a sunroof will be equipped with the Electronic
Climate Control System
