engine coolant HONDA ACCORD COUPE 2002 CL7 / 7.G Owners Manual

4-cylinder models6-cylinder models
6-cylinder models
The gauge stays at the same f uel
level reading af ter you turn of f the
ignition. When you add f uel, the
gauge slowly changes to the new
readingafteryouturntheignition
switch back ON (II).
The needle returns to the bottom
after you turn off the ignition. The
gauge shows the f uel level reading
immediately af ter you turn the
ignition switch back ON (II). This shows how much f uel you have.
It is most accurate when the car is on
level ground. It may show slightly
more or less than the actual amount
whenyouaredrivingoncurvyor
hilly roads.
This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.
There are two trip meters: Trip A
and Trip B. Switch between these
displays by pressing the Select/
Reset button repeatedly. Each trip
meter works independently, so you
can keep track of two dif f erent
distances.
To reset a trip meter, display it, and
then press and hold the Select/Reset
button until the number resets to
‘‘0.0’’.
Both trip meters will reset if the car’s
battery goes dead or is disconnected. This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise to near
the upper red mark. If it reaches the
red (Hot) mark, pull saf ely to the
side of the road. Turn to page f or
instructions and precautions on
checking the engine’s cooling
system.
324
Trip Meter
Temperature GaugeFuel Gauge
Gauges
Inst rument s and Cont rols64

CONT INUED
The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear window.Turn the temperature control dial
all the way to the lef t.
Make sure the A/C is of f .
Select and Fresh Air mode.
Set the f an to the desired speed.
This section covers how to set up the
system controls f or ventilation,
heating, cooling, dehumidif ying, and
def rosting.
The engine must be running f or the
heater and air conditioning to
generate hot and cold air. The heater
uses engine coolant to warm the air.
If the engine is cold, it will be several
minutes bef ore you f eel warm air
coming from the system.
The air conditioning does not rely on
engine temperature.
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep
these clear of leaves and other
debris.
It is best to leave the system in Fresh
Air mode under almost all conditions.
Keeping the system in Recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to Recirculation mode when
you are driving through smoky or
dusty conditions, then switch back to
Fresh Air mode when the condition clears.
1.
2.
3.
Heating and Cooling
Comf ort and Convenience Feat ures
Vent ilat ion
How to Use the System
111
T TE
EM
M P
PE
ER
RA A T
TU
UR REE
C
CO ON NTTR
RO OL L D
DI
IAA L
L
F
FA
A N
N C
COON NTTR
RO OL L D
DI
IAA L
L
A
AI
IRR C
COON NDDI
ITT I
IOON NIINNG G B
BUUT TT
TO
ON N
M
M
O
ODDE
E B
BUUT TT
TO
ON NSS
R
RE EC
CI IRRC CUUL LAA T
TI
IOON N B
BUUT TT
TO
ON N

When the interior has cooled down
to a more comf ortable temperature,
close the windows and set the
controls as described f or normal
cooling.Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
) when driving in stop-and-go
traf f ic or climbing a long, steep hill.
If it moves near the red zone, turn
of f the A/C until the gauge reads
normally.
If the interior is very warm f rom
beingparkedinthesun,youcancool
it down more rapidly by setting up
the controls this way: Turn on the A/C by pressing the
button. The light above the button
comesonwhenafanspeedis
selected.
Make sure the temperature
control dial is all the way to the left.
Select .
If the outside air is humid, select
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
Set the f an to the desired speed.
Start the engine.
Turn on the A/C by pressing the
button. Make sure the tempera-
ture control dial is turned all the
way to the left.
Set the f an to maximum speed.
Open the windows partially. Select
and Fresh Air mode.
1.
2.
3.
4. 1.
2.
3.
4.
5.
64
Comf ort and Convenience Feat ures
Heating and Cooling
T o Cool wit h A /C
112
T TE
EM
M P
PE
ER
RA A T
TU
UR REE
C
CO ON NTTR
RO OL L D
DI
IAA L
L
A
A I
IRR C
COON NDDI
ITT I
IOON NIINNG G B
BUUT TT
TO
ON N
R
RE EC
CI IRRC CUUL LAA T
TI
IOON N B
BUUT TT
TO
ON N
M
M
O
ODDE
E B
BUUT TT
TO
ON NSS
F
FA A N
N C
COON NTTR
RO OL L D
DI
IAA L
L

For saf ety, make sure you have a
clear view through all the windows
bef ore driving away.To shut of f the system temporarily,
turn the fan speed and temperature
control dials all the way to the lef t.
You should shut the system
completely of f only f or the f irst f ew
minutes of driving in cold weather,
until the engine coolant warms up
enough to operate the heater. Keep
the fan on at all other times so stale
air does not build up in the interior.
Start the engine.
Select .
When you select , the
system automatically switches to
Fresh Air mode and turns on the
A/C.
Switch the fan and temperature
controls to maximum.
To rapidly remove exterior f rost or
ice f rom the windshield (on very cold
days), f irst select the Recirculation
mode. Once the windshield is clear,
select the Fresh Air mode to avoid
f ogging the windows. These settings direct all the air f low
to the defroster vents at the base of
the windshield and the side window
def roster vents. The air f low will get
warmer and clear the windows faster
as the engine warms up. You can
close the side vents with the dial
underneath each vent. This will send
more warm air to the windshield
defroster vents.
To remove exterior f rost or ice f rom
the windshield and side windows
after the car has been sitting out in
cold weather:
1.
2.
3.
Heating and Cooling
Comf ort and Convenience Feat ures
To Turn Everything Of f
114

Bef ore you begin driving your Honda,
youshouldknowwhatgasolineto
use, and how to check the levels of
important f luids. You also need to
know how to properly store luggage
or packages. The inf ormation in this
section will help you. If you plan to
add any accessories to your car,
please read the inf ormation in this
section f irst..............................
Break-in Period .192
.........................................
Gasoline .192
.........
Service Station Procedures . 193
................
Filling the Fuel Tank . 193
....................
Opening the Hood .194
...............................
Oil Check .196
.........
Engine Coolant Check . 198
...............................
Fuel Economy .199
.....................
Vehicle Condition .199
...........................
Driving Habits .199
...
Accessories and Modif ications . 200
.............................
Carrying Cargo .202
Bef ore Driving
Bef ore Driving191

Refer toon page f or inf ormation
on checking other items in your
Honda.
Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page f or
inf ormation on adding the proper
coolant.
Remove the dipstick again and
check the level. It should be
between the upper and lower
marks.
If it is near or below the lower mark,
see on page .
4.
248 253245
Service Station Procedures
Bef ore Driving
Owner Maintenance
Checks
A dding
Engine Coolant
A dding Oil
Engine Coolant Check
198
M M I
INN
M
M
A
AX
X
M
M I
INN M
M
A
AX
X
R
RE
ES
SE ER
RV V E
E T
TA
A N
NK K
R
REES
SE ER
RV V E
E T
TA
A N
NK K
6
6- -c
cy yl liinn d
de
err m
m o
od
de
ellss
4
4- -c
cy yl liinn d
de
err m
m o
od
de
ellss
U
UP
PP
PE
ER
R M
M A
AR
RKK
L
LO OW WE ER
R M
M A
AR
RKK

This section also includes
Maintenance Schedules f or normal
driving and severe driving conditions,
a Maintenance Record, and instruc-
tions f or simple maintenance tasks
you may want to take care of
yourself .
If you have the skills and tools to per-
f orm more complex maintenance
tasks on your Honda, you may want
to purchase the Service Manual. See
page f or inf ormation on how to
obtain a copy, or see your Honda
dealer. This section explains why it is
important to keep your car well
maintained and to f ollow basic
maintenance saf ety precautions.......................
Maintenance Saf ety .234
.
Important Safety Precautions . 235
.................
Maintenance Schedule . 236
...
Required Maintenance Record . 243 .......
Owner Maintenance Checks . 245
..............................
Fluid Locations .246
......................................
Engine Oil .248
..................................
Adding Oil .248
....................
Recommended Oil .248
..............................
Synthetic Oil .250
....................................
Additives .250
.....
Changing the Oil and Filter . 250
.............................
Cooling System .253
............
Adding Engine Coolant . 253
.......
Replacing Engine Coolant . 255
....................
Windshield Washers .260
.......................
Transmission Fluid .261
Automatic .........................
Transmission .261
5-speed Manual .........................
Transmission .263
................
Brake and Clutch Fluid . 264
............................
Brake System .264
...........................
Clutch System .265
..............................
Power Steering .266
.....................
Air Cleaner Element .267
....................................
Hood Latch .269
Spark Plugs ..............
(4-cylinder Models) . 269
..............................
Replacement .269 ............................
Specif ications .270
Spark Plugs ..............
(6-cylinder Models) . 271
..............................
Replacement .271
............................
Specif ications .273
...........................................
Battery .274
.................................
Wiper Blades .277
..............
Air Conditioning System . 279
.................
Dust and Pollen Filter . 280
.....................................
Drive Belts .280
....................................
Timing Belt .281
...............................................
Tires .282
......................................
Inf lation .282
..................................
Inspection .283
..............................
Maintenance .284
.............................
Tire Rotation .285
...
Replacing Tires and Wheels . 285
......................
Wheels and Tires .286
..........................
Winter Driving .286
.............................
Snow Tires .287
............................
Tire Chains .287
.............................................
Lights .288
.....................
Headlight Aiming .290
........................
Replacing Bulbs .290
...........................
Storing Your Car .291
361
Maintenance
Maint enance233

µ
ÎÌ
Ì
Ì Î
Follow the Normal Conditions
Maintenance Schedule if the
severe driving conditions
specif ied in the Severe
Conditions Maintenance
Schedule do not apply.
NOTE: If you only
drive under a
‘‘severe’’ condition, you should
f ollow the Normal Conditions
Maintenance Schedule.
Follow the Maintenance
Schedule f or Severe Conditions.
OCCASIONALLY
Maint enance
U.S. Owners
Canadian Owners
238
Visually inspect the following items: Balancer belt applies to 4-cylinder
models only.
See information on maintenance and
emissions warranty, last column, page
.
miles x 1,000
km x 1,000
months
Service at the indicated
distance or time whichever
comes first.
Replace every 7,500 miles (12,000 km) or 1 year
Check oil and coolant at each fuel stop
Rotate tires every 7,500 miles (12,000 km)
15
24
12
30
48
2445
72
3660
96
4875
120 60 90
144 72 105
168
84 120
192
96
Every 120,000 miles (192,000 km) or 6 years
120,000 miles (192,000 km) or 6 years, then every 90,000 miles (144,000 km) or 5 years
Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Cooling system hoses and connections Exhaust system
Fuel lines and connections 120,000 miles (192,000 km) or 10 years, then every 60,000 miles
(96,000 km) or 5 years
Every 3 years (independent of mileage)
Replace engine oil
Replace engine oil filter
Check engine oil and coolant
Replace air cleaner element
Inspect valve clearance
Replace spark plugs
Replace timing belt, balancer belt , and inspect
water pump
Inspect and adjust drive belts
Inspect idle speed
Replace engine coolant
Replace transmission fluid
Inspect front and rear brakes
Replace brake fluid
Check parking brake adjustment
Replace dust and pollen filter
Rotate tires (Check tire inflation and condition
at least once per month) Adjust only if noisy
1::
MT
AT
237
1
Maintenance Schedule for Normal Conditions

µµ
Ø
Ø
Ø
Ø
Ø
Ø
Ø Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Î
Ì
Ì
Ì
Î
Maint enance239
A, B, C, D
U.S. Owners
Canadian Owners
A
B
C
D
See information on maintenance and emissions warranty, last
column, page .
Balancer belt applies to 4-cylinder models only.
Check engine oil and coolant at each fuel stop.
Check and adjust valve clearance, cold engine, only if noisy.
NOTE:
·
· :
:
237
Service at the indicated distance or time, whichever comes first. Do the items in as required for each distance/time interval.
Refer to page to determine which schedule to use.Use the Maintenance Schedule for Severe Conditions.
Do items in A.
Do items in A, B.
Do items in A.
DoitemsinA,B,C.
Do items in A.
Do item in D.
Do items in A, B.
Do items in A.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do items in A.
DoitemsinA,B,C.
Do item in D.
Do items in A.Replace timing belt, balancer belt , and inspect
water pump. Check idle speed.
Inspect valve clearance.
Replace spark plugs.
Do items in A, B.
Do items in A.
DoitemsinA,B,C. Replace engine coolant.
Replace manual transmission fluid.
Replace automatic transmission fluid.
7,500 mi/12,000 km
15,000 mi/24,000 km/1 yr
22,500 mi/36,000 km
30,000 mi/48,000 km/2 yrs
37,500 mi/60,000 km
3 yrs (independent of mileage)
45,000 mi/72,000 km/3 yrs
52,500 mi/84,000 km
60,000 mi/96,000 km/4 yrs
67,500 mi/108,000 km
75,000 mi/120,000 km/5 yrs
82,500 mi/132,000 km
90,000 mi/144,000 km/6 yrs
6 yrs (independent of mileage)
97,500 mi/156,000 km
105,000 mi/168,000 km/7 yrs
112,500 mi/180,000 km
120,000 mi/192,000 km/8 yrs
120,000 mi/192,000 km/10 yrs
then replace every 60,000 mi/
96,000 km/5 yrs
120,000 mi/192,000 km/6 yrs
120,000 mi/192,000 km/6 yrs
then replace every 90,000 mi/
144,000 km/5 yrs Replace engine oil.
Rotate tires (follow pattern on page
267).
Replace engine oil filter.
Inspect front and rear brakes.
Check parking brake adjustment.
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks.
Inspect cooling system hoses and connections. Inspect exhaust system.
Inspect fuel lines and connections.
Replace air cleaner element.
Inspect and adjust drive belts.
Replace dust and pollen filter.
Replace brake fluid every 3 years (independent of
mileage).
238Maintenance Schedule for Normal Conditions (listed by distance/time)

µ
µ
Î
Î
Î Ì
ÌÌ ÌÎÎ
Î
Î
Follow the Severe Conditions
Maintenance Schedule if you
drive your car under
one or more of the f ollowing
conditions: Driving less than 5 miles (8
km) per trip or, in f reezing
temperatures, driving less
than 10 miles (16 km) per trip.
Driving in extremely hot
[over 90°F (32°C)] conditions.
Extensive idling or long
periods of stop-and-go driving.
Trailer towing, driving with a
roof rack, or driving in
mountainous conditions.
Driving on muddy, dusty, or
de-iced roads.
Follow the Maintenance
Schedule f or Severe Conditions.
MAINLY
U.S. Owners
Canadian Owners
Maint enance240
Visually inspect the following items:
Service at the indicated
distance or time whichever
comes first.
miles x 1,000
km x 1,000
months
Replace every 3,750 miles (6,000 km) or 6 monthsCheck oil and coolant at each fuel stop
Every 60,000 miles (96,000 km) or 3 years
Inspect every 7,500 miles (12,000 km) or 6 months
Rotate tires every 7,500 miles (12,000 km)
Every 7,500 miles (12,000 km) or 6 months
Tie rod ends, steering gear box, and boots
Suspension components, Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and conditions of fluids
Cooling system hoses and connections
Exhaust system, Fuel lines and connections
Lights and controls, Vehicle underbody 15
24
12
30
48
2445
72
3660
96
4875
120 60 90
144 72 105
168
84 120
192
96
120,000 miles (192,000 km) or 10 years, then every 60,000 miles (96,000 km) or 5 years
Balancer belt applies to 4-cylinder models only. See information on maintenance and
emissions warranty, last column, page
.
Every 3 years (independent of mileage)
Replace engine oil and oil filter
Check engine oil and coolant
Clean ( ) or replace ( ) air cleaner element
Use normal schedule except in dusty
conditions
Inspect valve clearance
Replace spark plugs Replace timing belt , balancer belt , and
inspect water pump
Inspect and adjust drive belts
Inspect idle speed
Replace engine coolant
Replace transmission fluid
Inspect front and rear brakes
Replace brake fluid
Check parking brake adjustment
Replace dust and pollen filter
Lubricate all hinges, locks, and latches
Rotate tires (Check tire inflation and condition
at least once per month)
See dust and pollen filter on page for replacement information under special driving conditions. See timing belt on page for replacement information under special driving conditions. Adjust only if noisy
MT
AT
1:
2:
3: :
237
281
280
60,000 miles (96,000 km) or 3 years, then every 30,000 miles (48,000 km) or 2 years
11 ,2
3
Maintenance Schedule for Severe Conditions
