2005 Accord Hybrid Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through\
this reference.
For a printed owner's manual, click on authorized manuals or go to www.h\
elminc.com.
Contents


Instruments and Controls........................................................................\
......................................... 51
Indicators, gauges, dashboard, and steering column.
Features ........................................................................................................................\
...................... 99
Climate, audio, steering wheel, security, cruise control, and HomeLink.
Before Driving........................................................................\
.......................................................... 151
Fuel, vehicle break-in, and cargo loading.
Driving ........................................................................\
...................................................................... 165
Engine and transmission operation.
Maintenance........................................................................\
............................................................. 189
Schedules, fluid checking, minor services, and vehicle storage.
Taking Care of the Unexpected........................................................................\
.............................. 229
Flat tire, dead battery, overheating, fuses.
Technical Information........................................................................\
............................................. 257
Vehicle specifications, tires, fuels, and emissions controls.
Warranty and Customer Relations (U.S. and Canada)................................................................ 271
Warranty and contact information.
Authorized Manuals (U.S. only)........................................................................\
.............................. 275
How to order.
Index........................................................................\
............................................................................. I
Service Information Summary
Fluid capacities and tire pressures.

Driver and Passenger Safety ........................................................................\
.................................... 7
Seat belts, SRS, and child protection. Introduction ........................................................................\
............................................................... i
A Few Words About Safety........................................................................\
........................................ ii
Your Vehicle at a Glance........................................................................\
........................................... 4
Main Controls
Owner's Identification Form

After all occupants have adjusted
their seats and put on seat belts, it is
very important that they continue to
sit upright, well back in their seats,
with their feet on the floor, until the
vehicle is parked and the engine is
of f .
Sitting improperly can increase the
chance of injury during a crash. For
example, if an occupant slouches,
lies down, turns sideways, sits
forward, leans forward or sideways,
or puts one or both f eet up, the
chance of injury during a crash is
greatly increased.
This could cause
very serious injuries in a crash.
See page f or additional
inf ormation about your seat belts
and how to take care of them. If a seat belt does not seem to work
properly, it may not protect the
occupant in a crash.
The front seats have adjustable seat
belt anchors. To adjust the height of
an anchor, press and hold the release
buttons and slide the anchor up or
down as needed (it has f our
positions). Using a seat
belt that is not working properly can
result in serious injury or death.
Have your dealer check the belt as
soon as possible.
20
CONT INUED
Maintain a Proper Sitting
Position
6.
Protecting A dults and Teens
Never place t he shoulder port ion of a
lap/shoulder belt under your arm orbehind your back.
No one should sit in a seat wit h aninoperat ive seat belt .
Driver and Passenger Saf ety
17
RELEASE
BUTTONS
—
—
y
y
('yy

When you turn the ignition switch to
ON (II), this indicator will come on
brief ly then go out. This tells you the
system is working properly.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:If the SRS indicator does not come
on after you turn the ignition
switch to ON (II).
If the indicator stays on after the
engine starts.
If the indicator comes on or
flashesonandoff whileyoudrive. The SRS indicator alerts
you to a potential problem
with your airbags or seat belt
tensioners. If you see any of these indications,
the airbags and seat belt tensioners
may not work properly when you
need them.
This indicator
alerts you that the
passenger’s side
airbag has been automatically shut
of f . It does mean there is a
problem with your side airbags.
When you turn the ignition switch to
ON (II), the indicator should light
brief ly and go out (see page ). If it
doesn’t light, stays on, or comes on
while driving without a passenger in
the front seat, have the system
checked. 55
Additional Inf ormation About Your Airbags
How the SRS Indicator Works
How the Side A irbag Of f
Indicator Works
not
28
Canada
U.S.
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
—
—
y
y
('y
y

Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
Have the exhaust system inspected
f or leaks whenever:
With the trunk open, airf low can pull
exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
trunk open, open all the windows and
set the climate control system as
shown below.
If you must sit in your parked vehicle
with the engine running, even in an
unconfined area, adjust the climate
control system as f ollows:
Select the f resh air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside.
1.
2.
3.
4.
Carbon Monoxide Hazard
Driver and Passenger Saf ety
49
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
—
—
yy
('yy

The instrument panel has many
indicators to give you important
inf ormation about your vehicle.If this indicator comes on when the
engine is running, the battery is not
being charged. For more inf ormation,
see page .
See page .This indicator has two f unctions:
This indicator comes on when you
turn the ignition switch to ON (II). It
reminds you and your passengers to
f asten your seat belts. A beeper also
sounds if you have not f astened your
seat belt.
If you turn the ignition switch to ON
(II) bef ore f astening your seat belt,
the beeper sounds and the indicator
f lashes. If you do not f asten your
seat belt bef ore the beeper stops, the
indicator stops f lashing but remains
on.
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator f lashes
again at regular intervals. Itcomesonwhenyouturnthe
ignition switch to ON (II). It is a
reminder to check the parking
brake. A beeper sounds if you try
to drive with the parking brake not
f ully released. Driving with the
parking brake not f ully released
can damage the brakes and tires.
If it remains lit af ter you f ully
release the parking brake while
the engine is running, or if it
comes on while driving, there
could be a problem with the brake
system. For more inf ormation, see
page .
The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running. For
more inf ormation, see page .
1.
2.
246
247 247
249
L ow Oil Pressure
Indicator
Charging System
Indicator
Malf unction Indicator
Lamp
Parking Brake and Brake
System Indicator
Seat Belt Reminder
Indicator
Instrument Panel Indicators
54
U.S. Canada
—
—y

y
('yy

This indicator comes on when you
turn on the Cruise Control Master
Button. (see page .)
This indicator comes on when you
set the cruise control. See pagef or inf ormation on operating the
cruise control. This indicator comes on f or a f ew
seconds when you turn the ignition
switch to ON (II). It will go of f if you
have inserted a properly-coded
ignition key. If it is not a properly-
coded key, the indicator will blink
and the engine will not start (see
page ).
This indicator also blinks several
times when you turn the ignition
switch f rom ON (II) to ACCESSORY
(I) or LOCK (0).This indicator comes on when the
washer f luid level is low. Add washer
fluidwhenyouseethisindicator
come on (see page ).
142
142 78 205Canadian model only
Cruise Control IndicatorImmobilizer System
Indicator
Washer Level Indicator
Cruise Control Main
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
59
—
—y

y
('yy

If your f uel cap is loose or missing, a
‘‘CHECK FUEL CAP’’ message
appears as text in the odometer/
outside temperature display af ter
you start the engine. Turn the
engine of f and conf irm the f uel cap is
installed. If it is, loosen the cap, then
retighten it at least 3 clicks. When
you restart the engine, the message
appears again. To clear, press and
hold the Trip/Reset button until the
message is replaced by the
odometer/outside temperature
display.
This indicator normally comes on
when you turn the ignition to ON (II)
and goes off after the engine starts.
If it comes on at any other time,
there is a problem in the Electric
Power Steering system. If this
happens, stop the vehicle in a saf e
place and turn of f the engine. Reset
the system by restarting the engine.
The indicator will not turn of f
immediately. If it does not go of f
after driving a short distance, or
comes back on again while driving,
take the vehicle to your dealer to
have it checked. With the indicator
on, the EPS may be turned of f ,
making the vehicle harder to steer.
If the power steering system
overheats while driving, the assisting
power is reduced and steering may
f eel slightly harder.
If you drive with the system overheated continuously or
repeatedly, this can damage the
power steering system.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II). If it comes
on at any other time, it indicates a
problem in the Integrated Motor
Assist (IMA) system. With the IMA
indicator on, the vehicle may not
accelerate as it normally does. Have
the vehicle checked by the dealer as
soon as possible.
See page .
174 Check Fuel Cap Display
Electric Power Steering
(EPS) Indicator
IMA System Indicator
A uto Idle Stop Indicator
Instrument Panel Indicators
60
—
—y

y
('yy

µ
µ
µ
µIf the system still detects a loose or
missing f uel f ill cap, the malf unction
indicator lamp (MIL) comes on.
Turn the engine of f , and check or
retighten the f uel f ill cap at least3
clicks. The MIL goes out af ter3days
of normal driving once the cap is
tightened or replaced. If it does not
go out, have your dealer inspect the
vehicle. For more inf ormation, see
page .
The indicator comes on f or 2
seconds each time you turn the
ignition switch to the ON (II)
position.Each time you turn the ignition
switch to the ON (II) position, the
indicator comes on f or 2 seconds,
and then f lashes f or 10 seconds.
The indicator is on when the ignition
switch is in the ON (II) position.
Ref er to the maintenance schedules
on pages and f or inf ormation
on vehicle maintenance.
247
194 195If the travel distance is 6,0007,500 miles (9,600 12,000 km) af terthe last reset
If the travel distance is 0 6,000 miles (0 9,600 km) af ter the last reset If the travel distance is over 7,500 miles
(12,000 km) af ter the last resetMaintenance Required Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
61
MAINTENANCE REQUIRED INDICATOR
—
—y

y
('yy

While the engine is operating in its
most economical range, this
indicator may come on and stay on.
After having your vehicle serviced,
ask your dealer if the system has
been reset. If it has not, reset it as
f ollows:
Turn of f the engine.
Press and hold the Select/Reset
knob in the instrument panel, then
turn the ignition switch to ON (II).
Hold the knob f or about 10
seconds until the indicator resets.
1.
2.
3. Fuel Economy Indicator
Instrument Panel Indicators
62
SELECT/RESET KNOB
—
—y

y
('yy

The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.This display shows the outside
temperature in Fahrenheit (U.S.
models) or Centigrade (Canadian
models). To see the outside
temperature, press and release the
Select/Reset knob until the
temperature is displayed.
The temperature sensor is in the
f ront bumper. Theref ore, the
temperature reading can be af f ected
by heat ref lection f rom the road
surf ace, engine heat, and the
exhaust f rom surrounding traf f ic.
This can cause an incorrect
temperature reading when your
speed is under 19 mph (30 km/h).
The sensor delays the display update
until it reaches the correct outside
temperature. This may take several
minutes.
Gauges
Odometer
Outside T emperature Display
64
—
—y

y
('yy
