How to operate the heating and air
conditioning system, the audio
system, and other conveniencef eatures.
A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column. ID numbers, dimensions, capacities,
and technical information.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer. What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The maintenance minder shows you
when you need to take your vehicle
to the dealer for maintenance service.
There is also a list of things to check
and instructions on how to check
them.
This section covers several problems
motorists sometimes experience,
and details how to handle them.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system (SRS),
and valuable inf ormation on how to
protect children with child restraints.
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
Overview of Contents
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
FeaturesT echnical Inf ormation
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
Maintenance Driving Bef ore Driving
T aking Care of the Unexpected
3
06/08/08 14:15:36 31SDR620_008

µ
This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work. And
it tells you how to properly restrain
inf ants and children in your vehicle.
.........
Important Safety Precautions . 8
.......
Your Vehicle’s Saf ety Features . 9
.....................................
Seat Belts . 10
.........................................
Airbags . 11
.........
Protecting Adults and Teens . 13
.....
1. Close and Lock the Doors . 13
...........
2. Adjust the Front Seats . 13
............
3. Adjust the Seat-Backs . 14
...
4. Adjust the Head Restraints . 15
5. Fasten and Position the Seat
.....................................
Belts . 16
6. Maintain a Proper Sitting ................................
Position . 17
.....
Advice f or Pregnant Women . 18
...
Additional Safety Precautions . 19
Additional Inf ormation About Your .................................
Seat Belts . 20
..
Seat Belt System Components . 20 ......................
Lap/Shoulder Belt . 21
Automatic Seat Belt ...............................
Tensioners . 22
...............
Seat Belt Maintenance . 23
Additional Inf ormation About Your .....................................
Airbags . 24
......
Airbag System Components . 24
How Your Front Airbags
.........................................
Work . 26
...
How Your Side Airbags Work . 29
How Your Side Curtain Airbags
.........................................
Work . 31
..
How the SRS Indicator Works . 31
How the Side Airbag Of f
......................
Indicator Works . 32
How the Passenger Airbag Of f ......................
Indicator Works . 33
.............................
Airbag Service . 34
...
Additional Safety Precautions . 35
Protecting Children General ................................
Guidelines . 36
All Children Must Be ...............................
Restrained . 36
All Children Should Sit in a .................................
Back Seat . 37The Passenger’s Front Airbag
................
Poses Serious Risks . 37
If You Must Drive with Several ...................................
Children . 39
If a Child Requires Close ..................................
Attention . 39
...
Additional Safety Precautions . 40
Protecting Inf ants and .........................
Small Children . 41
.......................
Protecting Inf ants . 41
.........
Protecting Small Children . 42
.....................
Selecting a Child Seat . 43
....................
Installing a Child Seat . 44
Installing a Child Seat ............................
with LATCH . 45
......
with a Lap/Shoulder Belt . 47
...........................
with a Tether . 49
...........
Protecting Larger Children . 50
...............
Checking Seat Belt Fit . 50
..................
Using a Booster Seat . 51
When Can a Larger Child
...............................
Sit in Front . 52
...
Additional Safety Precautions . 53
.............
Carbon Monoxide Hazard . 54
...................................
Saf ety Labels . 55
Driver and Passenger Saf ety
Driver and Passenger Saf ety
7
06/08/08 14:15:57 31SDR620_012

This indicator comes on when you
turn on the cruise control master
button (see page ).
This indicator comes on when you
set the cruise control. See pagef or inf ormation on operating the
cruise control. This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. It will
gooffifyouhaveinserteda
properly-coded ignition key. If it is
not a properly-coded key, the
indicator will blink and the engine
will not start (see page ).
This indicator also blinks several
times when you turn the ignition
switch f rom the ON (II) position to
the ACCESSORY (I) or LOCK (0)
position.
This indicator comes on when the
washer f luid level is low. Add washer
fluidwhenyouseethisindicator
come on (see page ).
This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. It
remindsyouthatitistimetotake
your vehicle in f or scheduled
maintenance. The maintenance main
items and sub items will be displayed
in the inf ormation display. See page
f or more inf ormation on the
maintenance minder.
This indicator goes of f when your
dealer resets it after completing the
required maintenance service.
147
147 193 82
209
Canadian model only
Cruise Control Indicator Cruise Control Main
Indicator Immobilizer System
Indicator
Washer Level Indicator
Maintenance Minder
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
65
06/08/08 14:27:05 31SDR620_070

This shows how much f uel you have.
It may show slightly more or less
than the actual amount. The needle
returns to the bottom after you turn
of f the ignition.
The inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.Your vehicle’s onboard diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘CHECK FUEL CAP’’ message
appears on the information display.
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
the f uel f ill cap. To scroll to another
display, press the select/reset knob.
The ‘‘CHECK FUEL CAP’’ message
will appear each time you restart the
engine until the system turns the
message of f .
If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
167 246
Fuel Gauge Check Fuel Cap Message
Maintenance Minder
Gauges
Inst rument s and Cont rols
73
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
06/08/08 14:28:27 31SDR620_078

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
Do not change the oil until the
scheduled maintenance time.
Avoidhardbrakingforthefirst
200 miles (300 km).
Do not tow a trailer.
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. Your vehicle is designed to operate
on unleaded gasoline with a pump
octane number of 87 or higher. Use
of a lower octane gasoline can cause
a persistent, heavy metallic rapping
noise that can lead to engine damage.
We recommend quality gasoline
containing detergent additives that
help prevent f uel system and engine
deposits.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.
Some gasoline today is blended with
oxygenates such as ethanol or
MTBE. Your vehicle is designed to
operate on oxygenated gasoline
containing up to 10 % ethanol by
volume and up to 15 % MTBE by
volume. Do not use gasoline
containing methanol.
If you notice any undesirable
operating symptoms, try another
service station or switch to another
brand of gasoline.
For f urther important f uel-related
inf ormation, please ref er to your
.
Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the malfunction indicator
lamp on your instrument panel to
come on. If this happens, contact your dealer f or service.
Break-in Period, Fuel Recommendation
Break-in Period
Fuel Recommendation
Quick Start Guide
156
06/08/08 14:42:00 31SDR620_161

To Open the Hood:Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower lef t corner of the dashboard.
The hood will pop up slightly. Put your f ingers under the f ront
edge of the hood near the center.
Slide your hand to the lef t until
you f eel the hood latch handle.
Push this handle up to release it.
Lif t up the hood.
If the hood latch handle moves stif f ly,
or if you can open the hood without
lif ting the handle, the mechanism
should be cleaned and lubricated.
Push the f uel f ill door closed until
it latches. Screw the fuel fill cap back on
until it clicks at least once. If you
do not properly tighten the cap,
the malf unction indicator lamp
maycomeon(seepage ).You
will also see a ‘‘CHECK FUEL
CAP’’ message on the inf ormation
display.
1. 2.
5.
6.
246
Opening and Closing the Hood
Service Station Procedure
158
HOOD RELEASE HANDLE
LATCH
06/08/08 14:42:21 31SDR620_163

µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
Your vehicle displays engine oil lif e
and maintenance service items on
the inf ormation display to show you
when you should have your dealer
perf orm engine oil replacement and
indicated maintenance service.
Based on the engine operating
conditions and accumulated engine
revolutions, the onboard computer in
your vehicle calculates the remaining
engine oil lif e and displays it as a
percentage.
To see the current engine oil lif e,
turn the ignition switch to the ON
(II) position, then press and release
the Select/Reset knob repeatedly
until the engine oil lif e indicator
appears (see page ).The remaining engine oil lif e is
shownonthedisplayaccordingto
this table:
67
CONT INUED
Calculated Engine Oil Lif e (%)
100 % 91 % 90 % 81 %
80 % 71 %
70 % 61 %
60 % 51 %
50 % 41 %
40 % 31 %
30 % 21 %
20 % 16 %
15 % 11 %10 % 6 % 5% 1% 0% Displayed
Engine Oil Lif e (%) 100 %90 %
80 %
70 %
60 %
50 %
40 %
30 %
20 %
15 %
10 %5%
0%
Maintenance Minder
Engine Oil L if e Display
Maint enance
193
ENGINE OIL LIFE DISPLAY
06/08/08 14:47:44 31SDR620_198

If the remaining engine oil lif e is 15
to 6 percent, you will see the engine
oil lif e indicator every time you turn
the ignition switch to the ON (II)
position. The maintenance minder
indicator will also come on, and the
maintenance item code(s) for other
scheduled maintenance items
needing service will be displayed
next to the engine oil lif e indicator.
When the remaining engine oil lif e is
5 to 1 percent, you will see a
‘‘SERVICE’’ message in the
inf ormation display, along with the
same maintenance item code(s),
everytimeyouturntheignition
switch to the ON (II) position.
The maintenance item code or codes
indicate the main and sub items
required at the time of the oil change
(see page ).
You can switch the information
display f rom the engine oil lif e
display to the odometer or the trip
meter. Press and release the Select/
Reset knob on the instrument panel.
When the engine oil lif e is 15 to 1
percent, the maintenance minder
indicator ( ) comes on every
time you turn the ignition switch to
the ON (II) position, then it goes out
if you switch the inf ormation display.
When you see this message, have
the indicated maintenance
perf ormed by your dealer as soon as
possible.
196
Maintenance Minder
194
MAINTENANCE ITEM CODE
06/08/08 14:47:53 31SDR620_199

µ
When the remaining engine oil lif e is
0 percent, the engine oil lif e indicator
will blink. The display comes on
everytimeyouturntheignition
switch to the ON (II) position. The
maintenance minder indicator
( ) also comes on and remains
on in the instrument panel. When
you see this message, immediately
have the indicated maintenance done
by your dealer. The maximum total mileage shown
is ‘‘ 9999.’’
If you do not perf orm the indicated
maintenance, negative mileage is
displayed and begins to blink af ter
the vehicle has been driven 10 miles
(10 km) or more.
Negative mileage means your
vehicle has passed the maintenance
required point.
Immediately have the indicated
maintenancedonebyyourdealer. To change the inf ormation display
f rom the engine oil lif e display to the
odometer or the trip meter, press
and release the Select/Reset knob.
When the engine oil lif e is 0 percent
or negative mileage, the
maintenance minder indicator
( )remainsonevenif you
change the inf ormation display.
Immediately have the service done,
and make sure to reset the display as
described on the next page.
Maintenance Minder
Maint enance
195
06/08/08 14:48:04 31SDR620_200

Turn the ignition switch to the ON
(II) position.
If maintenance service is done by
someone other than your dealer,
reset the maintenance minder as
f ollows:
Press the Select/Reset knob until
the engine oil lif e indicator is
displayed.
Your dealer will reset the display
af ter completing the required
maintenance service. You will see
‘‘OIL LIFE 100%’’ on the inf ormation
display the next time you turn the
ignition switch to the ON (II)
position.
All maintenance items displayed in
the inf ormation display are in code.
For an explanation of these
maintenance codes, see page . Press and hold the Select/Reset
knob f or about 10 seconds. The
engine oil lif e and the maintenance
item code(s) will blink.
3.
1.
2.
199
Maintenance Main Items and Sub
Items
Resetting the Engine Oil Lif e
Display
Maintenance Minder
196
MAINTENANCE SUB ITEM (S)
MAINTENANCE MAIN ITEM
06/08/08 14:48:15 31SDR620_201
