service indicator HONDA ACCORD HYBRID 2007 CL7 / 7.G User Guide

Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).If the charging system
indicator comes on brightly
when the engine is running, the
battery is not being charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning lights.
This indicator should never
come on when the engine is
running. If it starts f lashing or stays
on, the oil pressure has dropped very
low or lost pressure. Serious engine
damage is possible, and you should
take immediate action.
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(seeon page
).
1.
2.
4. 3.
159
203
255
L ow Oil Pressure Indicator
Charging System Indicator
Emergency T owing
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
245
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
06/08/08 14:55:39 31SDR620_250

However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully. Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired as
soon as possible (seeon page ).
The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and as
a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake.
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ). If the ABS indicator comes on with
the brake system indicator, have
your vehicle inspected by your
dealer immediately.
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads. 211
255Emergency
Towing
Brake System Indicator
T aking Care of t he Unexpect ed
247
Canada
U.S.
06/08/08 14:55:56 31SDR620_252

............Checklist, Before Driving . 170
..................Childproof Door Locks . 85
............................Child Seats . 36, 43-49
...........Lower Anchorage Points . 45
..........Tether Anchorage Points . 49
..............Climate Control Sensors . 117
.........................Clock, Setting the . 145
......................................Coat Hook . 103
..................CO in the Exhaust . 54, 265
............Cold Weather, Starting in . 171
..............................Compact Spare . 234
.................Console Compartment . 101
.................Consumer Inf ormation . 272
.............Controls, Instruments and . 57
Coolant
........................................Adding. 207
....................................Checking. 160
.........................Proper Solution. 207
...................Temperature Gauge . 72
Crankcase Emissions Control
........................................System. 265
............Cruise Control Operation . 147
.............Customer Service Of f ice . 272
...............DANGER, Explanation of .iii
...................................Dashboard . 4, 58
................Daytime Running Lights . 78
............Defects, Reporting Safety . 274
................Def ogger, Rear Window . 79
....................................Dimensions. 260
...............Dimming the Headlights . 76
Dipstick
..........Automatic Transmission . 210
..................................Engine Oil. 159
..........................Directional Signals. 76
........Disc Brake Wear Indicators . 180
.....................Disposal of Used Oil. 206
Doors
..............Locking and Unlocking . 84
..........DOT Tire Quality Grading . 262
...........Driver and Passenger Safety . 7
...........................................Driving. 169
....................................Economy. 161
..........Dual Temperature Control . 115
..............................Economy, Fuel. 161
Electric Power Steering (EPS)
.......................................Indicator. 66
............Emergencies on the Road . 233
.............Battery, Jump Starting . 241
...........Brake System Indicator . 247
................Changing a Flat Tire . 235
.....Charging System Indicator . 245
..................Checking the Fuses . 249
.....Low Oil Pressure Indicator . 245
...Malf unction Indicator Lamp . 246
..................Overheated Engine . 243
...........................Emergency Brake. 98
......................Emergency Flashers. 79
......................Emergency Towing. 255
.......................Emissions Controls. 265
Engine
....Coolant Temperature Gauge . 72
Malf unction Indicator
................................Lamp . 60, 246
..............Oil Pressure Indicator . 245
..............Oil, What Kind to Use . 203
...............................Overheating. 243
............................Specif ications. 261
............................Speed Limiter. 174
................................Starting . 83, 171
...................Engine Speed Limiter . 174
Index
D
E
II
06/08/08 15:00:22 31SDR620_283

.Taking Care of the Unexpected . 233
Technical Descriptions
......DOT Tire Quality Grading . 262
.....Emissions Control Systems . 265
Three Way Catalytic
...............................Converter . 267
.......................Temperature Gauge . 72
..............Tether Anchorage Points . 49
..Three Way Catalytic Converter . 267
..........................Time, Setting the . 145
....................................Timing Belt . 212
....................................Tire Chains . 228
.........Tire, How to Change a Flat . 235
.................................Tire Labeling . 264
...............................................Tires . 223
..............................Air Pressure . 224
.........................Checking Wear . 225
..........................Compact Spare . 234
......DOT Tire Quality Grading . 262
......................................Inf lation . 223
..................................Inspection . 225
...................................Replacing . 226
......................................Rotating . 226
...........................................Snow . 227
.........................Select/Reset Knob . 78
...............................Serial Number . 258
....................Service Intervals . 193-199
.............................Service Manual. 275
...........Service Station Procedure . 157
..........................Setting the Clock. 145
.....Shif t Lever Position Indicator . 172
........................Shif t Lock Release. 175
..............................Side Airbags . 11, 29
...How Your Side Airbags Work . 29
How the Side Airbag Of f
......................Indicator Works. 32
................Side Curtain Airbags . 11, 31
How Your Side Curtain
..........................Airbags Work. 31
...............................Signaling Turns. 76
.....................................Snow Tires. 227
................................Sound System. 118
Spare Tire
......................................Inf lating. 234
............................Specif ications. 261
....................Specif ications Charts . 260
................................Speed Control. 147
................................Speed Limiter. 174
..........SRS, Additional Inf ormation . 24
...Additional Safety Precautions . 35
.............................Airbag Service. 34
How the SRS Indicator
.......................................Works. 31
How Your Front Airbags
.......................................Works. 26
How Your Side Airbags
.......................................Works. 29
........................SRS Components. 24
.............................SRS Indicator. 31, 61
....START (Ignition Key Position) . 83
.......................Starting the Engine. 171
................With a Dead Battery . 241
........Steam Coming f rom Engine . 243
Steering Wheel
..................................Adjustment. 80
.............Anti-theft Column Lock . 83
...................Stereo Sound System . 118
..........................................Sun Visor. 99
........................Sunglasses Holder. 102
Supplemental Restraint
................................System . 11, 24
......................................Servicing. 34
.........................SRS Indicator . 31, 61
...................System Components . 24
..................................Synthetic Oil. 204
Index
T
VI
06/08/08 15:00:50 31SDR620_287
