wiper blades HONDA CIVIC COUPE 2011 8.G Owners Manual

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
This section also includes
instructions on how to read the
Maintenance Minder messages on
the information display, and
instructions f or simple maintenance
tasks you may want to take care of
yourself .
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.U.S. Vehicles:
......................
Maintenance Saf ety . 290
.................
Maintenance Minder . 291
..............................
Fluid Locations . 298
........................
Adding Engine Oil . 300
.......
Recommended Engine Oil . 300
..............................
Synthetic Oil . 301
................
Engine Oil Additives . 301
Changing the Engine Oil and
...........................................
Filter . 302
..............................
Engine Coolant . 304
....................
Windshield Washers . 307
....
Automatic Transmission Fluid . 308
........
Manual Transmission Fluid . 309
................
Brake and Clutch Fluid . 310
....................
Power Steering Fluid . 311
.............................................
Lights . 312
................
Cleaning the Seat Belts . 319
.....................................
Floor Mats . 320
..................
Dust and Pollen Filter . 321
.................................
Wiper Blades . 321
...............................................
Tires . 323
...................
Checking the Battery . 333
.............................
Vehicle Storage . 335
..................................
Interior Care . 336
383
Maintenance
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Maint enance
289
TM
Main Menu

Check the f luid level in the
windshield washer reservoir at least
monthly during normal use.When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather. The low washer
level indicator comes on when the
level is low (see page ).
Check the f luid level by removing
the cap and looking at the level
gauge. 65
On Canadian models:
Windshield Washers
Maint enance
307
LEVEL GAUGELEVEL GAUGE Si
DX, DX-G, LX, SE, EX, EX-L
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
Main Menu

Check the condition of the wiper
blades at least every six months.
Replace them if you f ind signs of
cracking in the rubber, areas that are
getting hard, or if they leave streaks
and unwiped areas when used.
This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the heating and
cooling system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message on the
inf ormation display. It should be
replaced every 15,000 miles (24,000
km) if you drive primarily in urban
areas that have high concentrations
of soot in the air, or if the f low f rom
the heating and cooling system
becomeslessthanusual.
To replace a wiper blade:
Raise each wiper arm of f the
windshield, lif ting the driver’s side
first, then the passenger’s side.
1.
CONT INUED
On models with A/C
Wiper Blades
Dust and Pollen Filter
Dust and Pollen Filter, Wiper Blades
Maint enance
321
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and wiper arms.
Main Menu

Slidethebladeoutof theholder.
Pull up the cover release tab on
the end of the blade assembly,
then remove the cover.
Disconnect the blade assembly
fromthewiperarmbypushingin
the release button. Then slide the
blade assembly out of the wiper
arm.
2.
3.4.
Wiper Blades
322
BLADE
HOLDER
RELEASE BUTTON COVER
RELEASE TAB
Main Menu

Keeping the tires properly inf lated
provides the best combination of
handling, tread lif e, and riding
comf ort.Underinf lated tires wear unevenly,
adversely affect handling and fuel
economy, and are more likely to
fail from being overheated.
Overinf lated tires can make your
vehicleridemoreharshly,are
more prone to damage f rom road
hazards, and wear unevenly.
To saf ely operate your vehicle, your
tires must be the proper type and
size, in good condition with adequate
tread, and correctly inf lated.
The f ollowing pages give more
detailed inf ormation on how to take
care of your tires and what to do
when they need to be replaced.
Align the slots in the new blade
with the retaining edges on the
holder, then slide the blade onto
the holder. Keep about 1 inch of
the holder extended f rom the
blade assembly so you can
reinstall the cover.
Reinstall the cover onto the blade
assembly.
Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Lower the wiper arm down against
the windshield, the passenger’s
side first, then the driver’s side.
5. 6. 7. 8.
CONT INUED
Inf lation Guidelines
Tires
Wiper Blades, Tires
Maint enance
323
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
Main Menu

CONT INUED
........................
Parking Lights . 74, 316
Parking Over Things that
....................................
Burn . 278, 375
....
Passenger Airbag Of f Indicator . 30
..........................................
PC Card . 181
.............
PC Card Error Messages . 193
.............................
PGM-FI System . 374
...................................
Pollen Filter . 321
..........................
Power Door Locks . 83
......
Power Socket Locations . 110, 112
....................
Power Steering Fluid . 311
............................
Power Windows . 104
.........
Pregnancy, Using Seat Belts . 16
........................
Preparing to Drive . 269
.........
Protecting Adults and Teens . 11
...
Additional Safety Precautions . 16
.....
Advice f or Pregnant Women . 16
........................
Protecting Children . 33
.......................
General Guideline . 33
................
Installing a Child Seat . 41
.......................
Protecting Inf ants . 38
.......
Protecting Larger Children . 48
.........
Protecting Small Children . 39
.................
Selecting a Child Seat . 40
Using Child Seats with
.....................................
Tethers . 46 .............................
Using LATCH . 42
...................
Radiator Overheating . 347
...........
Radio/Disc Sound System . 124
Radio/Disc/PC Card/USB Sound
........................................
System . 159
............................
Radio, XM
. 129, 163
...
Recommended Tire Pressures . 325
.................
Radio Thef t Protection . 221
...................
Readiness Codes . 350, 376
Rear Lights, Bulb
..............................
Replacement . 316
............................
Rear Seat Access . 96
........................
Rear Seat, Folding . 101
...........................
Rearview Mirror . 108
.................
Rear Window Def ogger . 77
................
Reclining the Seat-backs . 95
.......
Recommended Shif t Speeds . 272
........................................
Ref ueling . 253
.................
Reminder Indicators . 57, 59
................
Remote Audio Controls . 219
.......................
Remote Transmitter . 89
Replacement Inf ormation
..............
Dust and Pollen Filter . 321 ................
Engine Oil and Filter . 302
..........................................
Fuses . 352
................................
Light Bulbs . 312
.............
Maintenance Minder . 291
................................
Spark Plugs . 364
......................
Tires and Wheels . 330
.............................
Wiper Blades . 321
Replacing Seat Belts Af ter a ............................................
Crash . 20
.............
Reporting Saf ety Def ects . 382
Reserve Tank, Engine
...............................
Coolant . 257, 304
...............................
Restraint, Child . 33
..................
Reverse Gear Position . 275
...........................
Reverse Lockout . 273
................................
Rotation, Tire . 328
..................................
Saf ety Belts . 8, 18
............
Safety Defects, Reporting . 382
.................................
Saf ety Features . 7
...........................................
Airbags . 9
.......................................
Seat Belts . 8
Index
INDEX
R
S
VII
TM
Main Menu

Î
Î
Unexpected, Taking Care..........................................
of the . 337
..
Unif orm Tire Quality Grading . 367
........................
Unleaded Gasoline . 252
USB Adapter
..................
Cable . 144, 153, 196, 207
.
USB Flash Memory Device . 151, 204
.......
Used Oil, How to Dispose of . 304
................................
Vanity Mirror . 113
.................
Vehicle Capacity Load . 264
......................
Vehicle Dimensions . 364
....
Vehicle Identif ication Number . 362
Vehicle Stability Assist (VSA
)
....................................
System . 282
...
VSA Activation Indicator . 64, 282
.........................
VSA Of f Switch . 283
........
VSA System Indicator . 64, 282
.............................
Vehicle Storage . 335
.....................................
Ventilation . 120
.................................................
VIN . 362
..................................
Viscosity, Oil . 301 ............
WARNING, Explanation of . iii
................
Warning Button, Hazard . 77
.........
Warning Labels, Location of . 53
....................
Warranty Coverages . 381
Washer, Windshield
........
Checking the Fluid Level . 307
.......................................
Indicator . 65
.....................................
Operation . 73
Wheels ...............
Adjusting the Steering . 78
............
Alignment and Balance . 327
..........................
Compact Spare . 338
...................................
Replacing . 329
..............................
Wrench, Nut . 340
Windows .............................
Auto Reverse . 105
................
Operating the Power . 104
...........................
Rear, Def ogger . 77
Windshield .......................................
Cleaning . 73
...................................
Def roster . 122
.......................................
Washers . 73
Wipers, Windshield .......................
Changing Blades . 321 .....................................
Operation . 73
..............
WMA . 135, 152, 173, 182, 205
....................................
Worn Tires . 326
.....
Wrecker, Emergency Towing . 358
.............................
XM
Radio . 129, 163
:U.S.only
Index
V W
X
U
X
Main Menu
