SPECIFICATIONS
MAINTENANCE
Testing of Readiness Codes
Your vehicle has “readiness codes” as part of the onboard self-diag\
nostic system.
Some states refer to these codes as a test to see if your vehicle’s emissions
components are working properly. The codes may not be read if you go through the
testing just after the battery has gone dead or been disconnected.
To check if they are set, turn the vehicle on without starting the engine\
. The
malfunction indicator lamp will come on for several seconds. If it goes \
off, the
readiness codes are set. If it blinks fi ve times, the readiness codes are not set.
If you are required to have your vehicle tested before the readiness cod\
es are set,
prepare the vehicle for retesting by doing the following:
1. Fill the gas tank to approximately 3/4 full.
2. Park the vehicle and leave the engine off for 6 hours or more.
3. Make sure the ambient temperature is between 40°F and 95°F (4°\
C and 35°C).
4. Start the engine without touching the accelerator pedal, and let it idle\
for 20
seconds.
5. Keep the vehicle in Park (P) or Neutral for manual transmission. Incre\
ase the engine speed to 2,000 rpm, and hold it there for about 3 minutes.
6. Let the engine idle with your foot off the accelerator for 20 seconds.
7. Select a nearby, lightly traveled major highway where you can maintain a speed of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the \
highway
with the vehicle in Drive (D) or 5th gear. Do not use cruise control. When traffi c
allows, drive for 90 seconds without using the accelerator pedal. (Vehicle speed
may vary slightly; this is OK.) If you cannot do this for a continuous \
90 seconds
because of traffi c conditions, drive for at least 30 seconds, then repeat two more
times (for a total of 90 seconds).
8. Drive in city/suburban traffi c for at least 10 minutes. When traffi c conditions allow, let the vehicle coast for several seconds without using the accelerato\
r
pedal or the brake pedal.
9. Park the vehicle and leave the engine off for 30 minutes.
The readiness codes are erased when the battery is disconnected, and set\
again
only after several days of driving under a variety of conditions.
If a testing facility determines that the readiness codes are not set, y\
ou may be
requested to return at a later date to complete the test, or see your de\
aler. SPECIFICATIONS
Civic Sedan
Vehicle
*1: Manual transmission models
*2: Automatic transmission models
*3: LX and LX-C models with manual transmission
*4: LX and LX-C models with automatic transmission
*5: EX, EX-C, and EX-L models
ModelHonda Civic 4-Door
Curb Weight (2,734-2,826 lbs)
*11,275-1,311 kg
(2,811-2,890 lbs)*2Maximum permissible
weight 1,660 kg (3,660 lbs)*31,685 kg (3,715 lbs)*41,720 kg (3,792 lbs)*5
1,240-1,282 kg
Dimensions
*1: LX, LX-C, EX, EX-C, and EX-L models without front licence
plate base
*2: LX, LX-C, EX, EX-C, and EX-L mo dels with front licence plate
base
*3: LX, LX-C, EX, EX-C, and EX-L mo dels with front licence plate
bases
Length4,555 mm (179.3 in)*14,570 mm (179.9 in)*24,580 mm (180.3 in)*3WidthHeight1,450 mm (57.1 in)
Wheelbase 2,670 mm (105.1 in)
TrackFront1,492 mm (58.7 in)Rear1,516 mm (59.7 in)
1,755 mm (69.1 in)
Engine and Fuel
Fuel Engine Specifications
Displacement110 cu-in (1,798 cm3)
Spark Plugs NGK
DENSO
Fuel:
TypeUnleaded gasoline, Pump
octane number of 87 or higher
Fuel Tank Capacity 13.2 US gal (50 ℓ)
DILZKR7B11GS
DXU22HCR-D11S
Tires
*1: Vehicle with 16 inch wheel
*2: Vehicle with 17 inch wheel
*3: Vehicle with 18 inch wheel
RegularSize215/70R16 100S*1225/65R17 102T*2P225/60R18 99H*3
Pressure
psi (kPa [kgf/cm2])32 (220 [2.2])*133 (230 [2.3])*230 (210 [2.1])*3
Compact
Spare Size
T165/80D17 104M
Pressure
psi (kPa [kgf/cm2]) 60 (420 [4.2])
Wheel SizeRegular16 x 6.5J*117 x 7J*218 x 7J*3Compact Spare17 x 4T
Light Bulbs
Headlights (Low Beam)55W (H11)
Headlights (High Beam) 60W (HB3)
Fog Lights*35W (H8)
Front Turn Signal/Side Marker/
Parking Lights
*28/8W (Amber)Front Turn Signal/
Side Marker Lights*28/8W (Amber)
Side Turn Signal Lights
(on Door Mirrors)
*LEDParking Lights*LED
Upper Rear Side Marker/Taillights 3CP
Lower Rear Side Marker/Brake/
Taillights21/5W
Back-Up Lights 21W
Rear Turn Signal Lights21W (Amber)
High-Mount Brake Light LED
Rear License Plate Light3CP
Cargo Area Light 8W
Vanity Mirror Lights*14W
Fluids
Brake/Clutch Fluid
Automatic Transmission (CVT) Fluid
Manual Transmission FluidSpecifiedHonda Heavy Duty Brake Fluid DOT 3
SpecifiedHCF-2
Capacity
SpecifiedHonda Manual Transmission Fluid
Capacity
Engine Oil
Engine Coolant
Recommended· Honda Genuine Motor Oil 0W-20
· API Premium-grade 0W-20
detergent oil
Capacity Change
Change
including
filter
3.9 US qt (3.7 ℓ)
SpecifiedHonda Long-Life Antifreeze/Coolant
Type2
Ratio
Capacity1.48 US gal (5.59 ℓ)
(change including the remaining 0.125
US gal (0.475 ℓ) in the reserve tank)
Washer Fluid
Tank CapacityU.S.: 2.6 US qt (2.5 ℓ)
Canada: 4.8 US qt (4.5 ℓ)
3.6 US qt (3.4 ℓ)Change
Change 1.5 US qt (1.4 ℓ)
3.7 US qt (3.5 ℓ)
50/50 with distilled water

136 || 137
SPECIFICATIONS
SPECIFICATIONS
Civic Sedan Si
Vehicle
ModelHonda Civic 4-Door
No. of Passengers: 2
3
5
Front
Rear
Total
Weights:Gross Vehicle
Weight Rating U.S.: 3,925 lbs (1,780 kg)
Canada: 1,780 kg
Gross Axle Weight
Rating (Front)U.S.: 2,117 lbs (960 kg)
Canada: 960 kg
Gross Axle Weight
Rating (Rear)U.S.: 1,830 lbs (830 kg)
Canada: 830 kg
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 13.2 – 15.0 oz (375 – 425 g)
Lubricant Type SP-10
Engine and Fuel
Engine Specifications
FuelDisplacement144 cu-in (2,354 cm3)
Spark Plugs NGK
DENSOILZKR7B-11S
SXU22HCR11S
Fuel:
TypeUnleaded premium gasoline, Pump
octane number of 91 or higher
Fuel Tank Capacity 13.2 US gal (50 ℓ)
Tires
*1: Optional for U.S. models (summer tires)
RegularSize225/40R18 92V
225/40R18 92Y*1Pressure
psi (kPa [kgf/cm2])33 (230 [2.3])
32 (220 [2.2])*1
Compact
Spare Size
T135/80D16 101M
Pressure
psi (kPa [kgf/cm2]) 60 (420 [4.2])
Wheel SizeRegular18 x 7 1/2JCompact Spare16 x 4T
Light Bulbs
Headlights (Low Beam)51W (HB4)
Headlights (High Beam) 60W (HB3)
Fog Lights35W (H8)
Front Turn Signal/Parking/Side
Marker Lights 28/8W (Amber)
Brake/Taillights21/5W
Rear Turn Signal Lights 21W (Amber)
Rear Side Marker LightsLED
Back-Up Lights 16W
Taillights3CP
High-Mount Brake Light LED
Rear License Plate Lights5W
Trunk Light 5W
Interior LightsMap Lights8WCeiling Light8W
Fluids
Engine Oil
Engine Coolant
Recommended· Honda Genuine Motor Oil 0W-20
· API Premium-grade 0W-20
detergent oil
Capacity Change 4.2 US qt (4.0 ℓ)
Change
including
filter
4.4 US qt (4.2 ℓ)
SpecifiedHonda Long-Life Antifreeze/
Coolant Type2
Ratio 50/50 with distilled water
Capacity1.45 US gal (5.5 ℓ)
(change including the remaining
0.125 US gal (0.475 ℓ) in the
reserve tank)
Washer Fluid
Tank CapacityU.S.: 2.6 US qt (2.5 ℓ)
Canada: 4.8 US qt (4.5 ℓ)
Civic Coupe
Vehicle
Vehicle Specications
*1: Manual transmission models
*2: Automatic transmission models
ModelHonda Civic 2-Door
Curb Weight 1,279 kg (2,820 lbs)*11,306 kg (2,879 lbs)*2
weight 1,720 kg (3,792 lbs)
DimensionsLength4,550 mm (179.1 in)
Width 1,755 mm (69.1 in)
Height1,415 mm (55.7 in)
Wheelbase 2,620 mm (103.1 in)
TrackFront1,492 mm (58.7 in)Rear1,516 mm (59.7 in)
Maximum permissible
Engine and Fuel
Displacement110 cu-in (1,798 cm3)
Spark Plugs NGK DILZKR7B11GS
DENSO DXU22HCR-D11S
Fuel:
TypeUnleaded gasoline, Pump octane
number of 87 or higher
Fuel Tank Capacity 13.2 US gal (50 ℓ)
Engine Specifications
Fuel
Tires
Tires
*1: Except EX-L model
*2: EX-L model
RegularSizeP205/55R16 89H*1P215/45R17 87V*2Pressure
psi(kPa[kgf/cm2])32 (220 [2.2])
Compact
Spare Size T135/80D15 99M
Pressure
psi(kPa[kgf/cm
2])
60 (420 [4.2])
Wheel SizeRegular16 x 6 1/2J*117 x 7J*2Compact Spare15 x 4T
Light Bulbs
Headlights (Low Beam)55 W (H11)
Headlights (High Beam) 60 W (HB3)
Front Turn Signal/Position/Side
Marker Lights28/8 W
Brake/Taillights 21/5 W
Rear Side Marker Lights5 W
Rear Turn Signal Lights 21 W (Amber)
Back-Up Lights16 W
High-Mount Brake Light 21 W
Rear Licence Plate Light5 W
Interior Lights Map Lights 8 W
Ceiling Light 8 W
Fluids
Engine Oil
Engine Coolant
RecommendedGenuine Honda Motor Oil
API service SL or higher grade
0W-30, 0W-40, 5W-30, 5W-40, 10W-30,
10W-40, 15W-40
Capacity Change 3.5 ℓ (3.7 US qt)
Change
including
filter
3.7 ℓ (3.9 US qt)
SpecifiedHonda All Season Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity5.59 ℓ (1.48 US gal)
(change including the remaining 0.475 ℓ
(0.125 US gal) in the reserve tank)
Washer FluidTank Capacity2.5 ℓ (2.6 US qt)
Brake/Clutch Fluid
Automatic Transmission Fluid
Manual Transmission FluidSpecifiedBrake Fluid with DOT3 or DOT4
SpecifiedHonda ATF DW-1
(automatic transmission fluid)
Capacity Change 2.4 ℓ (2.5 US qt)
SpecifiedHonda Manual Transmission Fluid
Capacity Change 1.4 ℓ (1.5 US qt)

138 || 139
SPECIFICATIONS
SPECIFICATIONS
Civic Coupe Si
Vehicle
ModelHonda Civic 2-Door
Curb Weight 1,374 kg (3,029 lbs)
weight 1,780 kg (3,924 lbs)
DimensionsLength4,550 mm (179.1 in)
Width 1,755 mm (69.1 in)
Height1,415 mm (55.7 in)
Wheelbase 2,620 mm (103.1 in)
TrackFront1,496 mm (58.9 in)Rear1,516 mm (59.7 in)
Maximum permissible
Engine and Fuel
Engine Specifications
FuelDisplacement144 cu-in (2,354 cm3)
Spark Plugs NGK ILZKR7B-11S
DENSO SXU22HCR11S
Fuel:
TypeUnleaded premium gasoline, Pump octane
number of 91 or higher
Fuel Tank Capacity 13.2 US gal (50 ℓ)
Tires
*1: Optional for U.S. models (summer tires)
RegularSize225/40R18 92V
225/40R18 92Y*1Pressure
psi(kPa[kgf/cm2])33 (230 [2.3])
32 (220 [2.2])*1
Compact
Spare Size
T135/80D16 101M
Pressure
psi(kPa[kgf/cm2]) 60 (420 [4.2])
Wheel SizeRegular18 x 7 1/2JCompact Spare16 x 4T
Light Bulbs
Headlights (Low Beam)55 W (H11)
Headlights (High Beam) 60 W (HB3)
Fog Lights55 W (H11)
Front Turn Signal/Position/Side
Marker Lights 28/8 W
Brake/Taillights21/5 W
Rear Side Marker Lights 5 W
Rear Turn Signal Lights21 W (Amber)
Back-Up Lights 16 W
High-Mount Brake LightLED
Rear Licence Plate Light 5 W
Interior Lights Map Lights 8 W
Ceiling Light 8 W
Fluids
Brake/Clutch Fluid
Manual Transmission FluidSpecifiedBrake Fluid with DOT3 or DOT4
SpecifiedHonda Manual Transmission Fluid
Capacity Change 1.9 ℓ (2.0 US qt)
Engine Oil
Engine Coolant
RecommendedGenuine Honda Motor Oil
API service SM or higher grade
0W-30, 0W-40, 5W-30, 5W-40, 10W-30,
10W-40, 15W-40
Capacity Change 4.0 ℓ (4.2 US qt)
Change
including
filter
4.2 ℓ (4.4 US qt)
SpecifiedHonda All Season Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity5.5 ℓ (1.45 US gal)
(change including the remaining 0.475 ℓ
(0.125 US gal) in the reserve tank)
Civic Natural Gas (CNG)
Vehicle
Model Honda Civic 4-Door Natural Gas
No. of Passengers:
Front
Rear
Tot al 2
3
5
Weights:
Gross Vehicle Weight
Rating 3,870 lbs (1,755 kg)
Gross Axle Weight
Rating (Front) 2,007 lbs (910 kg)
Gross Axle Weight
Rating (Rear) 1,863 lbs (845 kg)
Air Conditioning:
Refrigerant Type
Charge Quantity
Lubricant Type HFC-134a (R-134a)
13.2 – 15.0 oz (375 – 425 g)
SP-10
Engine and Fuel
Engine SpecificationsDisplacement 110 cu-in (1,798 cm3)
Spark Plugs NGK SILKR8B8DS
FuelFuel Tank
Service Pressure 3,600 psi (24,800 kPa) at 70°F (21°C)
Fuel Tank
Capacity 3,000 psi:
Slow filling
Fast filling6.96 GGE
5.84 GGE
3,600 psi:
Slow filling
Fast filling 7.7 7 G G E
6.51 GGE
Tires
RegularSize P195/65R15 89H
Pressure

psi (kPa[kgf/cm2]) 3 0 ( 210 [2.1] )
Compact
Spare
*1Size T135/80D15 99M
Pressure
psi (kPa[kgf/cm
2]) 60 (420 [4.2])
Wheel Size Regular 15 x 6J
Compact Spare
*115 x 4T
*1: Models with compact spare tire
Light Bulbs
Headlights (Low Beam) 51W (HB4)
Headlights (High Beam) 60W (HB3)
Front Turn Signal/Parking/Side
Marker Lights 28/8W (Amber)
Brake/Taillights 21/5W
Rear Turn Signal Lights 21W (Amber)
Rear Side Marker Lights LED
Back-Up Lights 16W
Taillights 3CP
High-Mount Brake Light 21W
Rear License Plate Lights 5W
Tr unk Light 5W
Interior Lights
Map

Lights
C

eiling Light 8W
8W
Fluids
Washer FluidTank Capacity 2.6 US qt (2.5 ℓ)
Brake FluidSpecified Honda Heavy Duty Brake Fluid DOT 3Automatic Transmission Fluid
Specified
Honda ATF DW-1

(automatic transmission fluid)
Capacity Change 2.5 US qt (2.4 ℓ)

Engine Oil
Recommended • Honda Genuine Motor Oil 0W-20
• API Premium-grade 0W-20
detergent oil
Capacity Change 3.7 US qt (3.5 ℓ)
Change
including
filter
3.9 US qt (3.7 ℓ)

Engine Coolant
Specified Honda Long-Life Antifreeze/Coolant
Type2
Ratio 50/50 with distilled water
Capacity 1.45 US gal (5.50 ℓ)
(change including the remaining

0.125 US gal (0.475 ℓ) in the reserve tank)

140 || 141
CUSTOMER INFORMATIONCUSTOMER INFORMATION
CUSTOMER INFORMATION
Learn about information specifi c to you as a Honda customer and how to get help.
Frequently Asked Questions/ Troubleshooting
Below are some frequently asked questions and troubleshooting items that you may
have about the vehicle.
Q: How do I set the vehicle clock?
A: For vehicles without navigation, see page 44. For vehicles with navigation, the
time is automatically set using GPS signals.
Q: Why doesn’t the vehicle start when I press the ENGINE START/STOP button?*
A: The brake pedal must be pressed to start the engine.
Q: What is the AUTO setting on my headlight lever?
A: When in the AUTO position, the vehicle’s exterior lights will automatically turn
on or off depending on the ambient lighting.
Q: Why won’t the driver’s door unlock when I grab the door handle, even though
the keyless access remote is within range?*
A: If you pull the handle too quickly, the system may not have time to confi rm the
door is unlocked. Wait to hear a beep to confi rm the door is unlocked. If you are
wearing gloves, the system may be slow to respond.
Q: After my battery was disconnected or went dead, the audio system is asking for
a code. Where do I nd this?
A: In most cases, you do not need to enter a code. Turn on the vehicle and the
audio system, and press and hold the power button until the system reactivates.
Q: Why can’t I operate Pandora® through the audio system?*
A: Audio may be streaming through Bluetooth® Audio. Make sure Pandora mode
is selected and the phone cable is properly connected to the USB adapter
cable (if using). Some phones may prompt you to “Allow” a connection.
Q: Is my phone compatible with Bluetooth features?
A: Visit handsfreelink.com (U.S.) or www.handsfreelink.ca (Canada) to
check phone compatibility for Bluetooth® Audio, Bluetooth® HandsFreeLink®,
and SMS text messaging.
Q: Every time I press the Talk button, the system gives me voice prompts. Can I turn
these off?*
A: From the Home screen, select SETTINGS. Select System, then select Voice
Prompt. Select Off.
*if equipped
Contact Us
Honda dealer personnel are trained professionals. They should be able to answer
all your questions. If you encounter a problem that your dealership does not solve
to your satisfaction, please discuss it with the dealership’s service manager or
general manager. If you are dissatisfi ed with the decision made by the dealership’s
management, contact Honda Automobile Customer Service.
U.S. Owners:
American Honda Motor Co., Inc.
Honda Automobile Customer Service
1919 Torrance Blvd.
Mail Stop 500-2N-7A
Torrance, CA 90501-2746
Tel: (800) 999-1009
In Puerto Rico and
the U.S. Virgin Islands:
Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546
When you call or write, please give us the following information:
• Vehicle Identifi cation Number
• Date of purchase
• Odometer reading of your vehicle
• Your name, address, and telephone number
• A detailed descripton of the problem
• Name of the dealer who sold the vehicle to you
Honda Roadside Assistance
24-hour emergency road service is available to you in the United States and
Canada throughout your 3-year/36,000-mile warranty term. Services include
jump starting, fl at tire and lockout assistance, towing, and more (limitations apply).
Call (866) 864-5211 (U.S.) or (800) 465-7587 (Canada).
Canadian Owners:
Honda Canada, Inc.
Customer Relations
180 Honda Blvd.
Markham, ON
L6C 0H9
Tel: (888) 946-6329
Fax: (877) 939-0909
e-mail: [email protected]
*if equipped

142 || 143
VOICE COMMAND INDEX
CUSTOMER INFORMATION
Warranty Coverages
Below is a brief summary of the warranties covering your new vehicle.
New Vehicle Limited Warranty: Covers your new vehicle, except for the emissions
control system and accessories, against defects in materials and workman\
ship.
Emissions Control Systems Defects Warranty and Emissions Performance
Warranty: Covers your vehicle’s emissions control systems. Time, mileage, and
coverage are conditional.
Seat Belt Limited Warranty: Covers seat belts that fail to function properly.
Rust Perforation Limited Warranty: Covers all exterior body panels that rust through
from the inside.
Accessory Limited Warranty: Covers Honda accessories.
Replacement Parts Limited Warranty: Covers all Honda replacement parts against
defects in materials and workmanship.
Replacement Battery Limited Warranty: Provides prorated coverage for a
replacement battery purchased from a Honda dealer.
Replacement Muf er Lifetime Limited Warranty: Covers a replacement muffl er for
the duration of the ownership.
Restrictions and exclusions apply to all these warranties. See the Warranty Manual
on the Owner Information CD or at owners.honda.com (U.S.) or myhonda.ca
(Canada) for complete descriptions of each warranty, including time, mileage, and
other conditional limitations.
Your vehicle’s original tires are covered by their manufacturer. Tire warranty
information can be found on the Owner Information CD or at owners.honda.com
(U.S.) or myhonda.ca (Canada). Learn about all available voice commands to help you operate the vehicle\
. Available
on vehicles with navigation.
Press the Talk button before you say a command. To view a list of available
commands in the vehicle, say “Voice help.” Select a category to hear the commands
read aloud.
Global Commands
The system accepts these commands on any screen.
Navigation CommandsThe system accepts these commands on the map/guidance screen.
• V
oice help
• Display menu
• Display setting
• Display navigation
• Display information
• Display voice portal • Display audio
• Display phone
• Back
• What is today’s date?
• What time is it?
General Commands
• Display map
• Go home 1 (or 2)
• Display voice portal
Route Commands
The system accepts these commands
when a route is set.
• How long to the destination?
• How far to the destination?
• Display destination map
• Display entire route
• Cancel route
• Repeat guidance Map Display Commands
• Display current location
• Display/Hide (specify icon type):
−ATM
− gas station
− restaurant
− post offi ce
− grocery store
− lodging (hotel, motel)
− parking garage
− parking lot
− school
− hospital
− freeway exit information

− traffi c

− traffi c speeds

− traffi c icons

− traffi c incidents
• Display north up
• Display heading up
• Display 3D map
• Display zoom in
• Display zoom out
VOICE COMMAND INDEX

144 || 145
VOICE COMMAND INDEX
VOICE COMMAND INDEX
Navigation Commands (continued)
Find Place Commands
•
Find nearest (specify place): − Fuel and auto
− Honda dealers
− Gas station
− Auto parts & electronics
− Auto repair & maintenance
− Car wash & detailing
− Motorcycle dealers
− Other car dealer
− Roadside assistance

−ATM
− Bank
− Check cashing
− Community
− Business
− City hall
− Civic center
− Convention center
− Court house
− Higher education
− Library
− Post offi ce
− School
− Emergency room
− Hospital
− Police station
− Veterinarian
− Lodging
− Bed & breakfast
− Hotel
− Recreation
− Amusement park
− Golf course
− Historical monument
− Marina
− Movie theater
− Museum
− Park
− Performing arts
− Sports complex
− Tourist attraction − Restaurant
− American restaurant
− Californian restaurant
− Chinese restaurant
− Coffee shop
− Continental restaurant
− Fast food
− French restaurant
− German restaurant

− Greek restaurant
−
Indian restaurant
− Italian restaurant
− Japanese restaurant
− Korean restaurant
− Mexican restaurant
− Pizza
− Seafood restaurant
− Thai restaurant
− Vegetarian restaurant
− Vietnamese restaurant
− Other restaurant
− Shopping area
− Accessory store
− Book store
− Clothing store
− Grocery store
− Home improvement store
− Mall
− Offi ce supply store
− Pharmacy
− Pet food store
− Sewing store
− Shoe store
− Sporting goods store
− Toy store
− Travel center
− Airport
− Automobile club
− Bus station
− Camping − Commuter rail station
− Ferry terminal
− Named place
− Park & ride
− Parking garage
− Parking lot
− Rental car agency
− Rest area
− Ski area
− Tourist information
− Train station
− Travel agency
− Truck stop
Climate Control Commands**
The system accepts these commands on most screens.
•
Climate control automatic
(maintains selected temperature)
• Climate control on*
• Climate control off*
• Air conditioner on*
• Air conditioner off*
• Climate control defrost on*
• Climate control defrost off*
• Rear defrost on*
• Rear defrost off*
• Climate control fresh air
• Climate control recirculate
• Climate control vent • Climate control bi-level (vent and
fl oor)
• Climate control fl oor
• Climate control fl oor and defrost
• Fan speed up
• Fan speed down
• Fan speed # (#: 1 to 7)
• Temperature # degrees (#: 57 to 87°F)
• Temperature up
• Temperature down
• Temperature max hot
• Temperature max cold
* These commands toggle the function on and off, so the command may not match your intended action.
**if equipped
Phone CommandsThe system accepts these commands on most screens.
•
Dial/call by number
• Call (phone number or name)
Info Commands
The system accepts these commands on most screens.
• T
rip computer
• Display traffi c list*
• Display traffi c on my route*
On-screen Commands
The system accepts these commands on any screen where applicable. All
available commands are highlighted in yellow when you press the T
alk button.
• Next (or Down)
• Previous (or Up)
• Right (or Left) • Dial/call by name
• Display clock
• Display wallpaper
• Return
• OK
• Delete

146 || 147
VOICE COMMAND INDEX
VOICE COMMAND INDEX
Audio Commands
The system accepts these commands on most screens. Audio volume levels
cannot be controlled using voice commands.


FM/AM Radio Commands
• Audio on*
• Audio off*
• Radio on*
• Radio off*
• Radio select FM
• Radio select AM
• Radio tune to # FM (#: frequency, e.g., 95.5)
• Radio tune to # AM (#: frequency, e.g., 1020)
• Radio seek up
• Radio seek down
• Radio next station
• Radio preset # (#: 1 to 12)
• Radio FM preset # (#: 1 to 12)
• Radio AM preset # (#: 1 to 6) SiriusXM
® Radio Commands
• Radio select XM
• XM channel # (#: 0 to 255)
• XM channel up
• XM channel down
• XM category up
• XM category down
• XM preset # (#: 1 to 12)
• XM scan*
• XM category scan*
• XM channel scan*
• XM category mode
• XM channel mode
• Radio scan*
Disc Commands
• Disc play
• Disc play track # (#: 1 to 30)
• Disc skip forward
• Disc skip back
• Disc track random*
• Disc track repeat*
• Disc track scan*
• Disc folder up
• Disc folder down
• Disc folder random*
• Disc folder repeat*
• Disc folder scan*
• Disc normal play USB Commands
• USB play
• USB play track # (#: 1 to 30)
• USB skip forward
• USB skip back
• USB track random*
• USB track repeat*
• USB track scan*
• USB folder up
• USB folder down
• USB folder random*
• USB folder repeat*
• USB folder scan*
• USB normal play
*These commands toggle the function on and off, so the command may not match your intended action.
Audio Commands (continued)
iPod
® Commands
• Music search
• iPod play
• iPod play track # (#: 1-30)
• iPod skip forward
• iPod skip back
• iPod track shuffl e*
• iPod album shuffl e*
• iPod track repeat*
• iPod normal play
• What/Who am I listening to?
• Who is this?
• What’s playing?
• Who’s playing?
• What album is this?
Pandora
® Commands
• Pandora play*
• Pandora skip forward
• Pandora station up
• Pandora station down
• Pandora pause*
• Pandora resume*
• Pandora like this song
• Pandora dislike this song
*These commands toggle the function on and off, so the command may not match your intended action.
Bluetooth® Audio Commands
• Bluetooth audio play
• Bluetooth audio skip forward
• Bluetooth audio skip back
• Bluetooth audio pause
• Bluetooth audio resume
• Bluetooth audio group up
• Bluetooth audio group down Commands may not work on some
phones or devices.
AUX Commands
• Auxiliary play (for HDMI video)

148 || 149
INDEX
INDEX
INDEX
ABS .........................................................24
Accessory Power Socket ...........................45
Airbags ...........................................................8
Air Conditioning System..............................41
Ambient meter ........................................26, 94
Anti-lock Brake System (ABS) .............24, 93
Audio Operation .....................................45, 50
Audio Commands .................................. 146
Auxiliary Input Jack .................................45
Bluetooth
® Audio ...............................55, 64
Compact Disc (CD) .......................49, 52, 61
FM/AM Radio ................................48, 51, 59
HDMI Port ..................................................45
HDMI Video ...............................................66
iPod
® ...................................................53, 62
Pandora® .............................................56, 65
SiriusXM® Radio .......................................60
Sound .........................................................47
Steering Wheel Controls .........................46
Touchscreen Operation ..........................57
USB Flash Drive ..................................54, 63
USB Port ....................................................45
Battery .......................................................125
Bluetooth
® Audio ...................................55, 64
Bluetooth® Audio Commands ..................147
Bluetooth® Handsfreelink® (HFL) .............67
Dialing a Number ...............................69, 74
E-Mail .........................................................76
HFL Controls ........................................67, 71
HondaLink™ Assist ..................................77
Making a Call ......................................69, 74
Pairing a Phone ..................................68, 73
Phonebook ..........................................69, 74
Siri™ Eyes Free ........................................77
SMS Text Messaging ........................70, 76
Speed Dial ...........................................69, 75
Voice Recognition Tips ............................72
Brake Assist System....................................93
Brake system ..........................................23, 24
Braking .........................................................93
Brightness Control .......................................34
Carbon Monoxide Gas...................................4
Changing a Flat Tire ...................................108
Changing Settings ........................................43
Charging system...........................................23
Child Safety ...................................................14
Childproof Door Locks .................................31
Child Seat ......................................................16 Adding Security with a Tether ...............19
LATCH-Compatible Child Seat ................17
Climate Control Commands ......................145
Climate Control System ...............................42 Clock .........................................................44
Compact Disc (CD) ...........................49, 52, 61
Compact Disc Commands.........................146
Condition Indicators ....................................25
Contact Us ...................................................141
Continuously Variable Transmission (CVT) ... 91
Cruise Control .........................................26, 95
Customer Information................................140
Customized Features ...................................43
Dashboard, Ceiling, and Other Controls .....2
Daytime Running Lights (DRL)....................24
Destination ....................................................81
Detour .........................................................84
Dialing a Number ...................................69, 74
Door Mirrors .................................................40
Door Operation .............................................31
DOT Tire Quality Grading ..........................131
Driver’s Seat ..................................................36
Driving .........................................................85
Braking .......................................................93
Continuously Variable Transmission (CVT) ...............................................91
Cruise Control ...........................................95
Eco Assist System ....................................94
ENGINE START/STOP button .................91
Ignition .......................................................90
LaneWatch™ ............................................96
Manual Transmission ..............................92
Maximum Load Limit ................................87
Paddle Shifters .........................................92
Power Mode .............................................91
Refueling ....................................................99
Shifting .......................................................91
Vehicle Stability Assist (VSA
®) ..............94
Wiper Blades ..........................................126
DRL .........................................................24
Eco Assist System........................................94
ECON Button .................................................94
ECON mode ...................................................26
Electric Power Steering (EPS) ...................24
Electronic Stability Control (ESC) ..............94
E-Mail .........................................................76
Emergency Engine Stop ............................106
Emergency Towing ....................................106
Engine Specs ..............135, 136, 137, 138, 139
Engine Coolant............................................124
Engine Oil.....................................................121
ENGINE START/STOP button .....................91
Exterior Lights ...............................................34
Fastening a Seat Belt ....................................7
Find Nearest Place ......................................82
Find Place Commands ...............................144 Flat Tire .......................................................108
Floor Mats .....................................................37
Fluids .......................135, 136, 137, 138, 139
FM/AM Radio ....................................48, 51, 59
FM/AM Radio Commands .........................146
Foot Brake .....................................................93
Frequently Asked Questions ....................140
Front Airbags (SRS) .......................................8
Front Door Inner Handle .............................31
Fuel gauge .....................................................26
Fuel Information ...................................99, 100
Fuse Locations............................................112
Gauges .........................................................26
HDMI Port......................................................45
HDMI Video ...................................................66
Headlight-Wiper Integration ......................35
Head Restraints ............................................38
High temperature .........................................24
Home Address ..............................................81
HondaLink™ ..................................................58
HondaLink™ .....................................Assist 77
Honda Roadside Assistance ....................141
Hood .......................................................119
Ignition .........................................................90
i-MID .........................................................28
Immobilizer ....................................................26
Info Commands...........................................145
Information Display......................................27
Instant fuel economy gauge.......................26
Instrument Panel ..........................................23
Intelligent Multi-Information Display
(i-MID) ............................................28
Interior Lights................................................34
Intermittent Wipers......................................35
iPod
® ...................................................53, 62
iPod® Commands .......................................147
i-VTEC indicator............................................26
Jump Starting .............................................103
LaneWatch™ ................................................96
Lap/Shoulder Seat Belts ...............................5
LATCH-Compatible Child Seat ....................17
Light Bulbs...................135, 136, 137, 138, 139
Lights ...................................................26, 34
Lock Tab .........................................................31
Low fuel .........................................................25
Low oil pressure ...........................................23
Low temperature ..........................................24
Low tire pressure .........................................25
Maintenance...............................................115 Battery .....................................................125
Engine Coolant ........................................124
Engine Oil .................................................121
Maintenance Minder™ .........................116
Service Codes .........................................117
Under the Hood ......................................119 Window Washer Fluid ...........................125
Making a Call ..........................................69, 74
Malfunction indicator lamp ........................24
Malfunction Indicators................................23
Manual Transmission ..................................92
Map Display Commands ...........................143
Map Legend ..................................................83
Master Door Lock Switch ...........................31
Maximum Load Limit....................................87
Mirrors .........................................................40
Moonroof .......................................................33
Multi-View Rear Camera ............................98
Navigation .....................................................78 Detour ........................................................84
Display and Controls ................................79
Entering a Destination .............................81
Find Nearest Place ..................................82
Home Address ..........................................81
Map Legend ..............................................83
Navigation Commands ..........................143
Place Category .........................................82
Routing .......................................................83
Steering Wheel Controls .........................78
Street Address ..........................................81
Traffi c .........................................................84
Turn-by-Turn Directions ..........................83
Voice Recognition Tips ............................80
Voice Prompt.............................................80
One-Touch Turn Signal ................................35
On/Off Indicators ..........................................26
On-screen Commands...............................145
Opening the Hood ......................................120
Overheating.................................................105
Paddle Shifters .............................................92
Pairing a Phone ......................................68, 73
Pandora® .................................................56, 65
Pandora® Commands ................................147
Parking brake..........................................25, 93
Passenger Airbag Off Indicator .................11
Phone ...................................................68, 73
Phonebook ..............................................69, 74
Phone Commands ......................................145
Place Category .............................................82
Power Door Mirrors.....................................40
Power Driver’s Seat .....................................36
Power Mode .................................................91
Power Moonroof Operation .......................33
Power Window Lock ...................................32
Power Window Operation ..........................32
Radio .........................................................48
Readiness Codes........................................134
Rear Seats .....................................................39
Rearview Camera.........................................97
Rearview Mirror ...........................................40
Refueling........................................................99

150 || 151
INDEX
INDEX
Remote Battery Strength ..........................103
Remote Transmitter .....................................29
Reporting Safety Defects............................22
Rev indicator .................................................26
Roadside Assistance .................................141
Route Commands .......................................143
Routing 83
Safety Information .........................................3
Airbags .........................................................8
Child Safety ...............................................14
Reporting Safety Defects ........................22
Safety Label Locations ............................21
Seat Belts ....................................................5
Seat Belts ........................................................5 Fastening a Seat Belt ................................7
Seat Belt Inspection ..................................6
Seat Belt Reminder ..................................25
Shoulder Anchor ........................................7
Seat Heaters .................................................42
Seats .........................................................36
Service Codes.............................................117
Settings .........................................................43
Setting the Clock ..........................................44
Shifting .........................................................91
Shift Lever Does Not Move ......................104
Shoulder Anchor ............................................7
Side Airbags....................................................9
Side Curtain Airbags......................................9
Siri™ Eyes Free ............................................77
SiriusXM
® Radio ...........................................60
SiriusXM® Radio Commands ....................146
Smart Entry system ................................23, 30
SMS Text Messaging ............................70, 76
Sound .........................................................47
Specifi cations .............................................135
Speed Dial ...............................................69, 75
Speedometer ................................................26
Steering Wheel.............................................40
Steering Wheel and Nearby Controls ........1
Steering Wheel Controls.......................46, 78
Street Address..............................................81
Supplemental Restraint System (SRS) ...10, 23
System message ..........................................26
Text Messaging ......................................70, 76
Tire Information ..........................................127 DOT Tire Quality Grading ......................131
Infl ation Guidelines ................................127
Specifi cations .........135, 136, 137, 138, 139
Tire and Loading Information Label ....128
Tire and Wheel Replacement ...............128
Tire Chains ...............................................129
Tire Identifi cation Number (TIN) ..........130
Tire Labeling ............................................130
Tire Service Life ......................................129
Tire Terminology .....................................130 Wear Indicators .....................................127
Winter Tires .............................................129
Tire Pressure Monitoring System (TPMS) .........................................24, 107, 133
Tire Repair Kit .............................................111
Tire Service Life..........................................129
Touchscreen Operation ..............................57
Towing .......................................................106
Towing a Trailer ............................................89
TPMS .........................................24, 107, 133
Traffi c .........................................................84
Trip Computer ...............................................28
Troubleshooting ..........................................140
Trunk Opener ................................................31
Turn-by-Turn Directions ..............................83
Turn Signal ....................................................35
USB Commands..........................................146
USB Flash Drive......................................54, 63
USB Port ........................................................45
Vehicle Specs .............135, 136, 137, 138, 139
Vehicle Stability Assist (VSA
®) ......24, 26, 94
Visual Index.....................................................1
Voice Command Index ..............................143
Voice Prompt ................................................80
Voice Recognition Tips ..........................72, 80
VSA
® .............................................24, 26, 94
Warranty Coverages .................................142
Washer fl uid level ........................................26
Wear Indicators .........................................127
Windows........................................................32
Window Washer Fluid ...............................125
Winter Tires .................................................129
Wiper Blades ..............................................126
Wiper Operation ...........................................35
