HONDA CR-V 2009 RD1-RD5, RE7 / 3.G Owners Manual

The rear seat armrest is in the
center of the rear seat. Pivot it down
to use it.If your vehicle is equipped with a
dual deck cargo shelf , do not use the
shelf when any seat-back is f olded
down. Objects placed on this shelf
canbethrownforwardand
occupants can be injured during
sudden stops or a collision.
For more inf ormation on the dual
deck cargo shelf , see page .
The rear center seat-back has a
cargo area pass-through. To use the
cargo area pass-through, pull up the
release on top of the center seat-
backandfolditdown. 114
Seats
Cargo Pass-through
Inst rument s and Cont rols
97
REAR
\f—\f—y
y
(,\fy\f
\fy
2009 CR- V

See pagef or important saf etyinf ormation and a warning aboutimproperly positioning head restraints. 13
Your vehicle is equipped with head
restraints in all seating positions to
help protect you and your
passengers f rom whiplash and other
injuries.
They are most ef f ective when you
adjust them so the center of the back
of the occupant’s head rests against
the center of the restraint.The head restraints adjust f or height.
You need both hands to adjust a
restraint.Donotattempttoadjustit
while driving. To raise it, pull upward.
To lower the restraint, push the
release button sideways, and push
the restraint down.
Head Restraints
Seats
A djust ing t he Head Rest raint
98
RELEASE BUTTON
LEGS
SEAT-BACK CUSHION
Front Position
\f—\f—y
\fy
(,\fy\f
\fy
2009 CR- V

When a passenger is seated in the
rear center seating position, make
sure the center head restraint is
properly adjusted.Make sure the removed head
restraints are securely stored.
To remove a head restraint, pull it up
as f ar as it will go. Push the release
button, then pull the restraint out of
the seat-back. Make sure the head restraint locks
in position when you reinstall it.
When reinstalling a head restraint,
put the legs back in place. Then
adjust it to the appropriate height
while pressing the release button.
Seats
Removing t he Head Rest raint
Inst rument s and Cont rols
99
RELEASE BUTTON
RELEASE BUTTON
Rear Outer Position Rear Center
CUSHION
LEGS SEAT-BACK CUSHION
LEGS SEAT-BACK
Failure to reinstall the head
restraints can result in severe
injury during a crash.
Always replace the head
restraints before driving.
\f—\f—y
y
(,\fy\f
\fy
2009 CR- V

The driver’s and f ront passenger’s
seats have active head restraints. If
the vehicle is struck severely f rom
the rear, the occupant properly
secured with the seat belt will be
pushed against the seat-back and the
head restraint will automatically
move forward.
This reduces the distance between
the restraint and the occupant’s head.
It also helps protect the occupantsagainst whiplash and injuries to the
neck and upper spine.
Af ter a collision, the activated
restraint should return to its normal
position.
If the restraints do not return to their
normal position, or in the event of a
severe collision, have the vehicle
inspected by a Honda dealer.
For a head restraint system to work
properly:
Do not hang any items on the head
restraints, or f rom the restraint
legs.
Do not place any object between
an occupant and the seat-back.
Install each restraint in its proper
location.
Only use genuine Honda
replacement head restraints.
Seats
A ct ive Head Rest raint s
100
\f—\f—y
y
(,\fy\f
\fy
2009 CR- V

You can recline the seat-backs on the
f ront seats so they are level with the
rear seat cushions, making a large
cushioned area. To do this:Adjust the rear seats as f ar back
as possible.
Remove the f ront head restraints
(see page ), and store them
securely.
Only the passenger’s side can be
level as f ollows. Adjust the front seats forward as
f ar as possible. Pull up the seat-
back angle adjustment lever and
pivot the seat-back backward until
it is level with the rear seat
cushion.
The seat-back of the power
adjustable driver’s seat cannot be
level. Do not push the seat-back
down f orcibly.
Adjust the rear seat-back to the
desired position.
Reverse this procedure to return the
front and rear seats to the upright
position. Make sure you install the
head restraints and securely lock the
seats before driving.
When you return the seat-back to its
upright position, hold the seat-back
to keep it f rom going up too quickly.
1.
2.
4.
3.
98
EX-L model only EX-L model only
Reclining the Front Seats
Seats
Inst rument s and Cont rols
101
SLIDE BAR
SEAT-BACK ANGLE
ADJUSTMENT LEVER
\f—\f—y
y
(,\fy\f
\fy
2009 CR- V

Each rear seat-back can be folded
down separately to give more cargo
room. With either of the outer seat-
backs f olded-down, you can still
carry a passenger in the rear seat.
With the center seat-back folded-
down, either outer seating position
can be used.
You can also fold up the left or right
side of the rear seats separately to
create further cargo space (see page).
Remove any items from the seat
before folding down the seat-back. Push the seat belt buckles into the
seat cushion.
When you are f olding the rear center
seat-back, use the latch plate to
release the center seat belt from the
detachable anchor (see page ).
Allow the seat belt to retract into the
holder on the ceiling and store the
buckles in it.
Make sure the rear seat armrest is
stored.
1.
105
107
Folding the Rear Seats Down
Seats
102
LATCH PLATE
BUCKLE
\f—\f—y
\fy
(,\fy\f
\fy
2009 CR- V

Lower the rear head restraints to
their lowest position.
Pull up the release lever on the top
of the seat-back.
Fold the seat-back forward.
Do not put any heavy items on the
seat-back when it is folded down. Reverse this procedure to return the
seat-back to the upright position.
Make sure the seat is secured and
the seat belt is in f ront of the seat-
back bef ore driving.
In the rear center seating position,
be sure the detachable anchor is
latched securely (see page ).
Make sure that the f olded down rear
seat does not interf ere with the f ront
passenger’s seat-back. This will
cause the f ront passenger’s weight
sensors and the f ront passenger’s
seat belt reminder indicator to work
improperly (see pages and ).
Also check the passenger airbag of f
indicator to assure proper operation
of the passenger’s front airbag.
2.
3.
4. 107
1832
CONT INUED
Seats
Inst rument s and Cont rols
103
RELEASE LEVER
\f—\f—y


y
(,\fy\f
\fy
2009 CR- V

When any seat-back is f olded down,
do not use the dual deck cargo shelf
(if equipped).
Make sure all items in the cargo area
are secured. Loose items can f ly
f orward and cause injury if you have
to brake hard (See
on page ).The lef t and right rear seats can be
f olded up separately to make room
for cargo.
To f old the rear seat f orward:
Remove any items from the seat
beforeyoufolduptheseatcushion.Pull up the bar under the seat
cushion and slide the rear seat
backward. The rear seat will not
foldforwardunlessitisasfar
back as it will go. Follow steps 1 through 4 on page
f or f olding down the seat-
back.
Lower the center seat-back bef ore
f olding the passenger’s side seat
forward.
1. 2.
236 102
Carrying Cargo Folding the Rear Seat Forward
Seats
104
SLIDE BAR
\f—\f—y

y
(,\fy\f
\fy
2009 CR- V

Pull out the f astening strap f rom
the slit on the seat-back. Then
attach the anchor on the fastening
strap to the hook on the center
pillar.Pull down on the anchor to engage
the upper part of the anchor
securely on the hook, and make
sure the seat is secure.
Unlock the seat f rom the f loor by
pulling the lock release strap
located at the rear of the seat
cushion, under the seat back, then
lift the rear of the seat.
You cannot fold up the rear seat if
it is not latched securely in the
rearmost position.
3.
4.5.
CONT INUED
Seats
Inst rument s and Cont rols
105
LOCK RELEASE STRAP ANCHOR
HOOK
FASTENING
STRAP ANCHOR
FASTENING STRAP
HOOK
\f—\f—y
y
(,\fy\f

\fy
2009 CR- V

Make sure that the f olded up right
rear seat does not interf ere with the
f ront passenger’s seat-back. This will
cause the f ront passenger’s weight
sensors and the f ront passenger’s
seat belt reminder indicator to work
improperly (see page ). Also
check the passenger airbag of f
indicator to assure proper operation
of the passenger’s advanced f ront
airbag.
Reverse this procedure to return the
seat to the upright position.
Make sure the seat is securely
latched bef ore driving.
When you are not using the
fastening strap, store the strap into
the slit on the seat-back.Make sure both outer seat belts are
positioned in side of the rear seat-
backs.
In the center seating position of the
rear seat, be sure the detachable
anchor is latched securely bef ore
using the seat belt (see page ).
Make sure all items in the cargo area
are secured. Loose items can f ly
f orward and cause injury if you have
to brake hard (See
on page ).
Do not use the dual deck cargo shelf
(if equipped) when the seats are
folded down or forward.
The seat belt in the rear center seat
is equipped with a detachable anchor.
This allows the center seat belt to be
unlatched when the rear center seat
back is f olded down or the right side
rear seat is folded forward.
32
107
236 Carrying Cargo Detachable Anchor
Seats
106
Using the seat belt with the
detachable anchor unlatched
increases the chance of serious
injury or death in a crash.
Before using the seat belt,
make sure the detachable
anchor is correctly latched.
\f—\f—y
y
(,\fy\f


y
