319Continued
Handling the Unexpected
If a Tire Goes Flat
Changing a Flat Tire
If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then, stop in a safe place. Replace the flat tire with a compact
spare tire. Go to a dealer as soon as possible to have the full-size tire repaired or
replaced.
1.Park the vehicle on firm, level, and non-slippery and apply the parking brake.
2.Move the shift lever to
(P.
3.Turn on the hazard warning lights and turn the ignition switch to LOCK (0.
1Changing a Flat Tire
Periodically check the tire pressure of the compact
spare. It should be set to the specified pressure.
Specified Pressure: 60 psi (420 kPa, 4.2 kgf/cm
2)
When driving with the compact spare tire, keep the
vehicle speed under 50 mph (80 km/h). Replace with
a full-size tire as soon as possible.
The compact spare tire and wheel in your vehicle are
specifically for this model.
Do not use them with another vehicle.
Do not use another type of compact spare tire or
wheel with your vehicle.
Do not mount tire chains on a compact spare tire.
If a chain-mounted front tire goes flat, remove one of
the full-size rear tires and replace it with the compact
spare tire. Remove the flat front tire and replace it
with the full-size tire that was removed from the rear.
Mount the tire chains on the front tire.
Do not use a puncture-repairing agent on a flat tire,
as it can damage the tire pressure sensor.

uuIf a Tire Goes FlatuChanging a Flat Tire
324
Handling the Unexpected
1.Remove the center cap.
2.Place the flat tire face down in the spare tire
well.
3.Remove the spacer cone from the wing
bolt, flip it over, and insert it back on the
bolt. Secure the flat tire with the wing bolt.
4.Securely store the wheel nut wrench and
jack handle bar back in the tool bag. Store
the bag in the cargo area.
5.Store the jack in its holder. Turn the jack’s
end bracket to lock it in place.
If you replace a flat tire with the spare tire, the low tire pressure indicator comes on
while you are driving. After driving for a few miles (kilometers), the indicator will go
off and the TPMS indicator comes on, but this is normal.
If you replace the tire with a specified regular tire, the low tire pressure or TPMS
indicator will go off after a few miles (kilometers).■Storing the Flat Tire1Storing the Flat Tire
3WARNINGLoose items can fly around the interior in a
crash and can seriously injure the
occupants.
Store the wheel, jack, and tools securely
before driving.Spacer
ConeWing
Bolt
For compact spare tireFor full-size
tire
■TPMS and the Spare Tire1TPMS and the Spare Tire
The system cannot monitor the pressure of the spare
tire. Manually check the spare tire pressure to be sure
that it is correct.
Use the TPMS specific wheels. Each is equipped with
a tire pressure sensor mounted inside the tire behind
the valve stem.

Index
353
Index
Index
Numbers
4WD.......................................................... 251
AABS (Anti-lock Brake System).................. 256
Accessories and Modifications................ 264
Accessory Power Sockets......................... 135
Additives
Coolant .................................................. 282
Engine Oil ............................................... 277
Washer ................................................... 286
Additives, Engine Oil............................... 277
Adjusting
Armrest .................................................. 131
Front Seats.............................................. 122
Head Restraints ....................................... 125
Mirrors.................................................... 120
Rear Seat Back ........................................ 130
Rear Seats ............................................... 129
Steering Wheel ....................................... 119
Air Conditioning System (Climate
Control System)...................................... 145
Changing the Mode................................ 145
Defrosting the Windshield and
Windows .............................................. 146
Dust and Pollen Filter .............................. 311
Recirculation/Fresh Air Mode................... 145
Sensors ................................................... 148
Synchronized Mode ................................ 147
Using Automatic Climate Control............ 145Air Conditioning System (Heating and
Cooling System)...................................... 142
Cooling ................................................... 144
Defrosting the Windshield and
Windows ............................................... 144
Dust and Pollen Filter ............................... 311
Heating ................................................... 143
Air Pressure....................................... 299, 343
Airbags........................................................ 37
Advanced Airbags ..................................... 43
After a Collision......................................... 41
Airbag Care ............................................... 51
Event Data Recorder .................................. 21
Front Airbags (SRS) .................................... 40
Indicator ........................................ 48, 71, 74
Passenger Airbag Off Indicator .................. 49
Sensors...................................................... 37
Side Airbag Cutoff System ......................... 46
Side Airbag Off Indicator ........................... 50
Side Airbags .............................................. 44
Side Curtain Airbags .................................. 47
AM/FM Radio............................................ 156
Anti-lock Brake System (ABS).................. 256
Indicator .................................................... 71
Armrest..................................................... 131
Audio Antenna......................................... 152
Audio System............................................ 150
Adjusting the Sound ................................ 155
Auxiliary Input Jack .................................. 151
Error Messages ........................................ 186
General Information ................................ 190iPod®....................................................... 164
MP3/WMA/AAC ...................................... 169
Pandora®................................................. 167
Reactivating ............................................ 152
Recommended CDs ................................. 191
Recommended Devices............................ 193
Security Code .......................................... 152
Theft Protection ...................................... 152
USB Adapter Cable.................................. 151
USB Flash Drives ...................................... 193
Authorized Manuals................................ 351
Auto Door Locking/Unlocking................. 103
Customize ................................................. 89
Automatic Lighting.................................. 113
Automatic Transmission........................... 242
Creeping ................................................. 242
Fluid ........................................................ 284
Kickdown ................................................ 242
Operating the Shift Lever................... 15, 244
Shift Lever Does Not Move ...................... 328
Shifting ................................................... 243
Auxiliary Input Jack.................................. 151
Average Fuel Economy........................ 79, 82
Average Speed........................................... 82
AWD.......................................................... 251
BBattery...................................................... 307
Charging System Indicator................. 69, 331
Jump Starting .......................................... 326

354
Index
Maintenance (Checking the Battery) ........ 307
Maintenance (Replacing).......................... 308
Behind a Motorhome............................... 235
Belts (Seat).................................................. 29
Beverage Holders...................................... 134
Bluetooth® Audio..................................... 172
Bluetooth® HandsFreeLink®..................... 194
Booster Seats (For Children)....................... 64
Brake System............................................. 254
Anti-lock Brake System (ABS) ................... 256
Brake Assist System ................................. 257
Fluid ........................................................ 285
Foot Brake ............................................... 255
Indicator ............................................ 68, 333
Parking Brake .......................................... 254
Brightness Control (Instrument Panel).... 117
Bulb Replacement..................................... 287
Brake Light, Taillight, Back-Up Light, Rear
Turn Signal Light and Lower Rear Side
Marker Light ........................................ 290
Fog Lights ................................................ 288
Front Turn Signal/Parking Light ................ 290
Headlights ............................................... 287
High-Mount Brake Light .......................... 293
Rear License Plate Light............................ 293
Side Marker Lights ................................... 289
Upper Rear Side Marker/Taillight .............. 292
Bulb Specifications.................................... 342CCarbon Monoxide Gas............................... 65
Cargo Hook............................................... 137
Cargo Side Net.......................................... 136
Carrying Cargo................................. 227, 229
CD Player................................................... 161
Certification Label.................................... 344
Changing Bulbs........................................ 287
Charging System Indicator................. 69, 331
Child Safety................................................. 52
Childproof Door Locks............................. 102
Child Seat.................................................... 52
Booster Seats ............................................ 64
Child Seat for Infants................................. 54
Child Seat for Small Children ..................... 55
Installing a Child Seat with a Lap/Shoulder
Seat Belt .................................................. 60
Larger Children ......................................... 63
Rear-facing Child Seat ............................... 54
Selecting a Child Seat ................................ 56
Childproof Door Locks............................. 102
Cleaning the Exterior............................... 314
Cleaning the Interior................................ 312
Climate Control System............................ 145
Changing the Mode ................................ 145
Defrosting the Windshield and
Windows ............................................... 146
Dust and Pollen Filter............................... 311
Recirculation/Fresh Air Mode ................... 145
Sensors ................................................... 148
Synchronized Mode................................. 147Using Automatic Climate Control ............ 145
Clock........................................................... 96
Coat Hook................................................ 136
Compact Spare Tire.......................... 319, 343
Compass.................................................... 223
Console Compartment............................. 133
Controls...................................................... 95
Coolant (Engine)...................................... 282
Adding to the Radiator ........................... 283
Adding to the Reserve Tank .................... 282
Overheating ............................................ 329
Creeping (Automatic Transmission)........ 242
Cruise Control.......................................... 246
Indicator ................................................... 76
Cup Holders.............................................. 134
Customer Service Information................ 352
Customized Features................................. 84
DDaytime Running Lights.......................... 114
Dead Battery............................................ 326
Defrosting the Windshield and
Windows......................................... 144, 146
Detachable Anchor.................................... 34
Devices that Emit Radio Waves............... 345
Dimming
Headlights .............................................. 112
Rearview Mirror ...................................... 120
Dipstick (Engine Oil)................................ 278
Directional Signals (Turn Signal)............. 112

359
Index
Seats.......................................................... 122
Adjusting ................................................ 122
Driver’s Seat Lumbar Support .................. 122
Front Seats.............................................. 122
Rear Seats ............................................... 129
Seat Heaters ........................................... 139
Security System........................................ 106
Immobilizer System Indicator..................... 75
Security System Alarm Indicator ................ 75
Select Lever........................................ 15, 243
Operation ......................................... 15, 244
Releasing ................................................ 328
Won’t Move ........................................... 328
Select/Reset Knob...................................... 78
Selecting a Child Seat................................ 56
Selector Knob (Audio)............................. 153
Setting the Clock........................................ 96
Shift Lever.......................................... 15, 243
Shift Lever Position Indicator............ 69, 244
Shifting (Transmission)............................ 243
Shoulder Anchor........................................ 33
Side Airbags............................................... 44
Cutoff System ........................................... 46
Off Indicator ............................................. 46
Side Curtain Airbags.................................. 47
SMS Text Message............................ 206, 218
Snow Tires................................................ 306
Spare Tire......................................... 319, 343
Spark Plugs............................................... 342
Specifications........................................... 342
Specified Fuel................................... 260, 342Speedometer.............................................. 77
SRS Airbags (Airbags)................................. 40
Starting the Engine.................................. 239
Does Not Start ......................................... 325
Engine Switch Buzzer .............................. 111
Jump Starting .......................................... 326
Steering Wheel......................................... 119
Adjusting................................................. 119
Stopping.................................................... 258
Summer Tires............................................ 306
Sunglasses Holder..................................... 138
Supplemental Restraint System (SRS)........ 40
Switches (Around the Steering
Wheel)............................................. 2, 3, 111
Synchronized Mode.................................. 147
TTachometer................................................. 77
Tailgate..................................................... 104
Unable to Open ....................................... 339
Temperature Gauge................................... 77
Temperature Sensor................................. 148
Text Message.................................... 206, 218
Time (Setting)............................................. 96
Tire Pressure Monitoring System
(TPMS)..................................................... 251
Indicator ............................................ 73, 334
Tires........................................................... 298
Air Pressure ..................................... 299, 343
Checking and Maintaining....................... 298Inspection ............................................... 298
Labeling .................................................. 299
Puncture (Flat Tire) .................................. 319
Regulations ............................................. 301
Rotation .................................................. 305
Spare Tire ........................................ 319, 343
Summer .................................................. 306
Tire Chains .............................................. 306
Wear Indicators ....................................... 303
Winter..................................................... 306
Tonneau Cover......................................... 140
Tools.......................................................... 318
Towing a Trailer....................................... 231
Equipment and Accessories ..................... 232
Load Limits .............................................. 231
Towing Your Vehicle................................ 235
Behind a Motorhome .............................. 235
Emergency .............................................. 338
TPMS (Tire Pressure Monitoring
System).................................................... 251
Indicator............................................ 73, 334
Transmission............................................. 243
Automatic ............................................... 243
Fluid ........................................................ 284
Number................................................... 344
Shift Lever Position Indicator.............. 69, 244
Trip Meter................................................... 79
Troubleshooting....................................... 317
Blown Fuse...................................... 335, 336
Brake Pedal Vibrates .................................. 19
Buzzer Sounds When Opening Door.......... 20
