display HONDA CR-V 2015 RM1, RM3, RM4 / 4.G Quick Guide
[x] Cancel search | Manufacturer: HONDA, Model Year: 2015, Model line: CR-V, Model: HONDA CR-V 2015 RM1, RM3, RM4 / 4.GPages: 81, PDF Size: 14.87 MB
Page 59 of 81
![HONDA CR-V 2015 RM1, RM3, RM4 / 4.G Quick Guide 110 || 111
HANDLING THE UNEXPECTED
DRIVING
Refueling
Use the proper fuel and refueling procedure to ensure the best performan\
ce and
safety of your vehicle.
Fuel Information
Use of](/img/13/5803/w960_5803-58.png "HONDA CR-V 2015 RM1, RM3, RM4 / 4.G Quick Guide 110 || 111
HANDLING THE UNEXPECTED
DRIVING
Refueling
Use the proper fuel and refueling procedure to ensure the best performan\
ce and
safety of your vehicle.
Fuel Information
Use of")
110 || 111
HANDLING THE UNEXPECTED
DRIVING
Refueling
Use the proper fuel and refueling procedure to ensure the best performan\
ce and
safety of your vehicle.
Fuel Information
Use of unleaded gasoline of 87 octane or higher is recommended.
• Honda recommends TOP TIER Detergent Gasoline where available.
• Do NOT use gasoline containing more than 15% ethanol.
• Do NOT use gasoline containing methanol.
• Do NOT use gasoline containing MMT.
How to Refuel
1. The fuel fi ll door is located at the left rear of the vehicle. Park next to the service pump that is
most accessible.
2. Turn off the engine.
3. Pull the fuel fi ll door release handle near the parking brake. The fuel fi ll door opens.
4. Turn the fuel fi ll cap slowly to open. Place the fuel fi ll cap in the holder.
5. Insert the fi ller nozzle fully. When the tank is full, the fuel nozzle clicks off automatically.
6. Replace the fuel fi ll cap. Tighten it until you hear at least one click. Close the fuel fi ll door.
We recommend quality gasoline containing detergent additives that help
prevent fuel system and engine deposits. In addition, in order to mainta\
in good
performance, fuel economy, and emissions control, we strongly recommend the
use of gasoline that does NOT contain harmful manganese-based fuel addit\
ives
such as MMT, if such gasoline is available.
NOTICE
Pull
Holder
Gasoline is highly fl ammable and explosive. You can be burned or seriously
injured when handling fuel.
• Stop the engine, and keep heat, sparks, and fl ame away.
• Handle fuel only outdoors.
• Wipe up spills immediately.
WARNING
Learn about what to do in critical or emergency situations.
Smart Entry Remote Battery Strength*
If the battery life in your remote transmitter is weak, a message appear\
s in the
display with information on how to start the engine.
1. Touch the back of the remote transmitter to the
ENGINE START/STOP button while the indicator is
fl ashing.
2. With the brake pedal pressed, press the ENGINE START/STOP button within 10 seconds.
Jump Starting
Turn off the power to electric devices, such as audio and lights. Turn off the engine,
then open the hood.
1. Connect the fi rst jumper cable to your vehicle’s battery (+) terminal.
2. Connect the other end of the fi rst jumper cable to the booster battery (+) terminal. Use a 12-volt
booster battery only.
3. Connect the second jumper cable to the booster battery (-) terminal.
4. Connect the other end of the second jumper cable to the engine mounting bolt as shown. Do not
connect this jumper cable to any other part.
5. If your vehicle is connected to another vehicle, start the assisting vehicle’s engine and increase its
rpm slightly.
6. Attempt to start your vehicle’s engine. If it turns over slowly, make sure that the jumper cables have
good metal-to-metal contact.
WARNING: Battery posts, terminals, and related accessories contain lead and lead\
compounds. Wash your hands after handling.
Booster battery
A battery can explode if you do not follow the correct procedure, seriou\
sly
injuring anyone nearby.
Keep all sparks, open fl ames, and smoking materials away from the battery.
WARNING
HANDLING THE UNEXPECTED
*if equipped
Page 61 of 81
114 || 115
HANDLING THE UNEXPECTED
HANDLING THE UNEXPECTED
Emergency Engine Stop*
The ENGINE START/STOP button may be used to stop the engine due to an
emergency situation even while driving. If you must stop the engine, cho\
ose one of
the following operations:
• Press and hold the ENGINE START/STOP button for
two seconds, or
• Firmly press the ENGINE START/STOP button two times.
The steering wheel will not lock. The power mode changes to ACCESSORY, unless
the shift lever is in Park (P), in which case the power mode changes t\
o VEHICLE OFF.
Because turning off the engine also disables the power assist the engine\
provides
to the steering and braking systems, it will require signifi cantly more physical effort
and time to steer and slow the vehicle. Downshift gears and use both fee\
t on the
brake pedal, if necessary, to slow the vehicle and stop immediately in a safe place.
Do not press the button while driving unless it is absolutely necessary \
for the engine
to be switched off.
Emergency Towing
Call a professional towing service if you need to tow your vehicle.
Flat bed equipment: The operator loads your vehicle on the back of a tru\
ck. This is
the best way to transport your vehicle.
Wheel lift equipment: The tow truck uses two pivoting arms that go under\
the front
tires and lift them off the ground. The rear tires remain on the ground.\
This is an
acceptable way to tow your vehicle (2WD models only).
Trying to lift or tow your vehicle by the bumpers will cause serious dama\
ge. The
bumpers are not designed to support the vehicle’s weight.
Improper towing such as towing behind a motorhome or other motor vehicle\
can
damage the transmission.
NOTICE
*if equipped
Tire Pressure Monitoring System ( TPMS)
Monitors the tire pressure while you are driving.
If your vehicle’s tire pressure becomes signifi cantly low,
the low tire pressure indicator comes on and a message
appears on the multi-information display.
What to Do Stop your vehicle in a safe place. Check the tire
pressure and adjust the pressure to the specifi ed
level. The specifi ed tire pressure is on a label on the
driver’s doorjamb.
TPMS CalibrationAny time you infl ate, change, or rotate one of more of the tires, you need to
recalibrate the system.
On vehicles with information display
Press and hold the TPMS button on the dashboard.
The TPMS indicator blinks, and calibration begins.
On vehicles with multi-information display (MID)
Use the buttons on the steering wheel to enter and operate the Vehicle Settings
menu (see page 30).
1. Scroll to the Vehicle Settings screen and enter the menu.
2. Select TPMS Calibration.
3. Select Calibrate. Calibration begins.
4. Exit the menu.
Driving on an extremely underinfl ated tire can cause it to overheat. An overheated
tire can fail. Always infl ate your tires to the specifi ed pressure.
NOTICE
Page 65 of 81
122 || 123
MAINTENANCE
MAINTENANCE
Safety Precautions
Some of the most important safety precautions are listed below; however, we cannot
warn you of every conceivable hazard that can arise in performing mainte\
nance.
Only you can decide whether or not you should perform a given task.
Maintenance Safety
• To reduce the possibility of fi re or explosion, keep cigarettes, sparks, and fl ames away from the battery and all fuel-related parts.
• Never leave rags, towels, or other fl ammable objects under the hood.
• To clean parts, use a commercially available degreaser or parts cleaner, not gasoline.
• Wear eye protection and protective clothing when working with the battery\
or compressed air.
• Do not run the engine in confi ned spaces where carbon monoxide gas can accumulate.
Vehicle Safety
• The vehicle must be stationary, and parked on level ground with the parking brake set and the engine off.
• Be aware that hot parts can burn you.
• Be aware that moving parts can injure you.
Improperly maintaining this vehicle or failing to correct a problem befo\
re driving
can cause a crash in which you can be seriously hurt or killed.
Always follow the inspection and maintenance recommendations according t\
o
the schedules in this guide.
WARNING
Failure to properly follow maintenance instructions and precautions can \
cause
you to be seriously hurt or killed.
Always follow the procedures and precautions in this guide.
WARNING
Learn about basic maintenance that you can perform on the vehicle yourse\
lf, as well
as information about how to best maintain the vehicle.
MAINTENANCE
When maintenance is due, the Maintenance Minder indicator comes on and a\
message appears on the display every time you turn the vehicle on. Press\
the select/
reset knob to change displays.
Maintenance Minder™
Reminds you when indicated maintenance service is due.
Models with information display
Maintenance
Minder indicator
Main items Sub items
Maintenance Minder message
When maintenance is due, the system message indicator comes on and a mes\
sage
appears on the display every time you turn the vehicle on. Press the Inf\
o button on
the steering wheel to change displays. Models with multi-information display
System message
indicator
Main itemsSub items
Maintenance Minder message
• Independent of the Maintenance Minder information, replace the brake fl\
uid
every 3 years.
• Inspect idle speed every 160,000 miles (256,000 km).
• Adjust the valves during services A, B, 1, 2, or 3 if they are noisy .
Page 66 of 81
![HONDA CR-V 2015 RM1, RM3, RM4 / 4.G Quick Guide 124 || 125
MAINTENANCE
MAINTENANCE
U.S. Models
Maintenance, replacement, or repair of emissions control devices and sys\
tems
may be done by any automotive repair establishment or indivi](/img/13/5803/w960_5803-65.png "HONDA CR-V 2015 RM1, RM3, RM4 / 4.G Quick Guide 124 || 125
MAINTENANCE
MAINTENANCE
U.S. Models
Maintenance, replacement, or repair of emissions control devices and sys\
tems
may be done by any automotive repair establishment or indivi")
124 || 125
MAINTENANCE
MAINTENANCE
U.S. Models
Maintenance, replacement, or repair of emissions control devices and sys\
tems
may be done by any automotive repair establishment or individuals using \
parts
that are certi ed to EPA standards.
According to state and federal regulations, failure to perform maintenan\
ce on the
maintenance main items marked with # will not void your emissions warran\
ties.
However, all maintenance services should be performed in accordance with the
intervals indicated by the multi-information display.
Maintenance Minder Service Codes
These codes indicate what services are due on your vehicle. Under the Hood
Opening the Hood
1. Park the vehicle on a level surface, and set the parking brake.
2. Pull the hood release handle under the lower left corner of the dashboard.
3. Push up the hood latch lever in the center of the hood to release the lock mechanism, and open
the hood.
4. Remove the support rod from the clamp using the grip. Mount the support rod in the hood.
When closing, remove the support rod, and stow it in the clamp, then gently lower the hood.
Remove your hand at a height of approximately
12 inches (30 cm) and let the hood close.
Hood release handle
Lever
Support rod Grip
ClampP
ull
Do not open the hood when the wiper arms are raised. The hood will strik\
e the
wipers, and may damage either the hood or the wipers.
NOTICE
Engine coolant
reserve tank
W
asher uid
(blue cap) Engine oil
ll cap Engine oil dipstick
(orange)
Brake uid
(black cap)
Battery
Radiator cap
*1: If a message SERVICE does not appear more than 12 months after the display is reset, change the engine oil every year.
# : See information on maintenance and emissions warranty.
CODEMaintenance Main Items
A
Replace engine oil*1
BReplace engine oil*1 and oil filter
Inspect front and rear brakes
Check parking brake adjustment
Inspect tie rod ends, steering gearbox, and boots
Inspect suspension components
Inspect driveshaft boots
Inspect brake hoses and lines (Including ABS/VSA)
Inspect all fluid levels and condition of fluids
Inspect exhaust system#
Inspect fuel lines and connections#
*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry
and diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).
*4: Driving in mountainous areas at very low vehicle speeds or trailer towing results in higher transmission temperatures. This requires transmission fluid changes more frequently than
recommended by the Maintenance Minder. If you regularly drive your vehicle under these
conditions, have the transmission fluid changed every 25,000 miles (40,000 km).
CODEMaintenance Sub Items
1
Rotate tires
2Replace air cleaner element*2
Replace dust and pollen filter*3
Inspect drive belt
3
Replace transmission fluid*4
4Replace spark plugs
Inspect valve clearance
5
Replace engine coolant
6Replace rear differential fluid*
Page 67 of 81
126 || 127
MAINTENANCE
MAINTENANCE
Recommended Engine Oil
Honda Genuine Motor Oil
Premium-grade 0W-20 detergent oil with an API Certi cation Seal on the
container
This seal indicates the oil is energy conserving and
that it meets the American Petroleum Institute’s
latest requirements.
Use Honda Genuine Motor Oil or another
commercial engine oil of suitable viscosity for the
ambient temperature as shown.
You may also use synthetic motor oil if it is labeled with the API Certifi\
cation Seal
and is of the specifi ed viscosity grade.
Engine Oil
Park the vehicle on level ground, and wait approximately three minutes a\
fter turning
the engine off before you check the oil.
Checking the Oil 1. Remove the dipstick (orange loop).
2. Wipe the dipstick with a clean cloth or paper towel.
3. Insert the dipstick back all the way into its hole.
4. Remove the dipstick again, and check the level. It should be between the upper and lower marks.
Add oil if necessary.
Upper mark
Lower mark
Ambient temperature
Adding Oil
1. Unscrew and remove the engine oil fi ll cap.
2. Add oil slowly.
3. Reinstall the engine oil fi ll cap, and tighten it securely.
4. Wait for three minutes and recheck the engine oil dipstick.
Resetting the Engine Oil Life
If you change or replace the vehicle’s engine oil yourself, you must reset the
engine oil life. Use the buttons on the steering wheel to operate the Vehicle Menu
(see page 31).
1. Press MENU.
2. Select Maintenance Info.
3. Press the SOURCE button to enter reset mode. Select Yes. The maintenance codes disappear,
and the engine oil life display returns to 100%.
Engine oil
fi ll cap
Do not fi ll the engine oil above the upper mark. Overfi lling the engine oil can result
in leaks and engine damage.
NOTICE
Failure to reset the engine oil life after a maintenance service results\
in the system
showing incorrect maintenance intervals, which can lead to serious mecha\
nical
problems.
NOTICE
Page 76 of 81
![HONDA CR-V 2015 RM1, RM3, RM4 / 4.G Quick Guide 144 || 145
VOICE COMMAND INDEX
VOICE COMMAND INDEX
Learn about all available voice commands to help you operate the vehicle\
. Available
on vehicles with navigation.
Press the Talk butto](/img/13/5803/w960_5803-75.png "HONDA CR-V 2015 RM1, RM3, RM4 / 4.G Quick Guide 144 || 145
VOICE COMMAND INDEX
VOICE COMMAND INDEX
Learn about all available voice commands to help you operate the vehicle\
. Available
on vehicles with navigation.
Press the Talk butto")
144 || 145
VOICE COMMAND INDEX
VOICE COMMAND INDEX
Learn about all available voice commands to help you operate the vehicle\
. Available
on vehicles with navigation.
Press the Talk button before you say a command. To view a list of available
commands in the vehicle, press INFO and use the interface dial to select\
Voice Info.
Select a category to hear the commands read aloud.
Global Commands
The system accepts these commands on any screen.
Navigation CommandsThe system accepts these commands on the map/guidance screen.
General Commands
• Display map
• Display navigation
• Go home 1 (or 2)
Map Display Commands
• Voice help
• Display menu
• Display setting
• Display navigation
• Display information
• Display audio
• Display phone
• Back/Cancel
• What is today’s date?
• What time is it?
• Display current location
• Display/Hide (specify icon type):
−ATM
− gas station
− restaurant
− post offi ce
− grocery store
− lodging (hotel, motel)
− parking garage
− parking lot
− school − hospital
− freeway exit information
− traffi c
− traffi c speeds
− traffi c icons
− traffi c incidents
• Display north up
• Display heading up
• Display 3D map
• Display zoom in
• Display zoom out
VOICE COMMAND INDEX Navigation Commands (continued)
Find Place Commands
• Find nearest (specify place): − Fuel and auto
− Honda dealers
− Gas station
− Auto parts & electronics
− Auto repair & maintenance
− Car wash & detailing
− Motorcycle dealers
− Other car dealerships
− Roadside assistance
−ATM
− Bank
− Check cashing
− Currency exchange
− Community
− Business
− City hall
− Civic center
− Convention center
− Court house
− Higher education
− Library
− Post offi ce
− School
− Emergency room
− Hospital
− Police station
− Veterinarian
− Lodging
− Bed & breakfast
− Hotel
− Resort
− Recreation
− Amusement park
− Golf course
− Historical monument
− Marina
− Movie theater
− Museum
− Park − Performing arts
− Sports complex
− Tourist attraction
− Restaurant
− American restaurant
− Californian restaurant
− Chinese restaurant
− Coffee shop
− Continental restaurant
− Fast food
− French restaurant
− German restaurant
− Greek restaurant
− Indian restaurant
− Italian restaurant
− Japanese restaurant
− Korean restaurant
− Mexican restaurant
− Pizza
− Seafood restaurant
− Thai restaurant
− Vegetarian restaurant
− Vietnamese restaurant
− Other restaurant
− Shopping
− Shopping area
− Accessory store
− Book store
− Clothing store
− Grocery store
− Home improvement store
− Mall
− Offi ce supply store
− Pharmacy
− Pet food store
− Sewing store
− Shoe store
− Sporting goods store
− Toy store
Page 77 of 81
146 || 147
VOICE COMMAND INDEX
VOICE COMMAND INDEX
Route Commands
The system accepts these commands when a route is set.
• How long to the destination?
• How far to the destination?
• Display destination map
• Display entire route
• Cancel route
• Repeat guidance
• Route menu − Travel center
− Airport
− Automobile club
− Bus station
− Camping
− Commuter rail station
− Ferry terminal
− Named place
− Park & ride
− Parking garage
− Parking lot
− Rental car agency
− Rest area
− Ski area
− Tourist information
− Train station
− Travel agency
− Truck stop
Climate Control Commands
The system accepts these commands on most screens.
* These commands toggle the function on and off, so the command may not match your intended action.
• Climate control automatic
(maintains selected temperature)
• Climate control on*
• Climate control off*
• Air conditioner on*
• Air conditioner off*
• Climate control defrost on*
• Climate control defrost off*
• Rear defrost on*
• Rear defrost off*
• Climate control fresh air
• Climate control recirculate
• Climate control sync on*
• Climate control sync off*
• Climate control vent
• Climate control bi-level (vent and fl oor)
• Climate control fl oor
• Climate control fl oor and defrost
• Climate control mode automatic
• Fan speed up
• Fan speed down
• Fan speed # (#: 1 to 7)
• Fan automatic
• Rear lock on
• Rear lock off
• Temperature # degrees (#: 57 to 87°F)
• Driver temperature # degrees (#: 57 to 87°F)
• Passenger temperature # degrees (#: 57 to 87°F) • Temperature up
• Temperature down
• Driver temperature up
• Driver temperature down
• Passenger temperature up
• Passenger temperature down
• Temperature max heat
• Temperature max cool
• Driver temperature max heat
• Driver temperature max cool
• Passenger temperature max heat
• Passenger temperature max cool
• Front climate control automatic
• Front climate control off
• Rear climate control automatic
• Rear climate control off
• Rear climate control vent
• Rear climate control bi-level
• Rear climate control fl oor
• Rear fan speed up
• Rear fan speed down
• Rear fan speed # (#:1 to 5)
• Rear temperature up
• Rear temperature down
• Rear temperature max heat
• Rear temperature max cool
Page 79 of 81
150 || 151
INDEX
VOICE COMMAND INDEX
Phone Commands
The system accepts these commands on most screens.
• Dial/call by number • Dial/call by voice tag
Info Commands
The system accepts these commands on most screens.
• Trip computer
• Display traffi c list
• Display traffi c on my route • Display clock
• Display wallpaper
On-screen Commands
The system accepts these commands on any screen where applicable. All
available commands are highlighted in yellow when you press the Talk button.
• Next (or Down)
• Previous (or Up)
• Return
• OK (excluding Startup Confi rmation screen)
• Delete
INDEX
ABS ......................................................25, 99
Adaptive Cruise Control (ACC) ..............25, 102
Airbags ..............................................................9 Advanced Airbags ........................................9
Airbag Care ..................................................14
Airbag System Components ......................13
Airbag System Indicators ..........................11
Front Airbags (SRS) ......................................9
Passenger Airbag Off Indicator ................12
Side Airbags .................................................10
Side Curtain Airbags ...................................10
Supplemental Restraint System Indicator ... 11
Air Conditioning System.................................50
All Wheel Drive (AWD) ...................................25
Ambient Meter...............................................100
Anti-lock Brake System (ABS) ................25, 99
Audio Operation ..............................................54 Accessory Power Socket ..........................54
Audio Commands ......................................148
Auxiliary Input Jack ....................................55
Bluetooth
® Audio ..................................62, 71
Compact Disc (CD) ................................59, 68
FM/AM Radio .........................................58, 66
HDMI Port .....................................................55
HDMI Video ..................................................73
HondaLink™ .................................................65
Intelligent Multi-Information Display (i-MID) ...............................................57
iPod
® ......................................................60, 69
Pandora® ................................................63, 72
SiriusXM® Radio ........................................67
Sound ............................................................56
Steering Wheel Controls ............................55
Touchscreen Operation .............................64
USB Adapter Cable .....................................54
USB Flash Drive .....................................61, 70
USB Port .......................................................54
Automatic Dimming Rearview Mirror ..........48
Automatic Headlights .....................................40
Automatic Wipers ...........................................41
AUX Commands.............................................149
Auxiliary Input Jack ........................................55
AWD ............................................................25
Battery ..........................................................129
Bluetooth
® Audio ......................................62, 71
Bluetooth® Audio Commands .....................149
Bluetooth® HandsFreeLink® (HFL) ................74
E-Mail ............................................................83
HFL Controls ...........................................74, 78
HondaLink™ Assist .....................................84
Making a Call .........................................76, 81
Pairing a Phone .....................................75, 80
Siri Eyes Free ...............................................84 SMS Text Messaging ...........................77, 83
Speed Dial ..............................................76, 82
Voice Recognition Tips ...............................79
Brake Assist System.......................................99
Brake system .............................................24, 25
Braking ............................................................99
Brightness Control ..........................................39
Built-in key .......................................................32
Calibration ......................................................115
Carbon Monoxide Gas......................................4
Cargo Area Lights ...........................................39
Changing a Flat Tire ......................................116
Changing Settings .....................................30, 31
Changing Wiper Blades ...............................130
Charging system..............................................24
Child Safety ......................................................15 Childproof Door Locks ................................34
Selecting a Child Seat ................................17
Child Seat .........................................................17 Adding Security with a Tether ..................20
LATCH-Compatible Child Seat ...................18
Climate Control Commands .........................147
Climate Control System ..................................51
Clock ............................................................53
Collision Mitigation Braking System™ (CMBS™) ............................25, 27, 106
Compact Disc (CD) ....................................59, 68
Compact Disc (CD) Commands ...................148
Contact Us ......................................................142
Cruise Control ..........................................27, 101
Customer Information...................................141
Customized Features ......................................31
Dashboard and Ceiling Controls .....................2
Daytime Running Lights (DRL).......................25
Destination .......................................................88
Detour ............................................................91
Dialing a Number ......................................76, 81
Door Mirrors ....................................................48
Door Operation ................................................34
Door/tailgate open ..........................................26
DOT Tire Quality Grading .............................136
Driver’s power seat .........................................42
Driving ............................................................92 Braking ..........................................................99
Cruise Control ............................................101
Ignition ..........................................................97
Lane Departure Warning (LDW) ...25, 27, 104
Lane Keeping Assist System (LKAS) ... 25, 27, 105
LaneWatch™ .............................................107
Maximum Load Limit ...................................94
Multi-View Rear Camera .................108, 109
Power Mode ................................................97
Refueling .....................................................110
Page 80 of 81
152 || 153
INDEX
INDEX
Shifting ..........................................................98
Towing a Trailer ...........................................96
Driving Position Memory System .................47
Eco Assist System.........................................100
ECON Button ..................................................100
ECON mode ......................................................27
Electric Power Steering (EPS) ......................25
Electronic Stability Control (ESC) ...............100
E-Mail ............................................................83
Emergency Engine Stop ...............................114
Emergency Towing .......................................114
Engine and Fuel Specs .................................140
Engine Coolant...............................................128
Engine Oil........................................................126
ENGINE START/STOP button ........................97
Exterior Lights ............................................27, 40
Fastening a Seat Belt .......................................7
Find Nearest Place .........................................89
Find Place Commands ..................................145
Flat Tire ..........................................................116
Floor Mats ........................................................45
Fluids ..........................................................140
FM/AM Radio .............................................58, 66
FM/AM Radio Commands ............................148
Fog lights ....................................................27, 40
Foot Brake ........................................................99
Frequently Asked Questions .......................141
Front Airbags (SRS) ..........................................9
Front Door Inner Handle ................................34
Front Seats .......................................................42
Front Wipers ....................................................41
Fuel Information ............................................110
Fuse Locations...............................................119
Garage Opener ................................................49
Handling Information ........................................4
Hazard lights ....................................................27
HDMI Port.........................................................55
HDMI Video ......................................................73
Head Restraints ...............................................44
Headlight-Wiper Integration .........................41
Heated Windshield Button ............................51
HFL Controls ...............................................74, 78
High beams ......................................................27
Home Address .................................................88
HomeLink
® Garage Opener ...........................49
Honda Roadside Assistance .......................143
HondaLink™ .....................................................65
HondaLink™ Assist .........................................84
Hood ..........................................................125
Ignition ............................................................97
i-MID ............................................................57
Immobilizer .......................................................27
Info buttons ................................................29, 30
Info Commands..............................................150
Information Display.........................................28 Instrument Panel .............................................24
Condition Indicators ...................................26
Malfunction Indicators ...............................24
On/Off Indicators .........................................27
Intelligent Multi-Information Display (i-MID) ...............................................57
Interior Lights...................................................39
Intermittent Wipers.........................................41
iPod
® ......................................................60, 69
iPod® Commands ..........................................149
Jump Starting ................................................111
Key ............................................................32
Lane Departure Warning (LDW) .....25, 27, 104
Lane Keeping Assist System (LKAS) ...25, 27, 105
LaneWatch™ .................................................107
Lap/Shoulder Seat Belts ..................................5
LATCH-Compatible Child Seat .......................18
LDW ..............................................25, 27, 104
Light Bulbs......................................................140
Lights ......................................................27, 39
LKAS ..............................................25, 27, 105
Lock Tab ............................................................34
Low fuel ............................................................26
Low oil pressure ..............................................24
Low tire pressure ............................................26
Maintenance..................................................122 Maintenance Minder™ ......................27, 123
Safety Precautions ...................................122
Service Codes ............................................124
Under the Hood .........................................125
Making a Call .............................................76, 81
Malfunction indicator lamp ...........................25
Manual seats ...................................................43
Map Display Commands ..............................144
Map Legend .....................................................90
Map Lights........................................................39
Master Door Lock Switch ..............................34
Maximum Load Limit.......................................94
Mirrors ............................................................48
Moonroof ..........................................................38
Multi-Information Display ..............................29
Multi-View Rear Camera .....................108, 109
Navigation ........................................................85 Detour ...........................................................91
Display and Controls ...................................86
Entering a Destination ................................88
Find Nearest Place .....................................89
Home Address .............................................88
Map Legend .................................................90
Navigation Commands .............................144
Place Category ............................................89
Routing ..........................................................90
Steering Wheel Controls ............................85
Street Address .............................................88
Traffi c ............................................................91 Turn-by-Turn Directions .............................90
Voice Prompt................................................87
Voice Recognition Tips ...............................87
One-Touch Turn Signal ...................................40
On-screen Commands..................................150
Opening the Hood .........................................125
Overheating....................................................113
Pairing a Phone .........................................75, 80
Pandora
® ....................................................63, 72
Pandora® Commands ...................................149
Panic button .....................................................32
Parking brake.............................................26, 99
Passenger Airbag Off Indicator ....................12
Phone ......................................................75, 80
Phonebook .................................................76, 81
Phone Commands .........................................150
Place Category ................................................89
Power Door Mirrors........................................48
Power Mode ....................................................97
Power Moonroof .............................................38
Power seat .......................................................42
Power Tailgate .................................................36
Power Windows ..............................................37
Radio ......................................................58, 66
Readiness Codes...........................................139
Rear Camera ..........................................108, 109
Rear Seats ........................................................46
Rearview Mirror ..............................................48
Rear Wiper .......................................................41
Refueling.........................................................110
Remote Battery Strength .............................111
Remote Transmitter ........................................32
Reporting Safety Defects...............................23
Roadside Assistance ....................................143
Route Commands ..........................................146
Routing ............................................................90
Safety Information ............................................3 Carbon Monoxide Gas ..................................4
Childproof Door Locks ................................34
Child Safety ..................................................15
Handling Information ....................................4
Reporting Safety Defects ...........................23
Safety Label Locations ...............................22
Safety Messages ..........................................3
Seat Belts ...........................................................5 Fastening a Seat Belt ...................................7
Lap/Shoulder Seat Belts ..............................5
Seat Belt Inspection .....................................6
Seat belt reminder ......................................26
Seat Belt with Detachable Anchor ............8
Shoulder Anchor ...........................................7
Seat Heaters ....................................................52
Seats ............................................................42 Front Seats ...................................................42
Rear Seats ....................................................46 Select/reset knob ............................................28
SEL/RESET button .....................................29, 30
Service Codes................................................124
Settings ......................................................30, 31
Setting the Clock .............................................53
Shifting ............................................................98
Shift Lever Does Not Move .........................112
Shoulder Anchor ...............................................7
Side Airbags.....................................................10
Side Curtain Airbags.......................................10
Siri™ Eyes Free ...............................................84
SiriusXM
® Radio ..............................................67
SiriusXM® Radio Commands .......................148
Smart Entry system ...................................25, 33
SMS Text Messaging ...............................77, 83
Sound ............................................................56
Specifi cations ................................................140
Speed Dial ..................................................76, 82
Starter system .................................................25
Steering Wheel................................................47
Steering Wheel and Nearby Controls ...........1
Steering Wheel Controls..........................55, 85
Street Address.................................................88
Supplemental Restraint System (SRS) ........24
System message .............................................26
Tailgate ......................................................33, 35
Tailgate open ...................................................26
Text Messaging .........................................77, 83
Tire Chains ......................................................134
Tire Information .............................................132 DOT Tire Quality Grading .........................136
Infl ation Guidelines ...................................132
Tire and Loading Information Label .......133
Tire and Wheel Replacement ..................133
Tire Identifi cation Number (TIN) .............135
Tire Labeling ...............................................135
Tire Service Life .........................................134
Tire Terminology ........................................135
Wear Indicators ........................................132
Tire Pressure Monitoring System (TPMS) ............................................25, 115, 138
Tire Specs .......................................................140
Tongue load ......................................................96
Total trailer weight ..........................................96
Touchscreen Operation .................................64
Towing ....................................................96, 114
Towing Load Limits .........................................96
TPMS ............................................25, 115, 138
Traffi c ............................................................91
Troubleshooting .............................................141
Turn-by-Turn Directions .................................90
Turn Signal .................................................27, 40
Under the Hood .............................................125
USB Adapter Cable .........................................54
USB Commands.............................................149
