Page 219 of 345
You should do the following checks
and adjustments before you drive
your vehicle.1. Make sure all windows, mirrors, and outside lights are clean and
unobstructed. Remove frost, snow,
or ice.
2. Check that the hood is fully closed.
3. Visually check the tires. If a tire looks low, use a gauge to check its
pressure.
4. Check that any items you may be carrying are stored properly or
fastened down securely. 5. Check the seat adjustment (see
page83).
6. Check the adjustment of the inside and outside mirrors (see page93).
7. Check the steering wheel adjustment (see page74). 8. Make sure the doors, the hatch,
and the tailgate are securely
closed and locked.
9. Fasten your seat belt. Check that your passengers have fastened
their seat belts (see page14).
10. When you start the engine, check the gauges and indicators in the
instrument panel (see page57).
Preparing to Drive
215
Driving
2009 Element
Page 270 of 345
Replacing Rear Bulbs1. Open the hatch and the tailgate.Remove the two mounting screws
with a Phillips-head screwdriver,
and remove the taillight assembly
from the body by pulling it back.
2. Determine which of the four bulbs is burned out: brake/taillight, turn
signal light, side marker light, or
back-up light.
3. Remove the socket by turning it
one-quarter turn counterclockwise.
4. Pull the bulb straight out of its socket. Push the new bulb straight
into the socket until it bottoms. 5. Reinstall the socket into the light
assembly by turning it clockwise
until it locks.
6. Test the lights to make sure the new bulb is working.
7. When reinstalling the taillight assembly, first place the two pins
in the holes in place. Tighten the
two mounting screws.
SCREW
SCREW
TAILLIGHT ASSEMBLY
SOCKET SOCKET
SOCKET
SOCKET
Lights266
2009 Element
Page 282 of 345
On vehicles with navigation systemThe navigation system will also
disable itself. The next time you turn
on the ignition switch, the system
will require you to enter a PIN before
it can be used. Refer to the
navigation system manual.Vehicle Storage
If you need to park your vehicle for
an extended period (more than 1
month), there are several things you
should do to prepare it for storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your vehicle back on the road. If
possible, store your vehicle indoors.
●Fill the fuel tank.●Wash and dry the exterior
completely.●Clean the interior. Make sure the
carpeting, floor mats, etc., are
completely dry.●Leave the parking brake off. Put
the transmission in reverse
(manual) or Park (automatic).
●Block the rear wheels.●If the vehicle is to be stored for a
longer period, it should be
supported on jackstands so the
tires are off the ground.●Leave one window open slightly (if
the vehicle is being stored
indoors).●Disconnect the battery.●Support the front and rear wiper
blade arms with a folded towel or
rag so they do not touch the
windshield.●To minimize sticking, apply a
silicone spray lubricant to all door
and tailgate seals. Also, apply a
vehicle body wax to the painted
surfaces that mate with the door
and tailgate seals.
Checking the Battery, Vehicle Storage278
2009 Element
Page 287 of 345
If you have a flat tire while driving,
stop in a safe place to change it.
Drive slowly along the shoulder until
you get to an exit or an area to stop
that is far away from the traffic lanes.
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.1. Park the vehicle on firm, level, and
non-slippery ground. Put the
transmission in Park (automatic)
or reverse (manual). Apply the
parking brake.
If you are towing a trailer, unhitch
the trailer.
2. Turn on the hazard warning lights, and turn the ignition switch to the
LOCK (0) position. Have all
passengers get out of the vehicle
while you change the tire.
3. Open the hatch and the tailgate.
4. The spare tire, jack, and tools areunder the cargo area floor.
TOOLS
SPARE TIRE
JACK
CONTINUED
Changing a Flat Tire
283
Taking Care of the Unexpected
2009 Element
Page 335 of 345
Heating and Cooling
..................
104
Hood, Opening and Closing the
..........................................
200
Horn
............................................
69
Hydraulic Clutch
........................
258
I
Identification Number, Vehicle
...................................
306
Ignition Keys
.........................................
75
Switch
......................................
79
Immobilizer System
.....................
76
Important Safety Precautions
.........
6
Indicators, Instrument Panel
........
57
ABS (Anti-lock Brake)
..............
59
Brake (Parking and Brake System)
.........................
58,297
Charging System
..............
58,295
Cruise Control
..........................
60
Cruise Main
.............................
60
Door and Tailgate Open
...........
61
DRL (Daytime Running Lights)
..................................
60 High Beam
...............................
61
Key (Immobilizer System)
.......
60
Lights On
.................................
61
Low Fuel
..................................
61
Low Oil Pressure
..............
58,295
Low Tire Pressure
.............
62,227
Maintenance Minder
.........
59,243
Malfunction Indicator Lamp
.............................
58,296
Passenger Airbag Off
...............
32
Seat Belt Reminder
.............
18,58
Side Airbag Off
....................
32,59
SRS
.....................................
31,59
TPMS
................................
63,228
Turn Signal and Hazard Warning
...............................
60
VSA OFF
..................................
62
VSA System
.............................
62
Washer Level
...........................
61
Individual Map Lights
..................
95
Infant Restraint
............................
40
Infant Seats
..................................
40
Tether Anchorage Point
...........
48
Inflation, Proper Tire
..................
271
Recommended Pressures
.......
272
Inside Mirror
...............................
93 Inspection, Tire
..........................
273
Installing a Child Seat
..................
43
Instrument Panel
..........................
57
Instrument Panel Brightness
.......
72
Instruments and Controls
.............
55
Interior Lights
..............................
95
Introduction
...................................
i
iPod
®Error Messages
................
172
J
Jacking up the Vehicle
...............
283
Jack, Tire
...................................
283
Jump Starting
.............................
291
K
Keys
.............................................
75
L
Label, Certification
.....................
306
Lane Change, Signaling
...............
71
Lap/Shoulder Belt
.................
14,19
CONTINUED
Index
V
INDEX
2009 Element
Page 336 of 345
LATCH Anchorage System
..........
44
Light Control Switch
....................
95
Lights Bulb Replacement
...................
261
Indicator
...................................
57
Interior
.....................................
95
Parking
....................................
71
Turn Signal
..............................
71
Load Limit
..................................
208
LOCK (Ignition Key Position)
......
79
Locks Anti-theft Steering Column
.......
79
Fuel Fill Door
..........................
199
Glove Box
...............................
100
Hatch
.......................................
81
Lockout Prevention
..................
81
Power Door
..............................
80
Tailgate
....................................
82
Low Coolant Level
......................
201
Lower Anchors
.............................
44
Low Fuel Indicator
.......................
61
Low Oil Pressure Indicator
...........................
58,295
Lubricant Specifications Chart...
309
Luggage, Storing (cargo)
...........
207 M
Maintenance
..............................
241
Main Items and Sub Items
......
246
Minder
....................................
243
Minder Indicator
......................
59
Owner's Maintenance Checks
................................
248
Safety
......................................
242
Schedule
.................................
249
Malfunction Indicator Lamp
.......
296
Manual Transmission
.................
217
Checking Fluid Level
..............
257
Shifting
...................................
217
Manual Transmission Fluid
.......
257
Meters, Gauges
............................
64
Methanol in Gasoline
.................
198
Mirrors, Adjusting
........................
93
Modifications
.............................
206
Modifying Your Vehicle
.............
206
N
New Vehicle Break-in
.................
198
Normal Shift Speeds
..................
218 NOTICE, Explanation of
................
i
Numbers, Identification
.............
306
O
Odometer
.....................................
65
Off-Highway Driving Guidelines
..............................
238
Off-Road Precautions
..................
238
Oil Change, How to
......................
252
Change, When to
....................
243
Checking Engine
....................
201
Life, Engine
.............................
243
Pressure Indicator
.............
58,295
Selecting Proper Viscosity Chart
...................................
251
Onboard Refueling Vapor Recovery
................................
316
ON (Ignition Key Position)
..........
79
Outside Mirrors
...........................
93
Outside Temperature Indicator
....
68
Overhead Console
......................
101
Overheating, Engine
..................
293
Owner's Maintenance Checks
....
248
IndexVI
2009 Element
Page 339 of 345
How Your Side Curtain AirbagsWork
....................................
30
SRS Indicator
.........................
31,59
START (Ignition Key Position).....
79
Starting the Engine
....................
216
In Cold Weather at High Altitude
................................
216
With a Dead Battery
................
291
State Emissions Testing
.............
319
Steam Coming from Engine
.......
293
Steering Wheel Adjustment
...............................
74
Anti-theft Column Lock
............
79
Buttons
...........................
191,193
Stereo Sound System
.................
109
Storing Your Vehicle
..................
278
Sun Visor
...................................
100
Supplemental Restraint System
..............................
9,22
Servicing
..................................
33
SRS Indicator
......................
31,59
System Components
................
22
Synthetic Oil
..............................
252 T
Tachometer
..................................
64
Tailgate
........................................
82
Open Indicator
.........................
61
Opening the
.............................
82
Taillights, Changing Bulbs in
.....
266
Taking Care of the
Unexpected
............................
281
Technical Descriptions DOT Tire Quality Grading (U.S. Vehicles)
.............................
311
Emissions Control Systems
.....
316
Three Way Catalytic Converter
............................
318
Tire Pressure Monitoring System (TPMS) －Required Federal
Explanation
......................
314
Temperature Gauge
.....................
67
Tensioners, Seat Belts
..................
20
Tether Anchorage Points
.............
48
Theft Protection, Radio
..............
188
Three Way Catalytic Converter
...............................
318
Tilt the Steering Wheel
................
74 Time, Setting the
........................
189
Tire Chains
................................
276
Tire, How to Change a Flat
........
283
Tire Information
.........................
313
Tire Labeling
..............................
313
Tire Pressure Monitoring System (TPMS)
...........................
227,314
Tires
..........................................
271
Air Pressure
............................
272
Chains
.....................................
276
Checking Wear
.......................
273
Compact Spare
........................
282
DOT Tire Quality Grading (U.S. Vehicles)
.............................
311
Inflation
...................................
271
Inspection
...............................
273
Labeling
..................................
313
Low Tire Pressure Indicator
........................
62,227
Maintenance
...........................
274
Pressure Monitoring System
...
227
Replacing
................................
274
Rotating
..................................
274
Snow
.......................................
275
Specifications
..........................
310
CONTINUED
Index
IX
INDEX
2009 Element
