odometer HONDA ELEMENT 2009 1.G Owners Manual

This section gives information about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach.
Control Locations
..........................
56
Instrument Panel
..........................
57
Instrument Panel Indicators
..........
58
Gauges
..........................................
64
Information Display
..................
65
Odometer
..................................
65
Trip Meter
................................
66
Fuel Gauge
...............................
66
Check Fuel Cap Message
.........
66
Temperature Gauge
..................
67
Maintenance Minder
................
67
Outside Temperature Indicator
...............................
68 Controls Near the Steering
Wheel
.......................................
69
Windshield Wipers and Washers
....................................
70
Turn Signals and Headlights
.........
71
Instrument Panel Brightness
........
72
Hazard Warning Button
................
73
Rear Window Defogger
.................
74
Steering Wheel Adjustment
..........
74
Keys and Locks
.............................
75
Immobilizer System
......................
76
Remote Transmitter
......................
77
Ignition Switch
..............................
79
Door Locks
...................................
80
Power Door Locks
....................
80
Rear Doors
................................
81
Hatch
........................................
81
Tailgate
.....................................
82
Seats
.............................................
83
Seat Adjustments
......................
83
Driver's Seat Height Adjustment
...........................
84
Front Seat Armrests
..................
85
Head Restraints
.........................
85 Reclining the Front Seats
..........
87
Folding the Rear Seats
..............
88
Removing the Rear Seats
..........
90
Power Windows
............................
92
Mirrors
.........................................
93
Adjusting the Power Mirrors
.....
93
Rear Windows
...............................
94
Parking Brake
...............................
94
Interior Lights
...............................
95
Light Control Switch
.................
95
Individual Map Lights
...............
95
Courtesy Light
..........................
96
Ceiling Light
.............................
96
Cargo Area Light
.......................
96
Ignition Switch Light
.................
96
Interior Convenience Items
...........
97
Cooler Box
................................
98
Beverage Holders
.....................
99
Accessory Power Sockets
.......
100
Glove Box
...............................
100
Sun Visor
................................
100
Vanity Mirror
..........................
101
Overhead Console
..................
101
Instruments and Controls
55
Instruments and Controls
2009 Element

ꭧ: If equipped.
DRL
TACHOMETER SPEEDOMETER
FUEL GAUGE
U.S. model is shown. INFORMATION DISPLAY
ODOMETER/TRIP METER/
CHECK FUEL CAP MESSAGE TEMPERATURE GAUGESELECT/RESET
KNOB
OUTSIDE TEMPERATURE
INDICATOR
ꭧ
Gauges64
2009 Element

Information Display
The information display shows the
odometer, trip meter, engine oil life,
outside temperature (if equipped),
and maintenance item code(s).To switch the display, press and
release the select/reset knob
repeatedly. When you turn the
ignition switch to the ON (II)
position, your last selection is
displayed.Odometer
The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
and territorial regulations to
disconnect, reset, or alter the
odometer with the intent to change
the number of miles or kilometers
indicated.
OUTSIDE
TEMPERATURE
INDICATOR
ODOMETER
TRIP METER A
ENGINE OIL
LIFE TRIP METER B
U.S. model with outside temperature indicator is shown.
Gauges
65
Instruments and Controls
2009 Element

Outside Temperature IndicatorOn EX and SC modelsThis indicator displays the outside
temperature in Fahrenheit (U.S.
models) or Celsius (Canadian
models).
The temperature sensor is in the
front bumper. The temperature
reading can be affected by heat
reflection from the road surface,
engine heat, and the exhaust from
surrounding traffic. This can cause
an incorrect temperature reading
when your vehicle speed is under 19
mph (30 km/h). When you start your
trip, the sensor is not fully
acclimatized, therefore it may take
several minutes until the proper
temperature is displayed.In certain weather conditions,
temperature readings near freezing
(32°F, 0°C) could mean that ice is
forming on the road surface.
If the outside temperature is
incorrectly displayed, you can adjust
it up to
ꭗ5°F in U.S. models (ꭗ 3°C
in Canadian models) warmer or
cooler.
NOTE: The temperature must be
stabilized before doing this
procedure. To adjust the outside temperature
indicator, make sure the odometer is
shown in the display, then press and
hold the select/reset knob for 10
seconds. The following sequence will
appear for 1 second each: 0, 1, 2, 3, 4,
5,
－5, －4,－3,－2,－1, 0 (U.S.) or
0, 1, 2, 3, －3,－2,－1, 0 (Canada).
When the temperature reaches the
desired value, release the select/
reset knob. You should see the new
outside temperature displayed.Gauges68
2009 Element

The maintenance item code or codes
indicate the main and sub items
required at the time of the oil change
(see page246).
You can switch the information
display from the engine oil life
display to the odometer or the trip
meter. Press and release the select/
reset knob on the instrument panel.
When the engine oil life is 15 to 1
percent, the maintenance minder
indicator (
) comes on every time
you turn the ignition switch to the
ON (II) position, then it goes out if
you switch the information display.
When you see this message, have
the indicated maintenance performed
by your dealer as soon as possible.
When the remaining engine oil life is
0 percent, the engine oil life indicator
will blink. The display comes on
every time you turn the ignition
switch to the ON (II) position. The
maintenance minder indicator (
)
also comes on and remains on in the
instrument panel. When you see this
message, immediately have the
indicated maintenance done by your
dealer.
If you do not perform the indicated
maintenance, negative distance
traveled is displayed and begins to
blink after the vehicle has been
driven 10 miles (10 km) or more.
Negative distance traveled means
your vehicle has passed the
maintenance required point.
Immediately have the indicated
maintenance done by your dealer.
NEGATIVE DISTANCE TRAVELED
U.S. model is shown.
CONTINUED
Maintenance Minder
245
Maintenance
2009 Element

To change the information display
from the engine oil life display to the
odometer or the trip meter, press and
release the select/reset knob.
When the engine oil life is 0 percent
or negative distance traveled, the
maintenance minder indicator (
)
remains on even if you change the
information display.
Immediately have the service
performed, and make sure to reset
the display as described as follows. Maintenance Main Items and Sub
Items
All maintenance items displayed on
the information display are in code.
For an explanation of these
maintenance codes, see page249.Resetting the Engine Oil Life
Display
Your dealer will reset the display
after completing the required
maintenance service. You will see
‘‘
OIL LIFE 100% ’’on the information
display the next time you turn the
ignition switch to the ON (II)
position.
If maintenance service is done by
someone other than your dealer,
reset the maintenance minder as
follows:
1. Turn the ignition switch to the ON (II) position.
2. Press the select/reset knob repeatedly until the engine oil life
is displayed.
MAINTENANCE MAIN ITEM
MAINTENANCE SUB ITEM(S)
Maintenance Minder246
2009 Element

Honda dealership personnel are
trained professionals. They should
be able to answer all your questions.
If you encounter a problem that your
dealership does not solve to your
satisfaction, please discuss it with the
dealership's management. The
service manager or general manager
can help. Almost all problems are
solved in this way.
If you are dissatisfied with the
decision made by the dealership's
management, contact Honda
Customer Service.
U.S. Owners:American Honda Motor Co., Inc.
Automobile Customer Service
Mail Stop 500-2N-7A
1919 Torrance Boulevard
Torrance, California 90501-2746
Tel: (800) 999-1009
Canadian Owners:CUSTOMER RELATIONS
Honda Canada Inc.
715 Milner Avenue
Toronto, ON
M1B 2K8
Tel: 1-888-9-HONDA-9
Fax: Toll-free 1-877-939-0909Toronto (416) 287-4776In Puerto Rico and the U.S. Virgin
Islands:Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546
When you call or write, please give
us this information:●Vehicle identification number (see
page306)●Name and address of the dealer
who services your vehicle●Date of purchase●Odometer reading of your vehicle●Your name, address, and
telephone number●A detailed description of the
problem●Name of the dealer who sold the
vehicle to you
Customer Service Information322
2009 Element

Filling the Fuel Tank
..................
199
Filters Dust and Pollen
.......................
269
Oil
...........................................
252
Flashers, Hazard Warning
...........
73
Flat Tire, Changing a
.................
283
Floor Mats
.................................
268
Fluids Automatic Transmission
.........
256
Brake
......................................
258
Clutch
.....................................
258
Manual Transmission
..............
257
Power Steering
........................
260
Rear Differential
......................
258
Windshield Washer
.................
255
FM/AM Radio Reception
...........
186
Folding the Rear Seats
.................
88
Four-way Flashers
........................
73
Front Airbags
...........................
9,25
Front Seat Adjusting
..................................
83
Airbags
.................................
9,25
Fuel
............................................
198
Check Fuel Cap Message
........
66
Fill Door and Cap
....................
199
Gauge
......................................
66 Low Fuel Indicator
...................
61
Octane Requirement
...............
198
Oxygenated
.............................
198
Reserve Indicator
.....................
61
Tank, Filling the
......................
199
Fuel Economy
............................
202
Fuses, Checking the
..................
298
G
Gas Mileage, Improving
.............
202
Gasohol
......................................
198
Gasoline
.....................................
198
Gauge
.................................
64,66
Low Fuel Indicator
...................
61
Octane Requirement
...............
198
Tank, Refueling
.......................
199
Gas Station Procedures
..............
199
Gauges Engine Coolant Temperature...
67
Fuel
..........................................
66
Odometer
.................................
65
Speedometer
............................
64
Tachometer
..............................
64
Trip meter
................................
66 Gearshift Lever Positions
Automatic Transmission
.........
219
Manual Transmission
..............
217
Glove Box
..................................
100
Gross Axle Weight Rating (GAWR)
.................................
232
Gross Vehicle Weight Rating (GVWR)
.................................
232
H
Halogen Headlight Bulbs
...........
261
Hatch
...........................................
81
Hazard Warning Flashers
............
73
Headlights Aiming
....................................
261
Daytime Running Lights
..........
72
High Beam Indicator
................
61
High Beams, Turning on
..........
71
Lights On Indicator
..................
61
Low Beams, Turning on
...........
71
Reminder Chime
......................
71
Replacing Halogen Bulbs
........
261
Turning on
...............................
71
Head Restraints
............................
85
IndexIV
2009 Element

LATCH Anchorage System
..........
44
Light Control Switch
....................
95
Lights Bulb Replacement
...................
261
Indicator
...................................
57
Interior
.....................................
95
Parking
....................................
71
Turn Signal
..............................
71
Load Limit
..................................
208
LOCK (Ignition Key Position)
......
79
Locks Anti-theft Steering Column
.......
79
Fuel Fill Door
..........................
199
Glove Box
...............................
100
Hatch
.......................................
81
Lockout Prevention
..................
81
Power Door
..............................
80
Tailgate
....................................
82
Low Coolant Level
......................
201
Lower Anchors
.............................
44
Low Fuel Indicator
.......................
61
Low Oil Pressure Indicator
...........................
58,295
Lubricant Specifications Chart...
309
Luggage, Storing (cargo)
...........
207 M
Maintenance
..............................
241
Main Items and Sub Items
......
246
Minder
....................................
243
Minder Indicator
......................
59
Owner's Maintenance Checks
................................
248
Safety
......................................
242
Schedule
.................................
249
Malfunction Indicator Lamp
.......
296
Manual Transmission
.................
217
Checking Fluid Level
..............
257
Shifting
...................................
217
Manual Transmission Fluid
.......
257
Meters, Gauges
............................
64
Methanol in Gasoline
.................
198
Mirrors, Adjusting
........................
93
Modifications
.............................
206
Modifying Your Vehicle
.............
206
N
New Vehicle Break-in
.................
198
Normal Shift Speeds
..................
218 NOTICE, Explanation of
................
i
Numbers, Identification
.............
306
O
Odometer
.....................................
65
Off-Highway Driving Guidelines
..............................
238
Off-Road Precautions
..................
238
Oil Change, How to
......................
252
Change, When to
....................
243
Checking Engine
....................
201
Life, Engine
.............................
243
Pressure Indicator
.............
58,295
Selecting Proper Viscosity Chart
...................................
251
Onboard Refueling Vapor Recovery
................................
316
ON (Ignition Key Position)
..........
79
Outside Mirrors
...........................
93
Outside Temperature Indicator
....
68
Overhead Console
......................
101
Overheating, Engine
..................
293
Owner's Maintenance Checks
....
248
IndexVI
2009 Element
