Bulb ReplacementBack-up Lights ........................266
Brake Lights ........................... 266
Daytime Running Lights .........262
Front Parking/Turn Signal Lights .................................. 263
Front Side Marker Lights ........265
Headlights .............................. 261
High-mount Brake Light .........267
Rear Bulbs .............................. 266
Rear License Plate Lights ........267
Side Turn Signal Lights ...........264
Specifications .......................... 310
Taillights ................................. 266
Turn Signal Lights ..................266
Bulbs, Halogen .......................... 261
Bungee Cords ............................ 211
C
Capacities Chart .........................309
Carbon Monoxide Hazard ............52
Cargo ......................................... 207
Cargo Area Light ..........................96
Cargo Hook ................................ 212Cargo, How to Carry
..................207
Carrying Cargo .......................... 207
CAUTION, Explanation of ............iii
CD Care ..................................... 183
CD Error Messages ............125, 148
CD Player ........................... 119, 140
Ceiling Light ................................ 96
Certification Label ......................306
Chains, Tires .............................. 276
Changing a Flat Tire ..................283
Changing Oil
How to .................................... 252
When to .................................. 243
Charging System Indicator ........................... 58, 295
Check Fuel Cap Message ............66
Checklist, Before Driving ...........215
Child Safety .................................. 35
Booster Seats ........................... 50
Child Seats .................... 40, 41, 42
Important Safety Reminders .....39
Infants ...................................... 40
Larger Children .......................49
LATCH ..................................... 44
Risks with Airbags ...................36
Small Children ......................... 41Tethers
.................................... 48
Warning Labels ........................37
Where Should a Child Sit? ........36
Child Seats ............................. 35, 42
LATCH Anchorage Points ........44
Tether Anchorage Points .........48
Cleaning the Seat Belts ..............268
Clock .......................................... 189
Clutch Fluid ............................... 258
Code, Audio System ...................188
CO in the Exhaust ................52, 316
Cold Weather, Starting in ...........216
Compact Spare Tire ....................282
Controls, Instruments and ............55
Coolant
Adding .................................... 254
Checking ................................ 201
Proper Solution .......................254
Temperature Gauge .................67
Cooler Box ................................... 98
Courtesy Light ............................. 96
Crankcase Emissions Control System ................................... 316
Cruise Control Indicator ...............60
Cruise Control Operation ...........193
Cruise Main Indicator ..................60
Index
II

Wearing a Lap/ShoulderBelt .................................. 14, 19
Seats ............................................ 83
Head Restraints ........................85
Seats, Adjusting the .....................83
Sensors Driver's Seat Position Sensor ...27
Front Passenger's Weight Sensors ................................ 27
Impact Sensors ...................22, 23
Serial Number ............................ 306
Service Intervals .........................243
Service Manual (U.S. only) ........325
Service Station Procedures ........199
Setting the Clock ........................189
Shifting the Automatic Transmission .......................... 219
Shift Lever Position Indicators ...219
Shift Lock Release ......................221
Side Airbags ................................. 28
How the Side Airbag Off
Indicator Works ...................32
How Your Side Airbags Work ..28
Side Curtain Airbags ....................30
How Your Side Curtain Airbags Work .................................... 30Side Marker Lights, Bulb
Replacement in .......................265
Signaling Turns ............................ 60
Snow Tires ................................. 275
Sound System ............................ 109
Spare Tire .................................. 282
Inflating ........................... 271, 282
Specifications .......................... 310
Spark Plugs ................................ 308
Specifications ............................. 308
Speed Control ............................ 193
Speed Limiter ......................218, 221
Speedometer ................................ 64
SRS, Additional Information .........22
Additional Safety Precautions ...34
Airbag Service .......................... 33
Airbag System Components .....22
How the Side Airbag Off Indicator Works ...................32
How the SRS Indicator Works ..31
How Your Front Airbags
Work .................................... 25
How Your Side Airbags Work ..28
How Your Side Curtain Airbags Work .................................... 30
SRS Indicator ......................... 31, 59START (Ignition Key Position)
.....79
Starting the Engine ....................216
In Cold Weather at High Altitude ................................ 216
With a Dead Battery ................291
State Emissions Testing .............319
Steam Coming from Engine .......293
Steering Wheel Adjustment ............................... 74
Anti-theft Column Lock ............79
Buttons ........................... 191, 193
Stereo Sound System .................109
Storing Your Vehicle ..................278
Sun Visor ................................... 100
Supplemental Restraint
System .............................. 9, 22
Servicing .................................. 33
SRS Indicator ...................... 31, 59
System Components ................22
Synthetic Oil .............................. 252
T
Tachometer .................................. 64
CONTINUED
Index
IX
INDEX

ꭧ1: To use the horn, press the center pad of the steering wheel.
ꭧ 2: If equipped
ꭧ 3: Only on vehicles equipped with navigation system. Refer to the navigation system manual.
HEADLIGHTS/TURN SIGNALS
(P. 71)
REMOTE AUDIO CONTROLS
ꭧ2
(P. 191)
A/T model with navigation system is shown. STEERING WHEEL ADJUSTMENT
(P. 74)
CRUISE CONTROL BUTTONS
(P. 193)
WINDSHIELD WIPERS/WASHERS
(P. 70)
PASSENGER AIRBAG
OFF INDICATOR
(P. 32)
AUDIO SYSTEM
(P. 109)
DIGITAL CLOCK
(P. 189)
REAR WINDOW
DEFOGGER BUTTON
(P. 74)
ACCESSORY POWERSOCKET
(P. 100)
HORN
ꭧ 1
VSA OFF SWITCH
(P. 231)
HAZARD WARNINGBUTTON
(P. 73)
NAVIGATION SYSTEM
VOICE CONTROL BUTTONS
ꭧ
3
Your Vehicle at a Glance
4

Windshield Wiper
1. MIST
2. OFF
3. INT－Intermittent
3. LO －Low speed
5. HI －High speed
6. Windshield washers Push the right lever up or down to
select a position. MIST
－The wipers run at high
speed until you release the lever.OFF －The wipers are not activated.
INT －The length of the wipe
interval is varied automatically
according to vehicle's speed.
Vary the delay by turning the
adjustment ring. If you turn it to the
shortest delay (
position), the
wipers change to low speed
operation when the vehicle speed
exceeds 12 mph (20 km/h). LO －The wipers run at low speed.
HI －The wipers run at high speed.
Windshield Washer －Pull the
wiper control lever toward you, and
hold it. The washers spray until you
release the lever. The wipers run at
low speed, then complete one more
sweep after you release the lever. Rear Window Wiper and Washer
1. Rotate the switch clockwise to turn
the rear window wiper ON.
2. Hold past ON to turn the window wiper on and the window washer on.
3. OFF
4. Rotate the switch counterclockwise and hold to
spray the window washer and
operate the wiper.





ADJUSTMENT RING




Windshield Wipers and Washers
70
Table of Contents

To replace the battery, remove the
round cover on the back of the
transmitter by turning it
counterclockwise with a coin. Insert
a new battery with the＋side facing
up, and reinstall the cushion ring.
Align the
mark on the cover with
the
mark on the transmitter. Set
the cover in place and turn it clockwise.
As required by the FCC: This device complies with Part 15 of theFCC rules. Operation is subject to the
following two conditions: (1) This devicemay not cause harmful interference, and(2) this device must accept any
interference received, includinginterference that may cause undesiredoperation.
Changes or modifications not expresslyapproved by the party responsible for
compliance could void the user'sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.
Operation is subject to the following two
conditions: (1) this device may not causeinterference, and (2) this device must
accept any interference that may causeundesired operation of the device.Ignition Switch
The ignition switch has four
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III).
LOCK (0) －You can insert or
remove the key only in this position.
To turn the key, push it in slightly. If
your vehicle has an automatic
transmission, the shift lever must
also be in Park.
CONTINUED
Remote Transmitter, Ignition Switch
79
Instruments and Controls
Table of Contents

The lock tab on the passenger's door
locks and unlocks only that door.
Pulling up on the driver's door lock
tab only unlocks the driver's door.
To lock the driver's door, remove the
key from the ignition switch, push
the lock tab down or push the door
lock switch down, then close thedoor.
To unlock the driver's door from the
outside, turn the key and release it.
Lockout Prevention
With the driver's door open and the
key in the ignition switch, the master
door lock switch is disabled. It is not
disabled if the driver's door is closed.
If you try to lock the open driver's
door with the key in the ignition
switch by pushing in the lock tab, the
tabs on all doors pop up when you
close the door.Rear DoorsTo open the rear door, pull the rear
door handle located in the rear door
edge. The rear door can be opened
only when the front door is open.
To close the doors, close the rear
door first, then the front door. The
front door cannot be latched without
first closing the rear door. Closing
the rear door on the front door will
damage both doors.HatchTo lock or unlock the hatch.
● Use your master key to lock and
unlock the hatch. Turn the key
counterclockwise to lock the
hatch, and clockwise to unlock it.
Unlock
Lock
CONTINUED
Door Locks
81
Instruments and Controls
Table of Contents

The heating and air conditioning
system in your vehicle provides a
comfortable driving environment in all
weather conditions.
The standard audio system has many
features. This section describes those
features and how to use them. (If you
have an optional audio system, refer to
the operating instructions that came
with it.)
On EX and SC models
Your vehicle has an anti-theft audio
system that requires a code number to
enable it.
Vents, Heating, and A/C..............
104
Air Flow Controls .....................105
Ventilation ............................... 106
Using the Heater .....................106
Using the A/C ......................... 106
Dehumidify the Interior ...........
107 To Defog and Defrost
..............107
To Remove Exterior Frost or Ice From the Windows ..............108
To Turn Everything Off ............108
Audio System .............................. 109
Playing the FM/AM Radio (Models without navigation
system) ................................ 110
Playing the XM
®Radio (Models
without navigation system) ......113
Playing a Disc (Models without navigation system) ...................119
Disc Player Error Messages
(Models without navigationsystem) ................................ 125
Disc Changer Error Messages
(Models without navigationsystem) ................................ 126
Playing the FM/AM Radio
(Models with navigationsystem) ................................ 127
Playing the XM
®Radio (Models
with navigation system) ...........
132
Playing a Disc (Models with navigation system) ...................140Disc Player Error Messages
(Models with navigationsystem) ................................ 148
Playing a PC Card (Models with
navigation system) ...................149
PC Card Error Messages (Models with navigation system) ...........161
Playing an iPod
®(Models with
navigation system) ...................162
iPod
®Error Messages (Models
with navigation system) ...........
172
Playing a USB Flash Memory Device (Models with navigation
system) ................................ 173
USB Flash Memory Device Error
Messages (Models with
navigation system) ...............182
Protecting Your Discs ..................183
FM/AM Radio Reception .............186
Radio Theft Protection .................188
Setting the Clock .........................189
Remote Audio Controls ................191
Auxiliary Input Jack .....................
192
Cruise Control ............................. 193
Rearview Camera and Monitor .....196
Features
103
Features

Air Flow Controls
Fan Control Dial
Turn this dial clockwise to increase
the fan speed and airflow.
Temperature Control Dial
Turning this dial clockwise increases
the temperature of the airflow.
Air Conditioning (A/C) Button
This button turns the air
conditioning on and off. The
indicator in the button is on when the
A/C is on.
Recirculation Button
When the recirculation indicator is
on, air from the vehicle's interior is
sent throughout the system again.
When the indicator is off, air is
brought in from the outside of the
vehicle (fresh air mode).The outside air intakes for the
heating and cooling system are at the
base of the windshield. Keep this
area clear of leaves and other debris.
The system should be left in fresh air
mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C off,
can cause the windows to fog up.
Switch to recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air mode.
Rear Window Defogger Button
This button turns the rear window
defogger on and off (see page 74).
Mode Control Dial
Use the mode control dial to select
the vents the air flows from. Some air
will flow from the dashboard vents in
all modes.
The system automatically turns
on the A/C and switches to
recirculation mode. Air flows from
the center and side vents in the
dashboard (see page 106).
Air flows from the center and
corner vents in the dashboard.
Airflow is divided between the
vents in the dashboard and the floor vents.
Air flows from the floor vents.
When you select
, the system
automatically switches to fresh air mode.
Airflow is divided between the
floor vents and the defroster vents at
the base of the windshield.
CONTINUED
Vents, Heating, and A/C
105
Features
Table of Contents

On vehicles without navigation system
If your vehicle's battery is
disconnected or goes dead, you may
need to set the clock.
On LX model
To set the hour, press the H button
while pressing the CLOCK (SCAN/
RPT) button until the hour advances
to the desired time. Change the
minute by pressing the M button
while pressing the CLOCK (SCAN/
RPT) button until the minute
advances to the desired time.
You can use the R button to quickly
set the time to the nearest hour.
Press the R button while pressing the
CLOCK button. If the displayed time
is before the half hour, pressing R
sets the clock back to the previous
hour. If the displayed time is after the
half hour, pressing R sets the clock
forward to the beginning of the nexthour.
For example:
1:06 will reset to 1:00
1:53 will reset to 2:00
On EX and SC models
Press and hold the CLOCK button
until the numbers flash and you hear
a beep. Change the hour by pressing
the H button until the numbers
advance to the desired time. Change
the minute by pressing the M button
until the numbers advance to the
desired time.
TIME DISPLAY CLOCKBUTTON
H BUTTON R BUTTON M BUTTON
TIME DISPLAY
CLOCK BUTTON
H BUTTON R BUTTON M BUTTON
CONTINUED
Setting the Clock
189
Features
Table of Contents

You can quickly set the time to the
nearest hour. If the displayed time is
before the half hour, press the R
(RESET) button to set the clock back
to the previous hour. If the displayed
time is after the half hour, pressing R
sets the clock forward to the
beginning of the next hour.
For example:
1:06 will reset to 1:00
1:53 will reset to 2:00
When you are finished, press the
CLOCK button again.On vehicles with navigation system
The navigation system receives
signals from the global positioning
system (GPS), and the displayed
time is updated automatically by the
GPS. Refer to the navigation system
manual for how to adjust the time.
Setting the Clock
190
Table of Contents
