This indicator comes on f or a f ew
seconds when you turn the ignition
switch ON (II). If it comes on at any
other time, it indicates one of the
engine’s emissions control systems
may have a problem. Even though
you may f eel no dif f erence in your
car’s perf ormance, it can reduce
your f uel economy and cause your
car to put out excessive emissions.
Continued operation may cause
serious damage.Youshouldalsohavethedealer
inspect your car if this indicator
comes on repeatedly, even though it
may turn of f as you continue driving.
If you have recently ref ueled your
car, the cause of this indicator
coming on could be a loose or
missing f uel f ill cap. Check the cap
and tighten it until it clicks several
times. Replace the fuel fill cap if it is
missing. Tightening the cap will not
make the indicator turn of f
immediately; it takes one driving trip.
If the indicator remains on past one
driving trip, or the f uel cap was not
loose or missing, have the car
checked by the dealer as soon as
possible. Drive moderately until the
dealer has inspected the problem.
Avoid full-throttle acceleration and
driving at high speed.
CONT INUED
Malf unction Indicator L amp
T aking Care of t he Unexpect ed228
M M
A
AL
LFFUUN NCCTTI
IOON N I
INND DI
ICCA A T
TO
OR R L
LAA M
M P
P
If you keep driving with the
malf unction indicator lamp on, you can
damage your car’s emissions controls
and engine. Those repairs may not be
covered by your car’s warranties.

Your car has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics f or the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed.
If your car’s battery has been
disconnected or gone dead, these
codes are erased. It takes several
days of driving under various
conditions to set the codes again.If possible, do not take your car f or a
state emissions test until the
readiness codes are set. To check if
they are set, turn the ignition ON (II),
but do not start the engine. The
Malf unction Indicator Lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks 5 times, the readiness
codes are not set. Ref er to the
warranty manual f or more
inf ormation.
Malf unction Indicator L amp
T aking Care of t he Unexpect ed
Readiness Codes
229

Î
Î
Î
Î
If you must drive the car a short
distance in this condition, drive
slowly and cautiously. Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the
longer distance needed to stop, it is
hazardous to drive the car. You
should have it towed, and repaired as
soon as possible. (See on page .)
However, if the brake pedal does not
f eel normal, you should take
immediate action. Because of the
brake system’s dual-circuit design, a
problem in one part of the system
will still give you braking at two
wheels. You will f eel the brake pedal
go down much f arther bef ore the car
begins to slow down, and you will
have to press harder on the pedal.
The distance needed to stop will be
much longer. If it comes on at any other time, it
indicates a problem with the car’s
brake system. In most cases, the
problem is a low f luid level in the
brake f luid reservoir. Press lightly on
the brake pedal to see if it f eels
normal. If it does, check the brake
f luid level the next time you stop at a
service station (see page ). If the
fluid level is low, take the car to your
dealer and have the brake system
inspected f or leaks or worn brake
pads.
The Brake System Indicator is a
reminder to check the parking brake.
It comes on and stays lit if you do not
f ully release the parking brake. 179
237Emergency
Towing
Brake System Indicator
T aking Care of t he Unexpect ed230
B BR RAA K
KEE S
SYYSSTTE
EM
M I
INND DI
ICCA A T
TO
OR R
U
U. .SS. .i
inn d
di
icca at too r
r s
shh o
ow
wn n

All the electrical circuits in your car
have fuses to protect them from a
short circuit or overload. These
f uses are located in two f use boxes.The interior f use is underneath the
dashboard on the driver’s side.
Remove the storage pocket by
swinging the lid down, pushing up,
and pulling it straight out of its
hinges.The under-hood f use box is located
in the engine compartment. To open
it, push the tab as shown.
Fuses
T aking Care of t he Unexpect ed231
I IN
NT TE
ER
RI IOOR R T
TA
A B
B U
UNNDDE
ER
R- -H
H O
OO ODD

If something electrical in your car
stops working, the f irst thing you
should check f or is a blown f use.
Determine f rom the chart on pagesand , or the diagram on the
fuse box lid, which fuse or fuses
control that component. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
not the cause. Replace any blown
f uses and check the component’s
operation.
Turn the ignition switch to LOCK
(0). Make sure the headlights and
all other accessories are off.
Remove the cover f rom the f use
box. Check each of the large f uses in
the under-hood f use box by
looking through the top at the wire
inside. Removing these f uses
requires a Phillips-head screw-
driver.
Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse boxes by
pulling out each f use with the f use
puller provided in the under-hood
fuse box.
3.
1.
2. 4.
234 235
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed232
B BL
LOOW WN N F
FU
US SEE P
PU
UL LLLEE R
R
F
FU
US SEE

Look f or a burned wire inside the
f use. If it is burned, replace it with
oneof thesparefusesof thesame
rating or lower.If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your car.
Leave the blown fuse in that
circuit and have your car checked
by a qualif ied mechanic.
If you cannot drive the car without
f ixing the problem, and you do not
have a spare fuse, take a fuse of the
same rating or a lower rating f rom
one of the other circuits. Make sure
youcandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
5. 6.
Fuses
T aking Care of t he Unexpect ed233
B BL
LOOW WN N
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a replace-
ment f use with the proper rating f or the
circuit, install one with a lower rating.

µ
µ
Î
Î
Î
No. Amps. Circuits ProtectedNo. Amps. Circuits Protected
1
2
3
4
5
6
7
8
9
10 10 A
15 A
20 A
7.5 A
7.5 A
7.5 A 15 A
20 A
7.5 A 20 A SRS
Fuel Pump, SRS
Front Wiper
FI-ECU
Turn Light
Meter
IG Coil
Power Window, Passenger
Starter Signal
Power Window, Driver 11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
7.5 A
10 A
20 A
10 A
7.5 A
7.5 A
7.5 A
7.5 A 10 A
10 A
20 A
7.5 A
7.5 A
10 A
7.5 A ACC Radio
ACC Socket
Not used
LAF Heater
Small Light
Air Conditioning, R/C
Mirror
Daytime Running Light
Back Up Light
Interior Light
Radio
Daytime Running Light
Door Lock
Tailgate Lock
IMA
Not used
Rear Wiper
Back Light
: Canadian model only
Fuses
T aking Care of t he Unexpect ed234
INTERIOR FUSE BOX

µµ
No. Amps. Circuits ProtectedNo. Amps. Circuits Protected
1
2
3
4
5
6
7
8
9
10 50 A
80 A
30 A
10 A
15 A
10 A
15 A
15 A
15 A IG1 Main
Battery
ABS Motor
Hazard
IMA
Horn Stop
Fuel Pump
Lef t Headlight
Not used
Right Headlight 11
12
13
14
15
16
17
18
19
2030 A
40 A
30 A
20 A
40 A
30 A
40 A
7.5 A 20 A Cooling Fan
Heater Motor
Rear Defroster
ABS F/S
Power Steering
Back Up, ACC
Power Window
IMA ECU
Condenser Fan
Spare Fuse
Fuses
T aking Care of t he Unexpect ed235
UNDER-HOOD FUSE BOX

If your car gets stuck in sand, mud,
or snow, call a towing service to pull
it out (see page ).To use the towing hook:Remove the cover f rom the
bumper. Remove the towing hook and
wheel wrench f rom the tool box.
Screw the towing hook into the
hole and tighten it securely by
hand.
For very short distances, such as
freeing the car, you can use the
detachable towing hook that mounts
on the anchor in the f ront bumper.
1. 2.
3.
237
If Your Car Gets Stuck
T aking Care of t he Unexpect ed236

µ
µ
µ
There are three popular types of
prof essional towing equipment.
The tow
truck uses two pivoting arms that go
under the tires (f ront or rear) and lif t
them of f the ground. The other two
tires remain on the ground. If your car needs to be towed, call a
prof essional towing service or, if you
belong to one, an organization that
provides roadside assistance. Never
tow your car behind another vehicle
with just a rope or chain. It is very
dangerous.
The operator
loads your car on the back of a truck.
The tow
truck uses metal cables with hooks on the ends. These hooks go around
parts of the f rame or suspension and
the cables lif t that end of the car of f
the ground. Your car’s suspension
and body can be seriously damaged.
If your Honda cannot be transported
by f lat-bed, it should be towed by
wheel-lif t equipment with the f ront
wheels of f the ground. If due to
damage, your car must be towed
with the f ront wheels on the ground,
do the f ollowing:
With the f ront wheels on the ground,
it is best to tow the car no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
If your car is equipped with a f ront
spoiler, remove it bef ore towing so it
is not damaged.
Release the parking brake.
Shif t the transmission to Neutral.
Release the parking brake.
Start the engine.
ShifttoD,thentoN.
Turn of f the engine.
CONT INUED
5-speed Manual Transmission
Automatic Transmission
Wheel-lif t Equipment
Flat -bed Equipment
Sling-t ype Equipment
T his is
an acceptable way to tow your
Honda. This is the best way to transport
your Honda. T his method of towing is
unacceptable.
Emergency T owing
T aking Care of t he Unexpect ed237
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission, your car must be
transported with the f ront wheels of f
the ground.
