key HONDA INSIGHT 2014 2.G Owner's Manual

When the door is unlocked, you can
seetheredindicatoronthelocktab
above the inner door handle.You can customize the door lock/
unlock settings (see
page).
All doors and the hatch can be
locked f rom the outside by using the
key in the driver’s door. To unlock
only the driver’s door, insert the key,
turn it clockwise, and release it. The
remaining doors and the hatch
unlock when you turn the key a
second time within a f ew seconds.
To lock all doors and the hatch, push
the front of the master door lock
switch on the driver’s door, pull the
locktabrearwardonthedriver’s
door, or use the key on the outside
lock on the driver’s door.
Pushing the rear of the master door
lock switch will unlock all doors and
the hatch. Pushing f orward the lock
tab on the driver’s door unlocks only
that door. The lock tab on each passenger’s
door locks and unlocks that door.
108
CONT INUED
Door L ocks
133
Lock
Unlock LOCK TAB
MASTER DOOR LOCK SWITCH
To unlock
To lock
12/07/13 16:53:52 31TM8630_138
Inst rument s and Cont rolsTOC
2014 Insight

The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position (lever is
down), the door cannot be opened
f rom the inside regardless of the
position of the lock tab. To open the
door, push the lock tab f orward and
use the outside door handle.
To lock any passenger’s door when
getting out of the vehicle, pull the
lock tab rearward and close the
door. To lock the driver’s door,
remove the key from the ignition
switch, pull the lock tab rearward or
push the front of the master switch,
then close the door.
When the vehicle speed reaches
about 10 mph (U.S.)/15 km/h
(Canada) or more, all the doors and
the hatch lock automatically.
When you shif t to P af ter driving, the
driver’s door unlocks.
If you f orget and leave the key in the
ignition switch, lockout prevention
will not allow you to lock the driver’s
door. With any door or the hatch
open and the key in the ignition
switch, locking with master door
lock switch is disabled. If the driver’s
door is closed, the lock tab on the
driver’s door is not disabled. Pulling
the driver’s lock tab rearward will
lock all doors and the hatch. If you
try to lock an open driver’s door by
pulling the lock tab rearward, the
driver’s door lock tab pops out and
unlocks the driver’s door.
Def ault setting
L ockout Prevent ion
Childproof Door L ocks
Door L ocks
134
Unlock
Lock
LEVER
12/07/13 16:53:59 31TM8630_139
Inst rument s and Cont rolsTOC
2014 Insight

µµ
The ceiling light and the door
activated spotlights come on when
you press the UNLOCK button if the
lights are in the door activated
position. If you do not open any door
or the hatch within 30 seconds (or
whatever setting of the interior light
dimming time is set to), the light(s)
will f ade out. If you relock the doors
and the hatch with the remote
transmitter before 30 seconds have
elapsed, the light(s) will go of f
immediately.
To change the lock/unlock setting
and the relock timer setting, refer to
the customized settings on
page .
The keyless lock acknowledgment
beep and f lashing of the lights can
be deactivated (see
page).
Press this button once to
lock all doors and the hatch. Some
exterior lights will f lash once. When
you press LOCK twice within 5
seconds, the horn will sounds to
verif y that the doors are locked. You
cannot lock the doors if any door or
the hatch is not f ully closed or if the
key is in the ignition switch. If you press the LOCK button twice
within 5 seconds, you will hear a
horn to verify that the security
system has set.
Press this button once
to unlock the driver’s door (or all the
doors and the hatch depending on
the door lock setting). Press it twice
to unlock the remaining doors and
the hatch. Some exterior lights will
f lash twice when you press the
button the first time.
If you do not open any door or the
hatch within 30 seconds, they will
automatically relock, and the
security system (if equipped) will
reset. 114
108
CONT INUED
On LX and EX models
LOCK UNL OCK
Remote Transmitter
135
LED
LOCK BUTTON
UNLOCK
BUTTON PANIC
BUTTON
12/07/13 16:54:07 31TM8630_140
Inst rument s and Cont rolsTOC
2014 Insight

µAvoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperatures.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer. If it takes several pushes on the
button to lock or unlock the doors,
replace the battery as soon as
possible.
Battery type: CR1616
Press and hold this
button for about 1 second to attract
attention; the horn will sound, and
the exterior lights will f lash f or about
30 seconds. To cancel panic mode,
press any other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position. Panic
mode does not work when the key is
in the ignition switch.Remote Transmitter CareReplacing
the Transmitter Battery
PA NIC
Remote Transmitter
136
12/07/13 16:54:14 31TM8630_141
Inst rument s and Cont rolsTOC
2014 Insight

´
Be careful when
removing this screw as the
head of the screw can strip out.
Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
Remove the old battery and note
the polarity. Make sure the
polarity of the new battery is the
same ( side f acing down), then
insert it in the keypad.
To replace the battery:
Separate the keypad from the
transmitter by pushing any button
f rom outside. Place a cloth on the edge of the
keypad to prevent scratches, and
remove the upper half by carefully
prying on the edge with a coin.
Snap the two halves of the keypad,
then install the parts in reverse
order.
1.
2. 3.
4.
5.
CONT INUED
Remote Transmitter
137
NOTE:
SCREW BATTERY
COIN
KEYPAD
12/07/13 16:54:24 31TM8630_142
Inst rument s and Cont rolsTOC
2014 Insight

The hatch will lock or unlock when
you lock/unlock the driver’s door
with the key, the remote transmitter,
the master door lock switch, or the
locktabonthedriver’sdoor.
To unlock the hatch, turn the key
clockwise twice, push the rear of
the master door lock switch, or
push UNLOCK twice on the
remote transmitter.Keep the hatch closed at all times
while driving to avoid damaging the
hatch and to prevent exhaust gas
from getting into the interior. Seeon
page .
To open the hatch, push the release,
and lif t up. To close the hatch, use
thehandletolowerit,thenpress
down on the back edge.
56
Carbon Monoxide Hazard
Hatch
139
INNER HANDLE
RELEASE
12/07/13 16:54:33 31TM8630_144
Inst rument s and Cont rolsTOC
2014 Insight

The ceiling light has a three-position
switch: ON, Door Activated, and
OFF. In the Door Activated (center)
position, the light comes on when
you:After all doors are closed tightly, the
light dims slightly, then f ades out in
about 30 seconds.
The ceiling light (with the switch in
the center position) comes on when
you remove the key f rom the ignition
switch. If you do not open a door, the
light stays on, then f ades out in
about 30 seconds.
Turn on a spotlight by pushing the
lens. Push the lens again to turn it
off. You can use the spotlights at
Unlock the driver’s door with the
keyorremotetransmitter. Open any door. To change the ‘‘INTERIOR LIGHT
DIMMING TIME’’ setting, see
page
.
If you leave any door open without
the key in the ignition switch, the
ceiling light will go off after about
15 minutes. 105
CONT INUED
Ceiling L ight
Spotlights
Interior Lights
159
DOOR ACTIVATED POSITION
EX model with navigation systemPush
Push
SPOTLIGHTS
12/07/13 16:56:50 31TM8630_164
Inst rument s and Cont rolsTOC
all times.
2014 Insight

The alarm also activates if a
passenger inside the locked vehicle
turns the ignition switch on.Do not attempt to alter this system
or add other devices to it.
Once the security system is sets,
opening any door, the hatch, or the
hood without using the key or the
remote transmitter, will cause the
alarm to activate. It also activates if
the audio unit is removed f rom the
dashboard or the wiring is cut.
The security system helps to protect
your vehicle and valuables f rom thef t.
The horn sounds and a combination
of headlights, parking lights, side
marker lights and taillights f lashes if
someone attempts to break into your
vehicle or remove the audio unit.
This alarm continues for two
minutes, then the system resets. To
deactivate the system before the two
minutes have elapsed, unlock the
driver’s door with the key or the
remote transmitter.
The security system sets
automatically 15 seconds after you
lock the doors, hood, and the hatch.
For the system to activate, you must
lock the doors and the hatch f rom
the outside with the key, or use
driver’s lock tab, door lock master
switch, or remote transmitter. The
security system indicator on the
instrument panel starts blinking
immediately to show you the system
is setting itself .
To see if the system is set
af ter you exit the vehicle, press the
LOCK button on the remote
transmitter within five seconds. If
the system is set, the horn will beep
once. The security system does not set if
the hood, hatch, or any door is not
f ully closed. If the system will not set,
check the door and hatch open
indicator on the instrument panel
and multi-inf ormation display (see
page ) to see if the doors and
hatch are f ully closed. Since it is not
part of the monitor display, manually
check the hood. 12
On LX and EX models
Security System
221
NOTE:SECURITY SYSTEM INDICATOR
12/07/13 17:04:40 31TM8630_226
FeaturesTOC
2014 Insight

Î
Î
BluetoothHandsFreeL ink(Models without navigation system)
230
‘‘Change Language’’‘‘Hands Free Help’’
‘‘System
Set up’’
‘‘Tutorial’’ ‘‘Clear’’
‘‘Auto Transfer’’ ‘‘Call Notification’’ ‘‘Security’’
‘‘Change Passcode’’
Press HFL
Talk button
Press and release the HFL Talk button each time you give a command. Apply a security passcode to the system that must be input at each key
cycle to access the system
Change your security passcode
Set how you would like to be notified of an incoming call
Set calls to automatically transfer from your phone to HFL when you
enter the vehicle
Hear a list of available commands and additional information describing each command Clear the system of all paired phones, phonebook entries and security
passcode
Change language from English to French
Hear a tutorial for general rules on using the system
Canadian models
: (See
page 239)
(Seepage 240)
(See page 240)
(Seepage 240)
(See page 241)
(Seepage 242)
(Seepage 227)
(See page 227)
12/07/13 17:05:48 31TM8630_235
FeaturesTOC
2014 Insight

HFLusesaClass2Bluetooth,which
means, the maximum range between
your phone and vehicle is 30 feet
During a call, HFL allows you to talk
up to 30 minutes af ter you remove
the key from the ignition switch.
However, this may weaken the
vehicle’s battery. You can make calls using a name in
the HFL phonebook or any phone
number. You can also redial the last
number called.Once connected, you will hear the
person you called through the
audio speakers.
Say ‘‘ ’’ or ‘‘ .’’
Follow the HFL prompts and say
thenamestoredintheHFL
phonebook that you want to call.
Follow the HFL prompts to
confirm the name and make
Say ‘‘ ’’ or ‘‘ .’’
Follow the HFL prompts and say
the phone number you want to dial.
Follow the HFL prompts to
conf irm the number and say
‘‘ ’’ or ‘‘ .’’
Press and release the HFL Talk
button bef ore a command.
Press and release the HFL Talk
button bef ore a command.
1.
2.
3.
1.
2.
3.
Making a Call
Call DialCall Dial
Call Dial
Tomakeacallusinganameinthe HFL phonebook: T o make a call using a phone
number:
BluetoothHandsFreeL ink(Models without navigation system)
234
12/07/13 17:06:32 31TM8630_239
FeaturesTOC
the call.
(10 meters).
2014 Insight
