ECO mode HONDA INSIGHT 2014 2.G Service Manual

µµ
µ
µ µ
Press the sound ( ) button to
select an appropriate setting: bass,
treble, fader, balance, and SVC
(speed-sensitive volume
compensation). Turn the VOL/
SELECT knob to adjust the setting.
Adjusts the bass.Adjusts the treble.
Adjusts the front-to-back
strength of the sound.
Adjusts the side-to-
side strength of the sound.
Eachmodeisshowninthedisplayas
it changes. Turn the VOL/SELECT
knob to adjust the setting to your
liking. When the level reaches the
center, you will see ‘‘C’’ in the display. Adjusts the volume level
basedonthevehiclespeed.
Wait 10 seconds and the display
returns to normal. You can use the instrument panel
brightness control knob to adjust the
illumination of the audio system (see
page
). The audio system
illuminates when the parking lights
are on, even if the system is
The SVC mode controls the volume
based on vehicle speed. The f aster
you go, the louder the audio volume
becomes. As you slow down, the
audio volume decreases.
The SVC has f our modes: SVC OFF,
SVC LOW, SVC MID, and SVC
HIGH. Turn the VOL/SELECT knob
to adjust the setting to your liking. If
you f eel the sound is too loud,
choose low. If you f eel the sound is
too quiet, choose high. 124
Adjusting the Sound
BAS
TREBLE
FADER
BAL ANCE SVC
Audio System L ighting
Playing the FM/AM Radio (LX model and EX model without navigation system)
Speed-sensit ive Volume
Compensat ion (SVC)
187
12/07/13 17:00:26 31TM8630_192
FeaturesTOC
turned off.
2014 Insight

¼
The display shows up to 16
characters of selected text data (the
f older name, f ile name, etc.).
If the text data has more than 16
characters, you will see the first 15
characters and the indicator on
the display. Press and hold the
TITLE button until the next 16
characters are shown. You can see
up to 31 characters of text data.
When you press and release the
TITLE button while a disc without
text data is playing, you will see ‘‘NO
INFO’’ on the display. With the f older name, you will see
the FOLDER indicator in the display.
The TRACK indicator is shown with
the file or track name. You can see the album, artist, and
track name in the display. If a disc is
recorded in MP3 or WMA, you can
see the f older and f ile name, and the
album, artist, and track tag. Each time you press the TITLE
button, the display shows you the
text, if the disc was recorded with
text data.
Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3 or WMA, the numbers
of the current f older and f ile are
shown. The system will continuously
play a disc until you change modes.
You cannot load and play 3-inch
(8-cm)discsinthissystem.
For information on how to handle
and protect compact discs, see
page
.
214
T ext Data Display Function
To Load a Disc
Playing a Disc (LX model and EX model without navigation system)
190
12/07/13 17:00:49 31TM8630_195
FeaturesTOC
2014 Insight

µ
µ
This feature,
when activated, samples the first file
in each f older on the disc in the
order they are recorded. To activate
the folder scan feature, press the
SCAN button repeatedly. You will
see ‘‘F-SCAN’’ in the display. The
system will then play the f irst f ile in
the main f olders f or about 10
seconds. When it plays a f ile that you
want to continue listening to, press
and hold the SCAN button. When
the system samples the first file of
all folders, F-SCAN is canceled, and
the system plays normally.
Each time you press and release the
SCAN button, the mode changes
from file scan to folder scan, then to
normal play. Press the eject button ( ) to
remove the disc. If you eject the disc,
but do not remove it from the slot,
the system will automatically reload
the disc after 10 seconds and
begin playing.
Press the FM/AM button to switch
to the radio while a disc is playing.
To play the disc, press the CD button.
If you turn the system of f while a
disc is playing, either with the
( ) button or by turning of f the
ignition switch, the disc will stay in
the drive. When you turn the system
back on, the disc will begin playing
where it lef t of f .
For information on how to handle
and protect compact discs, see
page
.
The SCAN f unction
samples all the tracks on the disc in
the order they are recorded on the
disc (all f iles in the current f older in
MP3 or WMA mode). To activate the
scan feature, press and release the
SCAN button. You will see ‘‘SCAN’’
in the display. You will get a 10
second sampling of each track/f ile in
the disc/f older. Press and hold the
SCAN button to get out of scan
mode and play the last track sampled.
214
In MP3/WMA mode
FOLDER-SCANTo Stop Playing a Disc
Protecting Discs
SCAN
Playing a Disc (LX model and EX model without navigation system)
193
12/07/13 17:01:20 31TM8630_198
FeaturesTOC
2014 Insight

Do not connect your iPod using a
hub.
DonotkeeptheiPodinthe
vehicle. Direct sunlight and high
heat will damage it.
Do not use an extension cable
between the USB adapter cable
equipped with your vehicle and
your dock connector.
We recommend backing up your
data bef ore playing it.
Some devices cannot be powered
or charged via the USB adapter. If
this is the case, use the accessory
adapter to supply power to your
device.
iPod models conf irmed to be
compatible with your audio system
using the USB adapter cable are:
This audio system can play the audio
f iles on the iPodwith the same
controls used f or the in-dash disc
player. To play an iPod, connect it to
the USB adapter cable in the console
compartment by using your dock
connector, then press the AUX
button. The ignition switch must be
in the ACCESSORY (I) or ON (II)
position. The iPod will also be
recharged with the ignition switch in
these positions.
The system will only play songs
stored on the iPod with iTunes.
iPod and iTunes are registered
trademarks owned by Apple Inc. This system may not work with all
sof tware versions of these devices.
Model
iPod classic 80/160 G
iPod classic 120 G
iPod classic 160 G (launch in 2009)
iPod (5th generation)
iPod nano
iPod touch
Playing an iPod(U.S. L X model and EX model without navigation system)
To Play an iPod
196
NOTE:
12/07/13 17:01:41 31TM8630_201
FeaturesTOC
2014 Insight

Unclip the USB connector by
pivoting it, and pull out the USB
adapter cable in the console
compartment.Connect your dock connector to
the iPod correctly and securely.
Install the dock connector to the
USB adapter cable securely.If the iPod indicator does not appear
in the audio display, check the
connections, and try to reconnect the
iPod a f ew times.
If the audio system still does not
recognize the iPod, the iPod may
need to be reset. Follow the
instructions that came with your
iPod, or you can f ind reset
instructions online at
1. 2.
3.
www.apple.com/
CONT INUED
Connect ing an iPod
Playing an iPod(U.S. L X model and EX model without navigation system)
197
DOCK CONNECTOR
USB ADAPTER
CABLE
USB CONNECTOR
USB ADAPTER CABLE
12/07/13 17:01:49 31TM8630_202
FeaturesTOC
2014 Insight

µ
Î
Î
This feature
plays all available albums in a
selected list (playlists, artists, albums
or songs) in random order. The f iles
in each album are played in the
recorded order. To activate the
shuf f le album f eature, press the
RDM button repeatedly. You will see
‘‘F-RDM’’ in the display. To turn it
of f , press and hold the RDM button.
Each time you press the RDM
button, the mode changes f rom
shuffle all play to shuffle album play,
then to normal play. To play the radio when an iPod is
playing, press the FM/AM button. If
a disc is in the audio unit, press the
CD button to play the disc.
You can disconnect the iPod at any
time when you see the ‘‘OK to
disconnect’’ message in the iPod
display. Always make sure you see
the ‘‘OK to disconnect’’ message in
the iPod display bef ore you
disconnect it. Make sure to f ollow
the iPod’s instructions on how to
disconnect the dock connector f rom
the USB adapter cable.
The displayed message may vary
on models or versions. On some
models, there is no message
to disconnect.
If you reconnect the same iPod, the
system may begin playing where it
lef t of f , depending on what mode the
iPod is in when it is reconnected.
When you disconnect the iPod while
it is playing, the display shows ‘‘USB
NO DATA.’’
:
SHUFFL E AL BUM
T o Stop Playing Your iPod
Disconnect ing an iPod
Playing an iPod(U.S. L X model and EX model without navigation system)
200
12/07/13 17:02:14 31TM8630_205
FeaturesTOC
2014 Insight

If you see an error message on the
audio display while playing
an iPod, find the solution in the
chart to the right. If you cannot
clear the error message, take your
vehicle to your dealer.Cause
Error Message Solution
USB ROM Error
Appears when an
incompatible device is
connected
No files in iPod
Use of unsupported
iPod
Recognition failure of
iPodThere is a problem with the USB adapter unit.
Disconnect the device. Then, turn the audio
systemoff,andturnitonagain.Donot
reconnect the device that caused the error.
Appears when the iPod is empty. Store some
files in the iPod.
Appears when an unsupported iPod is
connected. See
page 196for the specification
information for iPods. If it appears when a
supported iPod is connected, update the iPod
software to the newer version.
Appears when the system does not
acknowledge the iPod. Reconnect the iPod.
iPodError Messages (U.S. L X model and EX model without navigation system)
201
USB ERROR BAD USBDEVICE
PLEASE CHECK OWNERS
MANUAL
iPod NO SONG
UNSUPPORTED VER.
CONNECT RETRY
12/07/13 17:02:18 31TM8630_206
FeaturesTOC
2014 Insight

Î
Î
CONT INUED
The recommended USB f lash
memory devices are 256 MB or
higher, and f ormatted with the FAT
f ile system. Some digital audio
players may be compatible as well.
Some USB f lash memory devices
(such as devices with security lock-
out f eatures, etc.) will not work in
this audio unit.
The audio system reads and plays
the audio f iles on the USB f lash
memory device in MP3, WMA or
AAC f ormats. Depending on the
f ormat, the display shows MP3,
WMA or AAC when a USB flash
memory device is playing.
This audio system can operate the
audio f iles on a USB f lash memory
device with the same controls used
f or the in-dash disc player. To play a
USB f lash memory device, connect it
to the USB adapter cable in the
console compartment, then press the
AUX button.
Only AAC format files recorded with
iTunes are playable on this audio unit.:
To Play a USB Flash Memory
Device
Playing a USB Flash Memory Device (U.S. L X model and EX model without navigation system)
203
12/07/13 17:02:30 31TM8630_208
FeaturesTOC
2014 Insight

Do not use a device such as a card
reader or hard drive as the device
or your f iles may be damaged.
Do not connect your USB f lash
memory device using a hub.
Do not use an extension cable to
the USB adapter cable equipped
with your vehicle.Do not keep a USB f lash memory
device in the vehicle. Direct
sunlight and high heat will damage
it.
Depending on the type and
number of f iles, it may take some
time before they begin to play.Depending on the sof tware the
f iles were made with, it may not be
possible to play some f iles, or
displaysometextdata.
Depending on the type of
encoding and writing sof tware
used, there may be cases where
character inf ormation does not
display properly.
We recommend backing up your
data bef ore playing a USB f lash
memory device.
Some devices cannot be powered
or charged via the USB adapter. If
this is the case, use the accessory
adapter to supply power to your
device.
Playing a USB Flash Memory Device (U.S. L X model and EX model without navigation system)
204
NOTE:
12/07/13 17:02:37 31TM8630_209
FeaturesTOC
2014 Insight

µ
µ
µ
Each time you press and release the
SCAN button, the mode changes
f rom f ile scan to f older scan, then to
normal play.This feature
samples the f irst f ile in each f older in
the order they are stored. To
activate the folder scan feature,
press the SCAN button repeatedly.
You will see ‘‘F-SCAN’’ in the display.
You will get a 10 second sampling of
the f irst f ile in each f older. Press and
hold the SCAN button to get out of
the f older scan mode and play the
last f ile sampled.
This feature samples all
f iles in the current f older in the
order they are stored. To activate
the scan feature, press the SCAN
button. You will see ‘‘SCAN’’ in the
display. You will get a 10 second
sampling of each f ile in the f older.
Press and hold the SCAN button to
get out of the scan mode and play
the last f ile sampled.
This
f eature plays the f iles in the current
f older in random order. To activate
the folder random feature, press the
RDM button repeatedly. You will see
‘‘F-RDM’’ in the display. To turn it
of f , press and hold the RDM button.
Each time you press the RDM
button, the mode changes f rom track
random, play to f older random play,
then to normal play. FOLDER SCAN
SCAN
FOLDER RANDOM
Playing a USB Flash Memory Device (U.S. L X model and EX model without navigation system)
209
12/07/13 17:03:10 31TM8630_214
FeaturesTOC
2014 Insight
