HONDA ODYSSEY 2009 RB3-RB4 / 4.G Owners Manual

Î
Î
See page11,91
See page 21,91 See page97
See page 34,98
See page
94,362
See page 91,481
See page 93,481 See page
97,481
See page 95,400
See page 94,399
See page 100,462 See page
96,479
See page 96,479
See page 97,480
U.S. Touring PAX only
:
Multi-Inf ormation Display
88
U.S.
Canada
U.S.
Canada Canada U.S.
——
y

y
(yy
2009 Odyssey

Î
Î
CONT INUED
See page35,94 See page
93
See page 92
See page 93 See page
92
See page 99,138
See page 99,160 See page
99,166
See page
98,392
See page 96,394 See page98,363 See page
95,417
Canadian model only
:
Multi-Inf ormation Display
Inst rument s and Cont rols
89
Canada Canada
U.S. Canada U.S.
U.S.
——
y


y
(yy
2009 Odyssey

The system message(s) triggers the
appropriate indicator(s) on the
instrument panel, including the
system message indicator, to come
on. The system message indicator
does not go of f until the problem(s)
is corrected.You will also hear a beep when the
system message comes on f or the
first time.
Most of the messages are displayed
f or about 5 seconds, and then the
normal display returns. If there are
several system messages to be
shown, the display switches these
messages every 5 seconds.
To cancel the message(s) bef ore 5
seconds elapsed, press the INFO
button on the steering wheel.
Even if you press the INFO button,
some messages stay on or come on
again at regular intervals until the
problem is corrected:
FASTEN SEAT BELT
FASTEN PASSENGER SEAT
BELT
RELEASE PARKING BRAKE
WARNING: APPROACHING
OBJECT
PAX SYSTEM WARNING
You can see the message(s) again by
pressing the INFO button repeatedly
if the system message indicator
remains lit on the instrument panel. (Models with PAX system)
Multi-Inf ormation Display
90
SYSTEM MESSAGE INDICATOR
\f—\f—
y

y
(\fy\f\fy
2009 Odyssey

If you start driving without releasing
the parking brake, the multi-
inf ormation display interrupts the
current display and shows
‘‘RELEASE PARKING BRAKE.’’
This message continues, and a
chime sounds, until you release the
parking brake, or the vehicle speed
slows down to less than 0.5 mph (0.8
km/h).
If the tailgate or any door(s) is not
closed tightly, the display reminds
you to close the tailgate or the
door(s) bef ore you start driving.
This display continues until you
close the door(s) or the tailgate.
Pressing the INFO button on the
steering wheel momentarily changes
the display to the normal display, but
it will come back af ter 5 seconds.
In addition to the seat belt reminder
indicator in the instrument panel,
you will also see a ‘‘FASTEN SEAT
BELT’’ or ‘‘FASTEN PASSENGER
SEAT BELT’’ message. This remains
displayed if you ignore it and do not
f asten the seat belt while driving.
CONT INUED
Multi-Inf ormation Display
Fast en Seat Belt
Door and T ailgat e OpenRelease Parking Brake
Inst rument s and Cont rols
91
Canada
U.S.
\f—\f—
y


y
(\fy\f\fy
2009 Odyssey

If you leave the key in the ignition
switch in the LOCK (0) or
ACCESSORY (I) position and open
the driver’s door, you will see
‘‘REMOVE KEY’’ on the display and
hear a reminder beeper.Your vehicle’s on board diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘TIGHTEN FUEL CAP’’ message
appears on the multi-inf ormation
display. Turn the engine of f , and
conf irm the f uel f ill cap is installed. If
it is, loosen it, then retighten it until
it clicks at least once. The message
should go of f af ter several days of
normal driving once you tighten orreplace the f uel f ill cap. To scroll to
another message, press the INFO
button. The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message of f .
If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
480
Multi-Inf ormation Display
Remove K ey T ight en Fuel Cap
92
\f—\f—
y

y
(\fy\f\fy
2009 Odyssey

If the brake f luid level is at or below
theMINmarkonthesideof the
brake f luid reservoir in the engine
compartment, you will see ‘‘BRAKE
FLUID LOW.’’ If you see this
message, have the brake system
checked by your dealer (see page). If the f luid level in the windshield
washer reservoir gets low, you will
see ‘‘WASHER FLUID LOW’’ on the
multi-inf ormation display.
If the level of the fuel in the tank
gets low, you will see ‘‘FUEL LOW’’
on the multi-information display, and
you must ref uel soon. The low f uel
indicator on the instrument panel will
also come on.
481
CONT INUED
On Canadian Touring model only
Multi-Inf ormation Display
Brake Fluid L ow Fuel L ow Washer Fluid L ow
Inst rument s and Cont rols
93
U.S.
Canada
\f—\f—
y

y
(\fy\f\fy
2009 Odyssey

This message, and the indicator to
the lef t of the message, is part of the
parking sensor system. If you are
approaching too close to an object,
you will see ‘‘WARNING:
APPROACHING OBJECT’’ on the
display and hear a beeper. See pagef or more inf ormation.
If the passenger’s side airbag has
automatically shut of f , you will see
‘‘PASSENGER SIDE AIRBAG OFF’’
on the multi-inf ormation display. See
page f or more inf ormation.
If one or more of your vehicle tires
are low on pressure, you will see a
‘‘CHECK TIRE PRESSURE’’
message on the display. See page
f or more inf ormation on the tire
pressure monitoring system (TPMS).
35
399
362
Multi-Inf ormation Display
Passenger Side A irbag Of f Check T ire PressureWarning: A pproaching Object
94
U.S.
Canada
\f—\f—
y

y
(\fy\f\fy
2009 Odyssey

CONT INUED
When the engine oil lif e reaches 15%,
the display shows ‘‘SERVICE DUE
SOON’’ and the code f or the
maintenance items to be perf ormed.
When the engine oil lif e reaches 5%,
the display shows ‘‘SERVICE DUE
NOW’’ along with the same
maintenance items.If there is a problem in the tire
pressure monitoring system (TPMS),
you will see ‘‘CHECK TPMS
SYSTEM’’ on the multi-inf ormation
display. If you see this message, the
TPMS is not monitoring tire
pressures. Have the TPMS checked
by your dealer as soon as possible
(see page ).
Have your dealer do the indicated
maintenance as soon as you see this
message, and have them reset the
display af ter completing the service.
If you do not perf orm the indicated
maintenance or do not reset the
display, the message changes to
‘‘SERVICE PAST DUE’’ when the
engine oil lif e becomes 0%.
These messages appear on the multi-
inf ormation display each time you
turn the ignition switch to the ON
(II) position.
For details on engine oil lif e and
maintenance messages, ref er to page
.
Also ref er to page f or important
maintenance saf ety precautions. 417
414 403
Multi-Inf ormation Display
Maint enance Messages Check T PMS Syst em
Inst rument s and Cont rols
95
\f—\f—
y

\fy
(\fy\f
\f\fy
2009 Odyssey

If you see ‘‘CHECK CHARGING
SYSTEM’’ on the multi-inf ormation
display, it means the battery is not
being charged. See page f or
more inf ormation.
If the engine oil is very low or has
lost pressure, you will see ‘‘CHECK
ENGINE OIL LEVEL’’ on the multi-
inf ormation display. You will also see
the low oil pressure indicator in the
instrument panel f lashing or staying
on. If you see this message, you
should take immediate action since
serious engine damage is possible.
Follow the procedure on page .
If there is a problem with the vehicle
stability assist (VSA) system, you
will see ‘‘CHECK VSA SYSTEM’’ on
the multi-information display. If you
see this message, have the VSA
system checked by your dealer (see
page ).
394
479479
Multi-Inf ormation Display
Check Charging Syst em
Check Engine Oil L evel
Check VSA Syst em
96
\f—\f—
y


y
(\fy\f
\f
y
2009 Odyssey

CONT INUED
If there is a problem with the
automatic transmission, you will see
‘‘CHECK TRANSMISSION’’ on the
multi-inf ormation display. Avoid
rapid acceleration, and have the
transmission checked by a dealer as
soon as possible.
If there is a problem with the brake
system, you will see ‘‘CHECK
BRAKE SYSTEM’’ on the multi-
inf ormation display. The parking
brake and brake system indicator in
the instrument panel will also come
on. See page f or more
inf ormation.
If you see ‘‘CHECK EMISSION
SYSTEM’’ on the multi-inf ormation
display, it means one of the engine’s
emission systems may have a
problem. Have your vehicle checked
by your dealer (see page ).
480
481
Multi-Inf ormation Display
Check T ransmission
Check Brake Syst em
Check Emission Syst em
Inst rument s and Cont rols
97
U.S.
Canada
\f—\f—
y

y
(\fy\f
\fy
2009 Odyssey
