If your seat belts get dirty, use a sof t
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air dry bef ore
you use the vehicle.
Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.If you remove the driver’s f loor mat,
make sure to re-anchor it when you
putitbackinyourvehicle. The driver’s f loor mat that came
with your vehicle hooks over the
f loor mat anchors. This keeps the
f loor mat f rom sliding f orward and
possibly interf ering with the pedals.If you use a non-Honda f loor mat,
make sure it f its properly and that it
canbeusedwiththefloormat
anchors. Do not put additional f loor
mats on top of the anchored mat.
This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the climate control
system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message on the
odometer/trip meter display or on
the multi-information display. It
should be replaced every 15,000
miles (24,000 km) if you drive
primarily in urban areas that have
high concentrations of soot in the air,
or if the f low f rom the climate
control system becomes less than
usual.
On EX, EX-L, Touring models
Floor Mats
Cleaning the Seat Belts
Dust and Pollen Filter
Cleaning the Seat Belts, Floor Mats, Dust and Pollen Filter
444
LOOP
——
y


y
(yy
2010 Odyssey

CONT INUED
Even though your vehicle is
equipped with TPMS, we
recommend that you visually check
your tires every day. If you think a
tire might be low, check it
immediately with a tire gauge.
Use a gauge to measure the air
pressure in each tire at least once a
month. Even tires that are in good
condition may lose 1 to 2 psi (10 to
20 kPa, 0.1 to 0.2 kgf /cm ) per
month. Remember to check the
sparetireatthesametime.
Check the air pressures when the
tires are cold. This means the
vehicle has been parked f or at least 3
hours, or driven less than 1 mile (1.6
km). Add or release air, if needed, to
match the recommended cold tire
pressures.If you check air pressures when the
tires are hot (driven f or several
miles/kilometers), you will see
readings 4 to 6 psi (30 to 40 kPa, 0.3
to 0.4 kgf/cm ) higher than the cold
readings. This is normal. Do not let
air out to match the recommended
cold air pressure. The tire will be
underinf lated.
Youshoulduseyourowntire
pressure gauge whenever you check
your tire pressures. This will make it
easier f or you to tell if a pressure
loss is due to a tire problem and not
due to a variation between gauges.
While tubeless tires have some
ability to self -seal if they are
punctured, you should look closely
for punctures if a tire starts losing
pressure.
The following chart shows the
recommended cold tire pressures f or
most normal and high-speed driving
conditions.
Tire Size
Tire Size
Cold Tire Pressure for
Normal Driving
Front:
Rear: Front:
Rear:
Cold Tire Pressure for
Normal Driving
EX-L models
LX, EX and Canadian DX models
Tires
Recommended T ire Pressures
Maint enance
451
235/65R16 103T
35 psi (240 kPa ,2.4 kgf/cm
)
33 psi (230 kPa ,
2.3 kgf/cm
)
235/65R16 103T 35 psi (240 kPa ,
2.4 kgf/cm
)
35 psi (240 kPa , 2.4 kgf/cm
)
——
y
y
(yy
2010 Odyssey

Every time you check inf lation, you
should also examine the tires f or
damage, f oreign objects, and wear.
Youshouldlookfor:Bumps or bulges in the tread or
side of the tire. Replace the tire if
youfindeitherof theseconditions.
Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see f abric or cord.
Excessive tread wear.
A tire this worn gives very little
traction on wet roads. You should
replace the tire if you can see three
or more tread wear indicators. Your tires have wear indicators
molded into the tread. When the
tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread lef t on
the tire.
Thecompactsparetirepressureis:
For convenience, the recommended
tire sizes and cold tire pressures are
on a label on the driver’s doorjamb.
For additional inf ormation about
your tires, see page .
496Tire SizeCold Tire Pressure for
Normal Driving
Front:
Rear:
Touring models
Tires
Tire Inspection
452
INDICATOR
LOCATION
MARKS
TREAD WEAR
INDICATORS
235/60R17 102T 33 psi (230 kPa ,
2.3 kgf/cm)
35 psi (240 kPa , 2.4 kgf/cm
)
60 psi (420 kPa , 4.2 kgf/cm)
——
y

y
(yy
2010 Odyssey

To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the inf ormation display or multi-
inf ormation display (depending on
models). Move the tires to the
positions shown in the diagram each
time they are rotated. If you
purchase directional tires, rotate
only f ront-to-back.
In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
Have your dealer check the tires if
you f eel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed f rom the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comf ort and tire lif e. For best results,
have the installer perform a dynamic
balance.
The service lif e of your tires is
dependent on many f actors,
including, but not limited to, driving
habits, road conditions, vehicle
loading, inf lation pressure,
maintenance history, speed, and
environmental conditions (even
when the tires are not in use).
The last f our digits of the TIN (tire
identif ication number) are f ound on
the sidewall of the tire and indicate
the date of manufacture (See
on page ).
In addition to your regular
inspections and inf lation pressure
maintenance, it is recommended that
you have annual inspections
perf ormed once the tires reach f ive
years old. It is also recommended
that all tires, including the spare, be
removed from service after 10 years
from the date of manufacture,
regardless of their condition or state
of wear.
496
If equipped
Tires
Tire Rotation
T ire Maintenance
Tire Service Lif e
Tire
Labeling
Maint enance
453
Front Front
(For Non-directional
Tires and Wheels) (For Directional
Tires and Wheels)
Improper wheel weights can damage
your vehicle’s aluminum wheels. Use
only genuine Honda wheel weights f or
balancing.
——
y
y
(yy
2010 Odyssey

´
Wheels: Tires marked ‘‘M S’’ or ‘‘All
Season’’ on the sidewall have an all-
weather tread design suitable for
most winter driving conditions.
For the best perf ormance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.
Tires:
See page f or inf ormation about
DOT Tire Quality Grading, and page
f or tire size and labeling
inf ormation. If you mount snow tires on your
vehicle, make sure they are radial
tires of the same size and load range
as the original tires. Mount snow
tires on all f our wheels. The traction
provided by snow tires on dry roads
maybelowerthanyouroriginaltires.
Check with the tire dealer f or
maximum speed recommendations.
496 494
All models except Touring models
All models except Touring models
Touring models
Touring models
Tires
Wheel and T ire Specif ications Winter Driving Snow T ires
Maint enance
455
16x7J
17x7J
235/65R16 103T
235/60R17 102T(TPMS)
(TPMS)
——
y
y
(yy
2010 Odyssey

When installing cables, f ollow the
manuf acturer’s instructions, and
mount them as tight as you can.
Make sure they are not contacting
the brake lines or suspension. Drive
slowly with them installed. If you
hear them coming into contact with
the body or chassis, stop and
investigate. Remove them as soon as
you begin driving on cleared roads.
The previously listed chains are the
only ones that have been approved
by Honda f or use on your vehicle.
Since Honda cannot test all chains,
you must be personally responsible
f or proper selection, installation, and
useof tirechains.
These chains are available at many
auto supply stores. For a complete
list of stores, visit the SCC website at
www.scc-chain.com. When insta
lling
chains, f ollow the manuf acturer’s
instructions, and mount them as
tightlyasyoucan.Driveslowlywith
chains installed.
Because your vehicle has limited tire
clearance, Honda strongly
recommends using the chains listed
below. Mount tire chains on your tires when
required by driving conditions or
local laws. Install them only on the
f ront tires.
Link-type: SCC Quick Grip QG1142
Cable-type: SCC SC Cable SC1042
Link-type: SCC Quick Grip QG1138
Cable-type: SCC SC Cable SC1038
All except Touring models
On Touring models
Tires
Tire Chains
456
——
y
y
(y
y
2010 Odyssey

The spare tire is stored behind the
sparetirecoveronthesidewallof
the cargo area on the driver’s side.Placethejackunderthejacking
point nearest the tire you need to
change. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch.
Remove the cover by holding the
two handles on the spare tire
cover and pulling the cover out. If you are changing a rear tire,
close the sliding door.
Unscrew the tire mounting wing
bolt, and take the spare tire out of
its holder. Make sure you also turn of f the
sliding door main switch.
Loosen each wheel nut 1/2 turn
with the wheel nut wrench.
8.
9. 10.
12.
11.
CONT INUED
On EX, EX-L, Touring models
Changing a Flat Tire
T aking Care of t he Unexpect ed
465
SEAT BELT
COVER
TIRE MOUNTING
WING BOLT
SPACER CONE
WHEEL NUT WRENCHWHEEL NUTS
——
y

y
(yy
2010 Odyssey

Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(seeon page
).
This indicator should never come on
when the engine is running. If it
starts flashing or stays on, the oil
pressure has dropped very low or
lost pressure. Serious engine
damage is possible, and you should
take immediate action.
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message on
the multi-information display (see
page ). If the charging system indicator
comes on brightly when the engine
is running, the battery is not being
charged.
You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display (see
page ).
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
Saf ely pull of f the road and shut
of f the engine. Turn on the hazard
warning lights.
1.
2.
3.
4. 88
88 371
426
486
On Touring models On Touring models
Emergency T owing
L ow Oil Pressure
Indicator
Charging System
Indicator
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
477
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
——
y

y
(yy
2010 Odyssey

If the indicator comes on repeatedly,
even though it may turn of f as you
continue driving, have your vehicle
checked by your dealer as soon as
possible.The indicator may also come on with
the ‘‘D’’ indicator.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ).
Your vehicle has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics f or the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed.To check if they are set, turn the
ignition switch to the ON (II)
position without starting the engine.
The malf unction indicator lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks 5 times, the readiness
codes are not set. If possible, do not
take your vehicle for a state
emissions test until the readiness
codes are set. Ref er to
f or more inf ormation (see
page ).
If your vehicle’s battery has been
disconnected or gone dead, these
codes are erased. It can take several
days of driving under various
conditions to set the codes again.
If this indicator comes on while
driving, it means one of the engine’s
emissions control systems may have
a problem. Even though you may
f eel no dif f erence in your vehicle’s
perf ormance, continued operation
may cause serious damage.
88
504
On Touring models
Malf unction Indicator L amp, Readiness Codes
Readiness Codes Emissions
Testing
Malf unction Indicator
Lamp
478
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
——
y
y
(yy
2010 Odyssey

µ
µ
µ µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ Î Î
Î
Î
ÎÎ
Î
Specif ications
Technical Inf ormation
493
Battery Lights Alignment
Fuses Seating Capacities Tires
60 W (HB3)
12 V
12 V 12 V
12 V
12 V
12 V
12 V
12 V
12 V 21 W
21/5 W
21 W
5W
16 W
2W
8W
3.8 W (2 CP)
Capacity 12 V
12 V 60 AH/5 HR
72 AH/20 HR
Headlights
Fog lights
Front turn signal lights
Front parking/side marker
lights
Rear turn signal lights
Stop/Taillights
Taillights
Back-up lights
License plate lights
High-mount brake light
Individual map lights
Vanity mirror lights
Cargo area light
Door courtesy light
Toe-in
Camber
Caster
0.00 in (0.0 mm)
0.08 in (2.0 mm)
0°
0°30’
2°32’
235/65R16 103T
Interior
Under-hood 12 V 51 W
12 V 55 W
12 V 21 W
12 V 3 CP
12 V 2 CP
12 V 8 W
12 V 5 W
235/60R17 102T
See page 483or the fuse box
cover. T135/80D17 103M
33 psi (230 kPa , 2.3 kgf/cm
)
35 psi (240 kPa , 2.4 kgf/cm)
35 psi (240 kPa , 2.4 kgf/cm)
60 psi (420 kPa , 4.2 kgf/cm)
Total
Front
Rear 8/7
2
3/2 3
Size
Pressure
See page 484and 485or the fuse
label attached to the dashboard.
See page 485or the fuse label
attached to the inside of the fuse
box door under the dashboard. Front
Rear
Front
Rear
Front
(Amber)
Driver’s side
Passenger’s side Front
Rear High
Low
:Second row
Third row
(H11) (HB4)
(Amber)
U.S. LX and Canadian DX modelsTouring models
EX-L models
1:
2: Front/Rear
Spare
Front
Rear
Spare
1
2
——
y
y
(yy
2010 Odyssey
