If the impact is on the passenger’s
side, the passenger’s side curtain
airbag will inflate even if there are no
occupants on that side of the vehicle.
If the rollover sensor detects your
vehicle is about to roll over, it signals
the control unit, which immediately
deploys both side curtain airbags and
activates both f ront seat belt
tensioners.
The airbag on the passenger’s side
will deploy, and the seat belt
tensioner will activate, even if there
are no passengers on that side of the
vehicle.To get the best protection f rom the
side curtain airbags, occupants
should wear their seat belts and sit
upright and well back in their seats.
In a moderate to severe side impact,
sensors will detect rapid acceleration
and signal the control unit to
instantly inflate the side curtain
airbag and activate the seat belt
tensioner on the driver’s or the
passenger’s side of the vehicle.
In a Side Impact In a Rollover
How Your Side Curtain A irbags
Work
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
33
——
y
y
(yy
2010 Odyssey

CONT INUED
When you turn the ignition switch to
the ON (II) position, the indicator
should come on f or several seconds
andthengooff (seepage ).If it
doesn’t come on, stays on, or comes
on while driving without a passenger
in the front seat, have the system
checked.This indicator alerts you that the
passenger’s f ront airbag has been
shut of f because weight sensors
detect about 65 lbs (29 kg) or less
(the weight of an inf ant or small
child) on the f ront passenger’s seat.
It does there is a problem
with the airbag.Be aware that objects placed on the
f ront seat can cause the indicator to
come on.
If no weight is detected on the f ront
seat, the airbag will be automatically
shut of f . However, the indicator will
not come on.
The passenger airbag of f indicator
may come on and of f repeatedly if
the total weight on the seat is near
the airbag cutof f threshold.
If an adult or teenage passenger is
riding in f ront, move the seat as f ar
to the rear as possible, and have the
passenger sit upright and wear the
seat belt properly.
This indicator alerts you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-inf ormation display (see page
). 68
89
On Touring models
Additional Inf ormation About Your Airbags
How the Passenger Airbag Of f
Indicator Works
How the Side
Airbag Of f
Indicator Works
not mean
not
Driver and Passenger Saf ety
35
PASSENGER AIRBAG OFF
INDICATOR
Canada
U.S.
CanadaU.S.
——
y
y
(yy
2010 Odyssey

Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by an authorized dealer or
a knowledgeable body shop.
Your airbag systems are virtually
maintenance f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:
If the indicator comes on with no
f ront seat passenger and no objects
on the seat, or with an adult riding
there, something may be interf ering
with the weight sensors. Look f or
and remove:
Any items under the f ront
passenger’s seat.
Any object(s) hanging on the seat
or in the seat-back pocket.
Any object(s) touching the rear of
the seat-back. Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. Any
seat belt tensioner that activates
must also be replaced. Take your vehicle to an
authorized dealer as soon as
possible. If you ignore this
indication, your airbags may not
operate properly.
Even if your
airbags do not inflate, your dealer
should inspect the driver’s seat
position sensor, the f ront
passenger’s weight sensors, the
f ront seat belt tensioners, and all
seat belts and their anchors worn
during a crash to make sure they
are operating properly.
If no obstructions are f ound, have
your vehicle checked by a dealer as
soon as possible.
Additional Inf ormation About Your Airbags
Airbag Service
An airbag ever inf lates. T he SRS indicat or alert s you t o a
problem.
If your vehicle has a moderat e t osevere impact .
36
——
y

y
(y
y
2010 Odyssey

Together, airbags and
seat belts provide the best
protection.
Tampering could cause
the airbags to deploy, possibly
causing very serious injury. This could make the
driver’s seat position sensor or the
f ront passenger’s weight sensors
inef f ective. If it is necessary to
remove or modif y a f ront seat to
accommodate a person with
disabilities, f irst contact Honda
Automobile Customer Service at
(800) 999-1009.
If water or
another liquid soaks into the seat-
back, it can prevent the side airbag
cutof f system f rom working
properly.
Additional Saf ety Precautions
Donotattempttodeactivateyour
airbags.
Do not t amper wit h airbagcomponent s or wiring f or anyreason. Do not remove or modif y a f ront
seat without consulting yourdealer.
Do not expose the f ront passenger’s
seat-back to liquid.
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
37
——
y

y
(yy
2010 Odyssey

The instrument panel has many
indicators to give you important
inf ormation about your vehicle. If this indicator comes on when theengine is running, the battery is not
being charged. For more inf ormation,
see page .
For more inf ormation, see page . This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
side curtain airbags, automatic seat
belt tensioners, driver’s seat position
sensor, or the f ront passenger’s
weight sensors. For more
inf ormation, see page .
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ).
You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display (see
page ).
The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running. For
more information, see page .
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message on
the multi-information display (see
page ).You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page
). 34
88
88
88 88
478
477
477
On Touring models On Touring models
On Touring models On Touring models
Malf unction Indicator
LampCharging System
Indicator
Supplemental Restraint
System (SRS) Indicator
L ow Oil Pressure
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
67
——
y
y
(yy
2010 Odyssey

¶¶µµ
µµµ
µµµ
This indicator displays the outside
temperature in Fahrenheit (U.S.
models) or Celsius (Canadian
models). To see the outside
temperature, press and release the
select/reset knob until the
temperature is displayed.
The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed. In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
If the outside temperature is
incorrectly displayed, you can adjust
it up to 5°F in U.S. models ( 3°C
in Canadian models) warmer or
cooler.
The temperature must be
stabilized bef ore doing this
procedure. To adjust the outside temperature
indicator, press and hold the select/
reset knob f or 10 seconds. The
f ollowing sequence will appear f or 1
secondeach:0,1,2,3,4,5, 5, 4,
3, 2, 1, 0 (U.S.) or 0, 1, 2, 3,
3, 2, 1, 0 (Canada).
When the temperature reaches the
desired value, release the select/
reset knob. You should see the new
outside temperature displayed.
On EX and EX-L models
Gauges
Outside Temperature Indicator
Inst rument s and Cont rols
79
NOTE:
——
y


y
(yy
2010 Odyssey

The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
You can adjust the outside
temperature on the multi-
inf ormation display (see page ).If there is a problem with your
vehicle, f or example the engine oil
level is low or a door is not f ully
closed, the multi-inf ormation display
will show you the problem. It does
this by interrupting the current
display with one or more messages.
Here is a list of messages shown on
the multi-information display:
This shows the outside temperature
in Fahrenheit (U.S. models), or in
Celsius (Canadian models).
110
CONT INUED
Multi-Inf ormation Display
Outside Temperature Display System Messages
Inst rument s and Cont rols
87
OUTSIDE TEMPERATURE DISPLAY
——
y



y
(yy
2010 Odyssey

This message, and the indicator to
the lef t of the message, is part of the
parking sensor system. If you are
approaching too close to an object,
you will see ‘‘WARNING:
APPROACHING OBJECT’’ on the
display and hear a beeper. See pagef or more inf ormation.
If the passenger’s side airbag has
automatically shut of f , you will see
‘‘PASSENGER SIDE AIRBAG OFF’’
on the multi-inf ormation display. See
page f or more inf ormation.
If one or more of your vehicle tires
are low on pressure, you will see a
‘‘CHECK TIRE PRESSURE’’
message on the display. See page
f or more inf ormation on the tire
pressure monitoring system (TPMS).
35
399
362
CONT INUED
Passenger Side A irbag Of f Check T ire PressureWarning: A pproaching Object
Multi-Inf ormation Display
Inst rument s and Cont rols
95
U.S.
Canada
——
y

y
(y
y
2010 Odyssey

If there is a problem with the
parking sensor system, the multi-
inf ormation display shows a
‘‘CHECK PARKING SENSOR
SYSTEM’’ message. See pagef or more inf ormation.
If there is a problem in the anti-lock
brake system (ABS), you will see
‘‘CHECKABSSYSTEM’’onthe
multi-inf ormation display. If you see
this message, have your vehicle
checked by a dealer (see page ). If there is a problem with your f ront
airbags, side airbags, passenger’s
side airbag automatic cutoff system,
automatic seat belt tensioners, side
curtain airbags, driver’s seat position
sensor, or the f ront passenger’s
weight sensors, you will see
‘‘CHECK AIRBAG SYSTEM’’ on the
multi-inf ormation display. Take your
vehicle to a dealer as soon as
possible(seepage ).
34
392
363
CONT INUED
Check Parking Sensor Syst em
Check A irbag Syst em
Check A BS Syst em
Multi-Inf ormation Display
Inst rument s and Cont rols
99
——
y

y
(y
y
2010 Odyssey

ÎÎ
Î
Î Î
Î Î ÎÎ
Î
Î
Î
Î
Î
Î
ÎTo use the horn, press the center pad of the steering wheel.
Only on vehicles equipped with navigation system. Ref er to the navigation system manual.
If equipped
1:
2:
3:
Controls Near the Steering Wheel
Inst rument s and Cont rols
133
HAZARD WARNING
BUTTON
WINDSHIELD WIPERS/WASHERS
REAR WINDOW WIPER/WASHER
CRUISE CONTROL
BUTTONS
VEHICLE STABILITY
ASSIST (VSA) OFF
SWITCH PASSENGER
AIRBAG OFF
INDICATOR
LIGHT CONTROL
SWITCH
STEERING WHEEL
ADJUSTMENT (P.
35)
NAVIGATION
SYSTEM
BUTTONS HORN
(P.193)
(P.189) (P.282)
(P.141) (P.134)
(P.135)
(P.319 )
(P. 281 )
(P. 140 )
(P.221, 285)
(P.205) REAR WINDOW
DEFOGGER BUTTON
(P.140)
PEDAL POSITION
ADJUSTMENT SWITCH
POWER SLIDING DOOR
SWITCH
MOONROOF SWITCH
POWER TAILGATE
SWITCHPARKING SENSOR
SYSTEM SWITCH MULTI-INFORMATION
BUTTONSAUDIO SYSTEM/
REAR
ENTERTAINMENT
SYSTEM CLOCK
HEADLIGHTS/TURN SIGNAL/
FOG LIGHTS
(P.162)
(P.158)/
(P.82)
(P.135,
138)
REMOTE AUDIO
CONTROL BUTTONS (P.395)
VEHICLE STABILITY
ASSIST (VSA) OFF
SWITCH (P.395)
(P.327)
BLUETOOTH
HANDSFREELINK
BUTTONS
(P.361)
2 1
3
3 3
3 3 33
3
3
3
3
——y
y
(y
y
2010 Odyssey
