HONDA ODYSSEY 2011 RB3-RB4 / 4.G Owners Manual

ÌWhen installing cables, f ollow the
manuf acturer’s instructions, and
mount them as tight as you can.
Make sure they are not contacting
the brake lines or suspension. Drive
slowly with them installed. If you
hear them coming into contact with
the body or chassis, stop and
investigate. Remove them as soon as
you begin driving on cleared roads.
Mount tire chains on your tires when
required by driving conditions or
local laws. Install them only on the
f ront tires.
This is the only chain that has been
approved by Honda f or use on your
vehicle. Since Honda cannot test all
chains, you must be personally
responsible f or proper selection,
installation, and use of tire chains.
This chain is available at many auto
supply stores. For a complete list of
stores, visit the SCC website at www.
scc-chain.com. When installing
chains, f ollow the manuf acturer’s
instructions, and mount them as
tightlyasyoucan.Driveslowlywith
chains installed.
Because your vehicle has limited tire
clearance, Honda strongly
recommends using the chain listed
below.
SCC Super Z-6 SZ-429
TiresTire Chains648
10/07/17 11:01:12 31TK8600_653
2011 Odyssey

The sensor on the negative terminal
monitors your vehicle’s battery
condition.
If there is a problem with the sensor,
you will see a ‘‘CHECK BATT
SENSOR’’ message on the
inf ormation display. Have the vehicle
checked by your dealer.
CONT INUED
Except Touring modelsTires, Checking the BatteryChecking the Battery
Maint enance
649
Using the wrong chains, or not
properly installing chains, can
damage the brake lines and
cause a crash in which you can
be seriously injured or killed.
Follow all instructions in this
owner’s manual regarding the
selection and use of tire chains.Traction devices that are the wrong
size or improperly installed can
damage your vehicle’s brake lines,
suspension, body, and wheels. Stop
driving if they are hitting any part of
the vehicle.
10/07/17 11:01:19 31TK8600_654
2011 Odyssey

µ
If there is a problem with the sensor,
you will see a ‘‘CHECK BATTERY
SENSOR’’ message on the multi-
inf ormation display. Have the vehicle
checked by your dealer.
Check the terminals f or corrosion (a
white or yellowish powder). To
remove it, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it of f with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
f uture corrosion.
If additional battery maintenance is
needed, see your dealer or a
qualif ied technician.
Battery posts,
terminals, and related accessories
contain lead and lead compounds. If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
If your vehicle’s battery is
disconnected, or goes dead, the time
setting will be reset to 1:00. To set
the time again, f ollow the setting
procedure (see page ).
The navigation system will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Ref er to the
navigation system manual.315
On vehicles without navigation system
On vehicles with navigation system
On Touring models
Checking the BatteryWARNING:
Wash your hands af ter handling.650
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.
10/07/17 11:01:27 31TK8600_655
2011 Odyssey

If you need to park your vehicle f or
an extended period (more than 1
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your vehicle back on the road. If
possible, store your vehicle indoors.Fill the f uel tank. Block the rear wheels.
If the vehicle is to be stored f or a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the vehicle is being stored
indoors).
Disconnect the battery.
Support the f ront and rear wiper
blade arms with a f olded towel or
ragsotheydonottouchthe
windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and tailgate seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and tailgate seals.Cover the vehicle with a
‘‘breathable’’ cover, one made
f rom a porous material such as
cotton. Non-porous materials, such
as plastic sheeting, trap moisture,
which can damage the paint.
If possible, periodically run the
engine until it reaches f ull
operating temperature (the
cooling f ans cycle twice).
Pref erably, do this once a month.
Wash and dry the exterior
completely.
Cleantheinterior.Makesurethe
carpeting, floor mats, etc., are
completely dry.
Leave the parking brake off. Put
the transmission in Park.
Vehicle Storage
Maint enance
651
10/07/17 11:01:37 31TK8600_656
2011 Odyssey

Vacuum dirt and dust f rom the
leather f requently. Pay close
attention to the pleats and seams.
Clean the leather with a sof t cloth
dampened with a 90% water and 10%
neutral soap solution. Then buf f it
with a clean, dry cloth. Remove any
dust or dirt on leather surf aces
immediately.On EX-L and Touring modelsInterior CareLeather652
10/07/17 11:01:40 31TK8600_657
2011 Odyssey

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .654
....................
Changing a Flat Tire .655
.............
If the Engine Won’t Start . 662
................................
Jump Starting .665
..............
If the Engine Overheats . 667
.........
Low Oil Pressure Indicator . 669
..........
Charging System Indicator . 670
.......
Malf unction Indicator Lamp . 671
...............
Brake System Indicator . 672
..............................................
Fuses .673
..............................
Fuse Locations .678
......................
Emergency Towing .683
Taking Care of the Unexpected
Taking Care of the Unexpected
653
10/07/17 11:01:44 31TK8600_658
2011 Odyssey

Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.The low tire pressure indicator
comes on and stays on af ter you
replace the flat tire with the
compact spare tire. Af ter several
miles (kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low
tire pressure indicator goes of f .
After the flat tire is replaced with
the spare tire, the low tire
pressure/TPMS indicator stays on.
Af ter several miles (kilometers)
driving with the spare, this
indicator begins to f lash, then
stays on again. You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-information
display (see page ).
Follow these precautions:
Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel. Do not mount snow chains on the
compact spare tire. This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving. Never exceed 50 mph (80 km/h).
Check the air pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:
577
Except Touring modelsTouring models
Compact Spare Tire65460 psi (420 kPa , 4.2 kgf/cm
)
10/07/17 11:01:51 31TK8600_659
2011 Odyssey

CONT INUED
Park the vehicle on f irm, level, and
non-slippery ground. Put the
transmission in Park. Apply the
parking brake.
If you are towing a trailer,
Turn on the hazard warning lights,
and turn the ignition switch to the
LOCK (0) position. Have all
passengers get out of the vehicle
while you change the tire.
Replace the tire when you can see
the tread wear indicator bars. The
replacement tire should be the same
size and design, mounted on the
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire. If you have a f lat tire while driving,
pull over saf ely. Drive slowly along
the shoulder until you get to an area
far away from traffic lanes.
2. 1.
Compact Spare Tire, Changing a Flat Tire
Changing a Flat T ire
Taking Care of the Unexpected
655
TREAD WEAR INDICATOR BAR
INDICATOR LOCATION MARK
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.
10/07/17 11:01:59 31TK8600_660
unhitch it.
2011 Odyssey

Move the second row seats to the
rear-most position (see page ).
Remove the f loor mat under the
second row seats (see page ).
Pull up the floor carpet. Raise the
f loor lid by lif ting up with the
handle, then remove it.Take the tool kit case out of the
spare tire well.
Take the jack, vinyl storage bag,
bracket, bracket mounting wing
bolt, and the tire mounting wing
bolt out of the tool kit case.
6.
7.
5. 4.
3. 637176
Changing a Flat Tire656
HANDLE FLOOR LID
FLOOR CARPET
TOOL KIT CASEBRACKET
VINYL STORAGE BAG
TIRE
MOUNTING
WING BOLT
BRACKET
MOUNTING
WING BOLT JACK
WING BOLT
10/07/17 11:02:07 31TK8600_661
2011 Odyssey

CONT INUED
Unscrew the wing bolt and take
the spare tire out of its well.
Place blocks in front and back of
the wheel diagonally opposite the
tire you are changing.Loosen each wheel nut 1/2 turn
with the wheel nut wrench.Placethejackunderthejacking
point nearest the tire you need to
change. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch.
8.
9.
10. 11.
Changing a Flat Tire
Taking Care of the Unexpected
657
WHEEL NUT WRENCH
JACKING POINT
The wheel nut wrench supplied with
your vehicle is specially adapted to f it
the hoist shaf t. Do not use any other
tool.
10/07/17 11:02:15 31TK8600_662
