Page 6 of 294
3Driver and Passenger Safety
This section gives you important
information about how to protect
you and your passengers. It shows
how to use seat belts properly. It
explains the Supplemental
Restraint System. And it tells you
how to properly restrain infants
and children in your vehicle.
Important Safety Precautions
4
. .
Your Vehicle’s Safety Features 5
Seat Belts 6
. . . . . . . . . . . . . . .
Airbags 7
. . . . . . . . . . . . . . . .
Seats and Seat-Backs 8
. . . . . .
Head Restraints 8
. . . . . . . . . .
Door Locks 9
. . . . . . . . . . . . .
Pre-Drive Safety Checklist 9
.
Protecting Adults 10
. . . . . . . . . .
1. Close and Lock the Doors 10
2. Adjust the Front Seats 10
. .
3. Adjust the Seat-Backs 11
. .
4. Adjust the Head Restraints12 5. Fasten and Position
the Seat Belts 13
. . . . . . . . .
6. Adjust the Steering Wheel15
7. Maintain a Proper Sitting Position 16
. . . . . . .
Advice for Pregnant Women 16
Additional Safety Precautions 17
Protecting Children 18
. . . . . . . .
All Children Must
Be Restrained 18
. . . . . . . . . .
Children Should Sit in
the Back Seat 19
. . . . . . . . . .
The Passenger’s Airbag Poses
Serious Risks to Children 19
If You Must Drive With
Several Children 20
. . . . . . .
If a Child Requires
Close Attention 21
. . . . . . . .
Additional Safety Precautions 21
General Guidelines for
Using Child Seats 22
. . . . . .
Protecting Infants 26
. . . . . . .
Protecting Small Children 31
. Protecting Larger Children
34
Using Child Seats
With Tethers 38
. . . . . . . . . . .
Using LATCH 39
. . . . . . . . . .
Additional Information About
Your Seat Belts 41
. . . . . . . . . . .
Seat Belt System
Components 41
. . . . . . . . . . .
Lap/Shoulder Belt 41
. . . . . . .
Lap Belt 42
. . . . . . . . . . . . . . .
Seat Belt Maintenance 42
. . . .
Additional Information About
Your SRS 43
. . . . . . . . . . . . . . .
SRS Components 43
. . . . . . . .
How Your Airbags Work 44
. .
How Your SRS Indicator
Light Works 45
. . . . . . . . . . .
SRS Service 46
. . . . . . . . . . . .
Additional Safety Precautions 46
Carbon Monoxide Hazard 47
. . .
Safety Labels 48
. . . . . . . . . . . . .
Driver and Passenger Safety
Page 49 of 294
46 Driver and Passenger Safety
• If the light stays on after the
engine starts.
• If the light comes on or flashes
on and off while you drive.
If you see any of these
indications, your airbags may not
deploy when you need them. See
your Honda dealer as soon as
possible.
Ignoring the SRS indicator light
can result in serious injury or
death if the airbags do not
inflate when needed.
Have your vehicle checked by a
dealer as soon as possible if
the SRS light alerts you to a
potential problem.
SRS Service
Your Supplemental Restraint
System is virtually maintenance-
free, and there are no parts you
can safely service. However, you
must have your vehicle serviced
if:
• Your airbags ever inflate. The
airbags and control unit must
be replaced. Do not try to
remove or replace the airbags
yourself. This must be done by
a Honda dealer or a
knowledgeable body shop.
• The SRS indicator light alerts
you to a problem. Take your
vehicle to an authorized Honda
dealer as soon as possible. If
you ignore this indication, the
airbags might not inflate when
you need them.
Additional Safety
Precautions
• Do not attempt to deactivate
your airbags. Together, airbags
and seat belts provide the best
protection in a moderate to
severe frontal collision.
• Do not tamper with SRS
components or wiring for any
reason. Tampering could cause
the airbags to deploy, possibly
causing very serious injury.
See page 174 for further
information and precautions
relating to your SRS.
Page 64 of 294
HIGH BEAM INDICATOR LIGHT
SEAT BELT REMINDER LIGHT
BRAKE SYSTEM INDICATOR LIGHT
CHARGING SYSTEM INDICATOR LIGHT
61Instruments and Controls
Seat Belt Reminder
As a reminder to you and your
passengers, this light will come
on for about six seconds each time
the key is turned to the “
ON”
position.
The beeper will also operate for
about six seconds after turning the
key to the “
ON” position if the
driver ’ s seat belt is not fastened.
Brake System
The service braking system is a
split system designed so that one
part will provide some braking
action if there is a loss of
hydraulic pressure in the other
part of the system.
To serve as a reminder, the
“
BRAKE” system light is
designed to come on while the
parking brake is set and the key is
turned to the “
ON” position. Have
Indicator Lights
Page 72 of 294
69Instruments and Controls
Depending on the type of problem,
the “
CHECK TRANS” light will
flash but the transmission may
continue to shift automatically. If
the transmission is shifting
normally, you do not have to
choose gears with the shift lever.
However, continued operation of
the vehicle with this light flashing
can cause serious mechanical
damage. You should have the
vehicle serviced by your Honda
dealer as soon as possible.
Winter Drive Indicator
Automatic Transmission only
The “Winter Drive” light will
come on when you push the
Winter Drive button with the
engine running and the
transmission lever in the “
D”
range. It also comes on for a few seconds
when you turn the ignition switch
to the “ON” position.
Refer to “Driving Pattern
Selector” later in this section.
Power Drive Indicator
Automatic Transmission only
The “Power Drive” light will
come on when you push the
Power Drive button with the
engine running.
It also comes on for a few seconds
when you turn the ignition switch
to the “ON” position.
Refer to “Driving Pattern
Selector” later in this section.
Page 211 of 294
208 Care and Maintenance
Promptly take any safety
problems to your Honda dealer
for service advice.
Parking
brake — Park on a fairly
steep hill and hold the vehicle
with the parking brake only. This
checks its holding ability.
Starter safety switch (automatic
transmission) —
Check the safety
switch by trying to start the
engine in each gear. The starter
should work only with the shift
lever in the “P” (Park) or “N”
(Neutral) position.
Starter safety switch (manual
transmission) —
To check the
safety switch, place the shift lever
in “Neutral,” push the clutch
pedal halfway and try to start the
engine. The starter should not
work. The starter should work only when the clutch pedal is fully
depressed.
Transmission shift indicator
(automatic transmission)
—
Check that the indicator points to
the gear chosen.
Steering — Be alert for any
changes in steering action. An
inspection or service is needed
when the steering wheel is harder
to turn or has too much free play,
or if there are unusual sounds
when turning or parking.
Wheel alignment, balance and
tires —
Uneven or abnormal tire
wear, or pulling to the right or left
on a straight and level road may
show the need for a wheel
alignment. A vibration of the
steering wheel or seat at normal
highway speeds means wheel balancing is needed. Check tire
pressures (including the spare) at
least monthly and whenever the
vehicle is serviced (see page 163).
Brakes — Watch for the
“
BRAKE” light coming on. Other
signs of possible brake trouble are
such things as repeated pulling to
one side when braking, unusual
sounds when braking or between
brake applications, or increased
brake pedal travel. If you note one
of these conditions, have the
system checked at once and
repaired if needed.
Owner Safety Checks
Page 264 of 294
261
Low Coolant Level217. . . . . . . .
Low Oil Pressure Indicator
65. .
Lower Gear, Downshifting to a
84
Lubricant Specifications Charts
235. . . . . .
Luggage, Loading
175, 233. . . . .
Luggage Light
110. . . . . . . . . . . .
M
Maintenance195. . . . . . . . . . . . . .
Periodic Checks. See Owner Safety Checks
Record
206, 207. . . . . . . . . . . .
Safety
201. . . . . . . . . . . . . . . . .
Schedule
203, 204, 20. . . . . .
Malfunction Indicator Lamp
63.
Map Light
112. . . . . . . . . . . . . . .
Meters, Gauges
58. . . . . . . . . . . Methanol in Gasoline
201. . . . . . .
Mirror Adjusting the
105. . . . . . . . . . .
Defogger
74. . . . . . . . . . . . . .
Vanity
106. . . . . . . . . . . . . . . . .
Moonroof
112. . . . . . . . . . . . . . . .
N
Neutral Gear Position77. . . . . . .
New Vehicle Break-In
158. . . . . .
Normal Shift Speeds
84. . . . . . .
NOTICE, Explanation of
i. . . . . .
Numbers, Identifications
232. . . .
O
Octane Requirement, Gasoline
200. . . . . . . . . . . . . . . .
Odometer, Trip
58. . . . . . . . . . . . Off-Road Driving. See the
Off-Road Driving Information
booklet in your owner’s packet.
Oil ChangeHow to
212. . . . . . . . . . . . . .
When to
204, 205, 211. . . . .
Checking Engine
213. . . . . . . .
Front and Rear Axle
216. . . . .
Pressure Indicator
65. . . . . . .
Selecting Proper Viscosity Chart
213. . . . . . . .
ON (Ignition Key Position)
101. .
Opening the Hood
109. . . . . . . . .
Opening the Tailgate
108. . . . . . .
Opening the Windows
107. . . . . .
Operation in Foreign Countries
173. . . . . . . .
Ordering Service Parts
232. . . . . .
Overheating, Engine
190. . . . . . .
Page 266 of 294
263
Rear Seat, Folding94. . . . . . . . .
Rear View Mirror
105. . . . . . . . . .
Rear Window Defogger
74. . . . .
Rear Window Wiper and Washer
74. . . . . . . . . . . . .
Reclining the Seat-Backs Front
11, 91, 93. . . . . . . . . . . .
Rear
97. . . . . . . . . . . . . . . . . .
Recommended Shift Speeds
84.
Reduced Power Indicator
\b 64. . .
Replacement Information Air Cleaner Element
214. . . . .
Coolant
204, 218. . . . . . . . . . .
Engine Oil and Filter
211. . . . .
Fuses
240. . . . . . . . . . . . . . . . .
Light Bulbs
243. . . . . . . . . . . .
Schedule
204. . . . . . . . . . . . . .
Spark Plugs
235. . . . . . . . . . . . Tires
166. . . . . . . . . . . . . . . . . .
Replacing Seat Belts After a Crash
43. . . . . . . . . . . .
Reporting Safety Defects
248. . . .
Reserve Tank, Coolant
217. . . . . .
Restraint, Child
18. . . . . . . . . . .
Reverse Gear Position
77. . . . . .
Rotation, Tire
166. . . . . . . . . . . . .
Rust Protection
225. . . . . . . . . . . .
S
Safety Defects, Reporting248. . .
Safety Labels, Location of
48. . .
Safety Messages
iv. . . . . . . . . . . .
Seat Belts
4, 6. . . . . . . . . . . . . . . .
\b
41
\b\b\b\b\b
Maintenance42. . . . . . . . .
System Components
41
\b\b\b\b
Advice for Pregnant Women16
Cleaning229. . . . . . . . . . . . . . .
Fasten and Positio
13
\b\b\b\b\b\b\b
Lap Belt42
\b\b\b\b\b\b\b\b\b\b\b\b\
\b\b\b\b\b
Lap/Shoulder Belt41
\b\b\b\b\b\b\b\b
Reminder Light6, 41, 61. . . . .
Seats
8, 89. . . . . . . . . . . . . . . . . . .
Adjusting the
90. . . . . . . . . . .
Seat-Backs
8, 91, 92, 97
\b\b\b\b\b\b\b
Self-Adjusting Brakes162. . . . . .
Serial Number
232. . . . . . . . . . . .
Service Intervals
204, 205, 206, 207. . . . .
Service Manual
253. . . . . . . . . . .
Service Station Information
197. .
Setting the Clock
153. . . . . . . . . .
Shift Lever Position Indicator
76
Shift-on-the-Fly System220. . . . .
Fluid Capacity
239. . . . . . . . . .
Side Marker Lights Bulb Replacement
243. . . . . . . .
Page 267 of 294
264
Signaling Turns. See Lane Change, Signaling
Small Children, Protecting
%$
\b\b\b
Snow Chains168. . . . . . . . . . . . .
Snow Tires
168. . . . . . . . . . . . . . .
Solvent-Type Cleaners
226, 227. .
Sound System
125, 133. . . . . . . .
Spare Tire Inflating (Pressure)
164, 239. .
Removal
189
\b\b\b\b\b\b\b\b\b\b\b\b\
\b\b\b\b
Specifications239. . . . . . . . . .
Spark Plugs Replacing
223. . . . . . . . . . . . . .
Specifications
235. . . . . . . . . .
Specifications Charts
235. . . . . . .
Speed Control
147. . . . . . . . . . . .
Speedometer
58. . . . . . . . . . . . . .
START (Ignition Key Position) 101
Starting the Engine157. . . . . . . . .
With a Dead Battery
184. . . . .
Steam Coming From Engine
190.
Steering Column Ignition Lock Switch
101. . . . . .
Steering Wheel Adjustment
115. . . . . . . . . . . .
Anti-Theft Column Lock
102. .
Stereo Sound System
125, 133. . .
Sun Visor
114. . . . . . . . . . . . . . . .
Supplemental Restraint System
7. . . . . . . . . .
Additional Information
43
\b\b\b\b
Additional
Safety Precautions
46
\b\b\b\b\b\b\b
Components41. . . . . . . . . . . .
Hazards
4, 8. . . . . . . . . . . . . . .
How the Airbag Works
44. . .
How the SRS Indicator Light Works
45. . . Service
46. . . . . . . . . . . . . . . .
T
Tachometer58. . . . . . . . . . . . . . .
Tailgate Operation
108. . . . . . . . .
Tape Player
128. . . . . . . . . . . . . . .
Temperature Gauge
60. . . . . . . .
Three-Way Catalytic Converter
172. . . . . . .
Tilt Steering Wheel
115. . . . . . . .
Time, Setting the
153. . . . . . . . . .
Tire Chains
168. . . . . . . . . . . . . . .
Tires
163. . . . . . . . . . . . . . . . . . . .
Air Pressure
164, 198, 239. . . .
Checking Wear
165. . . . . . . . .
DOT Tire Quality Grading
251
How to Change a Flat186. . . .
Inflation
164, 171, 198. . . . . . .
Inspection
165. . . . . . . . . . . . .
