Page 181 of 248

HONDA PILOT 2004 1.G Owners Manual µµ
To thoroughly f lush the
transmission, the technician
should drain and ref ill it with
Honda ATF-Z1 (Automatic
Transmission Fluid), then drive
the vehicle f or a short distance.
Do this three t

Page 182 of 248

HONDA PILOT 2004 1.G Owners Manual Check the brake f luid level in the
reservoirs monthly.
Replace it according to the time
recommendation in the maintenance
schedule.The f luid level should be between
theMINandMAXmarksontheside
of the

Page 183 of 248

HONDA PILOT 2004 1.G Owners Manual Check the level on the side of the
reservoir when the engine is cold.
The f luid should be between the
UPPER LEVEL and LOWER LEVEL.
If not add power steering f luid to the
UPPER LEVEL mark.A low power

Page 184 of 248

HONDA PILOT 2004 1.G Owners Manual Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk, readjustment may be required.
Adjustments should be perf ormed by
a Honda dealer or other qua

Page 185 of 248

HONDA PILOT 2004 1.G Owners Manual Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
To remove the f ront turn signal
bulb, push it in slightly and turn it
counterclockwise.
Install the new

Page 186 of 248

HONDA PILOT 2004 1.G Owners Manual Open the tailgate.
Remove the two screws, then pull
the rear light assembly straight
back to remove it from the body.
Remove the socket of the burned
out bulb by turning it one-quarter
turn counterclo

Page 187 of 248

HONDA PILOT 2004 1.G Owners Manual If you are changing the bulb on
the driver’s side, start the engine,
turn the steering wheel all the way
to the right, and turn off the
engine. If you are changing the
bulb on the passenger’s side

Page 188 of 248

HONDA PILOT 2004 1.G Owners Manual Pull the inner f ender cover away
f rom the f ender and bumper.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.Pull the burned out bulb straight
out of i

Page 189 of 248

HONDA PILOT 2004 1.G Owners Manual The driver’s f loor mat that came
with your vehicle hooks over the
f loor mat anchor. This keeps the
f loor mat f rom sliding f orward and
possibly interf ering with the pedals.
If you remove the dr

Page 190 of 248

HONDA PILOT 2004 1.G Owners Manual Raise the wiper arm of f the
windshield. Raise the driver’s side
first, then the passenger’s side.
Check the condition of the wiper
blades at least every six months.
Replace them if you f ind sign
