Page 71 of 578
The instrument panel has many
indicators to give you important
inf ormation about your vehicle. This indicator comes on when youturn the ignition switch to the ON
(II) position. It reminds you and your
passengers to f asten your seat belts.
A beeper also sounds if you have not
f astened your seat belt.
If your f ront passenger does not
f asten their seat belt, the indicator
comes on about 6 seconds af ter the
ignition switch is turned to the ON
(II) position. If you turn the ignition switch to the
ON (II) position bef ore f astening
your seat belts, the beeper sounds,
and the indicator f lashes. If you do
not fasten your seat belts before the
beeper stops, the indicator stops
f lashing but remains on.If either of you do not f asten your
seat belt while driving, the beeper
will sound and the indicator will f lash
again at regular intervals. For more
inf ormation, see page .
You will also see a ‘‘FASTEN SEAT
BELT’’ or ‘‘FASTEN PASSENGER
SEAT BELT’’ message on the multi-
inf ormation display (see page ).
For more inf ormation, see page .
20
20
93
On Touring models
Seat Belt Reminder
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
67
— —
y
y
(/ y y
2009 Pilot
Page 72 of 578
The engine can be severely
damaged if this indicator f lashes
or stays on when the engine is
running. For more inf ormation,
see page .
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message
on the multi-information display
(see page ).If this indicator comes on when the
engine is running, the battery is not
being charged. For more inf ormation,
see page .
You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display (see
page ).
For more inf ormation, see page
.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ). For more inf ormation, see
page .
525
93 525
93 526
93526
On Touring models On Touring models
On Touring models
L ow Oil Pressure
Indicator Charging System
IndicatorMalf unction Indicator
Lamp
Instrument Panel Indicators
68
— —
y
y
(/ y y
2009 Pilot
Page 73 of 578
This indicator has two f unctions:Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. A beeper
sounds if you drive with the
parking brake not f ully released.
Driving with the parking brake not
fully released can damage the
brakes and tires.
You will also see a ‘‘RELEASE
PARKING BRAKE’’ message on
the multi-information display (see
page ). If it remains on af ter you have
fully released the parking brake
while the engine is running, or if it
comes on while driving, there
could be a problem with the brake
system. For more inf ormation, see
page .
You will also see a ‘‘LOW BRAKE
FLUID’’ or ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display (see page ).
1. 2.
93 93
527
On Touring models On Touring models
Instrument Panel Indicators
Parking Brake
and Brake
System
Indicator
Inst rument s and Cont rols
69
U.S. Canada
— —
y
y
(/ y y
2009 Pilot
Page 74 of 578
This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
side curtain airbags, automatic seat
belt tensioners, driver’s seat position
sensor, or the f ront passenger’s
weight sensors. For more
inf ormation, see page .
You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page). This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates that the passenger’s side
airbag has automatically shut off.
For more inf ormation, see page .
This indicator normally comes on
f or a f ew seconds when you turn
the ignition switch to the ON (II)
position, and when the ignition
switch is turned to the START
(III) position. If it comes on at any
other time, there is a problem with
theABS.If thishappens,have
your vehicle checked at a dealer.
With this indicator on, your
vehicle still has normal braking
ability but no anti-lock f unction.
For more inf ormation, see page
.
You will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display (see page ).
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-inf ormation display (see page
).
33
93 9333
433 93
On Touring models On Touring models
On Touring models
Supplemental Restraint
System Indicator
Anti-lock Brake System
(A BS) Indicator
Side Airbag Of f
Indicator
Instrument Panel Indicators
70
U.S. Canada
— —
y
y
(/ y y
2009 Pilot
Page 75 of 578
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page .
Itcomesonasareminderthatyou
have turned off the vehicle
stability assist (VSA) system.
It flashes when VSA is active (see
page ).
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ). This indicator has three f unctions:
The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is
burned out (see page ). Replace
the bulb as soon as possible, since
other drivers cannot see that you are
signaling.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle f lash.
If itcomesonandstaysonatany
other time, or if it does not come on
when you turn the ignition switch to
the ON (II) position, there is a
problem with the VSA or Hill Start
Assist systems. Take your vehicle to
a dealer to have it checked. Without
VSA, your vehicle still has normal
driving ability, but will not have VSA
traction and stability enhancement.
See page for more information
on the VSA system.
It comes on along with the VSA
system indicator if there is a
problem with the VSA or Hill Start
Assist systems.
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ). 1.
2.
3. 488
93 435
435
435
93
On Touring modelsOn Touring models
Instrument Panel Indicators
Vehicle Stability Assist
(VSA ) System IndicatorVSA Activation Indicator
Turn Signal and
Hazard Warning
Indicators
Inst rument s and Cont rols
71
— —
y
y
(/ y y
2009 Pilot
Page 76 of 578
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost the pressure, and determine
the cause. If it is because of a flat tire,
replace the flat tire with the compact
spare (see page ), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service
(see page ). For more
inf ormation, see page . This indicator has two f unctions:
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the
multi-inf ormation display (see
page ).
Check the tire pressure monitor
on the multi-information display
and determine the cause (see page ). If this happens, pull to the side
of the road when it is saf e,
check which tire has lost
pressure on the multi-
inf ormation display, and
determine the cause. If it is
because of a flat tire, have the
flat tire repaired as soon as
possible. If two or more tires are
underinf lated, call a prof essional
towing service. For more
inf ormation, see page .
1.
512 94
428 535
535 424
On Touring models
Except Touring models
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator
Low Tire Pressure
Indicator
72
— —
y
y
(/ y y
2009 Pilot
Page 77 of 578
This indicator comes on when there
is a problem with the starter system.
For more inf ormation, see page .
If you see a ‘‘CHECK STARTER
SYSTEM’’ message on the multi-
inf ormation display, there is a
problem with the starter system (see
page ).
If this indicator begins to f lash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display. The indicator continues to
f lash f or a while (approximately 1
minute), then stays on. If this
happens, have your dealer check
the system as soon as possible.
For more inf ormation, see page
. This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
If this indicator comes on and stays
on at any other time, or if it does not
come on when you turn the ignition
switch to the ON (II) position, there
is a problem with the TPMS. With
this indicator on, the low tire
pressure indicator and the tire
pressure monitor will not come on
when a tire loses pressure. Take the
vehicle to your dealer to have the
system checked.
2.
430 415
94
On Touring models
Except Touring models
Except Touring models
Instrument Panel Indicators
Starter System
IndicatorTire Pressure Monitoring
System (T PMS) Indicator
Inst rument s and Cont rols
73
U.S. Canada
— —
y
y
(/ y y
2009 Pilot
Page 78 of 578
This indicator monitors the
temperature of the automatic
transmission f luid. It should come on
f or a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on while driving,
it means the transmission f luid
temperature is too high. Pull to the
side of the road when it is saf e, shif t
to Park, and let the engine idle until
the indicator goes out.You will also see an ‘‘A/T TEMP
HIGH’’ message on the multi-
inf ormation display (see page ).
94
4WD models only On 4WD Touring models
Instrument Panel Indicators
A/T Temperature
Indicator
74
Continuing to drive with the A/T
temperature indicator on may cause
serious damage to the transmission.
— —y
y
(/ y y
2009 Pilot
Page 79 of 578
This indicator comes on when there
is a system message on the multi-
inf ormation display. Press the INFO
button on the steering wheel (see
page ) to see the message (see
page ).
Most of the time, this indicator
comes on along with other indicators
in the instrument panel such as the
seat belt reminder indicator, SRS
indicator, VSA system indicator, etc.
This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. It
remindsyouthatitistimetotake
your vehicle in f or scheduled
maintenance. The maintenance main
items and sub items will be displayed
in the inf ormation display. See page
f or more inf ormation on the
maintenance minder.
This indicator goes of f when your
dealer resets it after completing the
required maintenance service. This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on at any other
time, there is a problem in the 4WD
system. Take the vehicle to your
dealer to have it checked.
If the indicator blinks while driving,
the VTM-4 fluid temperature is too
high. Pull to the side of the road
when it is saf e, shif t to Park, and let
the engine idle until the indicator
goes out.
85
93
459
Except Touring models On Touring models4WD models only
Message Indicator
Maintenance Minder
Indicator VTM-4 Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
75
Continuing to drive with the VTM-4
indicator blinking may cause serious
damage to the system.
— —
y
y
(/ y y
2009 Pilot
Page 80 of 578
This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button (see
page ).
This indicator comes on when you
set the cruise control. See pagef or inf ormation on operating the
cruise control. This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either the
or position. This indicator
will also come on when the light
switch is in AUTO and the lights
turn on automatically. If you turn the
ignition switch to the ACCESSORY
(I) or the LOCK (0) position without
turning of f the light switch, this
indicator will remain on. A reminder
chime will also sound when you open
the driver’s door.
This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. It will then go of f if
you have inserted a properly-coded
ignition key. If it is not a properly-
coded key, the indicator will blink,
and the engine’s f uel system will be
disabled (see page ).
This indicator comes on when you
turn on the f og lights. For more
inf ormation, see page . 124
348
348
126
133
Except LX models
Cruise Control Indicator Cruise Main Indicator High Beam Indicator
Fog L ight Indicator Lights On Indicator
Immobilizer System
Indicator
Instrument Panel Indicators
76
— —
y
y
(/ y
y
2009 Pilot
