The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it. There
are two trip meters: Trip A and Trip
B. Each trip meter works
independently, so you can keep track
of two dif f erent distances.
To reset a trip meter, display it, and
then press and hold the SEL/RESET
button until the number resets to
‘‘0.0.’’
When the main menu is blank or
Trip Computer, pressing the SEL/
RESET button changes the display
to ‘‘odometer/trip meter’’ ‘‘outside
temperature/trip meter’’ and ‘‘engine
oil lif e.’’
CONT INUED
Multi-Inf ormation Display
Trip Meter
Odometer
Inst rument s and Cont rols
87
TRIP METER
ODOMETER
U.S. model is shown.
——
y
y
(/yy
2009 Pilot

When you reset Trip A, AVERAGE
FUEL A, AVERAGE SPEED A, and
ELAPSED TIME A are reset at the
same time. When you reset Trip B,
AVERAGE FUEL B, AVERAGE
SPEED B, and ELAPSED TIME B
are reset.
You can customize the Trip A,
AVERAGE FUEL A, AVERAGE
SPEED A, and ELAPSED TIME A
reset condition on the multi-
inf ormation display (see page ).This shows the outside Fahrenheit
temperature in U.S. models, and
Centigrade temperature in Canadian
models.
In the lef t corner of the lower
segment, a compass indicates which
direction your vehicle is pointed.
104
Multi-Inf ormation Display
Outside Temperature
Compass
88
U.S. OUTSIDE TEMPERATURE
Canada
——
y
y
(/yy
2009 Pilot

Whenthetirepressuremonitoris
shown on the multi-inf ormation
display, press the SEL/RESET
button. The display changes as
shown.
You can see the pressure of each tire
in this monitor. If one or more tires
are low, inflate them to the correct
pressure. For more inf ormation, see
page .
This shows the remaining lif e of the
engine oil. It shows 100% af ter the
engine oil is replaced and the display
is reset. The engine oil lif e is
calculated based on engine operating
conditions and accumulated engine
revolutions. For more inf ormation,
see page .
The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
You can adjust the outside
temperature display (see page ).
459
103
428
Tire Pressure Monitor
Engine Oil L if e
Multi-Inf ormation Display
Inst rument s and Cont rols
89
U.S.
Canada
ENGINE OIL LIFE
——
y
y
(/yy
2009 Pilot

You can receive or make phone calls
f rom your cell phone through your
vehicle’s Bluetooth
HandsFreeLink(HFL) system
without touching your cell phone. To use the system, your cell phone
and the HFL system must be linked.
Not all cell phones are compatible
with this system. Ref er to page
for instructions on how to link
your cell phone to the HFL and how
to receive or make phone calls, or
visit the handsf reelink.com website.
Along with the trip meter, the trip
computer calculates these values:Instantaneous f uel mileage
Average Fuel Economy
Range
Average Vehicle Speed
Elapsed Time
360
Multi-Inf ormation Display
Trip Computer
BluetoothHandsFreeL ink
90
——
y
y
(/yy
2009 Pilot

This shows the estimated distance
you can travel on the fuel remaining
in the f uel tank. This distance is
estimated f rom the f uel economy
you received over the last several
miles(U.S.) or kilometers (Canada),
so it will vary with changes in speed,
traf f ic, etc.
This shows the average speed you
are traveling in miles per hour (mph)
forU.S.modelsorkilometersper
hour (km/h) f or Canadian models.This shows the time passed traveled
since you last reset it. When you turn
the ignition switch to the ON (II)
position, ELAPSED TIME is reset.
You can customize the TRIP A INFO
(Trip A, AVERAGE FUEL A,
ELAPSED TIME A, and AVERAGE
SPEED A) reset condition in the
multi-inf ormation display (see page
).
This shows your current f uel
mileage.
This shows your vehicle’s average
f uel economy in mpg (U.S. models)
or liter/100 km (Canadian models)
since you last reset the Trip A or
Trip B.
104
RANGE
AVERAGE SPEED A/B EL A PSED T IME A /B
INST A NT FUEL MPG (U.S.
models)/INST A NT FUEL L /100 km(Canadian models)
AVERAGE FUEL A/B
Multi-Inf ormation Display
Inst rument s and Cont rols
91
——
y

y
(/yy
2009 Pilot

ÛÝ
ÛÝ
If there is a problem with your
vehicle, f or example, the engine oil
level is low or a door is not f ully
closed, the multi-inf ormation display
will show you the problem. It does
this by interrupting the current
display with one or more messages. The system message(s) triggers the
appropriate indicator(s) on the
instrument panel, including the
system message indicator, to come
on. The system message indicator
does not go of f until the problem(s)
is corrected.
You will also hear a beep when the
system message comes on f or the
first time.
When there are several messages to
be shown, the system switches the
messages every 5 seconds.
The message is shown until you
push the INFO ( or ) button.
To see the message again, press the
INFO ( or ) button, 5 seconds
after the display disappears.
Here is a list of messages shown on
the multi-information display:
Multi-Inf ormation Display
System Messages
92
SYSTEM MESSAGE INDICATOR
——
y
y
(/yy
2009 Pilot

CONT INUED
See page167
See page
11
See page 20
See page 20
See page 33
See page 33 See page
527
See page 527 See page
525
See page 526
See page 525
See page 434
See page 435
See page 77
Multi-Inf ormation Display
Inst rument s and Cont rols
93
U.S.
Canada U.S.
Canada
U.S.
Canada
U.S.
Canada
——
y
y
(/yy
2009 Pilot

See page135
See page
400
See page
464
See page
429
See page 430
See page 430
See page 74
See page 145 See page
416
See page 417
See page 393
See page 481
See page 78 See page
391
See page 126
Multi-Inf ormation Display
94
U.S.
Canada U.S.
Canada
——
y
y
(/yy
2009 Pilot

When the main menu displays
‘‘Keyless Memory Settings ,’’ you
can customize some vehicle control
settings.
To enter the customizing mode,
press the SEL/RESET button.If you turn the ignition switch to the
ACCESSORY (I) or the LOCK (0)
position, or move the shif t lever out
of Park, the display will change to
the normal screen.
You can customize some vehicle
control settings f or ‘‘DRIVER 1’’ and
‘‘DRIVER 2’’ separately. If ‘‘DRIVER
1’’ or ‘‘DRIVER 2’’ is not displayed,
customizing is not possible.
To have the driver’s ID detected,
make sure your remote transmitter
is linked to the system (see Keyless
Memory Settings on page ).
If you want the settings as they were
when the vehicle lef t the f actory,
select DEFAULT ALL, as described
on page .
Ref er to the table on the f ollowing
pages about the settings you want to
customize. If you want to change any vehicle
control settings, select CHG
SETTING, then press the SEL/
RESET button.
To change the settings, the ignition
switch must be in the ON (II)
position, and the vehicle must be
stopped with the transmission in
Park. 151
98
CONT INUED
Multi-Inf ormation Display
Customize Settings
Inst rument s and Cont rols
95
TM TM
——
y
y
(/y
y
2009 Pilot

ÎÎÎ
Î
Î
µ™¶ ™
µ™¶ ™
Î
Menu Item DescriptionSetting Option
Group Setup Page
LANGUAGE SELECT ION
ADJUST OUTSIDE
TEMP. DISPLAY
TRIP A INFO RESET
MEMORY POSIT ION LINKChanges the language used in the display.
Changes the outside temperature reading above or
below its current reading.
Changes the setting of how to reset trip meter A,
average fuel A, elapsed time A, and average speed
A.
Changes the driver’s seat and the outside mirror
positions to a stored setting. ENGLISH
FRENCH
SPANISH
5°F 0°F 5°F
(U.S.) 3°C 0°C 3°C
(Canada)
with REFUEL
MANUAL ONLY
IGN OFF
ON
OFF
MET ER SET UP
(P.101)
POSITION SETUP
(P.106)
102
103
104
107
: Default setting
