See pages f or important saf ety
inf ormation and warnings about how toproperly position seats and seat-backs. 10 11
Make all seat adjustments bef ore
you start driving.
To adjust the seat forward and
backward, pull up on the lever under
the seat cushion’s f ront edge. Then
trytomovetheseattomakesureit
is locked in position.To change the seat-back angle, pull
up on the lever on the outside of the
seat bottom.
Seats
Inst rument s and Cont rols58

You vehicle’s windows are
electrically-powered. Turn the
ignition switch to ON (II) to raise or
lower either window.Each door has a switch that controls
its window. To open the window,
push the switch down and hold it.
Release the switch when you want
the window to stop. Close the
window by pulling back on the
switch and holding it.The driver’s armrest has a master
power window control panel. To
open the passenger’s window, push
down on the switch and hold it until
the window reaches the desired
position. To close the window, pull
back on the window switch. Release
the switch when the window gets to
the position you want.
Power Windows
Inst rument s and Cont rols59
DRIVER’S WINDOW SWITCH
MAIN
SWITCH
PASSENGER’S WINDOW SWITCH

µ
The master control panel also con-
tains these extra features:
To open the driver’s
window f ully, push the window
switch f irmly down and release it.
The window automatically goes all
the way down. To stop the window
f rom going all the way down, pull
back on the window switch brief ly.
To open the driver’s window only
partially, push the window switch
down lightly and hold it. The window
will stop as soon as you release the
switch.
The AUTO f unction only works to
lower the driver’s window. To raise
the window, you must pull back on
the window switch and hold it until
the window reaches the desired
position. The MAIN switch controls power to
the passenger’s window. With this
switch of f , the passenger’s window
cannot be raised or lowered. The
MAIN switch does not af f ect the
driver’s window. Keep the MAIN
switch of f when you have a child in
the vehicle so the child does not get
injured by operating the window
unintentionally.
Power Windows
Inst rument s and Cont rols
AUTO
60
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passenger is
away from the window before
closing it.

The convertible top on your Honda
lowers and raises electrically.
It is advisable to raise the top
whenever you park the vehicle. This
helps to protect the vehicle f rom
unexpected weather changes, and
f rom thef t of your valuables.Bef ore operating the convertible top,
make sure the vehicle is parked on
level ground, the rear def ogger is of f ,
and there is enough clearance above
the top.
Apply the parking brake. The
convertible top will not operate
unless the parking brake is f ully
engaged.
Turn the ignition switch to ON (II). Thereisalatchoneachside.Push
in the tabs, and pull the locking
levers down.
1.
2.
3.
CONT INUED
Convertible Top
Inst rument s and Cont rols
Lowering the Convertible Top
61
NOTICE:
LATCHTAB
LOCKING LEVER
Do not operate the convertible top in
f reezing weather. Y ou can damage
the material and the mechanism.
Do not operate the top if it is wet,
dirty, or covered with ice or snow.
Never drive the vehicle with the
convertible top half open.
Do not operate the convertible top if
the vehicle is on a jack, a hoist, or on
jack stands.
Park your vehicle in the shade
whenever possible. Extended
exposure to sunlight can cause the
convertible top to deteriorate.

With the latches released, push
the locking levers up until they
latch.PullbackandholdtheROOF
switch. The windows lower and
the roof f olds back. Release the
ROOF switch when the roof is
retracted completely into the rear
shelf .
4.
5.
Convertible Top
Inst rument s and Cont rols62
NOTICE:
LOCKING LEVER
ROOF SWITCH
Operating the convertible top
while any part of a passenger is
in the way of the convertible top
can cause serious injury.
Make sure that you, your
passenger, or any other people
around the vehicle are clear of
the moving convertible top.
Do not sit on the f olded
convertible top, or any items on top of
it. You could damage the top or the
rear window.

Use the convertible top cover when
the top is f olded to help prevent
f oreign objects, dirt, etc., f rom
getting into the material and the
mechanism.Remove the convertible top cover
f rom the trunk.
Pull the buttons on the snaps,
place them over the pins on the
back of the roll bar, then release
the buttons. If you do not pull the
snap button bef ore placing it on
the pin, you could break the snap.Pull the buttons, on the fastener
straps, place them on the pin on
thesidepaneljustbehindthe
doors, then release the buttons.
Fit the rear part of the top cover
into the space behind the
convertible top.
To remove the cover, reverse this
procedure.
1.
2.3.
4.
5.
Convertible Top
Inst rument s and Cont rols
Convertible T op Cover
63
CONVERTIBLE TOP COVER
SNAPPIN
PIN FASTENER STRAP

Apply the parking brake. The
convertible top will not operate
unless the parking brake is f ully
engaged.
Turn the ignition switch to ON (II).Push in the tab to release the
locking levers, and pull them down.
Note the movement of the latch
when you push in the tab.
While holding the lever down,
push in the tab to engage the latch
in the windshield header. Pull the
topdownandforwardif necessary.Push the locking levers up while
holding the tab. When the latch is
in place, release the tab. Make
sure the convertible top is securely
latched.
Push the ROOF switch f orward
and hold it. The windows, if raised,
will lower automatically.
The convertible top will rise.
Release the ROOF switch when
the top reaches the windshield
header. 5. 6.
1.
2.
3.
4.
Convertible Top
Inst rument s and Cont rols
Raising the Convertible T op
64
NOTICE:
TABLATCH
LOCKING LEVER
Operating the convertible top
while any part of a passenger is
in the way of the convertible top
can cause serious injury.
Make sure that you, your
passenger, or any other people
around the vehicle are clear of
the moving convertible top. Do not put any heavy items
on the f olded convertible top. You
could damage the material and the
mechanism.

Dust is the main cause of creaks or
other sounds coming f rom the
convertible top.
Regularly clean the body seals with
glass cleaner and a soft cloth. Do not
use a scraper or de-icing chemicals
to remove f rost, snow, or ice f rom
the top or the rear window.
Every three to six months,
depending on how of ten the top is
f olded, rub a thin f ilm of Shin-Etsu
Silicon Grease (available from your
Honda dealer, P/N 08798-9013) onto
the seals wherever they touch the
convertible top or each other. Do not lean or sit on an open door.
Do not push or pull the door glass
to open and close the door.
The convertible top seals are
designed to promote the f low of
water of f the roof . Spraying high-
pressure water directly on the
seals can distort them, causing a
leak. Use only a low-pressure
water stream when using a hose,
and avoid commercial car washes.
Convertible Top
Inst rument s and Cont rols
Maintenance
To reduce the possibility of leaks:
65

Move the selector switch to L
(driver’s side) or R (passenger’s
side).
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position reduces
glare f rom headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position. Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch so you can’t
move a mirror out of position by
accidentally bumping the switch.
1.
2.
3.
Mirrors
Inst rument s and Cont rols
Adjusting the Power Mirrors
66
TAB SELECTOR SWITCH
ADJUSTMENT SWITCH

To apply the parking brake, pull the
lever up f ully. To release it, pull up
slightly, push the button, and lower
the lever. The parking brake
indicator on the instrument panel
should go out when the parking
brake is f ully released (see page ).
If you try to drive the vehicle without
releasing the parking brake, the ABS
indicator may come on, and the ABS
may not work properly.40
Parking Brake
Inst rument s and Cont rols67
NOTICE:
Driving the vehicle with the
parking brake applied can damage the
rear brakes and axles.
