Hyundai Accent 2010 Owner's Guide

1
FEATURES OF YOUR HYUNDAI
9
B040D01S-GAT Locking From the Inside To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position. Whenthis is done, neither the outside nor the inside door handle can be used. B040E04A-AAT Child-protector Rear Door Lock (4 Door) Your Hyundai is equipped with a "child- protector" rear door lock assembly.When the lock mechanism is engaged, the rear door cannot be opened from the inside. Its use is recommended when-ever there are small children in the rear seat.
NOTE: When the door is locked, the red mark on the switch is not visible.
B040C01MC-AAT Locking From the Outside
The doors can be locked without a key. To lock the doors, first push the inside lock switch to the "LOCK" position sothat the red mark on the switch is not visible, then close the door. NOTE:
o If your vehicle is equipped with central door locking system, the door will not lock if the key is leftin the ignition switch when the front doors are closed.
o When locking the door this way, be careful not to lock the door withthe ignition key left in the vehicle.
B040C04MC o To protect against theft, always
remove the ignition key, close all windows, and lock all doors and the trunk lid (4 Door)/tail gate (3 Door) when leaving your vehicleunattended.UNLOCKLOCK
OMC025006B040E01MC

1FEATURES OF YOUR HYUNDAI
10THEFT-ALARM SYSTEM
To engage the child-protector feature so the door cannot be opened from theinside, move the child-protector lever to the " " position and close the door. Move the lever to the " " positionwhen normal door operation is desired. If you wish to be able to open the door from the outside, the outside door handle will function normally.
B070A01A-AAT (If Installed) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an au- dible alarm with blinking of the turnsignal lights.NOTE:
o When pushing the front portion of the driver's door lock switch, all vehicle doors will lock. If any dooris open when the switch is de- pressed, the door will remain locked when closed.
o When pushing the rear portion of the switch, all vehicle doors willunlock.
o The central door locking is oper- ated by turning the key in thedriver's door lock toward the frontor rear of the vehicle.
o If the door is locked/unlocked mul-
tiple times in rapid successionwith either the vehicle key or door lock switch, the system may stop operating temporarily in order toprotect the circuit and prevent damage to system components.
B040G03HP-AAT Central Door Locks (If Installed) The central door locking switch is lo- cated on the driver's arm rest. It is operated by depressing the door lock switch.
OMC029047
UNLOCK
LOCK

1
FEATURES OF YOUR HYUNDAI
11
B070C03MC-GAT Alarm Stage The alarm will be activated if any of the following occurs while the car is parkedand the system is armed.
1) Any door, tail gate (3 Door) included, is opened without using the trans- mitter.
2) The trunk lid (4 Door) is opened without using the key (For Europe).
3) The engine hood is opened. The alarming horn will sound and the turn signal lights will blink continuously for 27 seconds (For Europe, MiddleEast / Except Europe : This happens 3 times). To turn off the system, unlock the door with the transmitter.
NOTE:
1) If any door, trunk lid (4 Door) / tail gate (3 Door) or engine hood re- mains open, the system will notbe armed (For Europe). If any door, tail gate (3 Door) or engine hood remains open, thesystem will not be armed (Except Europe). If this happens, rearm the systemas described above.
2) Once the system is armed, only
the trunk lid (4 Door) may be un-locked using the ignition key with- out disarming the system (For Europe).
B070B03MC-GAT Armed Stage
B070B01MC
Park the car and stop the engine. Arm the system as described in the follow- ing paragraph.
1) Remove the ignition key from the ignition switch.
2) Make sure that all doors, trunk lid (4 Door) / tail gate (3 Door) and engine hood are closed and latched (For Europe).Make sure that all doors, tail gate (3 Door) and engine hood are closed and latched (Except Europe).
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal lights will blink once to indicate that the system is armed. CAUTION:
o Do not arm the system until all passengers have left the car. If thesystem is armed while a passenger(s)remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car.
o Avoid trying to start the engine while the system is armed (With-out immobilizer system).
!

1FEATURES OF YOUR HYUNDAI
12
B070D03MC-GAT Disarmed Stage The system will be disarmed when the driver's or passenger's door is unlocked by depressing the button on the trans- mitter after the system was armed. After completion of the step above, the turn signal lights will blink twice toindicate that the system is disarmed. If any door, trunk lid (4 Door) / tail gate (3 Door) included, is not opened within 30 seconds, the system will be rearmed (For Europe).If any door, tail gate (3 Door) included, is not opened within 30 seconds, the system will be rearmed (Except Eu-rope). B070D02AMC
CAUTION:
Only the transmitter can disarm thearmed stage. If the transmitter doesnot disarm the system, it is neces- sary to take the following steps; Without immobilizer system: 1. Unlock and open the door with the key, which will cause the alarm to be activated.
2. Insert the key in the ignition key
cylinder and turn the ignition keyto "ON" position.
3. Wait for 30 seconds. With immobilizer system: 1. Unlock and open the door with the
key, which will cause the alarm to be activated.
2. Insert the key in the ignition key
cylinder and turn the ignition keyto "START" position.
After completing the steps above,the system will be disarmed.
!
NOTE: When the system is disarmed with the interior light switched to "DOOR", the interior light will illuminate for 30seconds.
CAUTION:
Do not change, alter or adjust thetheft-alarm system because it couldcause the theft-alarm system to mal- function and should only be ser- viced by an authorized Hyundaidealer. Malfunctions caused by improper alterations, adjustments or modifi-cations to the theft-alarm system are not covered by your vehicle manu- facturer warranty.
!

1
FEATURES OF YOUR HYUNDAI
13
B070E02MC-AAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR1220
1. Remove the screw with a phillips
screwdriver.
2. Carefully separate the case with a
flat-head screwdriver.
3. Remove the battery cover with a coin. OMC025004
- The weather is extremely cold.
- The transmitter is close to a radio
transmitter such as a radio station or an airport which can interfere with normal operation of the trans-mitter.
When the transmitter does not workcorrectly, open and close the doorwith the ignition key. If you have a problem with the transmitter, con- tact an authorized Hyundai Dealer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entry system is inoperative due to expo-sure to water or liquids, it will not be covered by your manufacturer ve- hicle warranty. Replacement instructions:
B070F03A-GAT Keyless Entry System
(If Installed) Locking doors
1. Close all doors.
2. Push the button on the transmitter.
3. At the same time all doors lock, the
turn signal lights will blink once toindicate that the system is armed.
Unlocking doors 1. Push the button on the transmitter once more after all doors were locked.
2. At the same time all doors unlock,
the turn signal lights will blink twice to indicate that the system is dis- armed.
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition switch.
- You exceed the operating distance limit (10 m).
- The battery in the transmitter is weak.
- Other vehicles or objects may be
blocking the signal.

1FEATURES OF YOUR HYUNDAI
14
B060A02MC-GAT POWER WINDOWS (If Installed)
The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's
armrest and control the front (4/3 Door)
and rear windows (4 Door) on both sides
of the vehicle. The windows may beopened by depressing the appropriate window switch and closed by pulling up the switch. To open the window on the
driver's side, press the switch (1) halfway down. The window moves as long as the switch is operated. To fully open thedriver's window automatically, press the switch fully down. In automatic operation, the window will fully open even if you letgo of the switch. To stop at the desired opening, pull up and release the switch.
4 Door 3 Door
OMC029048
!
WINDOW GLASS
B050A01MC-AAT
To lower or raise the window, turn the window regulator handle clockwise or counterclockwise. WARNING:
When opening or closing the win- dows, make sure your passenger'sarms, hands and body are safely out of the way.
3FDA2015
CAUTION:
An inappropriately disposed battery can be harmful to the environment and human health. Dispose the bat-tery according to your local law(s) or regulation.
!
4. Remove the old battery from the
case and note the polarity. Make sure the polarity of the new battery is the same (+side facing up), then insert it in the transmitter.

1
FEATURES OF YOUR HYUNDAI
15
!WARNING:
1) Be careful that someone's head, hands and body are not trapped by a closing window.
2) Never try to operate the main
switch on the driver's door andthe individual door window switch in opposing directions at the same time. If this is done, the windowwill stop and cannot be opened or closed.
3) Do not leave children alone in the car. Always remove the ignitionkey for their safety.
OMC025015
CLOSE
OPEN
In order to prevent operation of the passenger front (4/3 Door) and rear windows (4 Door), a window lock switch(2) is provided on the armrest of the
driver's door. To disable the power win- dows, press the window lock switch. Torevert to normal operation, press the window lock switch a second time. NOTE: The power windows can be operated for 30 seconds after the ignition key is turned to the "ACC" or "LOCK"positions, or removed from the igni- tion switch. If the front doors are opened during this 30 second pe-riod, the power windows can no longer be operated without the igni- tion key turned to the "ON" position.OMC029049
NOTE: While driving with the rear windows down or with the sunroof (if installed) in an open (or partially open) posi-
tion, your vehicle may demonstrate
a wind buffeting or pulsation
noise. This noise is a normal occur-rence and can be reduced or elimi- nated by taking the following ac-
tions. If the noise occurs with oneor both of the rear windows down,
partially lower both front windows
approximately one inch. If you ex-perience the noise with the sunroof open, slightly reduce the size of the sunroof opening.

1FEATURES OF YOUR HYUNDAI
16SEATS
Driver’s seat 1. Seat forward/rearward lock releaselever
2. Seatback recliner control lever 3. Seat cushion height control lever
(If Installed)
4. Seat warmer switch (If Installed) Front passenger’s seat 5. Seat forward/rearward lock release
lever
6. Seatback recliner control lever 7. Seat warmer switch (If Installed) Rear seats
8. Seatback folding lever (If Installed)
9. Armrest (If Installed)
B080A01MC-GAT
OMC029025A
4 Door3 Door

1
FEATURES OF YOUR HYUNDAI
17
!
!
To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at the outsideedge of the seat. Now lean back until the desired seatback angle is achieved. To lock the seatback into position,release the recliner control lever.
B080C01A-AAT Adjusting Seatback Angle
To move the seat toward the front or rear, pull the lock release lever upward. This will release the seat on its track so you can move it forward or rearward tothe desired position. When you find the position you want, release the lever and slide the seat forward or rearward on itstrack until it locks into the desired position and cannot be moved further. WARNING:
To ensure the seat is locked se-curely, attempt to move the seat for- ward or rearward without using thelock release lever.
B080A01FC-GAT ADJUSTABLE SEATS
B080B02FC-GAT FRONT SEATS Adjusting Seat Forward andRearward
WARNING:
Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control or an acci-dent which may cause death, seri- ous injury, or property damage.
OMC029026
OMC029027

1FEATURES OF YOUR HYUNDAI
18
!WARNING:
To minimize risk of severe injury in the event of a collision or a sudden stop, both the driver and passenger seatbacks should always be in anupright position while the vehicle is in motion. The protection provided by the seat belts and airbags in afrontal collision may be reduced sig- nificantly when the seatbacks are reclined. There is greater risk thatthe driver and passenger will slide under the seat belt which may result in serious injury if a crash occurswhen the seatbacks are reclined. The seat belt cannot provide full protec- tion to an occupant if the seatback isreclined.!WARNING:
o For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of theheadrest is at the same height of the center of gravity of an occupant's head. Generally, thecenter of gravity of most people's head is similar with the height of the top of their eyes. Also, adjustthe headrest as close to your head as possible. For this reason, the use of a cushion that holds thebody away from the seatback is not recommended.
o Do not operate the vehicle with the
headrests removed as severe in-jury to the occupants may occur in the event of an accident. Head-rests may provide protection against neck injuries when prop- erly adjusted.
o Do not adjust the headrest posi- tion of the driver's seat while thevehicle is in motion.
C010104AMC Headrest
The driver's and front passenger's seats are equipped with a headrest for the occupant's safety and comfort.The headrest not only provides comfort for the driver and front passenger, but also helps to protect the head and neckin the event of a collision. OBH038075L
