9 VEHICLE SPECIFICATIONS
4
Oil & Grease Standard
API SJ, SL or ABOVE, SAE 5W-20, 5W-30 (ALL TEMP. RANGE)
ILSAC GF-3 or ABOVE SAE 10W-30 (ABOVE -18°C)
SAE 15W-40 (ABOVE -13°C) SAE 20W-50 (ABOVE -7°C)
Normal driving condition Severe driving condition HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands approved by Hyundai Motor Co.,Ethylene glycol, base for aluminum PSF-3 TYPE FLUID DOT 3 or DOT 4 EquivalentLUBRICATION CHART
J080A01TG-GAT
Quantity (liter)
Drain and refill ; With oil filter : 5.6 Without oil filter : 5.2 MAX. 1L /1500 Km MAX. 1L /1000 Km 10.98.6 0.9 As required
Item
Engine Oil Engine oil consumption TransaxleCoolant Power steeringBrake fluid
Automatic
